OneStream GFX Quick Start Guide
Version 2 – for firmware 1.2.1430.io
This guide gives a basic overview of installing and programming the OneStream GFX to route calls
between PBX Trunk ports and GSM. For more information please refer to the OneStream
Hardware Installation Guide and OneStream Programming Guide which are both included
with the unit.
1Hardware Installation
1. Insert SIM Cards and attach Antennae:
2. Take the bottom cover off by removing the
small screw at the bottom of the unit and
sliding the cover downwards
3. Connect the Safety Earth
Ground

2
4. Connect the first FXS port on
the OneStream to an
available Trunk Port on the
PBX.
5. Connect the second FXS port
on the OneStream to an
available Trunk Port on the
PBX.
6. Replace the bottom cover by sliding it back
upwards and replacing the screw.
7. Connect the power to the unit and wait for the
Red LED to go out.

OneStream GFX Quick Start Guide
3
2Programming
By default:
The Default routing plan will route all calls from the PBX to GSM and will route all incoming calls from
GSM to the PBX.
If you wish to change the routing plan (e.g. to only allow calls starting 08 to go to GSM) then use the
following procedure:
When OneStream starts up, it will try to find a DHCP Server to obtain an IP Address automatically.
If it does not find a DHCP server, it will use its default IP Address of 192.168.0.1.
2.1 Setting up your PC
In order to access the OneStream Web Interface and program the unit your PC must be set to a
compatible IP Address e.g. 192.168.0.2. To change the IP Address of your PC:
1. Click on the Start menu,
Control Panel (if you do not
see the display like this then
click on “Switch to Classic
View”):
2. Double-click on Network
Connections:

OneStream GFX Quick Start Guide
4
3. Right-click the Local Area Connection icon
and click Properties:
4. Click on the Internet Protocol (TCP/IP)
entry and click the Properties button.
Click the Use the following IP address option
and fill in the details as shown here:
IP Address: 192.168.0.2
Subnet Mask: 255.255.255.0
Click the OK button to exit the Internet Protocol Properties window
Click the Close button to exit the Local Area Connection Properties window

OneStream GFX Quick Start Guide
5
2.2 Editing the OneStream Programming
1. Connect one end of a Crossover (X-Over)
Ethernet Cable to the LAN port of the OneStream:
2. Connect the other end of the Crossover Ethernet cable to the LAN port of your computer.
3. Open Internet Explorer web browser on your PC.
4. In the Address Bar of the Internet
Explorer window type the IP Address of
the OneStream unit 192.168.0.1 and
press the Enter key. You will see the
Login screen for the OneStream unit:
5. Enter the Password for the OneStream unit and click the Login button. The default password is
12345678. If the password entered is correct you will be taken to the Home page.
6. Click on the Routes link on the left of the page. The current routing table will then be displayed.
This may be correct if pre-configured by the supplier, if not it will have the default setting shown
here:

OneStream GFX Quick Start Guide
6
7. To alter the routing to your requirements for Outbound GSM calls from the PBX, click the Edit icon
next to the route named GSM Outgoing and set the following options:
•In Dialled Numbers change the ? to (for example) 08? in order to route any number beginning
with 08. The ? is a wild card that allows any digit dialled after the 08.
Click the Save button to save your changes and return to the routing table

OneStream GFX Quick Start Guide
7
The Routing table should now look like this:
The OneStream is now ready for use.
