TECHOME TV LIFT (TVL3)
QUICK INSTALLATION AND
INSTRUCTION
MANUAL
www.techome.com.au
inf[email protected] | [phone]
3
DELETING THE MAX/MIN HEIGHT LIMITS
1. Adjust the TV Lift height to the
desired max or min height you wish
to delete. Using ‘UP’ or ‘DOWN’.
3. Hold ‘UP’ (For Max) or ‘DOWN’
(For Min) on the Switch Box for 3 seconds
until you hear a continuous beep.
2. Flick the ‘SET’ switch to the right
on the Switch Box.
4. Return the ‘SET’ button back to
the left again to regain control of
the TV Lift.
OR
3 sec
SETTING A MEMORIZED HEIGHT
1. Adjust the TV Lift height to the
desired height. Using any remote.
3. Pressing the ‘M’ button will now set
the TV Lift to the memorized height.
2. Press and hold the ‘M’ button
on the RF Remote until you hear
three (3) beeps.
OR

PAIRING THE RF REMOTE
INSTALLING THE CONTROL BOX
1 2
1. Flick the ‘SET’ switch to the right
on the Switch Box.
2. The Control Box will beep 3 times.
Followed by 7 seconds of silence and then
continuous beeping.
3. During the continuous beeping,
press any button on the RF Remote.
4. Return the ‘SET’ button back to
the left again to regain control of
the TV Lift.
7 sec
Silence
SETTING THE MINIMUM HEIGHT LIMIT
1. Adjust the TV Lift height to the
desired MINIMUM height.
3. Hold ‘DOWN’ on the Switch Box
until you hear two consecutive
beeps, indicating successful setting.
2. Flick the ‘SET’ switch to the right
on the Switch Box.
4. Return the ‘SET’ button back to
the left again to regain control of
the TV Lift.
OR
SETTING THE MAXIMUM HEIGHT LIMIT
1. Adjust the TV Lift height to the
desired MAXIMUM height.
3. Hold ‘UP’ on the Switch Box
until you hear two consecutive
beeps, indicating successful setting.
2. Flick the ‘SET’ switch to the right
on the Switch Box.
4. Return the ‘SET’ button back to
the left again to regain control of
the TV Lift.
OR
Switch Box IR Receiver
Control Box: TC11
Junction Box/Remote Receiver
TVL3
