USB2-GPIB Overview
The USB2-GPIB Converter enables you to remotely control an oscilloscope
from a PC using standard GPIB commands.
The GPIB connector conforms to IEEE488.2 standard. Its delimiter setting is
LF+EOI. Note that the USB2-GPIB does not function as a GPIB controller.
The USB connector conforms to USB 2.0. The source voltage is supplied from
the USB port.
GPIB driver needs to be properly configured to allow HS488 high speed mode,
including proper definition of the cable length.
For details of the supported GPIB commands, see the MAUI Oscilloscopes
Remote Control Manual and Automation manual on the Teledyne LeCroy website.
The minimum MAUI firmware version required for this device is 7.3.0.x.
Specifications
Power Feed
Bus-powered
USB Standard
USB Specification Revision 2.0
USB Connector
Type A
GPIB Connector
Amphenol 24-pin (male)
Power consumption
350 mA maximum (during operation)
Temperature, operating
+5 °C to +40 °C
Temperature, storage
-40 °C to +71°C
Humidity, operating
≤ 80% RH (non-condensing)
Altitude, operating
3048 m (10,000 ft) max at ≤ 25 °C
External Dimensions (mm)
61 (W) × 22 (H) × 113 (L) (mm)
Cable Length (mm)
750
Mass
Approx. 140 g
Specifications subject to change without notice.

USB2-GPIB Adapter
2EAR99 technology subject to restrictions on copyrights page.
Safety
To avoid personal injury or damage to the USB2-GPIB or any equipment
connected to it, review and comply with the following safety precautions.
Use only as intended. Using the adapter or connected equipment in a manner
not specified by the manufacturer(s) may impair the protection mechanisms.
Connect and disconnect properly. Do not disconnect the USB2-GPIB during
data transfer. The green LED of the USB2-GPIB stays lit while the
communication is in progress. Disconnecting equipment during this time may
result in data corruption or damaged equipment.
Do not use in wet/damp or explosive atmospheres.
For indoor use only. The USB2-GPIB is intended for indoor use and should be
operated in a clean, dry, environment.
Do not operate with suspected failures. Do not use USB2-GPIB if any part is
damaged. All maintenance should be referred to qualified service personnel.
Keep product surfaces clean and dry.
Connecting the Adapter
Insert the USB connector into the USB port of the oscilloscope, then attach the
IEEE-488/GPIB connector to GPIB port on the PC.
During the first use of the adaptor, Windows will install the device driver. You
may need to restart the oscilloscope for the adaptor to be functional.
Figure 1: Connecting USB2-GPIB.

Operator’s Manual
EAR99 technology subject to restrictions on copyrights page. 3
Setting up the GPIB Connection
Follow the steps below to set the PC’s GPIB address on the the oscilloscope
(Figure 2).
1. From the menu bar, choose Utilities > Utilities Setup, then open the
Remote dialog.
2. Select GPIB in the ‘Control From’ section.
3. Enter the GpibAddress value.
Figure 2: Remote dialog GPIB setup.
Checking Communication Status
The USB2-GPIB is equipped with two LEDs on the GPIB connector side that
indicate the communication status of the GPIB link:
•Red LED lit: READY, power to the USB2-GPIB is ON.
•Green LED blinking: ACTIVE GPIB connection.
Figure 2: READY and ACTIVE indicators on USB2-GPIB.

USB2-GPIB Adapter
4EAR99 technology subject to restrictions on copyrights page.
Firmware Upgrade
After initial driver installation or an oscilloscope firmware upgrade, it may be
necessary to upgrade the dongle firmware on the USB2-GPIB. A pop-up window
will appear to indicate incompatibility and instruct you to remove the device.
Follow these steps to upgrade the dongle firmware:
1. Download USB2-GPIB dongle firmware upgrade from
teledynelecroy.com. Extract this archive to a local folder of the PC
(e.g., C:\Temp).
2. Before reconnecting the USB2-GPIB device to the PC, open the
Windows Device Manager utility on the PC.
3. While pressing the dongle button underneath the case, plug the USB2-
GPIB USB connector into the PC’s USB port. The dongle should show
up as AT32UC3A in the Windows Device Manager list of devices.
4. Install the Atmel USB DFU driver:
•Right click on AT32UC3A in the Device Manager and choose
Update Driver Software.
•Browse to the Atmel_DFU_USB_Driver folder of the extracted
download archive.
The dongle should now show up as AT32UC3A3 under the Atmel USB
Devices folder of the Windows Device Manager list of devices.
5. Double-click the DFU_UpgradeDongleFW.bat file in the driver folder,
which will upgrade the dongle with the latest firmware. The dongle
firmware upgrade is successful if the red LED is on.

Operator’s Manual
EAR99 technology subject to restrictions on copyrights page. 5
Technical Support
For a complete list of offices by country, including our sales & distribution
partners, visit: teledynelecroy.com/support/contact
Teledyne LeCroy
700 Chestnut Ridge Road
Chestnut Ridge, NY, 10977, USA
teledynelecroy.com
Sales and Service:
Ph: 800-553-2769 / 845-425-2000
FAX: [phone]
contact.co[email protected]
Support:
Ph: 800-553-2769
[e-mail]
Service
If the converter is inoperable, send it back to Teledyne LeCroy. Contact us for a
Return Materials Authorization (RMA) number and shipping instructions before
sending it. We will repair it without charge as long as it is under warranty.
When sending back the converter, explicitly describe the following:
•RMA number
•Product name and serial number
•Description of the trouble
•Name/post/phone number of the owner

USB2-GPIB Adapter
6EAR99 technology subject to restrictions on copyrights page.
Certifications
Teledyne LeCroy certifies compliance to the following standards as of the date
of publication. For the current certifications, see the EC Declaration of
Conformity shipped with your product.
EMC Compliance
EC Declaration of Conformity - EMC
The product meets intent of EC Directive 2014/30/EU for Electromagnetic
Compatibility. Compliance was demonstrated to the following specifications as
listed in the Official Journal of the European Communities:
IEC/EN 61326-1:2013 EMC requirements for electrical equipment for
measurement, control, and laboratory use
European Contact:
Teledyne GmbH, European Division
Im Breitspiel 11c
D-69126 Heidelberg
Germany
Tel: [phone]
Australia & New Zealand Declaration of Conformity - EMC
The product complies with the EMC provision of the Radio Communications
Act per the following standards, in accordance with requirements imposed by
the Australian Communication and Media Authority (ACMA):
AS/NZS CISPR 11:2009/A1:2010, IEC 55011:2009/A1:2010 Radiated and
Conducted Emissions, Group 1, Class A.
Australia / New Zealand Contacts:*
RS Components Pty Ltd.
Suite 326 The Parade West
Kent Town, South Australia 5067
RS Components Ltd.
Units 30 & 31 Warehouse World
761 Great South Road
Penrose, Auckland, New Zealand
* Visit teledynelecroy.com/support/contact for the latest contact information.

Operator’s Manual
EAR99 technology subject to restrictions on copyrights page. 7
Safety Compliance
EC Declaration of Conformity – Low Voltage
The product meets the intent of EC Directive 2014/35/EU for Product Safety.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
IEC/EN 61010-031:2015 Safety requirements for electrical equipment for
measurement, control and laboratory use – Part 031: Safety requirements for
handheld probe assemblies for electrical measurement and test.
Environmental Compliance
End-Of-Life Handling
The product is marked with this symbol to indicate that it complies
with the applicable European Union requirements to Directives
2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).
The product subject to disposal and recycling regulations that vary
by country and region. Many countries prohibit the disposal of waste
electronic equipment in standard waste receptacles. For more information
about proper disposal and recycling of your Teledyne LeCroy product, visit
teledynelecroy.com/recycle.
Restriction of Hazardous Substances (RoHS)
The product conforms to the 2011/65/EU RoHS2 Directive inclusive of any
further amendments or modifications of said Directive.

933081-00 Rev A
November, 2020
