Style selections SHELF TOWER LWUSTCC User manual

F
1
Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
ITEM #5120857
MODEL #LWUSTCC
SHELF TOWER
2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Top panel 1
B Top frame 1
C Left upper side frame 1
D Right upper side frame 1
E Left lower side frame 1
F Right lower side frame 1
G Connect beam 5
H Bottom stretcher 1
I Shelf 4
J Bottom panel 1
A
C
E
G
G
G
G
G
H
I
I
I
I
J
D
B
STYLE SELECTIONS is a trademark or registered
trademark of LF, LLC. All rights reserved.
Call customer service at 1-877-888-8225,8 a.m. - 8 p.m., EST, Monday - Sunday.

43
HARDWARE CONTENTS (not shown actual size)
PREPARATION
SAFETY INFORMATION
WARNING
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
Please read and understand this entire manual prior to assembling the product.
1. Do not allow children to climb or play in or around this product.
2. Use this unit for its intended purpose only. Do not use shelves as step ladder.
3. To avoid damage, assemble the product on a sturdy, level and protective surface.
4. Two or more persons must work together to install the unit onto the wall.
5. Make sure all bolts/screws are tightly fastened before the unit is used.
6. Check bolts/screws periodically and tighten them if necessary.
MAXIMUM LOAD: 25 lb
(EVENLY DISTRIBUTED)
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 50 minutes
Tools Required for Assembly (not included): Rubber Mallet, Marking Pencil, Stud Finder, Phillips
Screwdriver, Power Drill and Drill Bit.
THIS UNIT IS INTENDED FOR USE ONLY WITH THE MAXIMUM WEIGHTS INDICATED. USE
WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHTS INDICATED MAY RESULT IN
INSTABILITY CAUSING POSSIBLE INJURY. DISTRIBUTE WEIGHT EVENLY.
AA
EE
BB
GG
CC DD
1/4” x 12 mm
Bolt
Qty. 42
M4 x 35 mm
Screw
Qty. 40
Hex wrench
Qty. 1
L-bracket
Qty. 4
Metal plate
Qty. 2
Back Crosser
Qty. 1
M5 x 65 mm
Screw
Qty. 1
HH II
Drywall Anchor
Qty. 1

5 6
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
1. Attach connect beams (G) and bottom stretcher (H)
between the lower side frames (E and F) using
1/4” x 12 mm bolts (AA). Tighten with hex wrench (CC).
4. Attach L-bracket (DD) to assembly, using
1/4” x 12 mm bolt (AA). Tighten with hex wrench (CC).
5. Attach top panel (A), shelves (I) and bottom panel (J) to
assembly. Secure in place with M4 x 35 mm screws (BB).
2. Attach connect beams (G) between the upper side
frames (C and D) using 1/4” x 12 mm bolts (AA). Tighten
with hex wrench (CC).
3. Attach top frame (B), left lower side frame (E) and
right lower side frame (F) to left upper side frame (C) and
right upper side frame (D), using 1/4” x 12 mm bolt (AA).
Tighten with hex wrench (CC).
1 4
52
3
AA
BB
AA DD
CC
AA
AA
CC
CC
CC
G
H
F
A
I
J
E
G
Hardware Used
Hardware Used
Hardware Used
1/4” x 12 mm Bolt
1/4” x 12 mm Bolt
1/4” x 12 mm Bolt
Hex wrench
Hex wrench
Hex wrench
x 4
x 6
x 10
x 1
x 1
x 1
AA
AA
AA
CC
CC
CC
G
C
D
E
C
D
B
F
E
F
H
B
C
D
Hardware Used
L-bracket
1/4” x 12 mm Bolt
Hex wrench
x 4
x 16
x 1
DD
AA
CC
Hardware Used
M4 x 35 mm Screw x 40
BB

78
ASSEMBLY INSTRUCTIONS
7. If you buy more than one unit, you can collect more
style.
8. Secure units together by attaching the metal plates (GG)
with the 1/4” x 12 mm bolts (AA) into the holes. Tighten with
hex wrench (CC).
NOTE: Must install step 6 for all secured units
7
8
GG
AA CC
Hardware Used
Metal plate
1/4” x 12 mm Bolt
Hex wrench
x 2
x 6
x 1
GG
AA
CC
6. Adjust oor levelers to level the unit against the wall
where desired. Using top frame (B) as a template, mark
one mounting holes location on the wall. Drill one pilot
holes into the wall where previously marked. Make sure
that the drilled holes can t for the wall anchors (sold
separately) properly. Press the anchors into the holes
and gently tap with a hammer until ush in the holes. If
the mounting hole coincides with a wooden stud, there is
no need wall anchor. Align top frame (B) and back cross-
ers (HH) over the drywall anchors (II) and secure with
M5 x 65 mm screw (EE). Tighten securely with phillips
screwdriver.
6
Hardware Used
BEE
II HH
Drywall Anchor x 1
x 1
II
Back Crosser
x 1
EE
HH
M5 x 65 mm
Screw
Wall
