Televes 149884 User manual

Antenna Kit / Kit Antena
Ref. 149884 (Ant-149831 + PSU-550104)
A
O
C
M x2
L x4
F x2
R x2 S x2 T x4 U x2 V x3
H x2
N x2
W x8
G x2
J x2 K x2
M6x25mm M6x30mm M6x33mm M6x40mm
(a1)
(a2)
(a3)
(c4)
(a4)
(b1)
UHF Directors
UHF Reectors
Main Assembly
VHF Reector Extension
VHF Reectors
Mounting Clamp
Assemblies
UHF Director Spacers
Support Braces
Dipole Assembly
Reector Self-locking Clamps
Fastening hardware
Connector PSU
Included 10mm wrench
(b2)
(b3)
MIX LR
Z
4x32mm
B1
B2
B3
D
E
Additional spare parts (x1)
PQ

2022 © Copyright, Televés S.A.U.
Televes USA LLC. Norfolk Tech Center 16596 E. 2nd Avenue Aurora, CO 80011 [e-mail] www.televes.com
Technical specications / Características técnicas
BOSS ON (Active)
Operating band Banda de trabajo MHz
High VHF
174 - 216
CH7 - CH13
UHF
470 - 608
CH14 - CH36
Gain Ganancia dBi 36.5 max.* 46 max.*
Output level Nivel de salida Auto*
Power supply Alimentación V 12
Consumption Consumo mA 70 max
Weight Peso lb / g 8.4 / 3820
Dimensions Dimensiones in / mm 84.1 x 29 x 34 / 2137 x 735 x 864
Wind load Carga al viento N 182.4 (@ 80 miles/h)(@ 130Km/h)
250.8 (@ 93 miles/h)(@ 150Km/h)
* The gain is automatically adjusted
according to the level of output.
La ganancia varía automáticamente
en función del nivel de salida.
Scan code to watch assembly video
Escanee el código al video de montaje
Safety Instructions:
LIGHTNING PROTECTION
If installed outdoors, be sure the antenna system is grounded so
as to provide protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code ANSI/NFPA70, or
CSA C22.1 sections 10, 16, and 54, of the Canadian Electrical Code,
provide information with respect to proper grounding of the mast
and supporting structure, grounding of the antenna lead-in wire to
an antenna discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode (see gure and
instructions).
Mount the lightning arrestor or 75 ohm coaxial grounding block as
close as possible to where the 75 ohm coaxial cable down lead enters
the house.
The ground wires for both the mast and the down lead should be
copper or aluminium wire, number eight (8) or larger.
The down lead wire from the antenna to the lightning arrestor and
the mast ground wire should be secured to the house, spaced from
four (4) to six (6) feet apart.
In the case of a “ground up” antenna installation it may not be
necessary to ground the mast if the mast extends four or more feet
in the earth. Consult a TV serviceman for the proper depth in your
location.
WARNINGS
To prevent re or shock hazard, do not expose the included power
supply to rain or moisture.
Installation of o-air antennas near power lines is dangerous. For
your safety, follow the installation instructions.
Any alteration or modication to the product or usage not in
accordance with product instructions voids the warranty.
Antenna Lead
in Wire
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
NEC - National Electrical Code
Ground
clamp
Electric Service
Equipment
Ground clamps
Power service Grounding Electrode System
(NEC Art 250, Part H)
Antenna Discharge Unit
(NEC Section 810-20)
(May substitute a 75 ohm
Coax Grounding Block)
Grounding Conductors
(NEC Section 810-21)
3 1 4, 5, 12 2, 11, 13 6, 7 8, 9, 10
A00625
High-VHF
This antenna provides optimal reception
for the following zone(s)
Esta antena brinda recepción óptima para las siguientes zonas
See www.antennaweb.org for the list of broadcasters
in each reception zone where you live.
Consulte www.antennaweb.org para obtener una lista de
emisoras en cada zona de recepción donde Usted reside.
UHF
This antenna provides optimal reception
for the following zone(s)
Esta antena brinda recepción óptima para las siguientes zonas
See www.antennaweb.org for the list of broadcasters
in each reception zone where you live.
Consulte www.antennaweb.org para obtener una lista de
emisoras en cada zona de recepción donde Usted reside.
