Technika DX6SS-6 User manual

USER GUIDE
60CM FREESTANINGDISHWASHER TDX6SS-6
TECHNIKA.COM.AU

PG 3
PG 3
CONTENTS TABLENote
•If you cannot solve the problems by yourself, please ask for help from a professional technician.
•The manufacturer, following a policy of constant development and updating of the product,
may make modifications without giving prior notice.
•If lost or out-of-date, you can receive a new user manual from the manufacturer or responsible
vendor. 1.Safety Information__________________________ 42.Product Overview__________________________ 73.Installation Instructions______________________ 8About Power Connection_______________________ 8 Water Supplier and Drain_______________________ 9 Connection of Drain Hoses_____________________ 10 Position the Appliance_________________________ 11 Freestanding Installation_______________________ 11
4. Using the Dishwasher_______________________ 12Control Panel________________________________ 13 Function of the Rinse Aid and Detergent____________15 Filling the Rinse Aid Dispenser___________________ 16 Filling the Detergent Dispenser__________________ 17
Basket Use Tips______________________________ 18 Preparing and Loading Dishes___________________ 19 Loading the Baskets According to AS/NZS 2007.1_____ 225. Programming the Dishwasher_________________ 24Wash Cycle Table____________________________ 24 Starting A Cycle Wash________________________ 25 Changing The Program Mid-cycle_______________ 25 Forgot to Add a Dish__________________________ 266. Maintenance & Cleaning_____________________ 27External Care________________________________ 27 Internal Care________________________________ 27 Caring for the Dishwasher______________________ 307. Troubleshooting Tips________________________ 31Error Codes_________________________________ 358. Technical Information_______________________ 36Product Fiche_______________________________ 37

PG 4
SAFETY INFORMATIONWhen using your dishwasher , follow the precautions listed below:
• Installation and repair can only be carried out by a qualified technician
• This appliance is intended to be used in household and similar applications such as:
- sta kitchen areas in shops, oces and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be done
by children without supervision.
• This appliance is not intended for use by persons (including children ) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. (For IEC60335-1 )
• Packaging material could be dangerous for children!
• This appliance is for indoor household use only. To protect against the risk of electrical
shock, do not immerse the unit, cord or plug in water or other liquid.
• Please unplug before cleaning and performing maintenance on the appliance.
• Use a soft cloth moistened with mild soap, and then use a dry cloth to wipe it again.
Warnings

PG 5
SAFETY INFORMATION• This appliance must be earthed. In the event of a malfunction or breakdown, earthing
will reduce the risk of an electric shock by providing a path of least resistance of electric
current. This appliance is equipped with an earthing conductor plug.
• The plug must be plugged into an appropriate outlet that is installed and earthed in
accordance with all local codes and ordinances.
• Improper connection of the equipment-earthing conductor can result in the risk of an
electric shock.
• Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly grounded.
• Do not modify the plug provided with the appliance; If it does not fit the outlet.
• Have a proper outlet installed by a qualified electrician.
• Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
• Do not operate your dishwasher unless all enclosure panels are properly in place.
• Open the door very carefully if the dishwasher is operating, there is a risk of water squirting
out.
• Do not place any heavy objects on or stand on the door when it is open. The appliance
could tip forward.
• When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door seal;
2) Warning: Knives and other utensils with sharp points must be loaded in the basket
with their points facing down or placed in a horizontal position.
• Some dishwasher detergents are strongly alkaline.
• They can be extremely dangerous if swallowed.
• Avoid contact with the skin and eyes and keep children away from the dishwasher when
the door is open.
• Check that the detergent powder is empty after completion of the wash cycle.
• Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent.
• For unmarked plastic items not so marked, check the manufacturer’s recommendations.
• Use only detergent and rinse agents recommended for use in an automatic dishwasher.
• Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
• The door should not be left open, since this could increase the risk of tripping.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
• During installation, the power supply must not be excessively or dangerously bent or
flattened.
• Do not tamper with controls.
• The appliance needs to be connected to the main water valve using new hose sets. Old
sets should not be reused.
• To save energy, in stand by mode , the appliance will switch o automatically while there is
no any operation in 30 minutes.
• The maximum number of place settings to be washed is 14.
Earthing Instructions

PG 6
SAFETY INFORMATIONDisposal• For disposing of package and the appliance please go to a recycling center. Therefore cut
o the power supply cable and make the door closing device unusable.
• Cardboard packaging is manufactured from recycled paper and should be disposed in the
waste paper collection for recycling.
• By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
• For more detailed information about recycling of this product, please contact your local city
oce and your household waste disposal service.
• DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.

PG 7
PRODUCT OVERVIEWIMPORTANT:
To get the best performance from your dishwasher, read all operating instructions
before using it for the first time.
NOTE:
Pictures are only for reference, dierent models may be dierent. Please prevail in kind.
DispenserLower spray armFilter assemblyInner pipeCutlery basketLower basketUpper spray armUpper basketCutlery rackCup rack

PG 8
INSTALLATION INSTRUCTIONSAttentionThe installation of the pipes and electrical equipments should be done by professionals.
Electrical RequirementsPlease look at the rating label to know the rating voltage and connect the dishwasher to the
appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or circuit breaker
recommended and provide separate circuit serving only this appliance.
Electrical Shock HazardDisconnect electrical power before installing
dishwasher. Failure to do so could result in
death or electrical shock.
For personal safety:Do not use an extension cord or an adapter plug with this
appliance. Do not, under any circumstances, cut or remove the
earthing connection from the power cord.
About Power ConnectionElectrical ConnectionEnsure the voltage and frequency of the power being corresponds to those on the rating plate.
Only insert the plug into an electrical socket which is earthed properly. If the electrical socket
to which the appliance must be connected is not appropriate for the plug, replace the socket,
rather than using a adaptors or the like as they could cause overheating and burns.

PG 9
INSTALLATION INSTRUCTIONSWater Supply and DrainCold water connectionConnect the cold water supply hose to a threaded 3/4 inch
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that
the water is clear. This precaution is needed to avoid the risk
of the water inlet to be blocked and damage the appliance.
WarningThe appliance is to be connected to the water mains using new hose sets and that old hose-
sets should not be reused.
About the safety supplyThe safety supply hose consists of the double walls. The hose’s system guarantees its
intervention by blocking the flow of water in case of the supply hose breaking and when the air
space between the supply hose itself and the outer corrugated hose is full of water.
WarningA hose that attaches to a sink spray can burst if it is installed on the same water line as the
dishwasher. If your sink has one, it is recommended that the hose be disconnected and the
hole plugged.
How to connect the safety supply hose1. Pull The safety supply hoses completely out from storage compartment located at rear of
dishwasher.
2. Tighten the connection of the safety supply hose to the faucet with thread 3/4 inch.
3. Turn water on and test for leaks before fully installing the dishwasher.
How to disconnect the safety supply hose1. Turn o the water.
2. Unscrew the safety supply hose from the faucet.

PG 10
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink,
making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000mm.
The free end of the hose must not be immersed in water to avoid the back flow of it.
Please securely fix the drain hose in either position A or position B
When connecting to a spigot (A), insure the spigot is drilled out fully to avoid blockages.
How to drain excess water from hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into
the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container
that is held outside and lower than the sink.
Water outletConnect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water drain hose is not kinked or squashed.
Extension hoseIf you need a drain hose extension, make sure to use a similar drain hose. It must be no longer
than 4 meters; otherwise the cleaning eect of the dishwasher could be reduced.
Syphon connectionThe waste connection must be at a height less than 100 cm (maximum) from the bottom of the
dish. The water drain hose should be fixed.
Connection of Drain HosesINSTALLATION INSTRUCTIONS

PG 11
Underneath existing work top(When fitting beneath a work top)
In most modern fitted kitchens there is only one single work
top under which cabinets and electrical appliances are
fitted. In this case remove the work top of the dishwasher by
unscrewing the screws under the rear edge of the top (a).
AttentionAfter removing the work top, the screws must be screwed
again under the rear edge of the top (b).
The height will then be reduced to 815 mm, as scheduled by the
International Regulations (ISO) and the dishwasher will fit perfectly under the kitchen working top.
Position the appliance in the desired location. The back should rest against the wall behind it, and
the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply
and drain hoses that can be positioned either to the right or the left sides to facilitate proper
installation.
Levelling the applianceOnce the appliance is positioned for levelling, the height
of the dishwasher may be altered via
adjustment of the screwing level of the feet. In any case,
the appliance should not be inclined
more than 2°.
NOTE: Only apply to the free standing dishwasher.
Position The ApplianceFree Standing InstallationFitting between existing carbinetsThe height of the dishwasher, 845 mm, has been
designed in order to allow the machine to be fitted
between existing cabinets of the same height in
modern fitted kitchens. The feet can be adjusted so
that correct height is reached.
The laminated top of the machine does not require any
particular care since it is heatproof, scratchproof and
stainproof. INSTALLATION INSTRUCTIONS

PG 12Please read the corresponding content in the instruction manual for detailed operating method.
USING THE DISHWASHER5
2Removing the larger residue on the cutlery3
4Filling the dispenserInside
Loading the basketsSelecting a program and running the dishwasherOutside
1Install the dishwasher

PG 13USING THE DISHWASHERControl Panel12345678910Press this button to turn on your dishwasher, the screen lights up.Press this button to select the appropriate washing program, corresponding indicator will be lit.When you have about or less than 6 place setting dishware to wash, you can choose this function to save energy and water. (It can only be used with Intensive, Normal, ECO, Glass and 90 min.)Operation (Button)This option allows you to lock the buttons on the control panel - except the Power button - so children cannot accidently star the dishwasher by pressingthe buttons on the panel.To lock or unlock the buttons on the control panel, press and hold the Half load button +Delay button for 3 seconds simultaneously.For better drying result.(It can only be used with Intensive, Normal, ECO, Glass, 90 min)To start the selected washing program or pause it when the dishwasher is working.PowerProgramExtra Drying124 Half loadPress this button to set the delay start time, the corresponding indicator will be lit.5 Delay6 Child lock37 Start/Pause

PG 14DisplayUSING THE DISHWASHERIntensiveHeavily soiled items include pots and pans. With dried on food.HeavyHeavily soiled loads, such as plates, glasses and lightly soiled
pots and pans.ECOThis is the standard program suitable for normally soiled loads, such as pots, plates, glasses and lightly soiled pans.GlassFor lightly soiled crockery and glass.90 minFor normally soiled loads that need quick wash. RapidA shorter wash for lightly soiled loads that do not need drying.Rinse Aid” indicator is lit, it means the dishwasher is If the “9 Warning indicator8 Program indicator10 Delay time indicatorTo show the delay time (3h/6h/9h)low on dishwasher rinse aid and requires a refill. Program endwhen the program is end, the indicator will be lit.

PG 15Function Of The Rinse Aid And DetergentThe rinse aid is released during the final rinse to prevent water from forming droplets on your
dishes, which can leave spots and streaks. It also improves drying by allowing water to roll o the
dishes. Your dishwasher is designed to use liquid rinse aids.
WarningOnly use branded rinse aid for dishwasher. Never fill the rinse aid dispense with any other
substances (e.g Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
When to refill the rinse aid dispenserUnless the rinse-aid warning light ( ) on the control panel is on, you can always estimate the
amount from the colour of the optical level indicator located next to the cap. When the rinse-aid
container is full, the indicator will be fully dark. The size of the dark dot decreases as the rinse-aid
diminishes. You should never let the rinse aid level be less than 1/4 full.
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator changes, as
illustrated below.
Function of detergentThe chemical ingredients that compose the detergent are necessary to remove, crush and
dispense all dirt out of the dishwasher. Most of the commercial quality detergents are suitable for
this purpose.
WARNING• Property Use of Detergent
Use only detergent specifically made for dishwashers use. Keep your detergent fresh and
dry.
Don’t put powdered detergent into the dispenser until you are ready to wash dishes.
• Dishwasher detergent is corrosive! Keep dishwasher detergent out of the reach
of children. USING THE DISHWASHER

PG 16USING THE DISHWASHERFilling The Rinse Aid Dispenser12Remove the rinse aid dispenser
cap by rotating it counterclockwise.
3Close the rinse aid dispenser cap
by rotating it clockwise.
Pour the rinse aid into the dispenser,
Adjusting the rinse aid dispenserThe rinse aid reservoir has six settings. Both the
recommended setting and the factory setting is “3”.
If the dishes are not drying properly or are spotted,
adjust the dial to the next higher number until your
dishes are spotfree.
Reduce it if there are sticky whitish stains on your
dishes or a bluish film on glassware or knife blades.
NOTE:Clean up any spilled rinse aid with an
absorbent cloth to avoid excessive foaming
during the next wash.
Rinse-Aid indicator

PG 17Note:• Be aware that depending on the soiling of water, setting may be dierent.
• Please observe the manufacturer’s recommendations on the detergent packaging.
USING THE DISHWASHERFilling The Detergent Dispenser1Press the release catch on the detergent dispenser to open the cover.Push latch to openAABAdd detergent into the larger cavity (A) for the main wash cycle.For more heavily soiled wash loads, also add somedetergent into the smaller cavity (B) for the pre-washcycle .3Close the cover and press on it until it locks into place.2

PG 18Basket Use TipsAdjusting the upper basketType 1:The height of the upper basket
can be easily adjusted to
accommodate taller dishes in
either the upper or lower basket.
Folding back the cup shelvesTo make room for taller items in the upper
basket, raise the cup rack upwards. You can
then lean the tall glasses against it. You can
also remove it when it is not required for
use.
Folding back the rack shelvesThe spikes of the lower basket are used for
holding plates and a platter. They can be
lowered to make more room for large items. USING THE DISHWASHER

PG 19• Consider buying utensils which are identified as dishwasher-proof.
• For particular items, select a program with the lowest possible temperature.
• To prevent damage, do not take glass and cutlery out of the dishwasher immediately after
the program has ended.
For washing the following cutlery/dishesAre not suitable• Cutlery with wooden, horn china or mother-of-pearl handles
• Plastic items that are not heat resistant
• Older cutlery with glued parts that are not temperature resistant
• Bonded cutlery items or dishes
• Pewter or copper items
• Crystal glass
• Steel items subject to rusting
• Wooden platters
• Items made from synthetic fibres
Are of limited suitability• Some types of glasses can become dull after a large number of washes
• Silver and aluminum parts have a tendency to discolour during washing
• Glazed patterns may fade if machine washed frequently
Recommendations for loading the dishwasherScrape o any large amounts of leftover food. Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow these loading guidelines.
(Features and appearance of baskets and cutlery baskets may vary from your model.)Place objects in the dishwasher in following way:
• Items such as cups, glasses, pots/pans, etc. are faced downwards.
• Curved items, or ones with recesses, should be loaded aslant so that water can run
•o.
• All utensils are stacked securely and can not tip over.
• All utensils are placed in the way that the spray arms can rotate freely during washing.
USING THE DISHWASHER

PG 20• Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so
that water cannot collect in the container or a deep base.
• Dishes and items of cutlery must not lie inside one another, or cover each other.
• To avoid damage, glasses should not touch one another.
• The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coee and tea cups.
• Long bladed knives stored in an upright position are a potential hazard!
• Long and / or sharp items of cutlery such as carving knives must be positioned horizontally
in the upper basket.
• Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Note:Very small items should not be washed in the dishwasher as they could easily fall out of the
basket.
Removing the dishesTo prevent water dripping from the upper basket into the lower basket, we recommend that
you empty the lower basket first, followed by the upper basket.
WARNINGItems will be hot! To prevent damage, do not take glass and cutlery out of the dishwasher for
around 15 minutes after the program has ended. USING THE DISHWASHER
