Tektronix, Inc. TDP4000 Manual

x
TDP3500 and TDP4000
3.5 GHz and 4 GHz Differential Probes
ZZZ
Quick Start User Manual
*P071221201*
071-2212-01

TDP3500 and TDP4000
3.5 GHz and 4 GHz Differential Probes
ZZZ
Quick Start User Manual
xx
www.tek.com
071-2212-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by
national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously
published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
KlipChip, TekVPI, and TwinFoot are trademarks of Tektronix, Inc.
TwinTip is a registered trademark of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If
any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts
and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement products used by Tektronix for
warranty work may be new or reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make
suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service
center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties,
taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix
shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than Tektronix
representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; c) to
repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or integrated with
other products when the effect of such modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR
IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY
PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
Table of Contents
General safety summary ................................................................................................................... iii
Environmental Considerations ............................................................................................................. vi
Preface..................................................................................................................................... vii
Documentation....................................................................................................................... vii
Conventions used in this manual.................................................................................................... vii
Returning the probe for servicing.................................................................................................... viii
Key features ................................................................................................................................ 1
Operating considerations................................................................................................................... 2
Installation .................................................................................................................................. 3
Connecting to the host instrument.................................................................................................... 3
Probe controls and indicators......................................................................................................... 4
Functional check. ........................................................................................................................... 6
Required equipment .................................................................................................................. 6
Calibration .................................................................................................................................. 8
Prerequisites .......................................................................................................................... 8
Required equipment .................................................................................................................. 8
Test procedure........................................................................................................................ 9
Basic operation ............................................................................................................................ 12
Probe head assembly................................................................................................................ 12
TDP3500 and TDP4000 Quick Start User Manual i

Table of Contents
Probe input........................................................................................................................... 13
Probe offset.......................................................................................................................... 15
Applications................................................................................................................................ 17
Accessories and options .................................................................................................................. 20
Using standard accessories . ........................................................................................................ 20
Optional accessories. ................................................................................................................ 30
Options............................................................................................................................... 33
Probing principles.......................................................................................................................... 34
Probe grounding . .................................................................................................................... 34
Input impedance and probe loading. ................................................................................................ 35
Maintenance............................................................................................................................... 36
Host instrument firmware............................................................................................................ 36
Error condition ....................................................................................................................... 36
Replacement parts................................................................................................................... 37
Cleaning.............................................................................................................................. 37
Index
ii TDP3500 and TDP4000 Quick Start User Manual

General safety summary
General safety summary
Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system. Read the safety sections of the other component
manuals for warnings and cautions related to operating the system.
To avoid fire or personal injury
Connect and disconnect properly. Do not connect or disconnect probes or test leads while they are connected to a voltage
source.
Ground the product. This product is indirectly grounded through the grounding conductor of the mainframe power cord. To avoid
electric shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings and markings on the product. Consult the product
manual for further ratings information before making connections to the product.
Connect the probe reference lead to earth ground only.
Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.
Do not operate without covers. Do not operate this product with covers or panels removed.
Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualified
service personnel.
TDP3500 and TDP4000 Quick Start User Manual iii

General safety summary
Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Terms in this manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.
Symbols and terms on the product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the marking.
WARNING indicates an injury hazard not immediately accessible as you read the marking.
CAUTION indicates a hazard to property including the product.
iv TDP3500 and TDP4000 Quick Start User Manual

General safety summary
The following symbol(s) may appear on the product:
TDP3500 and TDP4000 Quick Start User Manual v

Environmental Considerations
Environmental Considerations
This section provides information about the environmental impact of the product.
Restriction of hazardous substances
Complies with RoHS2 Directive 2011/65/EU.
Product End-of-Life Handling
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and use of natural resources. The equipment may
contain substances that could be harmful to the environment or human health if improperly handled at the product’s end of life. To
avoid release of such substances into the environment and to reduce the use of natural resources, we encourage you to recycle this
product in an appropriate system that will ensure that most of the materials are reused or recycled appropriately.
This symbol indicates that this product complies with the applicable European Union requirements according to
Directives 2012/19/EU and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For
information about recycling options, check the Tektronix Web site (www.tek.com/productrecycling).
vi TDP3500 and TDP4000 Quick Start User Manual

Preface
Preface
This manual describes the installation and operation of the TDP3500 and TDP4000 Differential probes. Basic probe operations and
concepts are presented in this manual. You can also check the Tektronix Web site for this document and other related information.
Documentation
To read about Read these documents *
First Time Operation, Functional Check, Operating Basics This manual.
Specifications, Performance Verification The technical reference manual
In-depth oscilloscope operation, user interface, GPIB commands The online help (from the Help menu on the
host instrument)
*To access the documentation that is installed on your instrument, click Start in the taskbar and select Programs > TekApplications.
Conventions used in this manual
The following icon is used throughout this manual to indicate a step sequence.
TDP3500 and TDP4000 Quick Start User Manual vii

Preface
Returning the probe for servicing
If your probe requires servicing, you must return the probe to Tektronix. If the original packaging is unfit for use or not available, use
the following packaging guidelines:
Preparation for Shipment
1. Use a corrugated cardboard shipping
carton having inside dimensions at
least one inch greater than the probe
dimensions. The box should have a carton
test strength of at least 200 pounds.
2. Put the probe into an antistatic bag or wrap
it to protect it from dampness.
3. Place the probe into the box and stabilize it
with light packing material.
4. Seal the carton with shipping tape.
5. Refer to Contacting Tektronix at the
beginning of this manual for the shipping
address.
viii TDP3500 and TDP4000 Quick Start User Manual

Key features
Key features
The TDP3500 and TDP4000 Differential probes enables you to make accurate differential measurements from DC to 3.5 GHz and
4 GHz using oscilloscopes featuring the Tektronix TekVPI oscilloscope interface. Key features include:
DC to 3.5 Ghz bandwidth (TDP3500)
DC to 4 Ghz bandwidth (TDP4000)
100 kΩdifferential input resistance
<0.3 pF differential input capacitance
>25 dB CMRR @ 1 GHz
Automatic unit scaling on the oscilloscope display
TDP3500 and TDP4000 Quick Start User Manual 1

Operating considerations
Operating considerations
Table 1: TDP3500 and TDP4000
Characteristic Description
Input Voltage Differential:
±2.0 V (DC + peak AC), 1.4 V RMS
Operating Voltage Input Range:
+5 V to –4 V (either input referenced to ground)
Temperature Operating: 0 to +40 °C (+32 °F to +104 °F)
Nonoperating: –40 °C to +71 °C (–40 °F to +160 °F)
Humidity Operating: up to +40 °C (+104 °F) 5-90% RH
Nonoperating: up to +60 °C (+140 °F) 5-90% RH
Altitude Operating: Up to 3000 meters (10,000 feet)
Nonoperating: Up to 15230 meters (50,000 feet)
Pollution Degree 2, Indoor use only
2TDP3500 and TDP4000 Quick Start User Manual

Installation
Installation
Connecting to the host instrument
NOTE. Your TekVPI instrument may require a
firmware upgrade to support full functionality
of the TDP3500 and TDP4000 probes. Before
you connect the probe, check the version
requirements. (See page 36, Host instrument
firmware.)
1. Slide the probe into the TekVPI receptacle.
The probe snaps when fully engaged.
When you connect the probe, the host
instrument reads information from the
probe and identifies the probe type.
2. To disconnect, press the latch release
button and pull away from the instrument.
TDP3500 and TDP4000 Quick Start User Manual 3

Installation
Probe controls and indicators
Status LED
When the probe is powered on, the Status
LED glows green, then dark, and then remains
lit green. This indicates that the probe is in
normal operating mode.
If the Status LED glows red, a fault may exist.
To clear the fault:
1. Disconnect the probe from the oscilloscope.
2. Reconnect the probe to the oscilloscope.
If the Status LED continues to glow red, return
the probe to Tektronix.
4TDP3500 and TDP4000 Quick Start User Manual

Installation
Menu button
1. Press the probe Menu button to display the
Probe Control screen on the oscilloscope.
NOTE. Probe menu screens vary slightly
between oscilloscope series; samples of
DPO7000C Series screens are shown here.
This screen includes controls for probe
functions that are not accessible on the probe,
such as Offset.
2. Use the touch-screen buttons on the
instrument to set the probe parameters.
3. Press the probe Menu button again to
close the Probe Control screen.
TDP3500 and TDP4000 Quick Start User Manual 5

Functional check
Functional check
Use the following procedure to check that your probe is functioning properly. To verify that your probe meets the warranted
specifications, refer to the Performance Verification procedures in the TDP3500 Probe Technical Reference.
NOTE. The DPO7000C series oscilloscope is used in all illustrations in this manual, unless noted otherwise.
Required equipment
Description and quantity Performance requirement Recommended example
Oscilloscope TekVPI Interface Tektronix DPO7000C Series
Tektronix 6 Series MSO
Square-pin adapter Probe tip to 0.25-in square pins for
external connections
Tektronix part number 016-1884-XX 1
Y-lead adapter 0.25-in square pins for probe tip
connections
Tektronix part number 196-3434-XX 1
MicroCKT Test Tips (2) 0.25-in square pins-to-mini clips Tektronix part number 206-0569-XX 1
1Standard probe accessory
6TDP3500 and TDP4000 Quick Start User Manual
