TECHLIGHTING ELEMENT E4-L A Series User manual

1
Installation Instructions for 920E4LED-A
Round or Square Element 4" Adjustable Housing
E4_-L_A_ 1.2
LED ROUND SQUARE-/
GP I :ENERAL RODUCT NFORMATION
This product is suitable for indoor locations.
This product can be dimmed with a standard electronic dimmer.
This instruction shows a typical installation.
HOUSING CLASP
HOUSING
1B INNER ADJUSTABLE BAR
OUTER ADJUSTABLE BAR
TAB
STOP POINT
3
3
NAIL
2
Install the Housing with Adjustable Bars
1A
2
3
4
Slide the inner adjustable bar completely through the
three housing clasps. Make sure the nail is on top.
Slide and push the outer adjustable bar completely onto
the inner adjustable bar so that the tab clicks into place
behind the stop point.This will prevent the adjustable bars
from coming apart.
Repeat steps 2 & 3 for the other side of the housing.
BREAK OFF
AND DISCARD
¾” or thicker
½” to ¾”
LEAVE TAB
IN PLACE
Keep Tab for ceiling ½” to ¾” thick.
When using adjustable hanger bars with ½”to ¾” thick
ceilings, leave the tab of the hanger bars in place.
Break off Tab for ceiling ¾” or thicker.
When using adjustable hanger bars with ¾”or thicker
ceilings, remove the tab by bending it at the perforation.
1
NOTE: Skip this section if installing the housing
with butterfly brackets.
CAUTION RISK OF FIRE-
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.

2
9
1E
COLLAR
HOUSING
ADJUSTABLE BAR 8
1D
COLLAR
NAIL
JOIST
NAIL
66
7
7
NOTE: The adjustable bars can be mounted to
joists that are spaced 16" - 24" apart.
Align the bottom of the end plates with the bottom of the
ceiling joists.
Level the adjustable bars and, with a hammer, tap the nails
completely into the joists to secure the adjustable bars.
6
7
6
7
Adjust the collar position (horizontal position) by sliding
the housing on adjustable bars.
When the desired location is achieved, tighten the two #6
self tapping screws to lock the housing onto the adjustable
bars.
8
9
NOTE: Notches in the collar can be used to
align multiple housings using a laser or string.
9
#6 SELF TAPPING
SCREW
HOUSING
COLLAR
NOTCH
Carefully cut and remove the zip ties.
5
1C
ZIP TIE

3
Connect Power to the Housing
Slightly loosen the wing nut located inside the housing to
slide the butterfly bracket up or down.
After achieving the proper location, tighten the wing nut
to secure the butterfly bracket in place.
Repeat steps 1 and 2 on for the other butterfly bracket.
Utilize the butterfly brackets to install the housing in
accordance with local electrical codes.
Install the Housing with Butterfly
Brackets
2A
1
2
3
4
NOTE: Notches in the collar can be used to align
multiple housings using a laser or string.
NOTE: Skip this section if installing the housing
with adjustable bars.
3A
Push the tab on the housing electrical box up and remove
the electrical box cover.
1
Install the conduit to the housing electrical box.
Run the power line wires into the housing electrical box.
Use the appropriate wiring diagram on the following page
to wire your fixture accordingly.
2
WARNING: RISK OF FIRE: When using the housing electrical box
for power feed through, use 4 - #12 , or 6 - #14
MAX AWG AWG
branch circuit wires.
3
3B
NOTE: When a fixture is installed in a location that requires
servicing from below the ceiling through the fixture
aperture, the branch circuit connections need to be able to
be brought out through the aperture.To accomplish this,
an NM type cable in conjunction with snap-in/push-in
connectors must be used and a 12” service loop must be
left available outside of the fixture housing wiring
compartment to allow additional branch circuit wiring to
be pulled through the snap-in/push-in connector and
extended out through the aperture below ceiling level.
BUTTERFLY
BRACKET
COLLAR
NOTCH
TAB
ELECTRICAL
BOX COVER
1
3
2
4
WING NUT
(INSIDE HOUSING)
WAGO
WAGO
WAGO
WAGO

4
Hi-Lume 2 Wire
EXTERNAL GROUND
GROUND
GREEN
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
GROUND
CONNECTOR
TO DRIVER
HOUSING
Hi-Lume Driver Wiring
Standard ELV/Triac
EXTERNAL GROUND
GROUND
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
Standard 0-10V
EXTERNAL GROUND
GROUND
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
GREY
PURPLE
0-10V (-) DIM
0-10V (+) DIM
EXTERNAL GROUND
EXTERNAL NEUTRAL
EXTERNAL HOT
HOT BLACK
0-10V (-) DIM
0-10V (+) DIM
HOUSING
HOUSING
Standard Driver Wiring
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
PURPLE
GREY
EXTERNAL GROUND
GROUND
GREEN
GROUND
HOUSING
CONNECTOR
TO DRIVER
EldoLED ECOdrive/SOLOdrive 0-10V
0-10V (+) DIM
0-10V (-) DIM
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
PURPLE
PURPLE
DIM/DIGITAL BUS
DIM/DIGITAL BUS
EXTERNAL GROUND
GROUND
GREEN
GROUND
HOUSING
CONNECTOR
TO DRIVER
EldoLED SOLOdrive DALI
EldoLED Driver Wiring
DRIVER
DRIVER
DRIVER
IC LABELED FIXTURE WIRING
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
ORANGE/WHITE
ORANGE
DALI CONTROL -
DALI CONTROL +
EXTERNAL GROUND
GROUND GREEN
GROUND
HOUSING
EldoLED DUALdrive DALI
EldoLED Tunable White Wiring
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
GREY/WHITE
PURPLE/WHITE
CCT 0-10V (-)
CCT 0-10V (+)
EXTERNAL GROUND
GROUND
GREEN
GROUND
HOUSING
EldoLED DUALdrive 0-10V
GREY
PURPLE
INTENSITY 0-10V (-)
INTENSITY 0-10V (+)
CONNECTOR
TO DRIVER
DRIVER
DRIVER
DRIVER
CONNECTOR
TO DRIVER
Hi-Lume EcoSystem
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
PURPLE
DIM/DIGITAL BUS
DIM/DIGITAL BUS
EXTERNAL GROUND
GROUND
HOUSING
PURPLE/WHITE
GROUND GREEN *
CONNECTOR
TO DRIVER
* If green/ground connection is available, wire to ground.

5
Standard ELV/Triac
EXTERNAL GROUND
GROUND
EXTERNAL NEUTRAL
EXTERNAL HOT
NEUTRAL WHITE
HOT BLACK
Standard 0-10V
EXTERNAL GROUND
GROUND
EXTERNAL NEUTRAL
NEUTRAL WHITE
GREY
PURPLE
0-10V (-) DIM
0-10V (+) DIM
EXTERNAL GROUND
EXTERNAL NEUTRAL
0-10V (-) DIM
0-10V (+) DIM
HOUSING
Standard Driver Wiring
EXTERNAL NEUTRAL
NEUTRAL WHITE
PURPLE
GREY
EXTERNAL GROUND
GROUND
GREEN
GROUND
HOUSING
EldoLED ECOdrive/SOLOdrive 0-10V
0-10V (+) DIM
0-10V (-) DIM
EXTERNAL NEUTRAL
NEUTRAL WHITE
PURPLE
PURPLE
DIM/DIGITAL BUS
DIM/DIGITAL BUS
EXTERNAL GROUND
GROUND
GREEN
GROUND
EldoLED SOLOdrive DALI
EldoLED Driver Wiring
NON-IC LABELED FIXTURE WIRING
EXTERNAL HOT
HOT BLACK
THERMAL PROBE
EXTERNAL HOT
HOT BLACK
HOT BLACK
THERMAL PROBE
EXTERNAL HOT
HOT BLACK
DRIVER
HOUSING
DRIVER
DRIVER
THERMAL PROBE
THERMAL PROBE
CONNECTOR
TO DRIVER
HOUSING
CONNECTOR
TO DRIVER
Hi-Lume 2 Wire
DRIVER
EXTERNAL GROUND
GROUND GREEN
EXTERNAL NEUTRAL
NEUTRAL WHITE
DRIVER
DRIVER
GROUND
EXTERNAL NEUTRAL
NEUTRAL WHITE
PURPLE
PURPLE
DIM/DIGITAL BUS
DIM/DIGITAL BUS
HOUSING
EXTERNAL GROUND
GROUND
HOUSING
Hi-Lume Driver Wiring
EXTERNAL HOT
HOT BLACK
EXTERNAL HOT
HOT BLACK
Hi-Lume EcoSystem
THERMAL PROBE
CONNECTOR
TO DRIVER
THERMAL PROBE
* If green/ground connection is available, wire to ground.
GROUND GREEN *
CONNECTOR
TO DRIVER
EldoLED Tunable White Wiring
EXTERNAL NEUTRAL
EXTERNAL HOT
GREY/WHITE
PURPLE/WHITE
CCT 0-10V (-)
CCT 0-10V (+)
EXTERNAL GROUND
GROUND GREEN
GROUND
HOUSING
EldoLED DUALdrive 0-10V
GREY
PURPLE
INTENSITY 0-10V (-)
INTENSITY 0-10V (+)
NEUTRAL WHITE
HOT BLACK
THERMAL PROBE
DRIVERDRIVER
CONNECTOR
TO DRIVER
EXTERNAL HOT
EXTERNAL GROUND
GROUND GREEN
GROUND
HOUSING
NEUTRAL WHITE
HOT BLACK
THERMAL PROBE
CONNECTOR
TO DRIVER
EldoLED DUALdrive DALI
ORANGE/WHITE
ORANGE
DALI CONTROL -
DALI CONTROL +
EXTERNAL NEUTRAL

6
Install Plaster Ring
(For Flangeless Versions)
Install Drywall
Align the cut out section of drywall with the collar and
install drywall.
2
WARNING: The housing is notRisk of Fire:
intended to be in contact with or covered with
combustible materials and insulation. Do not
install insulation within 3 inches of the housing
sides or above in such a manner to entrap heat.
4A
4-1/2"
ROUND COLLAR SQUARE COLLAR
4B
2
DRYWALL COLLAR JOIST
For round trims, mark a 4-1/2" diameter circle on drywall.
Cut out the marked section.
For square trims, mark a 4-1/2" square on drywall. Cut out
the marked section.
1
4-1/2"
Insert the plaster ring completely into the collar/ceiling
and secure them in place with the provided set screws and
Allen wrench.
1
ROUND PLASTER RING SQUARE PLASTER RING
NOTE: Longer set screws have been provided for
instances where the plaster ring does not reach the
collar and must be secured to the inside of the ceiling
cutout. Use the short set screws if the trim is installed in
the collar.
5A
CUT OUT
1
1
CUT OUT
1
1
SET SCREW
ALLEN
WRENCH
1
SHORT SET SCREW
TAB
TRIM HOLDER
LONG SET SCREW
TAB
CEILING

7
LENS LOCK
LENS LOCK
Plug the collar with the provided dust shield.
Properly plaster onto the plaster ring and drywall.
2
5D
Finish around the trim to match drywall.
4
45
3
Adjust the Lamp Housing
1To adjust the height, grip the module assembly and push
up to minimize glare and flash on the trim. Pull down on
the module assembly for maximum light output and
efficiency.
6A
MODULE
ASSEMBLY
MODULE
ASSEMBLY
Plug the collar with the provided dust shield.
Properly plaster onto the plaster ring and drywall.
2
6C
3
6B
LENS LOCK
PRESS TO
UNLOCK TILT
PRESS TO
UNLOCK TILT
2
2
5C
2
2

8
6B
2To tilt the lamp housing, unlock the assembly by pressing
on the latch and position the assembly until the desired
angle is reached.
NOTE: Lamp housing can tilt 40° vertically. Lock
intervals are 2.5° apart.
INDICATOR
MODULE
ASSEMBLY
LATCH
LATCH
NOTE: Lamp housing can rotate 361° horizontally.
3Pull the rotation lock out to unlock the lamp housing.
Rotate the lamp housing horizontally. When the desired
position is achieved push the rotation back to lock the
lamp housing in place.
4
6C
3
ROTATION
LOCK
LATCH CLOSED
LATCH
LATCH OPEN
LATCH

9
Install the Lenses (Optional)
7A
Place lenses (max. 2, optional) inside the lens holder
spring.
1
Line up tabs of the lens holder spring with the notches on
the optic holder and push the lens holder spring on.
2
7B
2
2
2
LENS HOLDER
LENSES

10
Notes

11
Notes

SAVE THESE INSTRUCTIONS!
7400 Linder Ave.
Skokie, 60077IL
847.410.4400
www.element-lighting.com
© 2020 Tech Lighting, L.L.C. All rights reserved.The "Element" graphic
is a registered trademark of Element. Element reserves the right to
change specifications for product improvements without notification.
12
