Techsis SE-4048 User manual
SE-4048
Version 1.0
May 2021
User Manual
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page2
Introduction to the installation manual
The Product User's Manual mainly introduces the software and hardware parameters, installation
methods, and precautions during the installation process of the SE-4048 switch.
This manual includes the following sections:
Chapter 1
Product introduction
• Briefly describe the basic functions and features of the switch
• detailed hardware and software specifications
• appearance information.
Chapter 2
•Hardware Connections
• Guide the connection and precautions between the switch and other devices.
Chapter 3
•Product Installation
• Guide the hardware installation method and precautions of the switch.
Chapter 4
•Product Packaging
•Use Recommendations
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page3
Chapter 1 Product Introduction
1.1 Product Introduction
The SE-4048 adopts a new generation of high-performance hardware and software platform to provide
flexible and cost-effective full Gigabit access and uplink ports. It supports Layer 3 routing protocols,
complete security protection mechanisms, and complete ACL/QoS policies and enrichment. The
VLAN function is easy to manage and maintain. It meets the user's easy-to-manage, high-security, and
low-cost networking requirements for network devices. It is suitable for network access, aggregation,
and core application scenarios in campus, hotel, and enterprise campus.
1. 2 Product Features
Full Gigabit Ethernet port
48 full Gigabit RJ45 network ports, and 4 10 Gigabit SFP fiber ports, breaking the traditional 100
mega bit limit, data transmission is not stuck
Broadcom high-end chip, performance is more stable and powerful
Broadcom high-end chip can greatly improve network data processing rate
Support DHCP
Support DHCP server, DHCP relay, DHCP Snooping
Support Apollo cloud platform one-stop management
Support cloud platform to visualize management of switches and PDs connected to the PD, making
operation and maintenance management easier
1.3 Product Software and Hardware Specifications
Hardware Features
Port
•48 10/100/1000Mbps RJ45 ports
•410G SFP+ fiber ports
•1 RJ45 Console port
•1 Mini-USB Console port
Performance
•Forward mode: store and forward
•Backplane bandwidth: 176 Gbps
•Packet forwarding rate: 131 Mpps
•Support 16 K MAC address table depth
Chip
•Broadcom high performance chip
Flash
•16MB
RAM
•256 MB DDR
Lightning protection
•±6KV
ESD
•Contact: ±6K Vair : ±8K V
Input power
•100-240V/50-60Hz
Dimensions (L × W × H)
•440mm × 365 mm × 44mm
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page4
Software Features
Basical Functions
•Support hardware watchdog, restore factory
Settings, system and port LED
•Support global information, statistics, log
information
•Support user management, alarm
management, configuration management
•Support port rate, duplex, flow control,
maximum frame length configuration
•Support port mirroring, port speed limit, port
energy saving
Apollo Cloud one stop management
•prevention in advance; Real-time map, fast
fault location; Cloud operation,
maintenance, configuration, upgrade batch
processing; Multi-user, multi-dimensional
authority, hierarchical control; AI blessing,
intelligent scheduling; Business analysis and
decision making; Open interface, customer
business import; Support for automatic
identification, management and acquisition
of information about the downlink device
Layer 3 interface
•Support Layer 3 interface
•Support IPv4/IPv6 Address configuration
•Support ARP configuration
•Support ND configuration
routing
•Support RIP V1/V2
•Support OSPFv1/OSPFv2 dynamic routing
•Support static routing
DHCP
•Support DHCP server
•Support DHCP relay
•Support DHCP Snooping
IPv6
•Support IPv6 Ping, IPv6 Tracert, IPv6 Telnet
•Support IPv6 SSH, IPv6 SSL
Protocol standard
•IEEE 802.3: Ethernet media access
control (MAC) protocol
•IEEE 802.3i:10BASE-T Ethernet
•IEEE 802.3u:100BASE-TX Fast
Ethernet
•IEEE 802.3ab:1000BASE-T Gigabit
Ethernet
•IEEE 802.3z:1000BASE-X Gigabit
Ethernet (Fiber）
•IEEE 802.3ad: Standard method for
performing link aggregation
•IEEE 802.3x: traffic control
•IEEE 802.1p: LAN layer 2 QoS/Cos
protocol on traffic priority (multicast
filtering function)
•IEEE 802.1q: VLAN Bridge operation
•IEEE 802.1d:STP spanning tree
•IEEE 802.1s: MSTP Multiple spanning
tree
•IEEE 802.1w: RSTP Fast spanning tree
•IEEE 802.1x: Access control and
authentication
•G.8032: ERPS Ethernet loop protection
switch
VLAN
•Support 4k numbers of VLAN
•Support 802.1Q VLAN, MAC VLAN, IP
VLAN
•Voice VLAN
Spanning tree
•Supports STP (IEEE 802.1d), RSTP
(IEEE 802.1w) and MSTP (IEEE 802.1s)
protocols
•Support loop protection,
•Support root bridge protection, TC
protection
•Support BPDU protection, BPDU
filtering
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page5
MAC address table
•Follow the IEEE 802.1d standard
•Support MAC address automatic learning
and aging
•Support static, dynamic, filtering address
table
Safety features
•Password protection
•Support user access based on port number,
IP address, and MAC address
•Support HTTPS, SSL V3, TLS V1, SSH
V1/V2
•Support IP-MAC-PORT ternary binding
•Support ARP protection, IP source
protection, DoS protection
•Support DHCP Snooping and DHCP attack
protection
•Support 802.1X authentication, AAA
•Support port security, port isolation
•Support CPU protection
Quality of Service (QoS)
•Support port priority, 802.1P priority, DSCP
priority
•Support SP, WRR, W FQ priority
scheduling algorithm
•Supports automatic identification,
management, and retrieval of information
about attached devices
Storm resist
•Support multicast resist
•Support broadcast resist
•Support for unknown unicast resist
Multicast
•Support IGMP v1/v2 Snooping
•Support fast leave mechanism
•Support for multicast VLAN
•Supports multicast filtering, packet
statistics, and unknown multicast discards.
Link aggregation
•Support static aggregation
•Support dynamic aggregation
•Support IP, MAC, hybrid load balancing
mode
•Supports up to 32 aggregation groups
Management and maintenance
•Support WEB network management
(HTTP, HTTPS, SSL V3)
•Support CLI (Telnet, SSH V1/V2, local
serial port)
•Support for SNMP V1/V2/V3
•Support LLDP, RMON
•Support ARP protection, IP source
protection, DoS protection
•Support CPU monitoring
•Support memory monitoring
•Support Apollo cloud platform one-stop
management and maintenance
•Support system log, grading warning
•Support Ping, Tracert detection, cable
detection
Access control (ACL)
•Support L2 (Layer 2) ~ L4 (Layer 4) packet
filtering
•Support port mirroring, port redirection,
flow rate limiting, QoS re-marking
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page6
1.4 Product appearance
Front panel
Contains indicator light, RJ45 port as shown below
Indicator light
The working information of the SE-4048 indicator is as shown in the following table.
Indicator light
Indicator light
instruction
normal status
Abnormal and trouble shooting
PWR Indicator
light
Power
Indicator light
Yellow light
lighting
If the light does not illuminate, check if
the power supply of the external power
outlet is normal, and the power adapter
is connected correctly.
Link Indicator
light
Connection
Indicator light
Yellow light
lighting
If the indicator is not light, check
whether the corresponding network
port is connected to the network device,
the network cable is connected
correctly, the network cable meets the
standard (the maximum transmission
distance of Category 5 is 100 meters),
whether the network cable is damaged,
and whether the network device is
damaged.
SYS Indicator
light
System
Indicator light
Green light
flashing
If the light is off, the device does not
start normally, please restart after
power off.
10GIndicator
light (XG1-
XG4)
Connection
indication
Green light
lighting
If the indicator is not light, check
whether the corresponding interface is
connected to the network device, the
optical module is damaged, and the
network device is damaged.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page7
❖RJ45ports
The SE-4048 supports 48 10/100/1000Mbps adaptive RJ45 ports.
Rear panel
❖Includes: power outlet, power switch, ground terminal
SFP port
The SE-4048 provides four 10 Gigabit SFP optical module expansion slots for
plugging into Gigabit SFP modules.
Console port
The Console port is used to connect to the serial port of a computer or other terminal to
manage or configure the switch.
Power socket
The power supply to the switch SE-4048 must be 100-240V~ 50/60Hz AC power.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page8
Chapter 2 Hardware Connection
2.1 Connecting RJ45 port
Connect the switch and the RJ45 port of the peer network device with a network cable.
2.2 Connecting SFP Ports
The SFP port of the SE-4048 supports only 10 Gigabit fiber modules. It is recommended
to use standard SFP module products.
The process of installing a fiber module on a switch is as follows:
1. Grasp the fiber module from the side and insert it smoothly along the SFP port slot
of the switch until the fiber module is in close contact with the switch;
2. Confirm the Rx and Tx ports of the fiber module when connecting. Insert one end
of the fiber into the Rx and Tx ports to ensure that the Tx and Rx ends of the
interface are correctly connected, and the other end of the fiber is connected to
another device.
3. After power-on, check the status of the corresponding indicator. If the indicator is
on, the link is up. If the indicator is off, the link is down. Check the line and
confirm that the peer device is enabled.
Note:
It is not allowed to excessively bend the fiber, and its radius of curvature should be no less
than 10cm;
Ensure the cleanliness of the fiber end face;
Please do not look directly into the fiber optic connector with your eyes, as this may cause eye
damage.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page9
2.3 Check before power-on
Check that the power supply of the power outlet meets the switch specifications.
Check that the power supply, switch, and rack are properly grounded.
Check whether the switch is connected to other network devices.
2.4 device initialization
The switch will automatically initialize after the power is turned on and the power switch is turned
on.
The indicator light will appear as follows:
1. After the power is turned on, the power indicator remains steady. When SYS enters the
flashing state, the system runs normally.
2. The indicator of each port indicates the connection status of each port, indicating that the
switch has started to work normally.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page10
Chapter 3: Product Installation
3.1Installation Precautions
Note: To avoid damage to the equipment and personal injury caused by improper use,
please observe the following precautions.
safety precautions
❖power supply remains off during the installation process. Wear an ESD-preventive wrist strap
and ensure that the ESD-preventive wrist strap is in good contact with the skin to avoid
potential safety hazards.
❖Switch only can work normally under the correct power supply. Please confirm that the
power supply voltage matches the voltage indicated by the switch.
❖Before powering on the switch, please make sure that the power circuit is not overloaded, so
as not to affect the normal operation of the switch and cause unnecessary damage.
❖To avoid the risk of electric shock, do not open the case while the switch is working, even if
it is not charged, do not open it yourself;
❖Before cleaning the switch, first pull out the power plug of the switch. Do not wipe with a
moist fabric. Do not use liquid to clean.
humidity
In order to ensure long-term stable operation of the switch and prolong its service life, please
maintain a certain temperature and humidity in the environment. Too high or too low ambient
humidity is likely to cause leakage, deformation and even corrosion of metal parts. If the temperature
is too high, the aging process of the insulation material will be accelerated, which will seriously
affect the service life of the equipment. The normal operation and storage temperature / humidity
of this series of switches are as follows:
Environmental description
temperature
Relative humidity
Working Temperature
0℃~40℃
10%～90% RH Non-condensing
Storage Temperature
-40℃～70℃
5%～90% RH Non-condensing
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page11
elevation
Products with this mark are only suitable for safe use in areas below 2000m above sea level.
dustproof
Dust falling on the surface of the switch can cause electrostatic adsorption and poor contact of the
metal contacts. Although the device itself has made certain measures in anti-static, when the static
electricity exceeds a certain intensity, it will still cause fatal damage to the electronic components on
the internal circuit board. To avoid the static electricity affecting the normal operation of the device,
please pay attention to the following:
1. Regular dust removal to keep indoor air clean;
2. Make sure that the equipment is well grounded to ensure the smooth transfer of static
electricity.
interference
Electromagnetic interference will affect the electronic components such as capacitors and inductors
inside the device by means of capacitive coupling, inductive coupling, impedance coupling, etc. To
reduce the adverse effects caused by electromagnetic interference, please pay attention to the
following:
1. The power supply system takes necessary measures against grid interference;
2. The switch should be away from high-frequency, high-power, high-current equipment, such
as wireless transmitters;
3. Take electromagnetic shielding measures when necessary.
lightning protection needs
When a lightning strike occurs, a strong current is generated in an instant, and the air in the discharge
path is instantaneously heated to 20,000 degrees Celsius, and an instantaneous large current is
enough to cause fatal damage to the electronic device. For better lightning protection, please note the
following:
1. Confirm that the rack is in good contact with the ground;
2. Make sure the power outlet is in good contact with the ground;
3. Reasonable wiring to avoid internal induction lightning;
4. When using outdoor wiring, it is recommended to use a signal lightning arrester.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page12
Installation rack requirements
Regardless of whether the switch is installed in a rack or other horizontal workbench, please note the
following:
1. Verify that the rack or table is stable, strong, and capable of withstanding a weight of at
least 5.5 kg;
2. Confirm that the rack itself has a good cooling system, or keep the room well ventilated;
3. Make sure the rack is well grounded, and the distance between the power socket and the
switch is less than 1.5 meters.
tool preparation
The Phillips screwdriver, electrostatic wrist strap, and cable fiber may be used during installation.
3.2 Product Installation
19inch standard rack mount
The SE-4048-P300 is designed to fit the standard 19-inch rack and can be easily mounted to the rack.
The specific installation steps are as follows:
1. Check the grounding and stability of the rack;
2. Install the two L-shaped brackets in the accessories on both sides of the switch panel and fix
them with the screws provided in the accessories.
3. Place the switch in the proper position in the rack and support it by the bracket. Fix the L-
bracket to the guide groove fixed at both ends of the rack with screws to ensure that the
switch is installed on the rack stably and horizontally.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page13
Note:
Good grounding of the rack is an important guarantee for anti-static, anti-leakage, lightning
protection and anti-interference of the equipment. Therefore, ensure that the grounding wire of the
rack is properly installed.
The equipment installed in the rack is generally from bottom to top to avoid overload installation;
Avoid placing other heavy objects on the surface of the switch to avoid accidents;
Ensure heat dissipation and air circulation.
3.3 login management interface
Step1: Connect the sw to the computer
Step 2: Change the computer IP to 192.168.254.X (2~254), and the Subnet mask is 255.255.255.0
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page14
Step3: Turn on the browser, input 192.168.254.1, and click Enter
Step4: Enter the web manage UI, Input the Username and PW, both are admin and log in
Step5: You already entered the web management UI of the switch and can start to configure the
switch
.
SE-4048
Tel:021-22371482 , Fax:021-66402031
Page15
Chapter 4: packing list and recommendations for use
4.1Open the package and check the list below.
Objects
Quantity
Remark
Switch
1 pc
\
Power cable
1 pc
Support power to SW
Hook
2 pcs
To installation
Warranty Card
1 pc
To After sale service
Manual
1 pc
To guide the user
4.2 Suggestions
1. For safety reasons, non-professionals should not open the product case；
2. Pay attention to the danger of strong electricity and safe protection when the
product is powered on；
3. Please select the correct power adapter to supply power to the switch. Confirm
whether it meets the switch requirements before use；
4. Do not use the switch in a humid environment to prevent water from entering the
fuselage through the casing, resulting in damage to the machine.；
5. Please turn on the power after the line connection is completed ；
6. When the product is powered on, please do not plug and unplug the cable if it is not
special.；
7. Do not use the switch in places with excessive dust and electromagnetic r adiation.
Do not use the switch in a place that is hot and not ventilated. ；
8. Please do not place heavy objects on the switch to avoid accidents. ；
9. It is recommended to use the switch indoors. It is recommended to add a
waterproof box when using it outdoors.
Note: The pictures in the manual are for reference only, whichever is subject to the actual
prod
Table of contents
