tecnotelai S5041 Quick start guide

S51
Via Bonazzi, 4 - 40013 Castel Maggiore (BO)
Tel. [phone] (10 linee) - Fax [phone]
[email protected] - www.tecnotelai.it
!/!1 3
!
RISKS RELATED TO THE INSTALLATION OF THE SHELF
Entirely made in stainless
steel AISI 304 (EN:
1.4301).
Suitable for cold storage
and food,
pharmaceutical and
chemical sectors.
"
"
"
STAINLESS STEEL BOLT SHELVING SYSTEM
installation, use and maintenance instructions
BEFORE MOUNTING the structure check the floors and floor slabs, they must be in good condition, without holes and
accentuated unevenness and must have an appropriate consistency for the capacity of the uprights. In the case of shelf to
be built on a mezzanine floor it is essential to consult a specialist in order to assess the resistance and the capacity of the
floor.
"
UNLOADING AND STORAGE OF MATERIALS. This must be carried out at a predefined location, away from the risks
arising from any everyday work and contemporary installation of other systems (electricity, water, air conditioning, etc.).
The staff must be informed about the interim storage program, the approach of the material to the area of installation and
realization of the system itself.
"
ASSEMBLY AND INSTALLATION OF SHELF. The staff assigned to this work shall be provided with protective gloves.
The personnel managers must coordinate all phases of movement and installation and ensure that all applicable standards
regarding the health and safety of workers are applied.
BEFORE BEGINNING THE MOUNTING READ CAREFULLY
THE CHAPTER "USE AND MAINTENANCE STANDARDS"

S51
Via Bonazzi, 4 - 40013 Castel Maggiore (BO)
Tel. [phone] (10 linee) - Fax [phone]
[email protected] - www.tecnotelai.it
!/!2 3
UPRIGHTS!
"
"
"
"
ART."
DIMENSIONS"
CAPACITY "
"
(mm)"
"
(kg)"
"
"
S5011"
35x35x2000"
120"
"
"
!
ADJUSTABLE FEET.
They have been inserted at the base of
the uprights.
"
1
MOUNTING SEQUENCE
SHELVES. Insert the shelves from the bottom up and for
each use 8 screws TE 6X16 with nut and 16 washers
without tightening.
When the shelving is completed tighten all the nuts.
"
2
PLAQUES. For each row of shelves, in a prominent
position a plaque must be placed indicating the maximum
capacity of the uprights and shelves.
"
3
plaque
CAPACITIES AND DIMENSIONS
In case of shelves with various spans with single
pillars, capacity is halved.
Always check the overall capacity for each span.
SHELF DIMENSIONS
Add the nominal length of the shelves.
"
ART.
S5011
35x35x2000
DIMENSIONS
UPRIGHTS
120
(mm)
(kg)
CAPACITY
ART.
REINFORC.
S5036
S5041
S5046
S5061
S5066
1200x500
100
100
1
1
1200x400
DIMENSIONS
1000x300
1000x400
(mm)
(kg)
1
1
100
100
1
1000x500
SHELVES
CAPACITY
100

S51
Via Bonazzi, 4 - 40013 Castel Maggiore (BO)
Tel. [phone] (10 linee) - Fax [phone]
[email protected] - www.tecnotelai.it
!/!3 3
USE AND MAINTENANCE STANDARDS
"
•Composition of spans. For each span it is necessary to place the shelves at a maximum distance of 500 mm apart.
"
•Safety. In declared seismic zones any kind of wall mounting is forbidden. !
The structures are intended for operations carried out manually, not with forklifts or pallet trucks.
"
•Capacities. For each row of shelves, in a prominent position 1 plaque must be placed indicating the capacities of the
uprights and shelves. The capacities indicated are always for uniformly distributed loads on the shelf, installed
according to our instructions and used correctly.!
Avoid dimensioning the structures at the limits of capacities.
"
•In case of damage to the structures you must immediately unload the shelving and replace the parts that are damaged
or deformed. Carefully check that the geometry of the shelf has not been changed.!
In case of frequent accidents it is necessary to have adequate safety measures
"
•The warehouse manager and operators must be provided with all the information about the technical
specifications of the shelf and the rules for correct use.
"
•The user, as required by Law, must verify the suitability and efficiency of the structures, planning a series of tests
and inspections and preparing the dedicated report.
"
•Every 3 years it is necessary to inspect the bolts relative to 10% of the spans. If more than 5% of the bolts measured
are not adequately tightened, proceed by checking 50% of the spans. Where more than 10% of the bolts have the same
problem you must have the entire shelf checked. In subsequent checks, check the parts not previously examined.
"
•Every 2 years check the verticality of the structures longitudinally and transversally. In case of deviations, provide
with shims to restore the geometry of the shelf.
"
•The surfaces of all components must be checked every 5 years for indoor normal environments and every year for
environments subject to corrosion (close to the sea, chemical fumes etc.). If any items are damaged by corrosion they
must be replaced.
"
•It is forbidden to modify the components of the structures by performing welding or preparing equipment of any kind.
"
"
Failure to follow the "installation, use and maintenance instructions" releases the supplier from any liability and
damages to persons or property.
