Omron Promi-SD 205-OA User manual

1
Version 1.0.0
Promi-SD™
205-OA
Bluetooth RS232C Serial Adapter
by Bluetooth
Enabling Wireless Serial Communications

Copyright © 2006 Sena Technologies, Inc. All rights reserved.
H
Worldwide Sales:
AVE Added Value Electronics BV
Vissersdijk Beneden 17
3319 GW Dordrecht
The Netherlands
Mr. Johan B. Bickel
Sales Manager
Tel. +31 (0)78 – 6215900
Fax [phone]
[e-mail]
http://www.ave-nl.com
For more information and Technical Support, please contact:
Sena Technologies, Inc.
210 Yangjae-dong, Seocho-gu
Seoul 137-130, Korea
Tel : [phone]
Fax : [phone]
E-Mail : H TU[email protected]UTH
Website : HTU http://www.sena.comUT H

Promi-SD 205-OA User Manual – Table of Contents 1
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Table of Contents
Before Using the Product ...................................................................... 3
Welcome........................................................................................................3
Copyrights/Certification/Limited Liability..................................................3
Precautions and Safety................................................................................3
General Terms and Conditions of Sale......................................................3
1. Getting Started .................................................................................. 7
Features of Promi-SD.....................................................................................7
Components..................................................................................................7
Assembly.........................................................................................................7
Locating the Controls...................................................................................7
2. Configurations ................................................................................. 12
Operation Modes........................................................................................12
LED Indicators ..............................................................................................12
Serial Ports.....................................................................................................12
Reset to Factory Defaults...........................................................................12
PromiWizardP™P............................................................................................12
PromiWINP™P................................................................................................. 12
Terminal Program........................................................................................12
Dip Switch.....................................................................................................12
Pairing Button...............................................................................................12
3. Connections .................................................................................... 22
RS232 Interface............................................................................................22
Pin Assignment.............................................................................................22
Power Supply...............................................................................................22
4. Trouble Shooting.............................................................................. 25
No Data Transmission..................................................................................25
Data Loss or Malfunctioning......................................................................25
Transmission Delay ......................................................................................25
5. Specifications .................................................................................. 27
Bluetooth Interface.....................................................................................27
Serial Interface.............................................................................................27
Power............................................................................................................27
Mechanical Dimensions.............................................................................27
Environmental..............................................................................................27
Default Antenna.......................................................................................... 27
Power Consumption...................................................................................27
Wireless Coverage......................................................................................27

Promi-SD 205-OA User Manual – Table of Contents 2
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Appendix A. AT Commands ................................................................ 1
Terminology....................................................................................................1
Command Category ...................................................................................1
Command Description.................................................................................1
Command Validity .......................................................................................1
Appendix B. S-Register ......................................................................... 1
Appendix C. Technical Support........................................................... 1
Appendix D. Connection to Omron PLC ............................................. 1

Promi-SD 205-OA User Manual – Before Using the Product 3
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Before Using the Product
Welcome
Copyrights/Certification/Limited Liability
Precautions and Safety
General Terms and Conditions of Sale
get UNWIRED, it’s easy!

Promi-SD 205-OA User Manual – Before Using the Product 4
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Welcome
Thank you for purchasing Promi-SD products.
Promi-SD is a terminal device for wireless serial communication using Bluetooth technology, the international standard
for short range wireless communications. Its interoperability and credibility delivers the maximum benefits of wireless
communication.
This user manual is designed to help you use the Promi-SD series properly. It is important that you read the manual to
ensure that you get the most out of your products.
Thank you.
Copyrights/Certification/Limited Liability
 Copyrights
Sena Technologies, Inc. has all the rights of the patent, trademark, literary property and intellectual property related to
this manual. You may not copy or reproduce any part of this manual unless authorized by Sena Technologies, Inc. You
can be punished by using any part of this manual illegally.
The companies, institutions, products, people and events used in examples are not real data. We don’t have any
intension to be related with any companies, institutions, products, people and events through this manual and should
not draw inferences. Users are responsible for observing the copyrights and intellectual properties.
 Certification
Promi- MIC Bluetooth CE FCC TELEC
SD205_OA  
 Limited Liability
Neither the manufacturer, importers nor dealers is responsible for any accidental damage including bodily injury or any
damage resulting from misuse or unsuitable operation by you. The information on this manual is prepared with the
current product specifications. The manufacturer, Sena Technologies, Inc., is adding new features to the product and
may persistently apply new technologies hereafter. All standards may be changed at any time without notice.
Precautions and Safety
 Electricity
 Use only the supplied AC adapter. Use of unauthorized power adapter is not recommended. Electrical shock
may result.
 Do not kink or crease the power cable or place heavy objects on the power cable. Fire can result from
damaged power cables.
 Do not handle power plug and adapter with wet hands. Electrical shock may result.
 Immediately power off the product and unplug the AC adapter if smoke or odors emit from the product and
adapter. Fire can result from improper use.
 Immediately power off the product and unplug the AC adapter if water or other liquids are present. Fire can
result from improper use.
 Product
 Promi-SD meets the RS-232 standards. Do not wire with non-standard products. Damage to your products may
result from improper use.
 Do not drop or subject the device to impact. Damage to your products may result from improper use.

Promi-SD 205-OA User Manual – Before Using the Product 5
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
 Keep away from harsh environments including humid, dusty, and smoky areas. Damage to your products may
result from improper use.
 Do not use excessive force on the buttons or attempt to disassemble the device. Damage to your products
may result from improper use.
 Do not place heavy objects on the product. Damage to your products may result from improper use.
General Terms and Conditions of Sale
1. GENERAL. These general terms and conditions of sale (along with any associated written specification, quotation and/or supplemental terms and conditions provided by
Seller) exclusively will govern the sale or licensing by Seller of all goods and services (including without limitation, hardware, firmware and software products, training,
programming, maintenance, engineering, parts, repair and remanufacturing services – hereinafter, "Products") furnished to Buyer hereunder, whether such sale or licensing
is effected by paper-based transactions or via facsimile or other forms of electronic data interchange or electronic commerce, and represents the entire agreement between
Buyer and Seller with respect thereto. Buyer’s receipt or acceptanceof delivery of any of theProducts ordered or purchased hereunder willconstitute its acceptance of these
terms and conditions. No addition or modification to these terms and conditions will be binding on Seller unless agreed to in writing signed by an authorized representative at
Seller’s headquarters. Seller objects to and rejects other terms and conditions that may be proposedby Buyer or that appear on or are referenced in Buyer’s purchase order
or requisition that are in addition to or otherwise not consistent with the terms and conditions set forth or referenced herein. This product is produced by SENA Technologies,
Inc.
2. WARRANTY. (a) Hardware: Seller warrants that new hardware Products furnished here-under will be free from defects in material, workmanship and design for a period
of one (1) year from the date of invoice from Seller or its appointed distributor, as the case may be. Repaired or replacement Products provided as a result of this warranty
subparagraph are similarly warranted for a period of six (6) months from the date of shipment to Buyer or the remainder of the original warranty term for that particular
Product, whichever is longer. (b) Software and Firmware: Unless otherwise provided in a Seller or third party license, Seller warrants that standard software or firmware
Products furnished hereunder, when used with Seller-specified hardware, will perform in accordance with published specifications prepared, approved, and issued by Seller
for a period of one (1) year from the date of invoice from Seller or its appointed distributor, as the case may be. Seller makes no representation or warranty, express or
implied, that the operation ofthe softwareor firmware Products will beuninterrupted or error free, or that the functions contained therein will meet orsatisfy Buyer's intended
use or requirements. (c) Non-Warranty Factory Remanufacture, Repair and Field Exchange: Seller warrants that non-warranty factory remanufactured or field exchanged
hardware Products or repaired hardware Product components will befree from defects in material and workmanship for a period of one (1) year from the date of invoice from
Seller or its appointed distributor, as the case may be. Repaired or replacement Products provided as a result of this warranty subparagraph are warranted for a period of
thirty (30) days from the date of shipment to Buyer or the remainder of the original warranty term, whichever is longer. (d) Services: Seller warrants that Products comprised
solely of services (e.g., training, on-site repair, engineering and custom application programming services) will be performed by appropriately skilled personnel employed or
retained by Seller. (e) “Open Box”Products: Seller warrants that hardware Products sold as “Open Box”(e.g., customer and distributor returns, factory refurbished or
reconditioned, etc.) will be free from defects in material and workmanship for a period of ninety (90) days from the date of invoice from Seller or its appointed distributor, as
the case may be. “Open Box”Products, while serviceable, may not reflect the latest series or revision. Repaired or replacement Products provided as a result of this
warranty subparagraph are similarly warranted for a period of thirty (30) days fromthe date of shipment to Buyer or the remainder of the original ninety-day warranty term for
that particular Product, whichever is longer. (f) Buyer Specifications/Compatibility: Seller does not warrant and will not be liable for any design, materials, construction criteria
or goods furnished or specified by Buyer (including that sourced from other manufacturers or vendors specified by Buyer). Any warranty applicable to such Buyer-specified
items will be limited solely to the warranty, if any, extended by the original manufacturer or vendor directly or indirectly to Buyer. Seller does not warrant the compatibility of
its Products with the goods of other manufacturers or Buyer’s application except to the extentexpressly represented in Seller’s published specifications or written quotation.
(g) Recyclable Materials: In keeping with environmental policies and practices, Seller reserves the right to utilize in its product manufacturing, repair and remanufacturing
processes certain recyclable materials (e.g., fasteners, plastics and the like) or remanufactured parts equivalent to new in performance or parts which may have been
subject to incidental use. However, such utilization will not affect any provided Product warranty or published reliability statistics. (h) Remedies: Remedies under the above
warranties will be limited, at Seller’s option, to the replacement, repair, re-performance or modification of, or issuance of a credit for the purchase price, of the Products
involved, and where applicable, only after the return of such Products pursuant to Seller's instructions. Replacement Products may be new, remanufactured, refurbished or
reconditioned at Seller’s discretion. Buyer requested on-site warranty service (consisting of time, travel and expenses related to such services) will be at Buyer’s expense.
The foregoing will be the exclusive remedies for any breach of warranty or breach of contract arising therefrom. (i) General: Warranty satisfaction is available only if (a) Seller
is provided prompt written notice of the warranty claim and (b) Seller’s examination discloses that any alleged defect has not been caused by misuse; neglect; improper
installation, operation, maintenance, repair, alteration or modification by other than Seller; accident; or unusual deterioration or degradation of the Products or parts thereof
due to physical environment or electrical or electro-magnetic noise environment. (j) THE ABOVE WARRANTIES ARE IN LIEU OF ALL OTHER WARRAN-TIES AND
CONDITIONS, WHETHER EXPRESSED, IMPLIED OR STATUTORY, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
USE, OR PERFORMANCE OR APPLICATION WARRANTIES, TO THE FULLEST EXTENT PERMITTED BY APPLI-CABLE LAW. Rights under the above warranties
(subject to noted limitations) extend to Buyer’s customers if Buyer is a Seller-appointed distributor for the Products.
3. DISCLAIMER AND LIMITATION OF LIABILITY. TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, SELLER WILL NOT BE LIABLE FOR ANY
BUSINESS INTERRUPTION OR LOSS OF PROFIT, REVENUE, MATERIALS, ANTICIPATED SAVINGS, DATA, CONTRACT, GOODWILL OR THE LIKE (WHETHER
DIRECT OR INDIRECT IN NATURE) OR FOR ANY OTHER FORM OF INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND. SELLER'S MAXIMUM
CUMULATIVE LIABILITY RELATIVE TO ALL OTHER CLAIMS AND LIABILITIES, INCLUDING OBLIGATIONS UNDER ANY INDEMNITY, WHETHER OR NOT INSURED,
WILL NOT EXCEED THE COST OF THE PRODUCT(S) GIVING RISE TO THE CLAIM OR LIABILITY. SELLER DISCLAIMS ALL LIABILITY RELATIVE TO GRATUITOUS
INFORMATION OR ASSISTANCE PROVIDED BY, BUT NOT REQUIRED OF SELLER HEREUNDER. ANY ACTION AGAINST SELLER MUST BE BROUGHT WITHIN
EIGHTEEN (18) MONTHS AFTER THE CAUSE OF ACTION ACCRUES. THESE DISCLAIMERS AND LIMITATIONS OF LIABILITY WILL APPLY REGARDLESS OF ANY
OTHER CONTRARY PROVISION HEREOF AND REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT (INCLUDING NEGLIGENCE AND
STRICT LIABILITY) OR OTHERWISE, AND FURTHER WILL EXTEND TO THE BENEFIT OF SELLER’S VENDORS, APPOINTED DISTRIBUTORS AND OTHER
AUTHORIZED RESELLERS AS THIRD-PARTY BENEFICIARIES. EACH PROVISION HEREOF WHICH PROVIDES FOR A LIMITATION OF LIABILITY, DISCLAIMER OF
WARRANTY OR CONDITION OR EXCLU-SION OF DAMAGES IS SEVERABLE AND INDEPENDENT OF ANY OTHER PROVISION AND IS TO BE ENFORCED AS
SUCH.
4. INTELLECTUAL PROPERTY INDEMNITY. Except as excluded herein, Seller will defend any suit or proceeding brought against Buyer arising out of a claim that the
design or construction of the Products sold or licensed hereunder by Seller infringes any patent, copyright or trademark granted or registered in the country of Seller’s
shipping destination, provided (a) Buyer promptly notifies Seller in writing of any such claim and any suit or proceeding, (b) at Seller’s expense, Buyer gives Seller the sole
right to defend, settle and control the defense of the suit or proceeding, (c) Buyerprovides all necessary information and assistance for such defense or settlement, and (d)
Buyer takes no position adverse to Seller in connection with such claim. In the event Seller is obligated to defend such suit or proceeding, Seller will pay all costs and
damages finally awarded or agreed upon by Seller that are directly related thereto. Seller’s obligations under this paragraph will be fulfilled if Seller, at its option and
expense: (i) procures for Buyer the right to continue using such Products, (ii) replaces the same with non-infringing equipment/software having functionality similar to that of
the Products, (iii) modifies the Products to make them non-infringing while retaining similar functionality, or (iv) if (i)-(iii) are not commercially practicable, refunds to Buyer the
purchase price of the affected Products in exchange for their return. Seller will have no obligation to defend or for any other liability with respect to: [a] any suit or proceeding
to the extent based on or arising out of a configuration or modification made, specified or requested by Buyer and which is incorporated into or constitutes the Products, [b]
the use of the Products in a process or application specified, requested or controlled by Buyer or any third parties, or [c] the use of the Products in combination with other
equipment, software or materials not supplied by Seller. As used in this paragraph, the term “Products”shall mean only Seller’s standard hardware and software that are
generally commercially available, and expressly excludes third-party-branded equipment/software. THIS PARAGRAPH IS IN LIEU OF ALL WARRANTIES OR
REPRESENTATIONS, WHETHER EXPRESS OR IMPLIED, THAT THE PRODUCTS WILL BE FREE OF THE RIGHTFUL CLAIM OF ANY THIRD PARTY BY WAY OF
INFRINGEMENT OR THE LIKE.

Promi-SD 205-OA User Manual – Before Using the Product 6
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
5. RESALE OF THIRD-PARTY BRANDED PRODUCTS AND SERVICES. NOTWITHSTANDING ANY OTHER PROVISION HEREIN, SELLER MAKES NO
REPRESENTATIONS, PROVIDES NO INDEMNITIES (INTELLECTUAL PROPERTY OR OTHERWISE), AND DISCLAIMS ALL WARRANTIES OF ANY KIND, EXPRESS
OR IMPLIED RELATIVE TO ANY THIRD-PARTY BRANDED PRODUCT OR SERVICE (INCLUDING TRAINING) WHICH MAY BE RESOLD OR SUBLICENSED BY
SELLER AS A DISCRETE ITEM HEREUNDER.
6. LICENSED SOFTWARE AND FIRMWARE. Use of Products comprised of software or firmware may be subject to Buyer’s acceptance of additional terms and conditions
set forth in separate Seller or third-party license agreements that will control to the extent necessary to resolve any conflict with the terms and conditions stated or otherwise
referenced herein. In the absence of a separate Seller’s license agreement, Buyer is granted a non-exclusive, non-transferable license to use provided Seller’s software or
firmware only inobject code form and solely in conjunction with Seller-provided Products, with no rights to sublicense, disclose, disassemble, decompile, reverse engineer,
or otherwise modify the software or firmware.
7. PACKING AND MARKING. Buyer-specified packing or marking may be subject to additional charges not otherwise included in the price of the Products.
8. WEIGHTS AND DIMENSIONS. Published or advertised weights anddimensions are estimates or approximations only and are not warranted.
9. PRICES. Prices and otherinformation shown in any Seller publication (including product catalogs and brochures) are subject to change without notice and to confirmation
by specific quotation. Such publications are not offers to sell and are maintained only as a source of general information. Prices do not include sales, use, excise, customs,
value-added or similar taxes. Buyer will pay or reimburse Seller for all such taxes as may be applicable. Time and material services will be provided in accordance with
Seller’s published service rates (including applicable overtime and travel expenses) in effect as of the date such services are provided, unless otherwise confirmed by
Seller’s written quotation or order acknowledgment. Billable service time includes travel time to and from the job site and all time Seller’s representatives are available for
work and waiting (whether on or off the job site) to perform the services.
10. CHANGES AND SUBSTITUTIONS. Buyer-requested order changes, including those affecting the identity, scope and delivery of the Products, must be documented in
writing and are subject to Seller’s prior approval and adjustments in price, scheduling and other affected terms and conditions. In any event, Seller reserves the right to reject
any change that it deems unsafe,technically inadvisable or inconsistent with established engineering or quality guidelines and standards, or incompatible with Seller's design
or manufacturing capabilities. Seller further reserves the right to substitute using the latest superseding revision or series or equivalent Product having comparable form, fit
and function.
11. RETURNS. All returns of Products will be pursuant to Seller’s instructions. Non-warranty returns of unused and resalable Products for credit will be subject to Seller’s
return policies in effect at the time, including applicable restocking charges and other conditions of return. Products returned under warranty must be properly packed and
shipped to Seller-specified locations. Shipping containers must be clearly marked per Seller’s instruction and shipped freight prepaid by Buyer. Notwithstanding the foregoing,
all sales of “Open Box”Products and any third-party branded products are final and do not qualify for non-warranty return.
12. ORDER CANCELLATION. Cancellation by Buyer prior to shipment is permitted only by written notice and upon payment to Seller of reasonable cancellation and
restocking charges, including reimbursement for direct costs. Cancellation charges associated with orders for custom Products or Products specifically manufactured to
Buyer’s specification may equal the actual selling price of the Products. Seller has the right to cancel an order for cause at any time by written notice, and Seller will be
entitled to cancellation and restocking charges as identified above. No termination by Buyer for cause will be effective unless and until Seller has failed to correct such
alleged cause within forty-five (45) days after receipt of Buyer’s written notice specifying such cause.
13. FORCE MAJEURE. Seller will not be liable for any loss, damage or delay arising out of its failure (or that of its subcontractors) to perform hereunder due to causes
beyond its reasonable control, including without limitation, acts of God, acts or omissions of Buyer, acts of civil or military authority, fires, strikes, floods, epidemics,
quarantine restrictions, war, riots, acts of terrorism, delays in transportation, or transportation embargoes. In the event of such delay, Seller’s performance date(s) will be
extended for such length of time as may be reasonably necessary to compensate for the delay.
14. DISPUTES. The parties will attempt in good faith promptly to resolve any dispute arising hereunder by negotiations between representatives of the parties who have
authority to settle the dispute. If unsuccessful, the parties further will attempt in good faith to settle the dispute by non-binding third-party mediation, with mediator fees and
expenses apportioned equally to each side. Any dispute not so resolved by negotiation or mediation may then be submitted to a court of competent jurisdiction in accordance
with the terms hereof. These procedures are the exclusive procedures for the resolution of all such disputes between the parties.
15. GOVERNING LAW AND FORUM. The agreement evidenced hereby and all disputes arising thereunder will be governed by and interpreted in accordance with the
internal laws and will be subject to the exclusive jurisdiction of the courts of the state, province or other governmental jurisdiction in which Seller’s principal place of business
resides, but specifically excluding the provisions of the 1980 UN Convention on Contracts for the International Sales of Goods. Should any term or provision hereof be held
wholly or partly invalid or unenforceable under applicable law, the remainder of the agreement evidenced hereby will not be affected thereby.
16. ASSIGNMENT. The agreement evidenced hereby may not be assigned by either party without the written consent of the other (which consent will not be unreasonably
withheld). However, consent will not be required for internal transfers and assignments as between Seller and its parent company, subsidiaries or affiliates as part of a
consolidation, merger or any other form of corporate reorganization.
17. LANGUAGE. The parties acknowledge that they have required that the agreement evidenced hereby be drawn up in English. Les parties reconnaissent avoir exigé la
rédaction en anglais du Contrat. In the event of a conflict between the English and other language versions, the English version will prevail.

Promi-SD 205-OA User Manual – 1. Getting Started 7
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
1. Getting Started
Features of Promi-SD
Components
Assembly
Locating the Controls
get UNWIRED, it’s easy!

Promi-SD 205-OA User Manual – 1. Getting Started 8
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Features of Promi–SD
 Reliability and Interoperability
Promi-SD is a terminal device for wireless serial communication using the Bluetooth technology that is international
standard of short range wireless communications. Promi-SD accomplishes more reliable wireless communication. As
Promi-SD can communicate with other Bluetooth devices, user may construct various communications with it.
Promi-SD 202/205 OA provides wireless communication with communication range up to 100m (Promi-SD202, 205) for
user’s various applications. In terms of noise, Promi-SD delivers better quality of communication than standard RS232
cables.
 Compact Design
Promi-SD has the most compact design of the same kind devices and can be placed conveniently into any devices or
equipments. Its detachable antenna of variety optimizes the quality and distance of wireless communications.
 Easy Configuration and Adaptation
Promi-SD can be configured and controlled by typical AT commands. User can easily configure Promi-SD on the
terminal program such as HyperTerminal and implements the wireless communication without modifying user’s existing
serial communication program. In addition to the basic AT commands, Promi-SD provides some expanded AT
commands for its various functions.
User friendly PromiWizard andPromiWIN are also provided for easy setup on Microsoft Windows.
For Promi-SD205, user can setup the serial port parameters by dip switch without PC.
 Security
The FHSS (Frequency Hopping Spread Spectrum) technique of Bluetooth lets Promi-SD have less radio interference and
no danger of hacking in air. Promi-SD also supports authentication and data encryption.
 Benefits
 No cable installation
 Free from the environmental limitations
 Easy relocation
 Simple maintenance

Promi-SD 205-OA User Manual – 1. Getting Started 9
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Promi-SD205
Stub Antenna
DC 5V Power Cable
Fig.1
-
1 Components of Promi
-
SD
※Antenna is left-hand threaded.
Fig.1-2 Assembly of Promi-SD
※Use of non-authorized power
adapter is not recommended.
Components
Please check the components of Promi-SD in Fig. 1-1 when purchasing. The picture of product may differ by models.
The components of the package may change for improving product capacity or quality without notice.
Assembly
Special RS232 Cable (Female-Female)
ONLY for PC to PROMI-SD202/205-OA connection
Part no. PSD00-00070

Promi-SD 205-OA User Manual – 1. Getting Started 10
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Locating the Controls

 Front Panel †
Fig.1-3 Locating the Controls
Front Panel †
Power Jack
Back Label ‡
Power Switch
Reset Button

Promi-SD 205-OA User Manual – 2. Configurations 11
Copyright © 2006 Sena Technologies, Inc. All rights reserved.

Promi-SD 205-OA User Manual – 2. Configurations 12
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
get UNWIRED, it’s easy!
2. Configurations
Operation Modes
LED Indicators
Serial Ports
Reset to Factory Defaults
PromiWizardP
™
P
PromiWINP
™
P
Terminal Program
Dip Switch
Pairing Button

Promi-SD 205-OA User Manual – 2. Configurations 13
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Operation Modes
In addition to the serial port configurations such as bit/second, data bit, parity, stop bit, flow control, Promi-SD has some
configurations for Bluetooth. For getting the most out of Promi-SD, user should understand the following Bluetooth
connection schemes.
A Bluetooth device can play a role as a master or slave. Master tries to connect itself to other Bluetooth device, and
slave is waiting to be connected from other Bluetooth devices. A Bluetooth connection is always made by a pair of
master and slave. A slave can be in two modes, Inquiry Scan or Page Scan mode. Inquiry Scan mode is waiting the
packet of inquiry from other Bluetooth devices and Page Scan mode is waiting the packet of connection from other
Bluetooth devices. Every Bluetooth device has its unique address, called BD (Bluetooth Device) address, which is
composed of 12 hexa-decimal numbers.
Promi-SD has 4 operation modes as follows. Each mode can be identified with LED indicators as illustrated in next
section.
 Mode0
Promi-SD must be in Mode0, when it is directly controlled by AT commands.
In this mode, there is no response when power on or software reset, and Promi-SD is just waiting for AT command input.
Neither master nor slave is assigned to Promi-SD in mode0. User can change the configurations of Promi-SD in this mode.
The factory default is set to Mode0.
 Mode1
Promi-SD tries to connect the last connected Bluetooth device.
Promi-SD in Mode1 is to be a master and tries to connect the last connected Bluetooth device. Promi-SD always stores
the BD address of the Bluetooth device to which Promi-SD has connected last time. When Promi-SD is initially used or
after hardware reset, there is no BD address stored in Promi-SD. In this case, Mode1 does not make any sense and
mode change from other operation modes to Mode1 is not allowed. The mode change to Mode1 can be made after
Promi-SD succeeds to connect to other Bluetooth device in Mode0. Once changed to Mode1, Promi-SD will try to
connect automatically the last connected Bluetooth device whenever power on or software reset.
Promi-SD in Mode1 cannot be discovered or connected by other Bluetooth devices.
 Mode2
Promi-SD is waiting for the connection from the last connected Bluetooth device.
Promi-SD in Mode2 is to be a slave and waiting for the connection only from the last connected Bluetooth device. Just
like Mode1, if there is no BD address stored in Promi-SD, the mode change from other operation modes to Mode2 is not
allowed. Once changed to Mode2, Promi-SD will wait for the connection from the last connected Bluetooth device
whenever power on or software reset.
Promi-SD in Mode2 cannot be discovered or connected to Bluetooth devices other than the last connected device.
 Mode3
Promi-SD is waiting for the connection from any other Bluetooth devices.
Promi-SD in Mode3 acts like in Mode2, but allows any connection from other Bluetooth device. Most of general
Bluetooth device is set to Mode3.
Promi-SD in Mode3 can be discovered and connected from any other Bluetooth devices.

Promi-SD 205-OA User Manual – 2. Configurations 14
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
LED Indicators
Indicator Power LED Standby LED Connect LED
Mode0 Green ┏━━━━━━━ Red ┏━━━━━━━
Mode1 Green ┏━━━━━━━ Green (every 1 sec) ┏┓
Mode2 Green ┏━━━━━━━ Green (every 3 sec) ┏┰┓
Mode3 Green ┏━━━━━━━ Green (every 3 sec) ┏┰┓
Connected Green ┏━━━━━━━ Green ┏━━━━━━━
RS232-Tx and RS232-Rx LED are blinking accordingly when data is transmitted. For small data transmission, it may be
hard to recognize the quick blinking.
Serial Ports
The applicable settings for serial ports are as follows.
Serial Port Settings Values
Baud rate 1200, 2400, 4800, 9600 , 19200, 38400, 57600, 115200, 230400
Data bit 8
Parity No parity , Even parity, Odd parity
Stop bit 1 , 2
Hardware Flow Control No use
The values in box are the factory defaults.
 Data Bit
Promi-SD supports only 8 data bit. In the case of 7 data bit, please contact the technical support.
Reset to Factory Defaults
To turn back all the configurations to its factory settings, press the reset button depicted in Fig. 1-3. Press the reset
button with a narrow pointed tool like paper clip longer than 1 second. Reset works only when power is on.
Dip Switch (Promi-SD205 OA)
This feature is only on Promi-SD205 OA. With the combination of 4 slot dip switches, baud rate can be set simply without
host computer.
Pairing Button
Dip Switch
Reset Button

Promi-SD 205-OA User Manual – 2. Configurations 15
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Upper 3 dip switches are used for setting baud rate. If the baud rate needs to be set out of the range given below,
PromiWIN or terminal program should be used for extended AT commands. At this time combination of dip switches
must be complied with AT cmd. Then baud rate will go back to 9600 as default.
2400 4800 9600 19.2K 38.4K 57.6K 115.2K AT cmdBaud
Rate
No use No useHardware Flow Control
Handshaking
Pairing Button
Promi-SD205-OA provides Pairing Button for instant configuration without PC to make an automatic connection
between two Promi-SDs. For convenience sake, name two Promi-SDs as SD1 and SD2 respectively.
Turn off all the nearby Promi-SD
Turn on SD1 and SD2 and hardware reset both of them by pressing Reset Button.
Press the Pairing Button of SD1 for 2 seconds until Standby LED turns off and Connect LED blinks 3 times every 2 seconds.
Keep the power ON.
Press the Pairing Button of SD2 for 2 seconds until Standby LED turns off and Connect LED blinks 3 times every 2 seconds.
Now press again the Pairing Button for 2 seconds until Connect LED blinks every 0.5 second.
Wait for SD1 & SD2 to be connected for a while until Connect LED’s of SD1 and SD2 is lit in green. It takes about 10
seconds to make a connection. If there are many Bluetooth devices nearby, it will take a little bit more.
Turn SD1 off and on. Connect LED blinks twice in green every 3 seconds.
Turn SD2 off and on. Connect LED blinks once in green every 1 second.
Now a pair of Promi-SD is configured to make automatic connection, whenever power off and on.
Just use this pair of Promi-SD like virtual serial cable.
* Note: While pairing is progressing through the pairing buttons, the Command Response doesn’t operate
automatically. Then, the response messages such as OK, Connect, Disconnect and so on are not sent by Promi-SD.
SD 1 status LED SD 2 status LED
1. hard reset Mode0 Standby LED turn on. 1. hard reset Mode0 Standby LED turn on.
2. push pairing
button
Mode3 Connect LED blinks 3
times every 2 sec.
2. push pairing
button
Mode3 Connect LED blinks 3
times every 2 sec.
3. 3. push pairing
button agian
Mode1 Connect LED blinks every
0.5 sec.
4. connected Slave Connect LED is lit in green 4. connected Master Connect LED is lit in green
Configuration Software
Configuration Software Usage Operating Platform
PromiWIN Individual setup of Promi-SD MS Windows 98SE or higher
PromiUpdater Firmware Update MS Windows 98SE or higher
This configuration software comes with the product, which also can be downloaded from http://www.sena.com
PromiWIN

Promi-SD 205-OA User Manual – 2. Configurations 16
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
PromiWIN is a program running on Microsoft Windows for the configuration of Promi-SD. Install PromiWIN on your
computer. Plug a Promi-SD into the serial port of the computer and turn on the power. Run PromiWIN.
Set each option properly and click [Confirm]. If the settings are different from the host computer, error message will
pop up. If the Promi-SD is in the status of connection, warning message will pop up. Then the current connection can
be cancelled by [Disconnect] button on the main window.

Promi-SD 205-OA User Manual – 2. Configurations 17
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
Serial port settings can be changed by <Start Configuration> and <PromiWIN Configuration> of PromiWIN in the menu
bar at upper left corner of the window without re-running the PromiWIN program.
The icons in the left side window come to the corresponding windows.
In device configuration window, hardware reset can be executed or operation mode and RS232 can be configured as
well. Security option also can be configured in this window.
Promi-SD supports two security options, Authentication and Encryption. If you check the Authentication option, you
must also enter the Pin Code value. If the authentication is activated, the connection, only between the Master and
Slave device that share the same Pin Code, is established. In case that Promi-SD connects to other Bluetooth device,
you must enter the other device’s Pin Code in Promi-SD. In general Bluetooth devices, 1234 or 0000 is used as a default
value. If you check Encryption option, the Promi-SD encrypts packets and sends them. The Encryption options works
well in case that only one between Master and Slaveuses this option.
Promi-SD has 4 response messages, ‘OK’, ‘ERROR’, ‘CONNECT’, and ‘DISCONNECT’. In some cases, these responses can
affect the host system unexpectedly. To prevent this, user can set the Command response to ON or OFF.

Promi-SD 205-OA User Manual – 2. Configurations 18
Copyright © 2006 Sena Technologies, Inc. All rights reserved.
For Promi-SD205 OA pin 4 and pin 5 are connected in the hardware to disable hardware flowcontrol. Thus H/W Flow
Control option will not work in this case. When the dip switch value isn’t ATcommand mode, the RS-232 menu is
disabled.
Click [Apply] button to reflect the given options toPromi-SD actually.
Connect(out) icon will show the following window to search and connect other Bluetooth devices.
Click [Search] button to search nearby Bluetooth devices. The maximum number of devices to be searched can be
controlled. Select one of the devices searched and click [Connect] button. The selected Bluetooth device must be in
Page scan mode. Click [Disconnect] button to cancel the connection normally.
After the connectionis established, you can test sensitivity through the START button.
The sensitivity test shows LInkQuality and RSSI values. If the LinkQuality approaches to 255 and RSSI approaches to 0, the
sensitivity is good. In general, when the distance is 10 meters, the sensitivity is the best. You can push the STOP button in
order to terminate the sensitivity test. The sensitivity test will continue until the STOP button is puished. If you close the the
PromiWin without pushing the STOP button, you must restart SD to terminate the test.
Connection(in) icon will show the following window to make Promi-SD wait to a connection from the other Bluetooth
device. The waiting time in seconds can be controlled. With 0 input for this waiting time, Promi-SD keeps waiting for
connection until [Cancel] button is clicked.
