Technology & Calibration Inc. TechCal User manual

Owner’s Manual
Technology & Calibration, Inc. - Houston, Texas
www.techcal.com

Operating Instructions
1) Thoroughly check instrument at the time of unpacking to inspect for any damage that
may have occurred during shipment.
2) Mount the unit as level as possible.
3) Make sure the recorder is secure.
4) Select the desired rotation speed on the chart drive.
5) Install chart by unlocking the chart hub.
6) Raise the Pen Lifter.
7) Slide the chart paper between the pens and the chart plate securing it in the tabs.
8) Lock the Hub and lower the Pen Lifter.
9) Verify that the pen (s) are in in contact with the chart paper and have sufficient ink.
10)Apply zero pressure and adjust the pen for chart zero.
11)Turn on the pressure to the unit.
12)Upon completion of test, turn off the Pressure.
13)Turn off the Chart Drive.
14)Lift pen (s) from Chart Paper.
15)Replace Pen covers to keep pens from drying out.
* If the recorder is suspected to be out of tolerance or not reading correctly please
contact an authorized repair facility or the manufacture for repair and/or recalibration.
* Each Tech Cal Recorder is supplied with NIST Traceable Certifications. It is required
that occasionally the recorder be recalibrated to ensure it accuracy.
General Specifications:
Case Polyethylene Copolymer, Chemical Resistant, Light Weight & Durable
Temperature Range: -10°F to 210°F
Window Lexan, Polypropylene, Impact Resistant
Chart Drive ‘C’ Battery Operated, UL and cUL Listed For Hazardous Locations,
Temperature Range: -40°F to 160°F
Chart Size 12-inch Diameter (American Meter Style)
Chart Rotation 60 Min, 96 Min., 12 HR, 1,2,7,8,14,16,31 & 32 Day
Number of Pens 1-3 (one for each element)
Pen Style Disposable, Clip-On
Element Type Pressure-Helical (bourdon), Stainless Steel
Temperature-Helical (bourdon) Class V Mercury Filled
Range Pressure 0 thru 30,000 PSI,
Temperature 0 - 250 Deg. F
Accuracy +/- .5% of Full Scale

Item Part # Description
14P143 Foot
24P136 Pen Lifter Assembly
34P113 Soft Grip Top Handle
44P131 Case Connector, 1/4” NPTF
54P121 Pen Mount Assembly
6.1 4P101 500 PSI Static Pressure Element
6.2 4P102 1K PSI Static Pressure Element
6.3 4P103 2K PSI Static Pressure Element
6.4 4P104 3K PSI Static Pressure Element
6.5 4P105 5K PSI Static Pressure Element
6.6 4P106 10K PSI Static Pressure Element
6.7 4P107 15K PSI Static Pressure Element
6.8 4P108 20K PSI Static Pressure Element
6.9 4P109 25K PSI Static Pressure Element
6.10 4P110 30K PSI Static Pressure Element
7.1 4P140 1st From Chart, Blue
7.2 4P141 2nd From Chart, Red
7.3 4P142 3rd From Chart, Green
84P801 Link Assembly
94P127 Pen Arm, Long Slot
10 4P139 Riser, Chart Plate
11 4P137 Riser, Temp. System
12 4P138 Riser, Chart Drive
Item Part # Description
13 4P130 Hub, G190
14 4P125 Pen Shaft Arm Assembly, 90 Deg
15 4P135 Range Adjustment Arm
16.1 4P122 1st From Chart, Shaft Assembly.
16.2 4P123 2nd From Chart, Shaft Assembly.
16.3 4P124 3rd From Chart, Shaft Assembly.
17 4P128 Chart Plate
18 4P120 Back Plate
19 4P144 Lexan Window
20 4P161 Ambient Temp. Sys., 0-150 Deg.F
21.1 4P111 0-150Deg F, Temp. Sys. /10’ Armor Cap
21.2 4P112 0-200Deg F, Temp. Sys. /10’ Armor Cap
21.3 4P164 50-250Deg F, Temp. Sys./10’ Armor Cap
22 4P163 Pen / Battery Holder
23.1 4P116 Black Case
23.2 4P117 Orange Case
23.3 4P118 Yellow Case
23.4 4P119 Silver Case
24 4P129 Chart Drive, Sonceboz 0820
25 4P158 Pipe Mount, 2” Slip-On
Not Shown 4P165 Spool, Temp. Cable
Not Shown 4P166 Panel Mount Brackets
Not Shown 4P167 Lower Connection Plate
Parts List

Warranty
Tech Cal Recorders are warranted against defective mate-
rials or workmanship for 12 months following the date of
shipment. Technology & Calibration, Inc.’s liability is lim-
ited to repair or replacement at the factory. No obliga-
tion can be assumed for recorders subjected to mis-
use or unauthorized repairs.
Manufactured By:
Technology & Calibration, Inc.
Houston, Texas
888-546-6506 Toll Free
www.techcal.com
© 2007 Technology & Calibration, Inc.
ISO 9001 Cered
