Tego Audio CERA User manual
V3.0 tegoaudio.com | support@tegoaudio.com
Charging Your CERA
For best performance, fully charge before use.
1. Connect the provided USB cable to your computer’s USB port, or any other
USB power source.
2. While charging, a red light at the base of the CERA will illuminate.
3. The red light will turn off once fully charged.
It will take approximately three hours to
fully charge your CERA.
Bluetooth: Stream audio wirelessly up to 33 feet with any Bluetooth enabled
device. (see next page for pairing instructions)
Audio Cable: Connect your CERA to any compatible device using the
3.5mm audio cable.
Create bigger sound by daisy-chaining multiple CERA speakers.
Bluetooth Daisy Chain
1. Pair your bluetooth enabled device to one CERA speaker.
2. Connect an infinite number of speakers using the daisy chain
mini USB/3.5mm audio cables.
3. Power on the additional speakers.
Audio Cable Daisy Chain
1. Connect your device to one CERA speaker using the 3.5mm audio cable.
2. Connect an infinite number of speakers using the daisy chain
mini USB/3.5mm audio cables.
3. Power on the additional speakers.
CERA Daisy Chain SoundConnectivity
Pairing Your CERA Pairing Your CERA (cont’d)
Preparing Your CERA Speaker For Pairing Turn on the CERA by pushing down
on the center of the Touch Control Panel. You will hear “Power On”
confirming that your CERA is on.
Approximately 30 seconds after the CERA is powered on, you will hear
“Pairing” accompanied by a flashing red light at the base of the speaker.
The CERA is now ready to be paired with your Bluetooth enabled device.
Preparing Your Phone or Device For Pairing For iPhone®, iPod®or iPad® :
Go to SETTINGS GENERAL BLUETOOTH, and turn on.
For Bluetooth pairing with other cell phones/devices, please refer to the
device’s owner’s manual.
In the Bluetooth settings of your device, add
or search for devices. Once “Tego Audio CERA” appears, select it.
If a password is required, enter “ØØØØ”
Once paired you will hear “Pairing Completed” followed by the pairing tone.
Once you’ve paired the CERA with a device, the CERA will automatically
connect when that device’s Bluetooth is enabled. Pairing is complete
when you hear the pairing tone.
The CERA will have a range of approximately 33 feet from your device.
If distortion begins to occur, place device closer to the speaker (or vice versa)
or recharge your CERA.
“POWER ON”
CERA Speaker Is
Now Powered On
“PAIRING COMPLETED”
CERA Speaker Is Now Paired
With Your Bluetooth Enabled
Device
“PAIRING”
CERA Speaker Is Ready
To Pair With Your
Bluetooth Enabled Device
Operating Your CERA Operating Your CERA (cont’d)
Next Song
On compatible devices you can skip to the next song.
Previous Song
On compatible devices you can skip to the previous song.
Volume Up
For best results turn your phone/device to MAX volume and use the
CERA touch panel to control volume.
Volume Down
You will hear a double tone when the minimum volume on the CERA
has been reached.
3.5mm Audio Line Input
USB Charging Port/Daisy Chain Port
It will take approximately three hours to fully charge the CERA.
To Power On
Push down on the center
of the Touch Panel Control
and release.
To Power Off
Push down on the center
of the Touch Panel Control
until closed.
Your CERA will
automatically open.
Specifications Safety Instructions
Model: CERA
Dimensions: diameter = 3.625"/92mm height = 2.375"/60.325mm
Net Weight: 100g
Speaker: 40mm
Power Output: 1.5W (maximum)
S/N: >70dB
AMP Frequency Range: 100Hz-20Hz
Charge Voltage: 5V
Li-ion Battery: 3.7V
Distor tion: <1.0 %
Charge Time: Approximately 3 Hours
Play Time: Approximately 5-7 Hours Depending on Volume & Audio Source
Transmission Distance: 10m/33ft
Work Frequency: 2.402-2.480GHz
Bluetooth Model: V3.0
Transmission Power: Bluetooth Class 2
The CERA uses special lubricants to regulate the speed & smoothness of the
Expanding Sound Chamber. If the CERA sits for an extended period of time, it may
affect the speed of which the Expanding Sound Chamber will open, but will return
back to normal after regular use. Variables such as temperature & altitude may
also affect the unit’s operation.
DO NOT pull hard once open; such actions will damage the unit.
The CERA wireless portable speaker by Tego Audio® has been designed and
built to the highest standards to ensure your personal safety. However, improper
use can result in potential electrical shock or fire hazards. Please read all safety
and operating instructions carefully before installation and use, and keep these
instructions handy for future reference. Take special note of all warnings listed in
these instructions and on the unit.
Keep unit away from water & liquids at all times
.
Do not place unit in a location in which ventilation opening will be blocked.
Keep unit away from direct sources of heat.
Only connect unit to the type of power supply described in the operating
instructions.
Do not use attachments not recommended by the product manufacturer.
Do not dispose your CERA speaker in a fire which may cause the battery to explode;
a battery explosion may cause severe injury or death.
Do not disassemble the built-in battery as it may cause electrical shock.
Do not charge your CERA in damp areas or in extremely high or low temperatures; this
may result in electrical shock.
Do not place or store your CERA speaker on or near your automobiles’ airbags; this
may result in serious injury if your airbag deploys.
Do not place the CERA on high surfaces, as the CERA may move during music
playback and cause the CERA to fall off an edge.
Do not use abrasive cleaners on your CERA as this may cause damage and/or
scratches to the unit.
•
•
•
•
•
•
•
•
•
•
•
Battery Cell: Rechargeable Lithium Polymer
Capacity: 5500 mAh
In put: 5V/1A
Micro USB output: 5V/1A
USB output: 5V/2A
Dimensions: 4.6 x 3 x 0.7 inches (116 x 78 x 18 mm)
Safety Instructions (cont’d) Warranty/FCC Statement
Do not place your CERA in contact with any sharp objects as this may result in
damage and/or scratches.
Do not attempt to repair, modify or disassemble the CERA, as this will void
your warranty. The CERA does not contain any components that are user-
serviceable.
Do not attempt to replace the CERA’s built-in battery as it is not changeable.
Observe all signs & displays that require an electrical device or RF radio
product to be switched off in a designated area.
Do not use the CERA inside an aircraft & be sure it is turned off prior to boarding.
Only use your CERA inside an aircraft if allowed by airline.
Do not dispose of the CERA battery with regular household trash. Only dispose
the CERA battery in accordance with local regulations.
•
•
•
•
•
•
•
Limited Warranty
For a period of 12 months from the original date of purchase, Tego Audio, a
division of Tego LLC, warrants this product to be free from defects in materials
& workmanship, under normal use & conditions.
For warranty instructions, please email: warranty@tegoaudio.com
FCC Statement
This equipment has been tested & found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules.
These Limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
The supplied interface cable must be used with the equipment in order to
comply with the limits for a digital device pursuant to Subpart B of Part 15
of FCC Rules.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
•
•
•
•
Questions?
Visit: tegoaudio.com
Email: suppo[email protected]
FCC Statement (cont’d)
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference
that may cause undesired operation.
FCC Caution
FCC ID: ZRCGEPBT50806A
The FCC identification number is located at the base of the CERA
wireless speaker.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
This device & its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
•
•
DO NOT dispose of unit with general waste; contains
lithium polymer battery. Please return it to a battery
recycling collection center. For a recycling center
near you, call 1-877-2-RECYCLE.
COMPLIANT
Package Contents
1x CERA Speaker
1x User Manual 1x 3.5mm
Audio Cable
1x Charging
Cable
1x Daisy Chain
Cable
1x Carrying Case
