Techwood 22742 User manual

OPERATING INSTRUCTIONS

22742 Full HD 1080P DVD

C O L O U R T E L E V I S I O N W I T H R E M O T E C O N T R O L

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER

PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

English - 1 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Contents

Media Browser.................................................. 19

Playing MP3 Files............................................. 19

Viewing JPG Files............................................. 20

Slideshow Options............................................ 20

Video Playback ................................................. 20

Analogue TV Menu System.................................. 20

Picture Menu..................................................... 20

Sound Menu ..................................................... 21

Feature Menu ................................................... 22

Source Menu .................................................... 22

Install Menu ...................................................... 23

Program Table .................................................. 23

PC-VGA Mode Menu System............................... 24

PC-VGA Position Menu .................................... 24

Phase................................................................ 24

Displaying TV Information .................................... 25

Mute Function....................................................... 25

Picture Mode Selection......................................... 25

Zoom Modes......................................................... 25

Auto .................................................................. 25

16:9................................................................... 25

4:3..................................................................... 25

Teletext ................................................................. 26

Tips....................................................................... 26

Image Persistence ............................................ 26

No Power .......................................................... 26

Poor Picture ...................................................... 26

No Picture ......................................................... 26

Sound ............................................................... 26

Remote Control................................................. 26

Input Sources.................................................... 26

Appendix A: PC Input Typical Display Modes....... 27

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types)........................ 28

Appendix C: Supported File Formats

for USB Mode....................................................... 29

Speciﬁcations ....................................................... 30

Important Instruction............................................. 31

Package Contents .................................................. 2

Features ................................................................. 2

Introduction............................................................. 2

Preparation............................................................. 3

Safety Precautions ................................................. 3

Moisture and Water ............................................ 3

Cleaning.............................................................. 3

Ventilation ........................................................... 3

Heat and Flames ................................................ 3

Lightning ............................................................. 3

Replacement Parts ............................................. 3

Servicing............................................................. 3

Waste Disposal................................................... 3

Information for Users in European

Union Countries .................................................. 4

Disconnecting the Device ................................... 4

Headphone Volume ............................................ 4

Installation........................................................... 4

LCD Screen ........................................................ 4

Warning .............................................................. 4

Connection to a Television Distribution

System (Cable TV etc.) from Tuner .................... 4

Overview of the Remote Control ............................ 5

LCD TV and Operating Buttons.............................. 6

Viewing the Connections- Back Connectors .......... 6

Viewing the Connections - Side Connectors .......... 7

Power Connection .................................................. 7

Aerial Connection ................................................... 7

Connecting the LCD TV to a PC............................. 8

Using Side USB Input............................................. 8

USB Memory Connection ................................... 8

Connecting to a DVD Player................................... 9

Using Side AV Connectors ..................................... 9

Connecting Other Equipment via Scart .................. 9

Inserting Batteries into the Remote Control.......... 10

Switching the TV On/Off ....................................... 10

Input Selection...................................................... 10

Basic Operations .................................................. 10

Operation with the Buttons of the TV................ 10

Operation with the Remote Control .................. 10

Initial Settings ........................................................11

General Operation.................................................11

Electronic Programme Guide (EPG) .................... 12

Displaying Subtitles .......................................... 12

Digital Teletext (** for UK only) ......................... 12

Analogue Teletext ............................................. 12

Widescreen....................................................... 12

IDTV Menu System .............................................. 13

Channel List...................................................... 13

Timers............................................................... 15

Conditional Access ........................................... 15

TV Setup........................................................... 15

Setup ................................................................ 15

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 101_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 1 03.12.2010 16:21:4203.12.2010 16:21:42

English - 2 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Package Contents

INFO

EPG

FAV

PRESETS

SUBTITLE

RETURN

SOURCE

SLEEP SCREEN

LANG.

Remote

Control

LCD TV

Batteries: 2 X AAA

Instruction Book

Note: You should check the accessories after purchasing.

Make sure that each accessory is included.

Features

• Remote controlled colour LCD TV.

• Fully integrated digital TV (DVB-T).

• HDMI connectors for digital video and audio. This

connection is also designed to accept high deﬁnition

signals.

• 200 programmes from VHF, UHF(analogue).

• 500 programmes for digital mode (IDTV).

• OSD menu system.

• Scart socket for external devices (such as video,

video games, audio set, etc.).

• Stereo sound system.

• 10 page Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward manual tuning.

• Sleep timer.

• Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• AVL (Automatic Volume Limiting).

• When no valid signal is detected, after 5 minutes the

TV switches automatically to standby mode.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, Windows 7, ME, 2000,

XP, Vista.

• Game Mode

Introduction

Thank you for choosing this product. This manual will

guide you for the proper operation of your

TV. Before operating the TV, please read

this manual thoroughly.

Please do keep this manual in a safe place

for future references.

This device is intended to receive and display TV

programs. The different connection options make

an additional expansion of the reception and display

sources possible (receiver, DVD player, DVD

recorder,VCR, PC etc.). This device is only suitable

for the operation in dry interiors.

This appliance is intended solely for private domestic

use and may not be used for industrial and commercial

purposes. We exclude liability in principle, if the device

is not used as intended, or unauthorized modiﬁcations

have been made. To operate your LCD-TV in extreme

ambient conditions may cause the damage of the

device.

Please read the corresponding instructions of

this handbook prior to the first usage of the

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 201_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 2 03.12.2010 16:21:4303.12.2010 16:21:43

English - 3 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

If any solid object or liquid falls into the cabinet, unplug

the TV and have it checked by qualiﬁed personnel

before operating it any further.

Cleaning

Before cleaning, unplug the TV set from

the wall outlet. Do not use liquid or aerosol

cleaners. Use soft and dry cloth.

Ventilation

The slots and openings on the TV set are intended for

ventilation and to ensure reliable operation. To prevent

overheating, these openings must not be blocked or

covered in anyway.

Heat and Flames

The set should not be placed near to open

ﬂames and sources of intense heat such

as an electric heater. Ensure that no open

ﬂame sources, such as lighted candles,

are placed on top of the TV. Batteries

should not be exposed to excessive heat

such as sunshine, ﬁre or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that

the service technician has used replacement parts,

which are speciﬁed by the manufacturer or have the

same speciﬁcations as the original one. Unauthorized

substitutions may result in ﬁre, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualified

personnel. Do not remove the cover

yourself as this may result in an electric

shock.

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and

should principally be recycled. Packaging materials,

such as foil bag, must be kept away from children.

• Batteries, including those which are heavy metal-

free, should not be disposed of with household

waste. Please dispose of used battery in an

environment friendly manner. Find out about the

legal regulations which apply in your area. Don’t try

to recharge batteries. Danger of explosion. Replace

batteries only with the same or equivalent type.

device, even when the usage of electronic devices is

familiar to you. Notice especially the chapter SAFETY

PRECAUTIONS. Carefully keep the handbook as

future reference. When selling the device or giving it

away, absolutely give these direction for use.

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top

of the set.

Use this device in moderate climates.

10 cm

Safety Precautions

Read the following recommended safety

precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220-240V

AC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the

power cord by the plug. Do not unplug the appliance

by pulling from the power cord and never touch the

power cord with wet hands as this could cause a short

circuit or electric shock. Never make a knot in the cord

or tie it with other cords. The power cords should be

placed in such a way that they are not likely to be

stepped on. A damaged power cord can cause ﬁre or

give you an electric shock. When it is damaged and

needs to be replaced, it should be done by qualiﬁed

personnel.

Moisture and Water

Do not use this device in a humid and

damp place (avoid the bathroom, the

sink in the kitchen, and near the washing

machine). Do not expose this device to

rain or water, as this may be dangerous

and do not place objects ﬁlled with liquids,

such as ﬂower vases, on top. Avoid from

dripping or splashing.

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 301_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 3 03.12.2010 16:21:4403.12.2010 16:21:44

English - 4 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

• Cold cathode fluorescent lamp in LCD PANEL

contains a small amount of mercury;

please follow the local laws or

regulations for disposal.

Information for Users in

European Union Countries

This symbol on the product or on its

packaging means that your electrical

and electronic device should be

disposed at the end of its service life separately from

your household wastes. There are separate collection

systems for recycling in EU.

For more information, please contact the local

authority or the dealer where you purchased the

product.

Disconnecting the Device

The mains plug is used to disconnect TV set from

the mains and therefore it must remain readily

operable.

Headphone Volume

Excessive sound pressure from earphones

and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the installation

instructions when mounted to the wall (if the option

is available).

LCD Screen

The LCD panel is a very high technology product with

about a million thin ﬁlm transistors, giving you ﬁne

picture details. Occasionally, a few non-active pixels

may appear on the screen as a ﬁxed blue, green or

red point. Please note that this does not affect the

performance of your product.

Warning

Do not leave your TV in standby or operating mode

when you leave your house.

Connection to a Television

Distribution System (Cable TV etc.)

from Tuner

Device connected to the protective earthing of the

building installation through the mains connection or

through other apparatus with a connection to protective

earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a

ﬁre hazard.

Connection to a cable distribution system has

therefore to be provided through a device providing

electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

The Standby / On button doesn´t separate this

device completely from mains. Moreover the device

consumes power in the standby operation. In order to

separate the device completely from mains, the mains

plug has to be pulled from the mains socket. Because

of that the device should be set up in a way, that an

unobstructed access to mains socket is guaranteed,

so that in case of emergency the mains plug can be

pulled immediately. To exclude the danger of ﬁre, the

power cord should principally be separated from the

mains socket prior to a longer period of non-usage,

i.e. during vacations.

Electrical device not in the hands of

children

Never let children use electrical device

unsupervised.

Children can´t always recognize properly the possible

dangers.

Batteries / accumulators can be life threatening when

swallowed. Store batteries unreachable for small

children. In case of swallowing a battery medical

aid has to be sought immediately. Also keep the

packaging foils away from children. There is danger

of suffocation.

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 401_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 4 03.12.2010 16:21:4503.12.2010 16:21:45

English - 5 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Overview of the Remote Control

Standby / On1.

Image size / Expand (in TXT mode)2.

Sleep timer3.

Numeric buttons4.

Return / Exit (in DTV mode) / Index page (in TXT5.

mode)

Cursor up / TXT up page6.

Cursor left7.

Programme up / Page down (in DTV mode)8.

Programme down / Page up (in DTV mode)9.

Mono-Stereo / Dual I-II / Current Language(in10.

DTV mode)

Swap11.

Electronic programme guide (in DTV mode)12.

Info / TXT reveal (in TXT mode)13.

Picture mode selection14.

Source selection15.

Red / Sound Menu / Channel List (in DTV mode)16.

(*)

Green / Picture Menu / Subtitle On-off (in DTV17.

mode) (*)

Yellow / Feature / Current language (in DTV18.

mode) (*)

Menu On-off19.

Blue / Install / Favourite mode (in DTV mode) (*)20.

OK / Select (analogue TV mode) / Hold (in TXT21.

mode) / Channel List (DTV mode)

Cursor right / Subpage (in TXT mode)22.

Cursor down / TXT Downpage23.

Volume up24.

Volume down25.

Mute26.

Teletext / Mix27.

Subtitle (in DTV mode) / TXT Subtitle (analague28.

TV mode)

FAV (*) (Favourite Selection)(in DTV mode)29.

Media Player buttons30.

(*) Only available for EU country options.

Note: Buttons that are not indicated with a

number on the remote control illustration are not

functional in TV mode.

Remote range is approximately 7m/23ft

INFO

EPG

FAV

PRESETS

SUBTITLE

RETURN

SOURCE

SLEEP SCREEN

LANG.

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 501_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 5 03.12.2010 16:21:4503.12.2010 16:21:45

English - 6 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

LCD TV and Operating Buttons

FRONT and REAR VIEW SIDE VIEW Control Buttons

Up button1.

Down button2.

Programme/Volume / AV3.

selection button

Standby / On button4.

Note:You can use “+/-” buttons to

change volume. If you want to change

channels, press P/V/AV button once

and then use “+/-” buttons. If you hold

the P/V/AV button about a few seconds,

source OSD will be displayed. Main

menu OSD cannot be displayed via

control buttons.

Viewing the Connections- Back Connectors

SCART socket inputs or outputs for external devices.1.

Connect the SCART cable between SCART socket on TV and SCART socket on your external device

(such as a VCR or a DVD player).

Note: If an external device is connected via the SCART socket,

the TV will automatically switch to AV mode.

PC Input is for connecting a personal computer to the TV set.2.

Connect the PC cable between the PC-VGA INPUT on the TV

and the PC output on your PC. Component Video Inputs (YpBPr)

are used for connecting component video.

You can use PC-VGA input to enable YPbPr signal connection

with a device that has component output. Connect the YPbPr to

PC cable between the PC INPUT on the TV and the component

video outputs of your device.

S/PDIF Coaxial Out3. outputs digital audio signals of the currently watched source. Dolby D Audio is

bypassed while in media browser mode only.

RF Input connects to an antenna or a cable system.4.

Note that if you use a media recorder, you should connect the aerial cable through the device to the

television with an appropriate antenna cable, as shown in the illustration in the following pages.

5. HDMI 1: HDMI 1 input

HDMI Input is for connecting a device that has an HDMI socket.

Your LCD Television is capable of displaying High Deﬁnition pictures from devices such as a High

Deﬁnition Satellite Receiver or DVD Player. These devices must be connected via the HDMI sockets

or Component Socket. These sockets can accept either 480i, 480p, 576p, 576i, 720p, 1080i, 1080p

signals. No sound connection is needed for an HDMI to HDMI connection

When you use the wall mount kit (optional) with the LCD TV, we would deﬁnitely recommend to plug all your cables into the

back of the LCD before mounting to the wall.

SPDIF

SCART

VGA

Coax.OUT

HDMI 1

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 601_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 6 03.12.2010 16:21:4603.12.2010 16:21:46

English - 7 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the1.

channels that you subscribe to. For more information, see “Conditional

Access” section

USB Input (functional in DTV mode only2.

Video Input is used for connecting video signals of external devices.Connect3.

the video cable between the VIDEO IN socket on the TV and the VIDEO OUT

jack on your device.

Audio Inputs are used for connecting audio signals of external devices.4.

Connect the audio cable between the AUDIO INPUTS on the TV and the

AUDIO OUTPUT jacks on your device.

Also to enable PC/YPbPr sound connection in such a case, use an

appropriate audio cable between the connected device’s audio outputs and

the TV’s audio inputs

Note: If you connect a device to the TV via the VIDEO or PC/YPbPr cable

you should also connect your device with an audio cable to the AUDIO

INPUTS of the TV to enable audio.

Headphone jack is used for connecting an external headphone to the system.5.

Connect to the HEADPHONE jack to use headphones.

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the

mains.

• Plug the power cable to the mains socket outlet.

Aerial Connection

• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

SPDIF

SCART

VGA

Coax.OUT

HDMI 1

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 701_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 7 03.12.2010 16:21:4703.12.2010 16:21:47

English - 8 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Connecting the LCD TV to a

For displaying your computer’s screen image on

your LCD TV, you can connect your computer to the

TV set.

• Power off both computer and display before making

any connections.

• Use 15-pin D-sub display cable to connect a PC

to the LCD TV. Use an audio cable between audio

inputs of the TV (side) and audio output of your PC

to enable sound connection.

• When the connection is made, switch to PC-VGA

source. See “Input selection” section.

• Set the resolution that suits your viewing requirements.

Resolution information can be found in the appendix

parts.

SPDIF

SCART

VGA

Coax.OUT

HDMI 1

PC audio cable

(not supplied)

to AUDIO INPUTS

on the TV

PC RGB cable

(not supplied)

to PC input

Audio

Inputs

PC Input

Using Side USB Input

• You can connect USB devices to your TV by using

the USB input of the TV. This feature allows you to

display/play music,photo or video ﬁles stored in a

USB stick.

• It is possible that certain types of USB devices (e.g.

MP3 Players) may not be compatible with this TV.

• You may back up your ﬁles before making any

connections to the TV set in order to avoid any

possible data loss. Note that manufacturer will not

be responsible for any ﬁle damage or data loss.

• The TV supports only FAT32 disk formatting. NTFS

format is not supported. If you connect a USB disk

with NTFS format, “usb is unformetted” osd will

be displayed.

• Do not pull out USB module while playing a ﬁle.

CAUTION: Quickly plugging and unplugging

USB devices, is a very hazardous operation.

Especially, do not repeatedly quickly plug

and unplug the drive. This may cause

physical damage to the USB player and

especially the USB device itself.

USB Memory Connection

• Plug your USB device to the USB input of the

TV.

Note: USB hard disk drives are not supported.

5Vdc-Max:500mA

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 801_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 8 03.12.2010 16:21:4803.12.2010 16:21:48

English - 9 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer

to your DVD player’s instruction book for additional

information. Power off both the TV and the device

before making any connections.

Note: Cables shown in the illustration are not supplied.

• If your DVD player has an HDMI socket, you can

connect via HDMI. When you connect to DVD player

as illustrated below, switch to HDMI source. See,

“Input Selection” section.

• Most DVD players are connected through

COMPONENT SOCKETS. YPbPr can be used

only when you connect a device that has a YPbPr

output through the PC input with YPbPr to PC cable.

To enable sound connection, use AUDIO IN located

side of the TV (YPbPr cable is not supplied).

• When the connection is made, switch to YPbPr

source. See, “Input selection” section.

• You may also connect through the SCART socket.

Use a SCART cable as shown below.

HDMI

input

Scart socket YPbPr to PC

cable (optional)

Component

audio

inputs

DVD Player

Note: These methods of connection perform the same

function but in different levels of quality. It is not necessary

to connect by all three methods.

Using Side AV Connectors

You can connect a range of optional equipment

to your LCD TV. Possible connections are shown

below. Note that cables shown in the illustration are

not supplied.

• For connecting a camcorder, connect to the VIDEO

IN socket and the AUDIO SOCKETS. For selecting

the related source, see the section “Input selection”

in the following parts.

• To listen the TV sound from headphones, connect

to the HEADPHONE jack of theTV

Camcorder

Headphone

Connecting Other Equipment

via Scart

Most devices support SCART connection. You can

connect a; DVD recorder or a VCR to your LCD TV by

using the SCART socket. Note that cables shown in

the illustration are not supplied. Power off both the TV

and the devices before making any connections.

For more information, refer to your device’s own

instruction book.

SCART socket

Decoder

DVD Recorder Video Recorder

01_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 901_MB46_[GB]_(01-TV)_1900UK_IDTV_NICKEL15_22742W_10071406_50181370.indd 9 03.12.2010 16:21:4903.12.2010 16:21:49
