TECHLIGHTING Tigris 700BCTIGRS32 Series User manual

1.0
Installation Instructions for
Tigris Mirror Round Surface (LED)
700BCTIGRS32_-LED_
1
920BCTIGSD
GP I :ENERAL RODUCT NFORMATION
This product is suitable for indoor locations only.
This product may be dimmed with a low voltage electronic
dimmer.
Bring power supply lines to the mirror in accordance with
local electrical codes.
This instruction shows a typical installation.
CAUTION—RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
BCATH OLLECTION
Install the Hardware
Locate the studs on the wall where the mirror is going
to be mounted (Max 28-1/4" separation).
Use minimum of four slots to mount the back plate to
the studs with four screws and washers provided. Do
not drive the screws all the way in at this time.
1A
Bring the power line to one of the four circular hole on
the backplate.
While holding the back plate level and in the desired
position, tighten the four screws to secure it.
SCREW
BACKPLATE
STUD
2A
POWER LINE
2WASHER
1
2
1 1
3
4
3
4
4 4
4
2
2 2
2

2
Prepare the Mirror for Installation
Loosen (do not remove) the two screws on side of the
electrical box in the center of the pan.
Remove the electrical box lid.
Remove the proper knock out and install the provided
conduit connector.
3A
Install the Pan
Feed the power line wire through the conduit connector
into the pan.
Place the four pan holes onto the four back plate
threaded rods.
3B
Tighten the four provided nuts to secure the pan onto
the back plate.
POWER LINE
THREADED ROD
PAN HOLE
CONDUIT CONNECTOR
1
2
3
1
2
1
2
3
SCREW
SCREW
ELECTRICAL BOX
LID
KNOCKOUT
2A
12
1
3
2
3
NUT

3
Replace the lid onto the electrical box and tighten the
two screws.
Carefully replace the mirror onto the hinge and tighten
the two screws.
Connect the Power
6
7
3C
3
4
5
Connect the fixture to a suitable ground in accordance
with local electrical codes.
Connect the neutral power line wire to the white fixture
wire with a wire nut.
Connect the hot power line wire to the black fixture
wire with a wire nut.
3
4
5
3D
LID
SCREW
SCREW
SCREW
SCREW
HINGE
7
7
6

4
