Techone DLG-1000 User manual

1.Wing 2.Stabilizer 3.Canopy Cover 4.Fuselage and rudder
1.Vertical tail pushrod
2.Elevator tail pushrod
3.Wing pushrod
4.fixed carbon rod
5.The screw of canopy cover
6.Wing Fixed screw
7.Elevator fixed screw
8.Y harness
1.Elevator and the relevant screw 2.Install elevator on plastic plat of fuselage
with screw by screwdriver.
Fuselage length: 995mm (39.2 in.)
Wingspan: 812mm (32 in.)
Flying Weight: 189--199g (with battery)
UBEC: 3 Amp
Servo: 3.7g micro servo * 4pcs
Radio: 4/more channel
Battery: 2S 250-400mAh
DLG-1000 DLG-1000
Item no.: 0880009
1.Easy installation,there is nothing but only need to install the vertical wing fences.
2.The spinner part and gripper have been used the perfect anti-resistance design.
3.The good and safe design of servo location.
4.Good thermal dissipation design for the fuselage and motor.
5.The canopy use plastic clip design,it’s easy to destuffing and the battery equipment,
etc are not easy to throw away.
DLG-1000 DLG-1000
3.Elevator Wire length 90MM, 3.7G
Servo and accessories.
4.Insert and screw the servo into the slot
on fuselage by screwdriver. 5.Elevator tail pushrod
6.Cross the pushrod into carbon tail rod and install it on the adjuster and elevator
servo horn, then fixed with screw, and make sure to keep the rudder in the same
horizontal line.
7.Elevator Wire Length 80MM,3.7g servo and
accessories
8.Put the servo into the slot on fuselage,and fixed with screw.
9.Rudder pushrod
10.Cross the pushrod into carbon tail rod of fuselage and install it on the adjuster
and rudder servo horn, then fixed with screw,and make sure to keep the rudder
in the same horizontal line.
11.Aileron servo wire length 330mm, 3.7g
servo and accessories
12.Screw the left and right servo arm
by screwdriver
DLG-1000 DLG-1000
13.Glue the aileron servo 14.Seal the routing place with transparent
tape.
15.Aileron pushrod 16.Connect the servo to aileron pushrod
and fixed with screw by screwdriver.
17.Aileron connection as picture. 18.Cross the aileron servo into the routing
hole of fuselage.
19.Wing fixed screw 20.Tighten the screw by screwdriver after
wing installed
21.Y Harness 22.Connect the aileron servo wire to
Y harness
23.Receiver 24.Insert all servo wires into the receiver
25.3A UBEC
26.Connect the receiver to the UBEC 27.Place in order after the equipment
connection
DLG-1000 DLG-1000
28.Lipo battery 2S 350MAH
29.Lock the plastic canopy cover with screw after the equipment connection
30.Throwing carbon rod
31.Reserve two mounting holes on left and right
wing tip, consumers can choose the suitable
hole they think, then bond with glue
32.The suggested installing way for your reference.
DLG-1000 DLG-1000
Item No.088701-Wingspan
Item No.088704-Fuselage
Item No.088703-Horizontal stabilizer
Item No.088702-Vertical stabilizer
Item No.088710-3A UBEC
Item No.088711-350mah 7.4V lipo20c Battery
DLG-1000 DLG-1000
Item No.088707-3.7g Servo 220mm
Item No.088708-3.7g Servo 90mm
Item No.088709-3.7g Servo 80mm
Item No.088706-PP decal
Item No.088705-Accessory pack
