ORDERNo.AD0203063C2
Compact Disc Player
SL-HD560E
Traverse Deck:RAE0152ZMechanismSeries
Colour
(N)...........GoldType
System
SC-HD560:
Tuner;ST-HD560, Amplifier;SE-HD560,
CD Player;SL-HD560, Cassette Deck;RS-HD560,
Speakers;SB-HD560 (MadeinSpain.)
SPECIFICATIONS
Specifications
1

Digital outputterminal: Optical ×1
Audio section
DA converter: 1bit2DACMASH
Format
Sampling frequency: 44.1kHz
Pickup
Wavelength: 780 nm
General
Dimensions(W×H×D): 210×76.3×246 mm
Mass: 1.3kg
Notes:
Specificationsaresubjecttochangewithoutnotice.
Mass and dimensionsareapproximate.
*Noteon CD-R and CD-RW
Thisunitmay notbeabletoplay someCD-R dueto
thecondition ofrecording.
Itcannotplay CD-RW.
1. Note
1. Because touniqueinterconnecting cables, whenacomponent
requires service, send orbring intheentiresystem.
2. Refertotheservice manual forModel No. SE-HD560 (OrderNo.
AD0203061C2) forinformation on Accessories and Packaging.
2. BeforeRepair
Thisequipment(SL-HD560), whichisacomponentofthesystem, issuppliedwithpowerfrom
theAmplifier(SE-HD560)through theTuner(ST-HD560). Whenrepairing thisequipmentor
checking operation ofthesystem, besuretoconnecttoothersystemcomponentswithit.
Powersupplyand operation checks inthestateofitas asingleequipmentisimpracticable.
2

3. Handling Precautions forTraverse Deck
Thelaserdiodeinthetraverse deck (optical pickup)may break downduetopotential difference
causedbystaticelectricityofclothes or humanbody.
Sobecareful ofelectrostaticbreakdownduring repairofthetraverse deck (optical pickup).
3.1. Handling oftraverse deck (optical pickup)
1. Donotsubject thetraverse deck (optical pickup)tostatic
electricityas itisextremelysensitivetoelectrical shock.
2. To protect thelaserdiodeagainst electrostaticbreakdown, short
theflexibleboard(FFCboard)withacliporsimilarobject. Referto
Fig. 3-1.
3. Take carenottoapplyexcessivestress totheflexibleboard(FFC
board).
4. Donotturnthevariableresistor(laserpoweradjustment). Ithas
alreadybeenadjusted. Referto Fig. 3-1.
Fig. 3-1.
3.2. Grounding forelectrostaticbreakdownprevention
3.2.1. Humanbodygrounding
Use theanti-staticwriststraptodischargethestaticelectricityfrom your body. Referto Fig. 3-2.
Fig. 3-2.
3

3.2.2. Worktablegrounding
Putaconductive material (sheet) or steel sheeton thearea wherethetraverse deck (optical
pickup)isplaced, and ground thesheet. Referto Fig. 3-3.
Fig. 3-3.
Caution:
Thestaticelectricityofyourclothes will notbegroundedthrough
thewrist strap.
Sotake carenottolet yourclothes touchthetraverse deck (optical
pickup).
4. Precaution of LaserDiode
5. Location of Controls
6. Operation Checks and Component Replacement
Procedures
4

-Thissection describes procedures forchecking theoperation of
themajorprintedcircuitboardsand replacing themain
components.
-Forreassemblyafteroperation checks orreplacement, reverse the
respectiveprocedures. Special reassemblyprocedures are
describedonlywhenrequired.
6.1. Checking forthemainP.C.B.
-Check themainP.C.B. as shownbelow.
6.2. Checking fortheCD servoP.C.B.
-Follow the(Step1) -(Step3) ofitem6.1.
5

-Check theCD servoP.C.B. as shownbelow.
6

6.3. Replacementforthetraverse deck ass’y
-Follow the(Step1) -(Step3) ofitem6.1.
-Follow the(Step1) -(Step5) ofitem6.2.
7

8

9

10

6.4. Replacementforthebelt, loading motorass’yand loading switch
11

-Follow the(Step1) -(Step3) ofitem6.1.
-Follow the(Step1) -(Step5) ofitem6.2.
-Follow the(Step1) -(Step9) ofitem6.3.
7. ErrorCode Displayand ServoAdjustment Function
Thisunithas anerror codedisplay function, sothatiftheunitoperates incorrectly, thefaultis
displayedusing anerror codeon theFL display oftheTuner(ST-HD560). Italsohas aservo
adjustmentfunction for displaying thestatusofservosystem functions(Focus, Tracking, CLV
servo)on theFL display ofthetuner. Thesystem control ICand FL display arepartofthetuner
somake surethesystem has beenconnectedproperlybeforeusing these functions. Use these
twofunctionsfor guidanceduring faultdiagnosisand repair.
Note:
Check beforehand forscratching orsoiling ofthetest disc
12

(SZZP1054C), and soiling orotherproblemswiththepickup lens.
7.1. Errorcodedisplayprocedure
Table7-1.
FL display Symptom Cause
H15 WhenCD tray opens, itcloses byitself. Disc tray opendetectswitch(S790)
fault.
H16 WhenCD tray closes, itopensbyitself. Disc tray close detectswitch(S791)
fault.
F15
Does notplay, evenwhen
button ispressed.
Pickup restdetectswitch(S701)
fault.
F26
Does notmove, evenwhen
button ispressed.
System control ICand servo
processor
(IC201, IC702)fault.
7.2. Servoadjustmentprocedure
13

7.3. Errorcodebasedon troubleshooting
-ThisunitissatisfactoryiftheerrorcodeisE00 .
-Beforetesting, check that thetest disc isfree ofscratches and
optical pickup isclean.
8. ToSupplyPowerSource
Thisunitisdesignedtooperateon powersuppliedfrom system connected. / Whenacomponent
requires service, use thesystem connectionstosupplypowersource. / For system connections,
referto Fig.8-1.
Fig. 8-1.
9. SchematicDiagramNotes
-Thisschematicdiagrammaybemodifiedat anytimewiththe
developmentofnew technology.
14

Notes:
S701:
Rest detect switchinOFF position
S790:
Disc Trayopendetect switchinOFF position
S791:
Disc Trayclose detect switchinOFF position
S801:
Disc trayopen/close switch/ ( OPEN/CLOSE)
S802:
Pause switch( )
S803:
F.Skip/searchswitch( )
S804:
Playswitch( )
S805:
Stop switch( )
S806:
R.Skip/searchswitch( )
S807:
15

CD editswitch(EDIT)
S808:
Repeat switch(REPEAT)
S809:
Randomplayswitch(RANDOM)
-Indicatedvoltagevalues arethestandardvalues fortheunit
measuredbytheDC electroniccircuittester(high-impedance) with
thechassistakenas standard. Therefore, theremayexist some
errorsinthevoltagevalues, depending on theinternalimpedance of
theDC circuittester.
Nomark
:CD Stop
():CD Play[1 kHz, L+R, 0dB]
-Importantsafetynotice:
Components identifiedbymarkhavespecial characteristics
importantforsafety.
Furthermore, special parts whichhavepurposes offire-retardant
(resistors), high-qualitysound (capacitors), low-noise (resistors),
etc. areused.
Whenreplacing anyofcomponents, besuretouse only
manufacturer’sspecifiedparts shownintheparts list.
-Thesupplypartnumberisdescribedaloneinthereplacementparts
list.
-Caution!
ICand LSI aresensitivetostaticelectricity.
Secondarytroublecanbepreventedbytaking careduring repair.
Covertheparts boxes madeofplastics withaluminumfoil.
Ground thesoldering iron.
Putaconductivemat on theworktable.
DonottouchthelegsofICorLSI withthefingersdirectly.
-Voltageand signal line
16

:Positivevoltageline
:CD signal line
10. SchematicDiagram
11. Printed Circuit BoardDiagram
12. Type Illustration of ICs, Transistorsand Diodes
13. Wiring Connection Diagram
14. Block Diagram
15. Troubleshooting Guide
17

18

16. Terminal Function of ICs
16.1. IC201 (C2BBFD000340):/ SystemControl
Pin
No.Terminal Name I/O Function
1Vcc I Powersupplyterminal
2VREF I Reference voltageinput
3AVSS -GND terminal
4SYNC I Powerfailuredetectsignal input
5SUBQ I Sub-codeQdatasignal input
6SQCK O Sub-codeQresistor clock signal
output
7BLKCK I Sub codeblock clock signal
input
8BREQ I Serial communication request
signal inputfrom FL display/
System control IC
9BCS O Serial communication CS signal
outputfor FL display/System
control IC
10 BCLK O Serial communication clock
signal outputfor FL display/
System control IC
11 DATAO O Serial communication data
signal outputfor FL display/
System control IC
12 DATAI I Serial communication data
signal inputfrom FL display/
System control IC
13 CW O Loading motor control signal
(OPEN) output
14 CCW O Loading motor control signal
(CLOSE)output
15 CNVSS -GND terminal
16 SERVO
RST OResetsignal output
17 NC - Notused, open
18 RESET I Resetsignal input
19 X IN I Oscillator connectedterminal (F=
6MHz)
20 X OUT O
19

Pin
No.Terminal Name I/O Function
21 VSS -GND terminal
22 LED
ORG OLED(orange)control signal output
23 NC - Notused, open
24
25 LED
GRN OLED(green)control signal output
26 TEST O TESTmodesignal output
27 MDATA O Command datasignal output
28 MCLK O Command clock signal output
29 MLD O Command loadsignal output
30 STATUS I Statussignal input
31 NC - Notused, open
32
33 REST
SW IRESTdetectswitchsignal input
34
|
36
NC - Notused, open
37 OPEN
SW IDisc tray opendetectswitch signal input
38 NC - Notused, open
39 H:CR2 O ConnectedtoGND
40 KEY2 I Key switches detectsignal input
41 KEY1 I Key switches detectsignal input
42 CLOSE
SW IDisc tray close detectswitch signal input
16.2. IC701 (AN8885SBE1V):/ ServoAmp
