Introduction
The TechLogix TL-TP100-HDC2 revolutionizes high-bandwidth HDMI signal distribution
by leveraging HDBaseT technology to transmit 18G HDMI signals, including HDR and
4K@60 4:4:4, up to 100m (330 ft.) over standard twisted pair cabling.
The system works by lightly compressing signals above 10G for twisted pair transport,
and then uncompressing the signal at the destination end.
Flexible options for ARC (Audio Return Channel) allow the receiver to accept HDMI,
analog, or digital optical. The transmitter can output the audio on HDMI, analog, or
digital optical outputs.
Additional built-in features such as flexible power with Port-Saver™ protection, IR and
RS232 signal distribution, and Ethernet pass-through make the TL-TP100-HDC2
extremely powerful and extremely flexible.
Features at a Glance
• 18G HDMI (4K@60) up to 100m
• ARC on HDMI, Analog, and Optical Inputs and Outputs
• Deep color, DTS-HD, Dolby TrueHD compatible
• HDR compatible
• Light compression (2:1 ratio) on signals over 10G
• Single twisted pair transmission
• HDMI 2.0 / HDCP 2.2
• Built-in RS232, IR & Ethernet transmission
• Ethernet ports on send & receive
• Diagnostic LEDs
• Power from either transmitter or receiver
• Includes IR accessories & mounting ears
• Compatible with TechLogix rack-mounting systems
Package Contents
• [1] Transmitter
• [1] Receiver
• [2] Mounting kits
• [1] Power Supply
• [1] IR Emitter
• [1] IR Receiver
• [1] RS232 cable
• [2] Mini-Toslink Adapters
• [2] 3-Pin Terminal Blocks

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Panel Descriptions
Transmitter
Name
Description
1
Link LED
HDBT link status indicator
• OFF: no link
• GREEN: link successful
• Blinking GREEN: link abnormal
2
HDCP LED
HDCP compliant indicator
• OFF: no HDMI traffic (no picture)
• GREEN: traffic with HDCP
• Blinking GREEN: traffic without HDCP
3
Power LED
OFF: No power
RED: DC power present
4
ARC Connection Switch
Select ARC output as HDMI or analog/optical
5
Audio Output
Dual function audio output port
• Standard 3.5mm TRS for analog stereo
• Optical 5.1 audio with included adapter
6
IR In
Connects to a 5V IR receiver (with carrier); signals
tranmitted to the remote receiver.
NOTE: Use TL-IR-CC if connecting to a third party
control system.

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
7
IR Out
Connects to a 5V IR emitter (with carrier); signals
tranmitted from the remote receiver
8
Ethernet
100m Ethernet interface. If a strong connection is
present, the yellow LED indicators on the
corresponding ports will blink and the green LED
indicators will remain solid.
9
Twisted Pair Output
Connect to the TP In socket on the receiver via a
twisted pair cable. Supports bi-directional PoC.
Port-Saver™ protection prevents damage to
Ethernet devices that may be connected during
device installation.
10
HDMI Input
Connect to an HDMI source
11
RS232
RS232 control connector
12
24V DC Input
Connect with DC24V 1.25A power adaptor. (Not
necessary if receiver connects with power).

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Receiver
Name
Description
A
Link LED
HDBT link status indicator
• OFF: no link
• GREEN: link successful
• Blinking GREEN: link abnormal
B
HDCP LED
HDCP compliant indicator
• OFF: no HDMI traffic (no picture)
• GREEN: traffic with HDCP
• Blinking GREEN: traffic without HDCP
C
Power LED
OFF: No power
RED: DC power present
D
ARC Connection Switch
Select ARC input as HDMI or analog/optical
E
Audio Input
Dual function audio input port
• Standard 3.5mm TRS for analog stereo
• Optical 5.1 audio with included adapter
F
IR In
Connects to a 5V IR receiver (with carrier); signals
tranmitted to the remote receiver.
NOTE: Use TL-IR-CC if connecting to a third party
control system.
G
IR Out
Connects to a 5V IR emitter (with carrier); signals
tranmitted from the remote receiver
H
Ethernet
100m Ethernet interface. If a strong connection is
present, the yellow LED indicators on the

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
corresponding ports will blink and the green LED
indicators will remain solid.
I
Twisted Pair Input
Connect to the TP Out socket on the transmitter via
a twisted pair cable. Supports bi-directional PoC.
Port-Saver™ protection prevents damage to
Ethernet devices that may be connected during
device installation.
J
HDMI Output
Connect to an HDMI display
K
RS232
RS232 control connector
L
24V DC Input
Connect with DC24V 1.25A power adaptor. (Not
necessary if transmitter connects with power).

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
System Connection
Usage Precautions
System should be installed in a clean environment that has a proper temperature and
humidity.
All of the power switches, plugs, sockets and power cords should be installed properly.
All devices should be connected before powering on the devices.
The twisted pair terminations for the devices should be a straight-thru conforming to the
TIA/EIA T568B standard.
Connection Procedure
1. Connect an HDMI source (such as a set top box) to the HDMI IN port of the
transmitter with an HDMI cable.
2. Connect TP OUT port of the transmitter to TP IN port of the receiver using a
twisted pair cable.
3. Connect an HDMI display to HDMI OUT port of the receiver with an HDMI cable.
4. If IR control is required, perform the following:
a. Connect the IR emitter to the IR OUT port on either the transmitter or
receiver.
b. Connect the IR receiver to the IR IN port on either the transmitter or
receiver.
5. If RS232 control is required, connect the RS232 port of the devices to be
controlled to the receiver or the transmitter.
6. If Ethernet (LAN) support is required, connect the devices to the Ethernet ports.
7. If ARC (audio return channel) from the display to the source is required:
a. Receiver side:
i. HDMI audio: Slide the ARC Connection switch to HDMI.
ii. Analog audio: Slide the ARC Connection switch to Analog/Opt.
Connect a standard TRS audio input on the Audio In port.
iii. Optical audio: Slide the ARC Connection switch to Analog/Opt.
Insert the included analog to optical adapter into the Audio In port.
Connect a standard optical to the adapter.
b. Transmitter side:
i. HDMI audio: Slide the ARC Connection switch to HDMI.
ii. Analog audio: Slide the ARC Connection switch to Analog/Opt.
Connect a standard TRS audio input on the Audio Out port.
iii. Optical audio: Slide the ARC Connection switch to Analog/Opt.
Insert the included analog to optical adapter into the Audio Out
port. Connect a standard optical to the adapter.
8. Connect the DC24V power adaptor to either the transmitter or receiver. Power
will be transmitter to the remote extender via the twisted pair cable.

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Panel Drawings
Transmitter

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Receiver

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Specifications
I/O Connections (Transmitter)
HDMI Input
HDMI Type A Receptacle (supports ARC)
Audio Output
3.5mm TRS / Mini-TOSLINK Combo (Stereo analog / Optical
Digital)
Twisted Pair
8P8C port (Shielded RJ45) with Port-Saver™ protection
IR Input
3.5mm TRS Jack
IR Output
3.5mm TS Jack
RS232
3pin phoenix socket (Tx/Gnd/Rx)
24V DC Power
5.5 mm Outside Diameter, 2.1 mm Inside Diameter Barrel
(Locking)
Ethernet
8P8C port (Shielded RJ45)
I/O Connections (Receiver)
HDMI Output
HDMI Type A Receptacle (supports ARC)
Audio Input
3.5mm TRS / Mini-TOSLINK Combo (Stereo analog / Optical
Digital)
Twisted Pair
8P8C port (Shielded RJ45) with Port-Saver™ protection
IR Input
3.5mm TRS Jack
IR Output
3.5mm TS Jack
RS232
3pin phoenix socket (Tx/Gnd/Rx)
24V DC Power
5.5 mm Outside Diameter, 2.1 mm Inside Diameter Barrel
(Locking)
Ethernet
8P8C port (Shielded RJ45)
Supported Video and Audio
Maximum Distances
1080p/720p: 100m (330 ft.)
4K@30/10G: 100m (330 ft.)
4K@60/18G: 100m (330 ft.)
Maximum Video Compatibility
4K@60Hz 4:4:4
HDR supported
Video Compliance
HDMI 2.0, HDCP 2.2, and CEC (Consumer Electronics Control)
HDCP Compatibility
HDCP 2.2 Conversion – output version matches sink (display)
version
Embedded Audio (HDMI)
Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD
Master Audio
Embedded Audio (Analog)
PCM 2 channel 48kHz
Embedded Audio (Digital Optical)
Up to PCM 2 channel, 7.1 Dolby Digital Plus, and 7.1 DTS-HD
Input DDC Signal
5.0 volts p-p (TTL)
Input Video Signal
0.5 to 1.0 volts p-p
Ethernet Transmission Speed
Adaptive 10M/100M (max) / full duplex or half duplex
IR Carrier Frequency Range
33-55kHz at 5 volts
HDBaseT Signal Characteristics
Maximum Distance
100m (330 ft.)
Cable Requirements
Solid core shielded Category 5e, Category 6 or greater with
TIA/EIA-568B crimp pattern
Bandwidth
10.2 Gbps

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Compression Signal Characteristics
Compression ratio
Up to 2:1 (adaptive for signals above 10.2gbps)
Compression type
Color Space Conversion (VLC)
Chassis and Environmental
Enclosure
Painted aluminum
Dimensions
152mm x 109mm x 16mm
Shipping Weight
0.71Kg (1.55 lbs) (Tx+Rx)
Operating Temperature
(Environment)
-10° to +40° C
Operating Temperature (Chassis)
45° C
Operating Humidity (Environment)
10% ~ 90%
Storage Temperature (Environment)
-15° to +70° C
Storage Humidity (Environment)
0%~55%
Power, ESD, Regulatory
Maximum Power Consumption
20W (max)
Power Supply
24V DC
ESD Protection
15KV
Port-Saver Protection™
Twisted Pair connections employ 802.3af PoE controllers
which do not send power unless connected to a request port.
Network switch ports or Ethernet ports will not be damaged by
accidental cross-patching.
Regulatory
CE, FCC
Other
Standard Warranty
3 Year
Diagnostic Indicators
Power, Link, and HDCP LEDs
Network Indicators
Link Speed and Activity
Included Items
Installation Guide, power supply, US power cord, mounting “L”
brackets (4 ea), mounting screws (4 ea), IR Transmitter, IR
Receiver, 3.5mm Toslink Adapters (2 ea)

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
Troubleshooting and Maintenance
No image on display
• Ensure that the display device has been set to the correct input.
• Ensure that the HDMI cables used for both the source/transmitter and the
receiver/display are properly connected and are working. Test the HDMI cables
directly from a source to display and ensure their operation.
• Ensure that the twisted pair cable has not been damaged and that it has been
terminated correctly with T568B on both ends. A temporary length of twisted
pair cable can be used for testing to ensure that the devices are all compatible and
working properly.
• Ensure proper grounding of the power supply.
• Known issues with HDMI 1.2 source devices:
o Older compatibility (HDMI 1.2) may result in HDBaseT transmission issues.
Please contact Technical Support for a solution to these issues.
Color loss or poor picture quality:
• Ensure that the HDMI cables used for both the source and transmitter and the
receiver and display are properly connected and are of good quality. Test the
HDMI cables directly from a source to display and ensure their picture quality.
• Ensure proper grounding of the power supply.
• If the static becomes stronger or picture quality becomes worse when connecting
the video connectors, this may be due to improper grounding.
• Check the grounding and make sure all the components are properly grounded to
a common ground. Improper grounding may cause damage to the receiver.

TL-TP100-HDC2 User Manual
www.tlnetworx.com | +1-608-960-7242
After-sales Service
Product Limited Warranty: We warrant that our products will be free from defects in
materials and workmanship for three years.
Warranty coverage may be voided when:
The warranty period has expired
The factory applied serial number has been altered or removed from the product
There is damage, deterioration or malfunction caused by:
Atypical wear and tear
Use of supplies or parts not meeting the specifications
No certificate or invoice as the proof of warranty
Damage caused by force majeure
Non-authorized service
Technical Support: When contacting TechLogix support, please have the following
information available:
Product part number
Installation and sale date
Detailed failure information
Table of contents
Other Techlogix Extender manuals

Techlogix
Techlogix TL-TP100-HDC User manual

Techlogix
Techlogix TL-FO-USB3-01 User manual

Techlogix
Techlogix TL-FO-HD User manual

Techlogix
Techlogix TL-TP70-HDC User manual

Techlogix
Techlogix TL-TP40-HDC2 User manual

Techlogix
Techlogix TL-FO-USB3-02 User manual

Techlogix
Techlogix TTL-TP50-HDIR User manual

Techlogix
Techlogix TL-TP70-HD2ARC User manual

Techlogix
Techlogix TL-FO2-HDC User manual

Techlogix
Techlogix TL-TP50-HDIR User manual
