Techcomp UV 2600 User manual

UV/VIS Spectrophotometer
UV 2600
Version: 1
INSTRUCTION
MANUAL
UV2600 UV/VIS Spectrophotometer

CONTENT
PREDACE............................................................................................................................1
ABOUT THIS MANUAL .......................................................................................................1
PRECAUTIONS ON SAFETY.............................................................................................6
Chapter 1 Installation.........................................................................................................12
1.1 Unpacking.............................................................................................................12
1.2 Installation Conditions..........................................................................................13
1.2.1 Work Power Supply....................................................................................13
1.2.2 Work Table..................................................................................................13
1.3 Installation Environment.......................................................................................14
1.3.1 Operating Temperature..............................................................................14
1.3.2 Operating Humidity ....................................................................................14
1.3.3 Storage Temperature..................................................................................14
1.3.4 Atmospheric Environment..........................................................................14
1.3.5 Sample Solvent..........................................................................................14
1.3.6 Other General Notes..................................................................................14
1.4 Check of Contents................................................................................................15
1.5 Instrument Installation ..........................................................................................16
1.6 Check of Voltage and Fuse..................................................................................16
1.7 Connection of Communication Cable...................................................................17
1.7.1 PC Port.......................................................................................................17
1.7.2 Acc Port......................................................................................................17
1.8 Connection of Power Cord and Grounding Wire..................................................17
1.9 Power On..............................................................................................................18
Chapter 2 Function..........................................................................................................19
2.1 Work Principle.......................................................................................................19
2.2 Optical Path System.............................................................................................20
2.3 Circuit System ......................................................................................................21
2.4 Function Mode......................................................................................................22
2.5 Sample Compartment...........................................................................................23
2.6 Specifications........................................................................................................24
Chapter 3 Operation..........................................................................................................25
3.1 Preparation...........................................................................................................25
3.1.1 Install Software & Connect UV2600 to PC ................................................25
3.1.2 Initialization.................................................................................................25
3.2 Basic Operation....................................................................................................26
3.2.1 Operation Method ......................................................................................26
Chapter 4 Maintenance .....................................................................................................28
4.1 Daily Maintenance................................................................................................28
4.1.1 Cleaning of Sample Compartment.............................................................28
4.1.2 Clean of Spectrophotometer Cover ...........................................................30

4.1.3 Cleaning and Storing of Cuvette................................................................31
4.1.4 Add Lube....................................................................................................32
4.1.5 Clean of Window Frame and Lens of Sample Compartment .................32
4.2 Performance Verification......................................................................................33
4.3 Troubleshooting....................................................................................................34
4.3.1 Error Information........................................................................................34
4.3.2 Failure Cause and Countermeasure..........................................................35
4.3.3 Replacing fuses..........................................................................................35
4.4 Replacement of Consumable Parts .....................................................................36
4.4.1 Replacement of Light Source Lamp ..........................................................36
4.4.2 Clear of Lamp Use Time ............................................................................41
4.4.3 Adjustment of Lamp ...................................................................................41
4.5 Disassembly of Instrument Main Parts.................................................................45
4.5.1 Open Instrument Cover..............................................................................45
4.5.2 Removal Procedures of Power Switch ......................................................45
4.5.3 Removal of Control Board and Lamp Power Supply Board......................46
4.5.4 Removal Procedures of Pre-amplifier........................................................46
4.6 Storing of Instrument..........................................................................................47
4.6.1 After Test Is Finished..................................................................................47
4.6.2 Instrument Will Not Be Used for a Long Time ...........................................47

PREFACE&SAFETY SUMMARY
1
PREFACE
Thank you very much for your purchase of Techcomp Model UV2600
UV/VIS Spectrophotometer.
The Model UV2600 Spectrophotometer is intended for the purpose of
spectral analysis. Do not use it for any other purpose.
The Model UV2600 is designed for use by persons having a basic
knowledge of chemical analysis. Other persons should operate the
instrument in the presence of someone who has such basic knowledge.
Remember that improper use of the instrument, chemicals or samples
would result not only in wrong analytical data but in consequences adverse
to safety.
Before using the instrument, be sure to read through this instruction
manual to enable correct use.
For installation/maintenance of the instrument, read the instruction manual
carefully to attain a full understanding of the instructions. Be sure to
observe cautionary instructions.
Keep this manual handy for easy reference when necessary.
Information contained in this manual is subject to change without notice for
product improvement.
ABOUT THIS MANUAL
Before using the instrument, be sure to read through this instruction
manual. First of all, read “SAFETY SUMMARY” included at the beginning
of this manual for ensuring safety in operation of the spectrophotometer
main unit.

PREFACE&SAFETY SUMMARY
2
Precautions on Electromagnetic Wave Interference
（1）Possible Electromagnetic Wave Interference Caused by This Instrument
When this instrument is used in a residential area or an adjacent area
thereto, it may cause interference to radio and television reception.
To prevent this, use the specified system connection cables in strict
accordance with the instruction manual. The instrument is designed to
minimize possible electromagnetic wave interference caused by it if the
specified cables are connected properly.
However, there is no guarantee that electromagnetic wave interference will
not be caused by the instrument. If the instrument does cause
interference to radio or television reception, which can be determined by
turning off and on the instrument, the user is encouraged to try to correct
the interference by one or more of the following measures:
Increase separation between the instrument and radio/TV receiver.
Connect the instrument to an outlet on a circuit different from that to
which the radio/TV receiver is connected.
（2）Possible Electromagnetic Wave Interference Affecting This Instrument
If this instrument is used near an intense electromagnetic source,
interference noise may be given to the instrument to incur an adverse effect
on its performance or functionality.This effect will be less than 1% and still
could be accepted.
To prevent this, use the specified system connection cables in strict
accordance with the instruction manual. The instrument is designed to
minimize possible electromagnetic wave interference affecting it if the
specified cables are connected properly.
However, there is no guarantee that electromagnetic wave interference will
not occur in this instrument. If the instrument does incur electromagnetic
wave interference, which can be determined by turning on and off possible
sources of electromagnetic wave interference nearby, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient the instrument.
Increase separation between the instrument and possible sources of
electromagnetic wave interference.
Increase separation between the power cable of the instrument and
possible sources of electromagnetic wave interference.
Connect the instrument to an outlet on a circuit different from that to
which possible sources of electromagnetic wave interference are
connected.
Confirm that any other device connected with the instrument is not
affected by electromagnetic wave interference.

PREFACE&SAFETY SUMMARY
3
Warranty on Product
The Model UV2600 Spectrophotometer is warranted to operate according
to the specifications given in the instruction manual, provided it is used in
accordance with the instructions described in the manual.
（1）Scope of Warranty
(a) Main unit of the instrument which prove to be defective in design or
workmanship during the warranty period will be repaired without charge.
(b) A substitute part may be used for repair, or replacement with an
equivalent product may be made instead of repair.
(c) Such system components as a personal computer and printer to be
updated frequently for improvement may not be available in original
versions at the time of replacement.
(d) The instrument can’t be provided repair for free in warranty period if it
was sold to other user.
（2）Warranty Period
One year from the date of initial installation or received by the customer (The
deadline refer to the fist one).
（3）Limitations and Exclusions on Warranty
Note that this warranty is void in the following cases, even if they occur
within the warranty period.
(a) Failure due to operation at a place not meeting the installation
requirements specified by us
(b) Failure due to power supply voltage/frequency other than specified by
us or due to abnormality in power supply
(c) Corrosion or deterioration of the tubing due to impurities contained in
reagent, gas, air or cooling water supplied by the user
(d) Corrosion of the electric circuits or deterioration of the optical elements
due to highly corrosive atmospheric gas
(e) Failure due to use of hardware, software or spare parts other than
supplied by us
(f) Failure due to improper handling or maintenance by the user
(g) Failure due to maintenance or repair by a service agent not approved
or authorized by us

PREFACE&SAFETY SUMMARY
4
(h) After disposal of this instrument, or after its resale without our approval
(i) Failure due to relocation or transport after initial installation
(j) Failure due to disassembly, modification or relocation not approved by
us
(k) Consumables, and failure of parts that have reached the end of
specified useful life
(l) Failure of parts excluded from the warranty in the instruction manual or
other documents
(m)Failure due to acts of God, including fire, earthquake, storm, lightning,
social disturbance, riot, crime, insurrection, war (declared or undeclared),
radioactive pollution, contamination with harmful substances, etc.
(n) Failure of the hardware, or damage to the system software, application
software, data or hard disk due to computer virus infection
(o) Failure of the personal computer connected with the instrument, or
damage to the system software, application software, data or hard disk
due to power interruption or momentary power voltage drop caused by
lightning or the like
(p) Failure of the personal computer connected with the instrument, or
damage to the system software, application software, data or hard disk
due to disconnection of main power to the personal computer without
taking the specified normal shutdown procedure
Warning: Class A equipments is intended for use in an industrial environment. In the
documentation for the user, a statement shall be included drawing attention to the fact that
there may be potential difficulties in ensuring electromagnetic compatibility in other
environments, due to conducted as well as radiated disturbances.
（4）Disclaimer of Warranty
(a) Any express warranties other than the explicit conditions indicated in
(1) are excluded from this warranty.
Any other implied warranties of merchantability and fitness for a particular
purpose are not included in this warranty. No liability is assumed for
direct or indirect damages arising out of explicit or implied warranties.
(b) Oral or written information or advice given by our dealers, distributors,
agents or employees without our express permission shall not create a
warranty or in any way increase the scope of this warranty.
Installation, Relocation and After-sale Technical Service

PREFACE&SAFETY SUMMARY
5
Installation of this instrument shall be carried out by or under supervision of
qualified service personnel of Techcomp Corporation or its authorized service
agent.
Before installation of the instrument, the user shall make preparations for
satisfying the installation requirements in accordance with the instruction
manual.
If relocation of the instrument becomes necessary after initial installation
(delivery), please notify your local sales representative or nearest service
office of Techcomp.
Technology Training for User
For using the instrument safely and correctly, technology training speeches are
held at Techcomp’s or user’s site. Contact Techcomp for attending procedures.
Technology training speeches are payable, it will charge fee.
Disposal of this Instrument
When you discard equipment, please check and confirm some related
statute, law and practices .or ask the service section of Techcomp.
Other Precautions
（1）Handling of Chemicals and Samples
(1) The user is responsible for following relevant legal standards and
regulations in handling, storage and discarding of chemicals and samples
used in analytical operations of this instrument.
(2) Reagents, standard solutions and accuracy-control samples shall be
handled, stored and discarded as instructed by the respective suppliers.
（2）Notice on Instruction Manuals
(1) Information contained in the instruction manuals furnished with the
instrument is subjected to change without notice for product improvement.
(2) This manual is copyrighted by Techcomp with all rights reserved.
(3) No part of this manual may be reproduced or transmitted in any form or
by any means without our express written permission.

PREFACE&SAFETY SUMMARY
6
SAFETY SUMMARY
PRECAUTIONS ON SAFETY
Before using the Model UV2600 Spectrophotometer, be sure to read the
following safety instructions carefully.
General Safety Guidelines
Follow all the operating procedures provided in this manual.
Installation and maintenance of the product shall be carried out by
service personnel qualified therefore.
Be sure to observe the warnings indicated on the product and in the
instruction manual. Failure to do so could result in personal injury or
damage to the product.
The hazard warnings which appear on the warning labels on the
product or in the manual have one of the following alert headings
consisting of an alert symbol and signal word DANGER, WARNING, or
CAUTION.
DANGER: Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
(This warning does not apply to this product.)
WARNING: Indicates a potentially hazardous situation which, if
not avoided, can result in death or serious injury.
CAUTION: Indicates a hazardous situation which, if not avoided,
will or can result in minor or moderate injury, or
serious damage to the product.
: Precedes every signal word for hazard warnings, and
appears in safety-related descriptions in the manual.
“NOTICE” and “NOTE” are heading words which do not concern personal
safety directly.
NOTICE:Used to indicate an instruction for preventing damage to the
product.
NOTE: Used to indicate an instruction for ensuring correct use of the
product and accurate analysis therewith.

PREFACE&SAFETY SUMMARY
7
SAFETY SUMMARY
General Safety Guidelines
■Do not modify the product, replace parts that are not user-
serviceable, use non-specified parts, nor remove safety devices, as it
could be hazardous.
■Installation at delivery, maintenance and relocation should be referred
to our qualified service personnel.
■Do not perform any operation or action other than described in the
instruction manual. When in doubt, please contact our sales
representative or service office nearest you.
■When using a chemical for analytical operation, be sure to provide
proper ventilation in the laboratory room as per local requirements.
Inadequate ventilation could endanger human health.
Keep in mind that the hazard warnings in the manual or on the product
cannot cover every possible case, as it is impossible to predict and
evaluate circumstances beforehand.
Be alert and use your common sense.

PREFACE&SAFETY SUMMARY
8
SAFETY SUMMARY
This instruction manual contains the following cautious instructions.
DANGER
The warning “DANGER” does not apply to this product.
WARNING
Electric Shock in Contact with Dangerous High Voltage (500 V)
In contact with D2 lamp power supply voltage (500 V), you may receive an
electric shock to cause fatal or serious injury.
Before replacing the D2 lamp, make sure that the POWER switch of the
spectrophotometer main unit is turned off.
Electric Shock in Contact with Dangerous Voltage
In contact with power supply voltage (100-240V), you may receive an
electric shock to cause fatal or serious injury.
Before connecting the power cord, make sure that the POWER switch of
the spectrophotometer main unit is turned off.
CAUTION
Burn in Contact with High Temperature
The D2 lamp and WI lamp reach a high temperature.
They can burn you if touched.
Before replacing or adjusting the lamp, turn off the POWER switch and
wait until it cools down sufficiently.
Fatigue on Long Use
Watching the CRT screen in the same posture for a long time
accumulates fatigue in your eyes or body. For long use, take a 10 to
15-minute rest every hour for your health.
Oxygen Deficiency due to Presence of Nitrogen
■If nitrogen purging is carried out for long hours in a narrow room without
operating an exhaust duct, the oxygen concentration in the room will
decrease and an oxygen deficiency could result.
Be sure to operate an exhaust duct or else open a window during the
purge for ventilation purposes.

PREFACE&SAFETY SUMMARY
9
SAFETY SUMMARY
Remarks on safety of spectrophotometer
Electricity
(a) Confirm the power supply to the spectrophotometer is AC100-240V.
(50Hz or 60Hz).Power is more than 1 KVA.
Fluctuation in voltage or noise on the power line would not only affect
the spectrophotometer main unit adversely but also cause an accident.
(b) Be sure to provide grounding connection along with power connection.
Make sure that the spectrophotometer is grounded at a grounding
resistance of 10or less.
If grounding is improper, the spectrophotometer is easily affected by
external noise and floating voltage generated in it endangers physical
safety.
(c) High-voltage circuits are used inside the spectrophotometer.
Do not open any other cover than necessary for operation.
Fire
Avoid smoking and using a fire in the vicinity of the spectrophotometer.
Labels on spectrophotometer
There are warning labels of high pressure, high temperature on UV2600
Spectrophotometer. Pay attention to them during operation to avoid safety
accidents.
Back Up the Data
It is therefore recommended to back up the contents of the hard disk
beforehand.
To avoid misoperation, set space of more than 100 MB in computer
harddisk as work area for UV apllication software.
Computer Virus
If programs or data has suddenly been destroyed, if an unexpected
operation takes place or if an abnormal display appears on the screen,
your personal computer may have been infiltrated by a computer virus.
The computer virus is a rogue program that secretly invades a personal
computer and operates it willfully while destroying memorized data.
A program for eliminating the virus is called vaccine program.
There is a possibility of contamination with a computer virus by
downloading through communication a program including a computer
virus, or by using an exchangeable recording medium such as a floppy
disk that contains a computer virus. Also, it is possible to transmit the

PREFACE&SAFETY SUMMARY
10
virus from one personal computer to another via communication or
recording media. So avoid using a program or recording medium that
might include a virus.
Carry out check using a vaccine program if there is a possibility of
contamination with a virus. But depending on the type of vaccine
program, it may be impossible to eliminate the virus.
Personal Computer (PC)
Do not turn off the PC power supply alone. If the PC power supply is
turned off during access to the hard disk or floppy disk, the PC may
malfunction and the data or software stored in it may be destroyed. To
turn off the PC power supply, be sure to complete the spectrophotometer
control and data processing program (UV Analyst) before taking the
shutdown procedure for the system software.
Power Failure
A power failure or momentary voltage drop of the power supply due to
lightning, etc. may cause failure of the personal computer used with the
instrument and also damages the system software, application software
and other data.
To avoid such problems, it is recommended to use an AC uninterruptible
power source.

PREFACE&SAFETY SUMMARY
11
SAFETY SUMMARY
Warning Labels
The warning labels shown below are attached to the Model UV2600
Spectrophotometer.
（1）Dangerous Voltage（500V、100-240V）
The warning label above is attached to cover of lamp source compartment and power
supply socket.
（2）Attention to High Temperature
The warning label above is attached to cover of lamp source compartment.

CHAPTER 1 INSTALLATION
12
CHAPTER 1 INSTALLATION
1.1 Unpacking
After opening the packing case, put the instrument onto work table with great
care. Avoid serious shock to packing case when unpacking it. Moreover, the
weight of UV2600 spectrophotometer is about 50kg. Care should be taken
when moving it.
Figure 1-1 UV2600 UV/VIS Spectrophotometer
△Note：To avoid shock during transportation, sponge has been used for
fixing viewfinder in UV2600. Before powering on the instrument, first open
cover of light source compartment and take out sponge in viewfinder.
Otherwise, it may have influence on instrument initialization check and normal
use.

CHAPTER 1 INSTALLATION
13
1.2 Installation Conditions
Before installing the instrument, please confirm the following installation
conditions.
1.2.1 Work Power Supply
The requirements for UV2600 work power supply are as follows：
1）Voltage：AC100-240V, fluctuation within ±10% is allowed.
2）Frequency：50Hz or 60Hz，fluctuation within ±4% is allowed.
3）Power：more than 600VAis required. If other devices share the same power
supply,it needs more than 1KVA.
4）Grounding wire：Grounding resistance must be less than10Ωinstalled as per
relative standards.
1.2.2 Work Table
The requirements for work table are as follows：
1）Work table for UV2600 spectrophotometer should be horizontal and reliable,
withstanding weight of more than 85kg, with a width of more than 800mm, a
depth of more than 750mm.
2）If other devices will be put on the work table as well, the area required
should be more.
3）Leave space of more than 200mm at both sides of the instrument. Avoid
instrument touching to the wall directly.
4）The height of UV2600 spectrophotometer is about 270mm. For easy
operation, select suitable height of work table.

CHAPTER 1 INSTALLATION
14
1.3 Installation Environment
Work environment will have great influence on instrument performance and life
time. Before installing UV2600, confirm the following environment conditions
at installation site.
1.3.1 Operating Temperature
Allowed environmental temperature range：5～35℃.However, it is suggested
to install air conditioner and set room temperature to 20～25℃for instrument
under stable work status.
1.3.2 Operating Humidity
Allowed environmental humidity range：45％～85％。It is suggested to install
dehumidifying device and control the hunidity in room within 30％～70％for
instrument under stable work status.
1.3.3 Storage Temperature
Allowed temperature range for storage：－20～60℃。
1.3.4 Atmospheric Environment
1）Free from acid gas or alkaline gas and other gases which may corrode
metals significantly.
2）Free from gases which may dissolve paint such as from organic solvents
(particularly benzene, thinner etc).
1.3.5 Sample Solvent
1）Sample solvent and corrosive material should not to be put near instrument.
When using them, be careful to avoid drop or spill onto the cover or inside
sample compartment.
2）If organic solvent has been spilled on the cover or inside sample
compartment, please cleans it by soft cloth or paper at once.
3）If acid or alkali solution has been spilled inside sample compartment, please
take apart the compartment to wash and clean.
1.3.6 Other General Notes
a) Avoid direct sunlight (otherwise optical performance might deteriorate or the
housing might become discolored). Avoid installation by a window if at all
possible.
b) Vibrations or shocks strong enough to be felt by the human body must not
be transmitted to the instrument (otherwise the fine adjustment mechanism
might malfunction).
c) Avoid installation in near heat generating apparatus such as a gas burner,
electric heater or oven in order to prevent the mainframe cover being heated
beyond 70 Deg C.
d) Avoid installation near instruments which generate a strong electric field

CHAPTER 1 INSTALLATION
15
(such as an electric welding machine, high frequency furnace or pole
transformer).
e) Avoid a dusty environment (otherwise optical performance might
deteriorate).
f) The line voltage must be stable and free from a rapid fluctuation (otherwise
noise might increase).
g) Do not frequently turn on and off electric instruments (stirrer, vibrator, etc)
which are connected to the same power line as the UV2600 but are not fitted
with noise suppressors.
h) Height above sea level: ≤2000m.
I) Pollution degree: IP20.
J) Transient overvoltage is cagegory Ⅱ.
△Note
The optical system is very delicate.In addition, the control unit incorporates
high-density electronic circuit components which function as a computer.
The above cautions should be strictly observed.
1.4 Check of Contents
After unpacking, check the contents of delivery against the packing list. If any
part is missing or damaged, or if you have a question, contact the nearest
Techcomp sales representative.
Figure 1-2 UV2600 Spectrophotometer Accessory

CHAPTER 1 INSTALLATION
16
1.5 Instrument Installation
WARMING
The Voltage is AC100~240V, which may cause electric shock. Please
connect instrument power cord after instrument installation has been
finished.
To avoid shock during transportation, sponge has been used for fixing
viewfinder in UV2600. Before powering on the instrument, first open cover of
light source compartment and take out sponge in viewfinder. Otherwise, it may
have influence on instrument initialization check and normal use. The
procedures for taking out sponge are as follows：
1）Unscrew fix Screw on cover of light source compartment and remove cover
of light source compartment.
2）Take out sponge inside viewfinder.
3）Install cover and tighten the screw.
1.6 Check of Voltage and Fuse
WARMING
The Voltage of instrument is AC100-240V, which may cause electric
shock. Before selecting and confirming the voltage used, first confirm
power cord has not been connected to the instrument.
According to the voltage of work power supply, select and confirm the voltage
level allowed besides UV2600 plug of power supply（POWER）. Otherwise,
instrument failure or accident may occur.
Figure 1-3 Power supply of UV2600 Spectrophotometer
Fuse

CHAPTER 1 INSTALLATION
17
Select and confirm the suitable fuse according to voltage used.
Power supply voltage
Fuse Capacity
250V
F 3.15A
1.7 Connection of Communication Cable
Besides power supply plug（POWER）, UV2600 has PC port and Acc port.
1.7.1 PC Port
UV2600 is controlled by UV Analyst software. Operation control and data
analysis are done by PC.
Using communication cable (standard accessory) provided by UV control
software, connect UV2600 PC port to computer COM port.
1.7.2 Acc Port
Many optional accessories can be configured on UV2600, including autosipper
controlled by PC.
Using communication cable provided by optional part, connect UV2600 Acc
port to the optional part.
△NOTE
Pull in or pull out PC port and Acc port when main unit is turned off. Please
comply with the NOTE.
1.8 Connection of Power Cord and Grounding Wire
WARNING
Before plugging in the power cord, make sure the POWER switch is
turned off.
The procedures are as follows, shown in Figure 1-4.
1）Confirm power supply lines and ground connection are OK.
2）Confirm voltage of power supply is OK. (AC100-240V).
3）Plug the two sides of power cord into power supply output socket and
instrument power supply input socket respectively.
