Spectrum Industries Freedom One eLift Lectern User manual

??
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Important
Avant d’utiliser ce produit:
• Veillez à lire ce guide
• Respectez les consignes de sécurité et d’utilisation
• Vériez que vous disposez de toutes les pièces
nécessaires à l’installation
Importante
Antes de utilizar este producto:
• Lea este manual
• Cumpla con todas las instrucciones de prevención de
accidentes y operativas
• Revise que todas las partes y las cantidades correctas
estén incluidas
Any parts damaged during shipment must be reported within 5
days of receipt. To report information regarding missing parts or
damage, to purchase parts or accessories, or if you have any
questions, please contact us.
Thank you for purchasing Spectrum products!
Les pièces endommagées pendant le transport doivent faire
l’objet d’un rapport dans les 5 jours de leur réception. Veuillez
prendre contact avec nous si des pièces manquent ou sont
abîmées, si vous avez des questions, ou encore pour acheter
des pièces ou des accessoires.
Merci pour votre achat d’un produit Spectrum!
Si alguna parte se dañó durante el embarque, deberá reportarla
en un lapso de 5 días a partir de la recepción. Para reportar
cualquier información sobre partes faltantes o dañadas, para
adquirirlas o comprar accesorios, o bien, si tiene alguna duda,
póngase en contacto con nosotros.
¡Gracias por adquirir productos Spectrum!
Owner’s Manual
Le manuel du propriétaire
El manual del propietario
VideoVideo
VidéoVidéo
VídeoVídeo
SpecsSpecs
SpécicationsSpécications
EspecicacionesEspecicaciones
800-235-1262800-235-1262
http://www.spectrumfurniture.com
Owner’s ManualOwner’s Manual
0118408 Page 1 of 16
Freedom One eLift Lectern™
55542

2. Attach equipment rack casters / glides
0118408 Page 2 of 16
CAUTION
Keep clear of pinch points during worksurface movement. Note: The lift
actuators provide 540 lb of lift.
Always unplug the lectern before working under the worksurface.
Do not place anything under the worksurface when operating lift.
Although this lectern utilizes an anti-collision feature that briey stops
and reverses the worksurface motion in the event of an obstruction,
use caution when raising or lowering. Do not sit at, under, or on the
worksurface when operating the lift mechanism and be sure lectern
movement does not interfere with objects or people. Use caution when
raising or lowering the worksurface!
Control buttons
DownUp
Note: The lectern has a load-sensing, anti-collision feature programmed
into the controller that actively locks out the lift mechanisms when
unbalanced loads are encountered; i.e. an obstruction under the work-
surface, or weight from a person sitting on one side of the lectern.
1. On a non-abrasive surface, carefully tip the equipment rack onto its back or side.
2. Install the included stem casters or glides and tighten securely.
Note: 2 locking casters should be installed on the instructor-side for easy-access.
3. Tip the equipment rack back upright.
Figure 2.2
Locking stem
caster
for casters
Stem caster
Instructor side
Audience side
Glide
3
/
4”
5
/
8”for glides
Figure 1.2
Figure 2.1
Note: This unit is not designed for use with cord reels or surface-mount
cord reel accessories.
1. Lectern lift mechanism initial setup, operation, and reset procedure
Assembly / Setup
Preparation:
• Read all instructions before operation.
• Make sure lectern is plugged-in using the 15-foot, 15-amp power cord.
• Locate the “Up” and “Down” control buttons. Control pad is located on the instructor-
side under the worksurface front edge on opposite side from rack cabinet.
• Keep clear of pinch points during worksurface movement.
Normal Operation:
To raise or lower the lectern, press and hold the “up” or “down” arrow keys on the control
pad until the worksurface reaches the desired height. The worksurface can be adjusted
from 28.5”H (minimum) to 42”H (maximum).
Figure 1.1

0118408 Page 3 of 16
Figure 3.2
(2) 1/4-20
x 15mm JC
bolts
(4) 1/4-20 x 40mm
JC bolts
1. Determine which side of the lectern the equipment rack is to be installed (left
or right side). (Right-side installation shown.)
2. Attach the unit-to-unit brackets to the equipment rack side panel mounting
holes with (4) 1/4-20 x 15mm JC bolts. Figure 3.1.
Figure 3.1
Unit-to-Unit bracket
(2) 1/4-20 x
15mm JC bolts
Unit-to-Unit bracket
Lectern Equipment Rack with
installed unit-to-unit
brackets
3. Bring the equipment rack to the lectern and align the unit-to-unit
brackets with the mounting holes in the lectern leg.
4. Install (4) 1/4-20 x 40mm JC bolts through the top of the
lectern leg and tighten securely. Figure 3.2.
Equipment Rack
Lectern leg
4mm
Note: The ip-up shelf option may not be included with all congurations.
The shelf is designed for use on Freedom One eLift equipment racks that
are attached to the lectern with unit-to-unit connectors. The shelf installs
on the equipment rack side opposite the Freedom One Lectern.
Figure 4.2 Figure 4.1
Folding shelf
bracket
Release lever
(press here)
1. Determine which side of the equipment rack you want the shelf installed.
(Left or right).
2. Extend each shelf bracket by depressing the release lever and lifting
until it locks into the 90° position. Figure 4.1.
3. Using a second person to support the shelf, install the (8) 8-32 x 1/2” PH
thread-cutting screws into the side panel. Do not tighten until all screws
have been installed.
4. Tighten all screws securely.
5. Install 2” grommet.
Equipment Rack
Flip-up shelf
assembly
2” Grommet
8-32 x 1/2” PH
thread-cutting screws
(4 per bracket)
CAUTION
Keep clear of pinch points during shelf movement. Do not exceed 35 lb
[15.9 kg] of weight on shelf. Not for use on stand-alone equipment racks.
Operation
The shelf will automatically lock into place when lifted into the horizontal
position with the levers released. Figure 4.2. To lower or ip-up the shelf,
press and hold the shelf bracket levers while slowly lowering or raising the
shelf. Do not move the lectern while the shelf is in the horizontal position.
Note: Power and communication wiring for document cameras, laptop
computers, and / or projectors placed on the ip-up shelf should be routed
on top of the audience-side of the shelf. Use of the shelf grommet hole for
wiring will result in pinching of the cords when the shelf is folded.
Installing ip-up shelf (optional)
3. Connect lectern and equipment rack

4mm hex
wrench
Tools RequiredTools Required
Jigsaw
or
Router
Drill
Measuring
device
Pencil
Masking
tape
Drill bit
Overbridge insert panel (select overbridge lecterns)
0118408 Page 4 of 16
1/4-20 x 35mm
JC bolt
Overbridge
panel
1/4-20 x 35mm
JC bolt
1. To remove the overbridge insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a
4mm hex wrench and lift out the panel. Figure 5.1.
2. To make cutouts in the insert panel [optional]:
3. Install controller(s) / electronics into panel.
4. Re-install the overbridge panel and secure with (2) 1/4-20 x 35mm JC bolts.
Note: Blank overbridge panels require the cus-
tomer to make necessary cutouts with a jigsaw
or router. This has a moderate difculty rating,
so experience and skill with tools is required.
4mm
1. Identify all location(s) and sizes for controller(s) or electronics while making sure
all devices t within the maximum cutout space available in the overbridge panel.
See Figure 5.2, 5.3.
2. Locate and mark the exact cutout area(s) on the panel.
Note: Using masking tape on cut lines will minimize laminate chipping while cutting.
3. Carefully make the cutout(s) in the overbridge panel using a jigsaw or router.
Figure 5.1

Figure 5.3
0118408 Page 5 of 16
2” grommet
Freedom One eLift Overbridge Insert Panel Blank
(at view)
Overbridge
section view
2” grommet
Max cutout area
Cutouts should
be avoided here
if device will
descend below
worksurface
(Actuator
plug below
worksurface)
Worksurface opening below
Worksurface opening below
Figure 5.2

0118408 Page 6 of 16
The audience-side panel can be removed to access the rear portion of the equip-
ment rack.
1. To remove the panel, gently pull the top of the panel and lift the panel
out and away from the equipment rack. Figure 6.
2. To reattach, align the panel with the frame and snap into place.
• Before moving, unplug and secure all power cords.
• Close and lock doors.
• Remove any items from the top of the worksurface.
• Unlock the casters.
• Push slowly and carefully. Do not move over uneven or irregular surfaces.
• Do not allow children to move.
• Lock the casters after moving.
• Do not park unit in areas of heavy trafc.
• Do not run power cords across hallways, classrooms, or other areas
where they will be walked on.
• Do not leave unit unattended in areas where children have access.
• Keep doors closed and locked whenever unit is unattended or parked.
• Keep casters locked whenever the lectern is unattended.
Figure 7
Audience-side panel
Equipment Rack
Audience-side
Actuator
Up / Down
buttons
To wall outlet
Actuator
Note: The shroud panel can be
removed with 2 screws and /
or the worksurface extended to
access internal wiring.
Wire Loom
Wiring Diagram
Figure 6
Control Box
Removing eq. rack audience-side panel Moving and parking the lectern

W
D
YOUR LOGO HERE
Accessories
0118408 Page 7 of 16
Clear Acrylic Locking Door
39”H - 55512
32”H - 55510
• For instructor-side installation
• Can be installed hinged from the left or
right side
• Shipping weight: 13 lb [5.9 kg] (39”H)
11.5 lb [5.2 kg] (32”H)
Solid Locking Door
39”H - 55511
32”H - 55509
• For instructor or audience-side installation
• Can be installed hinged from the left or
right side
• Shipping weight: 13 lb [5.9 kg] (39”H)
11.5 lb [5.2 kg] (32”H)
Flip-up Shelf - 55543
• Shelf hinges lock into place in the upright position
• Includes 2” grommet
• Mounts on left or right side of equipment rack
• Available in matching, or White Chalk Dry Erase laminate
Dimensions: 19.25”W [48.9 cm] x 26”D
[66 cm] x 1”H [2.54 cm]
Weight capacity: 35 lb [15.9 kg]
Shipping weight: 27 lb [12.3 kg]
Unit-to-Unit Connector Kit - 55359
• For connecting equipment rack to lectern
• Simple installation-lectern and equipment
rack can remain right-side up
• Shipping weight: 9 lb [3.9 kg]
Customized Logo Panel - 55380
• To get a customized logo panel, contact
Spectrum to specify all logo details
• New logos require a rst time logo charge
Dimensions: 26”W [66 cm] x .625”D
[1.6 cm] x 19.09”H [48.5
cm]
Shipping weight: 15 lb [6.8 kg]
Overbridge Insert Panel-Large
One-piece - 96507
Two-piece - 96513
• Contact Spectrum to specify cutout size(s) and
position(s)
• Includes two 2” [5.08 cm] grommets with covers
• Customer-installed
96507 dims: 33.25”W [84.45 cm] x 9”D
[22.9 cm] x .79”H [2 cm]
96513 dims: 16.625”W [42.2 cm] x 9”D
[22.9 cm] x .79”H [2 cm]
Shipping weight: 8.5 lb [3.9 kg]
Flip-up shelf not for use on
stand-alone equipment racks.
Note: When used on the audience-side of
the equipment rack, the door will replace the
standard audience-side panel.

0118408 Page 8 of 16
Note: The keyboard tray protrudes 3.4375” [8.73 cm] below the work-
surface. If the lectern is used for ADA use, a higher adjusted worksur-
face (around 32”H) is necessary to provide wheelchair clearance.
Keyboard Tray - 55379
• Tray can be installed and used as a keyboard tray or ipped and used as a
storage drawer using pre-drilled mounting holes under the lectern worksurface.
• Wire management slots in tray
Dimensions: 22”W [55.9 cm] x 13.815”D [35.1 cm] x 4”H [10.2 cm]
Weight capacity: 25 lb [11.4 kg]
Shipping weight: 14 lb [5.4 kg]
Cutout required: 5.65”W [14.35 cm] x 1.65”D [4.19 cm]
Power cord: 9’ [274 cm] 14AWG *3C power cord
Power receptacles: 125V, 60hz, 15A tamper-resistant
USB charging ports: 2.1A (10.5W) (not data-compatible)
Dimensions: 6.38”W [16.2 cm] x 2.36”D [6 cm] x 3.54”H [9 cm]
Unit weight: 2 lb [.9 kg]
Shipping weight: 2.35 lb [1 kg]
Power Module - 99058
• (2) AC power receptacles
• (2) USB charge ports
• Aluminum housing and ange
• Thumbscrew clamps
• Requires worksurface cutout
• ETL-certied
• Available in black, silver, or white
• Customer-installed
Equipment Rack for Freedom One eLift - 55508
• 39”H (18RU) or 32”H (14RU)
• Front and rear rack rails
• Standard audience-side panel included
• Casters / glides assembled by customer
• 39”H [99.3 cm] or 32”H [81.3 cm] worksurface height (with casters)
• Two 2” grommets in each side panel provide cord access
• Up to two equipment racks can be attached to the lectern
(1 on left and 1 on right)
Worksurface options: • No Cutouts
• Custom Cutouts
• Power Module
Base options: • Twin Wheel Casters
• Glides
Door options: • Solid door
• Acrylic door
Shipping weight:
(nominal)
• 116 lb [52.7 kg] (39”H)
• 102 lb [46.3 kg] (32”H)
Freedom One eLift Lectern - 55542
• Electrically-adjustable worksurface
• ADA-compliant
• Available in surround or overbridge versions
• Factory-assembled with casters or glides
Lectern Style: • Surround
• Overbridge
Worksurface options: • No Cutouts
• Custom Cutouts
Base options: • Twin Wheel Casters
• Glides
Shipping weight:
(nominal)
151 lb [68.6 kg]

0118408 Page 9 of 16
Battery
Rechargeable Battery Pack System - 99045
• Creates a mobile lectern / desk by providing the ability to operate the
unit in locations without AC power
• Compact, lightweight lithium-ion battery plugs into and charges from the
existing lectern control box
• On-board LED light bars indicate charge capacity level
• Audio alarm signals when charging is needed
• Thermal switch protection, overcurrent protection
• Easy customer-installation
Battery Type Lithium-ion
Capacity 2.2 Ah / 53 Wh
Voltage (nominal) 24V
Discharge current 9A (max)
Max charging voltage 40V DC
Charging current 0.5 A
Certications EN 62133 (Battery safety testing)
UL 1642 (Lithium cells, standard test)
UN 38.3 (Transportation of Lithium batteries)
UL 2054 (Household and commercial batteries)
EN 60335-1 with CBH Advanced
Unit weight: (nominal) 1.32 lb [.6 kg]
Shipping weight: (nominal) 2 lb [.9 kg]
Battery / Control Box Compatibility:
Older CBD4 Linak control
boxes are not compatible
with this battery pack.
The CBD6S Linak control
box is compatible with
this battery pack.

0118408 Page 10 of 16
Note: The unit requires a 7” diameter of clearance to work with
Qi-enabled phones placed in any orientation. The 3” dia cutout
should be located on the worksurface at least 3.5” from any edge.
Cutout required: 3" dia (by customer)
Input: DC 5V (with included DC5V.2A power adapter)
Output: 5W max (with included DC5V.2A power adapter)
Power cord: 8’ [244 cm] with DC jack
Dimensions: 3.5” dia [8.9 cm] x 1.125”H [2.9 cm]
Shipping weight: 1 lb [.45 kg]
EM Wireless Charging Pad - 99057
• Uses electromagnetic technology
to charge Qi V1.2 compliant IC
devices (“Qi” enabled)
• LED to conrm pairing / charging
• Security tab prevents theft
• Requires 3” round cutout to be
made by customer
• UL-certied
Dual Flat Panel Monitor Arm - 95533
• Weight range: 3.5-13 lb [1.6-5.9 kg] per monitor
• Six mounting options (clamp, thru-desk, wall,
grommet hole, side bolt, reverse wall)
• Compatible with all VESA®monitors – includes
75mm and 100mm VESA®adapters
• Cable management concealed in arm
Flat Panel Monitor Arm
95512 - “Light-Duty” for monitors weighing 2-13 lb [.9-5.9 kg]
95522 - “Medium-Duty” for monitors weighing 7.5-25 lb [2.5-11.4 kg]
95509 - “Heavy-Duty” for monitors weighing 12-31 lb [5.4-14 kg]
• Six mounting options (clamp, thru-desk, wall, grommet hole, side
bolt, reverse wall)
• Compatible with all VESA®monitors – includes 75mm and
100mm VESA®adapters
• Cable management concealed in arm
Adjustable Drafting Stool - 38202
• 40-52” height-adjustment via pneumatic cylinder
• 360° swivel
• Tilting backrest
• 18” diameter xed foot ring
• 5-star base
