TeeJet CenterLine Series User manual

CenterLine Menu Guide
Version 2.02
START
SETUP GUIDANCE SWATH MAN % OVERLAP 0%
TOOLS WIDTH 30.0 (DEFAULT) SECTIONS 50%
AHEAD 1.5 (DEFAULT) WIDTH 1-5 100%
ANTENNA DIRECTION FORWARD DELAY
BACK NEXT
DISTANCE 0.0 (DEFAULT) TO START
HEIGHT 9.8 (DEFAULT)
NEXT
STATUS OFF
ON
ALARM OFF
ON
GPS TYPE DGPS
GPS
1HZMSG YES
NO
NEXT
TO START
LIGHTBAR SPACING 1.5 (DEFAULT)
MODE VEHICLE
SWATH
TEXT 1 X-TRACK
TEXT 2 SWATH #
SPEED
AREA
COURSE
OFF ENGLISH
STEER BAR NO SWEDISH
YES DANISH
NEXT DUTCH
TO START GERMAN
SYSTEM UNITS METRIC FRENCH
NEXT U.S. ITALIAN
TO START LANGUAGE PORTUGUESE
NEXT SPANISH
TO START POLISH
Only available when Swath Manager 5 is connected
Removed from menu setup when Swath Manager 5 is connected
98-01094 R8

Tilt Compensation Module
must be connected
START NEW? PATTERN HEADLAND STRAIGHT CURVE AB
SETUP RESUME? NEW AB MARK A MARK B
TOOLS RECEIVER AREA RIGHT CLOSE
LIGHTBAR LEFT
LEVEL A+
DEMO EXIT
NEXT APPLY OFF? APPLY ON?
TO START
Real-time Menu
Display Item Description
START Press Enter to begin guidance. Run Setup prior to starting. It is assumed
that the DGPS receiver is connected to the lightbar and running properly.
NEW? Press Enter to start a new field. All vehicle trajectory data, the return to
point location, and guideline information will be deleted.
RESUME? Press Enter to resume work in the current field. The vehicle trajectory,
return to point location, and guideline information stored in memory is
used for guidance operations.
APPLY OFF? Press Enter to turn the application off. Item then changes toAPPLY ON?
These menu items only appear if no switch box or boom sense cable is
being used and the <GUIDANCE><SETUP> setting is set to “OFF”.
APPLY ON? Press Enter to turn the application on. Item then changes to APPLY
OFF? These menu items only appear if no switch box or boom sense
cable is being used and the <GUIDANCE><SETUP> setting is set to
“OFF”.
Indicates that the current guidance mode is “Headland”.
STRAIGHT Indicates that the current guidnce mode is “Straight-Line”.
CURVED Indicates that the current guidance mode is “Curved”.
A+ Press Enter to shift guideline to current position. The heading (and shape
if in curved mode) of the original guideline is maintained, but the A/B line
is shifted to the vehicle location.
NEW AB Press Enter to create a new reference guideline. Mark A is displayed in
the text window for approximately 5 seconds. Press Enter to mark the A
location. Mark B will be displayed. Press Enter to mark the B location.
AREA Press Enter to being Boundary area determination. A prompt will ask for
the side of the implement that is closest to the edge of the area bound-
ary to be traced. Automatically or manually close the area. If an area has
already been determined, there is a VIEW item. Press Enter to view the
current area.
EXIT Press Enter to exit operations.
HEADLAND
TeeJet Technologies • 1801 Business Park Drive, Springfield, Illinois 62703 USA
[phone] • [phone] Fax • www.teejet.com
98-01094 R8
