Better Homes and Gardens FILLMORE BH47-084-599-04 User manual

PB 1
model# BH47-084-599-04
model# BH47-084-599-05
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
walnut
java
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
FILLMORE COFFEE TABLE

2
TOP PANEL
LEFT SIDE ASSEMBLY
RIGHT SIDE ASSEMBLY
BOTTOM PANEL
LOWER RAIL [X2]
BACK PANEL
UPPER RAIL
DRAWER FRONT
A
B
C
D
E
F
G
H
LEFT DRAWER SIDE
RIGHT DRAWER SIDE
DRAWER BACK
DRAWER BOTTOM
DRAWER SUPPORT
I
J
K
L
M
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Hammer Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
3. Cam
x23
4. Flat Head Screw
x9
1. Wood Dowel
x25
2. Cam Bolt
x23

4
1 2
3 4 5
180º
HOW TO USE THE CAM LOCK SYSTEM

4 5
x4 x6 x6
STEP 1
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6
x3 x5 x3
STEP 2
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6 7
x2 x2
STEP 3
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8
x5 x5 x5
STEP 4
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8 9
x7 x6 x6
STEP 5
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

10
x4 x1 x1 x9
STEP 6
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam 4. Flat Head
Screw
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

10 11
STEP 7

12
60 lbs. / 27.2 kg.
60 lbs. / 27.2 kg.
20 lbs. / 9.1 kg.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.
