Telit Wireless Solutions GainSpan GS2011M Installation manual

GS2011M Low Power Wi-Fi Module
Hardware User Guide
1VV0301482 Rev. 5.0 – 2018-01-10

1VV0301482 Rev. 5.0 Page 2 of 171 2018-01-10
GS2011M Low Power Wi-Fi Module Hardware User Guide
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
NOTICE
While reasonable efforts have been made to assure the accuracy of this document, Telit assumes
no liability resulting from any inaccuracies or omissions in this document, or from use of the
information obtained herein. The information in this document has been carefully checked and is
believed to be reliable. However, no responsibility is assumed for inaccuracies or omissions. Telit
reserves the right to make changes to any products described herein and reserves the right to
revise this document and to make changes from time to time in content hereof with no obligation
to notify any person of revisions or changes. Telit does not assume any liability arising out of the
application or use of any product, software, or circuit described herein; neither does it convey
license under its patent rights or the rights of others.
It is possible that this publication may contain references to, or information about Telit products
(machines and programs), programming, or services that are not announced in your country.
Such references or information must not be construed to mean that Telit intends to announce
such Telit products, programming, or services in your country.
COPYRIGHTS
This instruction manual and the Telit products described in this instruction manual may be,
include or describe copyrighted Telit material, such as computer programs stored in
semiconductor memories or other media. Laws in the Italy and other countries preserve for Telit
and its licensors certain exclusive rights for copyrighted material, including the exclusive right to
copy, reproduce in any form, distribute and make derivative works of the copyrighted material.
Accordingly, any copyrighted material of Telit and its licensors contained herein or in the Telit
products described in this instruction manual may not be copied, reproduced, distributed, merged
or modified in any manner without the express written permission of Telit. Furthermore, the
purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel,
or otherwise, any license under the copyrights, patents or patent applications of Telit, as arises by
operation of law in the sale of a product.
COMPUTER SOFTWARE COPYRIGHTS
The Telit and 3rd Party supplied Software (SW) products described in this instruction manual may
include copyrighted Telit and other 3rd Party supplied computer programs stored in semiconductor
memories or other media. Laws in the Italy and other countries preserve for Telit and other 3rd
Party supplied SW certain exclusive rights for copyrighted computer programs, including the
exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly,
any copyrighted Telit or other 3rd Party supplied SW computer programs contained in the Telit
products described in this instruction manual may not be copied (reverse engineered) or
reproduced in any manner without the express written permission of Telit or the 3rd Party SW
supplier. Furthermore, the purchase of Telit products shall not be deemed to grant either directly
or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent
applications of Telit or other 3rd Party supplied SW, except for the normal non-exclusive, royalty
free license to use that arises by operation of law in the sale of a product.

1VV0301482 Rev. 5.0 Page 3 of 171 2018-01-10
GS2011M Low Power Wi-Fi Module Hardware User Guide
USAGE AND DISCLOSURE RESTRICTIONS
I. License Agreements
The software described in this document is the property of Telit and its licensors. It is furnished by
express license agreement only and may be used only in accordance with the terms of such an
agreement.
II. Copyrighted Materials
Software and documentation are copyrighted materials. Making unauthorized copies is prohibited
by law. No part of the software or documentation may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language or computer language, in any form or
by any means, without prior written permission of Telit
III. High Risk Materials
Components, units, or third-party products used in the product described herein are NOT
fault-tolerant and are NOT designed, manufactured, or intended for use as on-line control
equipment in the following hazardous environments requiring fail-safe controls: the operation of
Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic Control, Life
Support, or Weapons Systems (High Risk Activities"). Telit and its supplier(s) specifically disclaim
any expressed or implied warranty of fitness for such High Risk Activities.
IV. Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service
names are the property of their respective owners.
V. Third Party Rights
The software may include Third Party Right software. In this case you agree to comply with all
terms and conditions imposed on you in respect of such separate software. In addition to Third
Party Terms, the disclaimer of warranty and limitation of liability provisions in this License shall
apply to the Third Party Right software.
TELIT HEREBY DISCLAIMS ANY AND ALL WARRANTIES EXPRESS OR IMPLIED FROM
ANY THIRD PARTIES REGARDING ANY SEPARATE FILES, ANY THIRD PARTY MATERIALS
INCLUDED IN THE SOFTWARE, ANY THIRD PARTY MATERIALS FROM WHICH THE
SOFTWARE IS DERIVED (COLLECTIVELY “OTHER CODE”), AND THE USE OF ANY OR ALL
THE OTHER CODE IN CONNECTION WITH THE SOFTWARE, INCLUDING (WITHOUT
LIMITATION) ANY WARRANTIES OF SATISFACTORY QUALITY OR FITNESS FOR A
PARTICULAR PURPOSE.
NO THIRD PARTY LICENSORS OF OTHER CODE SHALL HAVE ANY LIABILITY FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING WITHOUT LIMITATION LOST PROFITS), HOWEVER CAUSED AND
WHETHER MADE UNDER CONTRACT, TORT OR OTHER LEGAL THEORY, ARISING IN ANY
WAY OUT OF THE USE OR DISTRIBUTION OF THE OTHER CODE OR THE EXERCISE OF
ANY RIGHTS GRANTED UNDER EITHER OR BOTH THIS LICENSE AND THE LEGAL TERMS
APPLICABLE TO ANY SEPARATE FILES, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.

1VV0301482 Rev. 5.0 Page 4 of 171 2018-01-10
GS2011M Low Power Wi-Fi Module Hardware User Guide
Note: The features described in the present document are provided by the products equipped with
the software versions equal or higher than the versions shown in the table. See also the
Revision History chapter.
PRODUCT
GS2K based Modules
Software Release
5.5.0
APPLICABILITY TABLE

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 5 of 69 2018-01-10
Table of Contents
Chapter 1 GS2011M Overview ........................................................................................................ 19
1.1 Product Overview ..................................................................................................................19
1.2 GS2011M Module Product Features .....................................................................................19
Chapter 2 GS2011M Architecture .................................................................................................... 23
2.1 Architecture Description ........................................................................................................23
2.2 Wireless LAN and System Control Subsystem .....................................................................25
2.2.1 Onboard Antenna / RF Port / Radio .............................................................................25
2.2.1.1 802.11 MAC .........................................................................................................25
2.2.1.2 802.11 PHY .........................................................................................................26
2.2.1.3 RF/Analog ............................................................................................................27
2.2.2 Network Services Subsystem ......................................................................................27
2.2.2.1 APP CPU .............................................................................................................27
2.2.2.2 Crypto Engine ......................................................................................................27
2.2.3 Memory Subsystem .....................................................................................................27
2.2.3.1 SRAM ..................................................................................................................27
2.2.3.2 ROM ....................................................................................................................28
2.2.3.3 OTP ROM ............................................................................................................28
2.2.3.4 Flash Interface .....................................................................................................28
2.2.4 Clocks ..........................................................................................................................28
2.2.5 Real Time Clock (RTC) Overview ................................................................................29
2.2.5.1 RTC Main Features .............................................................................................29
2.2.5.2 Real Time Clock Counter .....................................................................................31
2.2.5.3 RTC I/O ................................................................................................................31
2.2.5.4 DC_DC_CNTL .....................................................................................................31
2.2.6 GS2011M Peripherals ..................................................................................................31
2.2.6.1 SDIO Interface .....................................................................................................31
2.2.6.2 SPI Interface ........................................................................................................32
2.2.6.3 UART Interface ....................................................................................................32
2.2.6.4 I2C Interface ........................................................................................................33
2.2.6.5 GPIO ....................................................................................................................33
2.2.6.6 ADC .....................................................................................................................33
2.2.6.7 PWM ....................................................................................................................33
2.2.7 System States ..............................................................................................................35
2.2.8 Power Supply ...............................................................................................................38
Chapter 3 Pin-out and Signal Description ........................................................................................ 41
3.1 GS2011Mxx Device Pin-out ..................................................................................................41
3.1.1 GS2011Mxx Module Pins Description ..........................................................................42
Table 7 Errata ..................................................................................................................46
3.1.2 GS2011M Pin MUX Function .......................................................................................47
3.1.3 GS2011M Program and Code Restore Options ...........................................................49
Chapter 4 Electrical Characteristics ................................................................................................. 51
4.1 Absolute Maximum Ratings ...................................................................................................51
4.2 Operating Conditions .............................................................................................................52
4.3 Internal 1.8V Regulator ..........................................................................................................52
4.4 I/O DC Specifications ............................................................................................................53
4.4.1 I/O Digital Specifications (Tri-State) Pin Types 4mA, 12mA, and 16mA ......................53

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 6 of 69 2018-01-10
4.4.1.1 I/O Digital Specifications for VDDIO=2.7V to 3.6V ..............................................53
4.4.2 RTC I/O Specifications .................................................................................................54
4.5 Power Consumption ..............................................................................................................55
4.6 802.11 Radio Parameters ......................................................................................................56
4.7 ADC Parameters ...................................................................................................................58
Chapter 5 Package and Layout Guidelines ..................................................................................... 61
5.1 GS2011Mxx Recommended PCB Footprint and Dimensions ...............................................61
5.1.1 Surface Mount Assembly .............................................................................................63

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 7 of 69 2018-01-10
About This Manual
This manual describes the GS2011M Low Power module hardware specification.
Refer to the following sections:
• Revision History, page 8
• Audience, page 8
• Standards, page 8
• Certifications, page 8
• Documentation Conventions, page 9
• Documentation, page 12
• Contact Information, Support, page 14
• Returning Products to GainSpan, page 15
• Accessing the GainSpan Portal, page 16
• Ordering Information, page 16

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 8 of 69 2018-01-10
Revision History
This version of the GainSpan GS2011M Low Power Wi-Fi Data Sheet contains the
following new information listed in Table 1, page 8.
Audience
This manual is designed to help system designers build low power, cost effective, flexible
platforms to add Wi-Fi connectivity for embedded device applications using the GainSpan
GS2011M based module.
Standards
The standards that are supported by the GainSpan modules are IEEE 802.11 b/g/n.
Certifications
GainSpan GS2011M Low Power Wi-Fi Module has Certification Compliance for the
following:
Table 1 Revision History
Version Date Remarks
1.0 June 2015
Removed reference to external PA, LNA, and control of external RF Switch
(GS2011MIE only). See 2.2.1.2 802.11 PHY, page 26.
Added Errata notification to the Pin Signal and Pin MUX tables regarding
SPI0_OUT and SPI1_OUT signals. See Table 7, page 42 and Table 8,
page 47.
Updated Power Consumption information in Table 15, page 55.
Updated 802.11 Radio Parameters Transmit/Receive Specifications for
1Mbps and 54Mbps in Table 16, page 56.
2.0 February 2016
Updated 802.11 Radio Parameters Output power (average) and Receive
Sensitivity at antenna port in Table 16, page 56.
Updated the Note under 5.1 GS2011Mxx Recommended PCB Footprint and
Dimensions
3.0 July 2016 Updated 802.11 Radio Parameters RF Frequency Range in Table 16, page 56
4.0 November 2017 Corrected the System State - WLAN Continuous Transmit from 16dbm to
15dbm see Table 15, page 55
5.0 January 2018 Updated Output power (average) for GS2011MIE and GS2011MIZ in Table
16, page 56

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 9 of 69 2018-01-10
Hereby, GainSpan Corporation declares that the radio equipment type GS2011MIZ &
GS2011MIE is in compliance with Radio Equipment Directive (RED) 2014/53/EU. The
Declaration of Conformity (DoC) for the same is available at URL:
https://www.telit.com/red/
Documentation Conventions
This manual uses the following text and syntax conventions:
– Special text fonts represent particular commands, keywords, variables, or window
sessions
– Color text indicates cross-reference hyper links to supplemental information
– Command notation indicates commands, subcommands, or command elements
Table 3, page 9, describes the text conventions used in this manual for software procedures
that are explained using the AT command line interface.
Table 2 Certification Compliance
Category Certification
Radio regulatory Certificates FCC, IC, TELEC, RED
Wi-Fi Alliance Certificates WPS 2.0, WMM, WMM-PS, WPA and WPA2 Enterprise, WPA and WPA2
Personal.
Table 3 Document Text Conventions
Convention Type Description
command syntax
monospaced font
This monospaced font represents command strings entered on a
command line and sample source code.
AT XXXX
Proportional font
description
Gives specific details about a parameter.
<Data> DATA
UPPERCASE
Variable parameter
Indicates user input. Enter a value according to the descriptions that
follow. Each uppercased token expands into one or more other token.
lowercase
Keyword parameter
Indicates keywords. Enter values exactly as shown in the command
description.
[]
Square brackets
Enclose optional parameters. Choose none; or select one or more an
unlimited number of times each. Do not enter brackets as part of any
command.
[parm1|parm2|parm3]

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 10 of 69 2018-01-10
?
Question mark
Used with the square brackets to limit the immediately following token
to one occurrence.
<ESC>
Escape sequence
Each escape sequence <ESC> starts with the ASCII character 27 (0x1B).
This is equivalent to the Escape key.
<ESC>C
<CR>
Carriage return Each command is terminated by a carriage return.
<LF>
Line feed Each command is terminated by a line feed.
<CR> <LF>
Carriage return
Line feed
Each response is started with a carriage return and line feed with some
exceptions.
< >
Angle brackets
Enclose a numeric range, endpoints inclusive. Do not enter angle
brackets as part of any command.
<SSID>
=
Equal sign
Separates the variable from explanatory text. Is entered as part of the
command.
PROCESSID = <CID>
.
dot (period)
Allows the repetition of the element that immediately follows it multiple
times. Do not enter as part of the command.
.AA:NN can be expanded to 1:01 1:02 1:03.
A.B.C.D
IP address
IPv4-style address.
10.0.11.123
X:X::X:X
IPv6 IP address
IPv6-style address.
3ffe:506::1
Where the : : represents all 0x for those address components not
explicitly given.
LINE
End-to-line input token
Indicates user input of any string, including spaces. No other parameters
may be entered after input for this token.
string of words
WORD
Single token
Indicates user input of any contiguous string (excluding spaces).
singlewordnospaces
Table 3 Document Text Conventions (Continued)
Convention Type Description

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 11 of 69 2018-01-10
Table 4, page 11, describes the symbol conventions used in this manual for notification and
important instructions.
Table 4 Symbol Conventions
Icon Type Description
Note
Provides helpful suggestions needed in understanding
a feature or references to material not available in the
manual.
Alert Alerts you of potential damage to a program, device,
or system or the loss of data or service.
Caution Cautions you about a situation that could result in
minor or moderate bodily injury if not avoided.
Warning Warns you of a potential situation that could result in
death or serious bodily injury if not avoided.
Electro-Static Discharge
(ESD)
Notifies you to take proper grounding precautions
before handling a product.

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 12 of 69 2018-01-10
Documentation
The GainSpan documentation suite listed in Table 5, page 12 includes the part number,
documentation name, and a description of the document. The documents are available from
the GainSpan Portal. Refer to , page 15 for details.
Table 5 Documentation List
Part Number Document Title Description
1VV0301415 GS2011M Evaluation Board Quick
Start Guide
Provides an easy to follow guide on
how to unpack and setup GainSpan
GS2000 based module kit for the
GS2011M module.
1VV0301437 GS2K Module Programming User
Guide
Provides users steps to program the
on-board Flash on the GainSpan
GS2000 based modules using DOS or
Graphical User Interface utility
provided by GainSpan. The user guide
uses the evaluation boards as a
reference example board.
1VV0301463 GS2011M Serial-to-Wi-Fi Adapter
Command Reference Guide
Provides a complete listing of AT serial
commands, including configuration
examples for initiating, maintaining,
and evaluating GainSpan Wi-Fi
GS2011M series modules.
1VV0301463 GS2100M Serial-to-Wi-Fi Adapter
Command Reference Guide
Provides a complete listing of AT serial
commands, including configuration
examples for initiating, maintaining,
and evaluating GainSpan Wi-Fi
GS2100M series modules.
1VV0301435 GS2K Module Evaluation Board
Hardware User Guide
Provides instructions on how to setup
and use the GS2000 based module
evaluation board along with component
description, jumper settings, board
specifications, and pinouts.
1VV0301482 GS2011M Low Power Wi-Fi Module
Hardware User Guide
Provides information to help Wi-Fi
system designers to build systems using
GainSpan GS2011M module and
develop wireless applications.

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 13 of 69 2018-01-10
GS2100M-DS-001212 GainSpan GS2100M Low Power
Wi-Fi Module Data Sheet
Provides information to help Wi-Fi
system designers to build systems using
GainSpan GS2100M module and
develop wireless applications.
1VV0301486 GS2011MxxS Low Power Wi-Fi
Module Hardware User Guide
Provides information to help Wi-Fi
system designers to build systems using
GainSpan GS2011MxxS module and
develop wireless applications.
1VV0301464
GS2011M IP-to-Wi-Fi Adapter
Application Command Reference
Guide
Provides a complete listing of AT serial
commands, including configuration
examples for initiating, maintaining,
and evaluation GainSpan IP-to-Wi-Fi
GS2000 based modules.
Table 5 Documentation List (Continued)
Part Number Document Title Description

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 14 of 69 2018-01-10
Documentation Feedback
We encourage you to provide feedback, comments, and suggestions so that we can improve
the documentation. You can send your comments by logging into Telit Support Portal. If
you are using e-mail, be sure to include the following information with your comments:
– Document name
– URL or page number
– Hardware release version (if applicable)
– Software release version (if applicable)
Contact Information, Support
For general contact, technical support services, technical questions and to report
documentation errors contact Telit Technical Support at:
[email protected]
We recommend adding “Wi-Fi” in subject of the email. For example, the subject of email
can be “Wi-Fi: Your actual issue or question in brief” like “Wi-Fi: SPI Driver Issue”.
Also, in description of your email, please provide details about the issue, product and
module including software firmware version, module version and type, application being
used, customizations done to application, use case, issue frequency, and ability to recreate
it among other things wherever applicable.
Alternatively, for more Technical Support information or assistance, perform the following
steps:
1. Visit http://www.telit.com, go to Products> Wi-Fi and Blue-tooth, then scroll down to
the Telit Wi- Fi Portal.
2. Click Access the Portal Here icon which will direct you to the GainSpan portal
http://www.gainspan/secure/login.com
1. Log in with your customer Email and Password.
2. Select the Location.
3. Select Q&A tab.
4. Select Ask a New Question.
5. Enter your technical support question, product information, and a brief description.
For detailed information about where you can buy the Telit modules or for
recommendations on accessories and components visit:
http://www.telit.com
Our aim is to make this guide as helpful as possible. Keep us informed of your comments
and suggestions for improvements. Telit appreciates feedback from the users of our
information.

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 15 of 69 2018-01-10
Returning Products to GainSpan
If a problem cannot be resolved by GainSpan technical support, a Return Material
Authorization (RMA) is issued. This number is used to track the returned material at the
factory and to return repaired or new components to the customer as needed.
To return a hardware component:
1. Determine the part number and serial number of the component.
2. Obtain an RMA number from Sales/Distributor Representative.
3. Provide the following information in an e-mail or during the telephone call:
– Part number and serial number of component
– Your name, organization name, telephone number, and fax number
– Description of the failure
4. The support representative validates your request and issues an RMA number for
return of the components.
5. Pack the component for shipment.
Guidelines for Packing Components for Shipment
To pack and ship individual components:
– When you return components, make sure they are adequately protected with
packing materials and packed so that the pieces are prevented from moving
around inside the carton.
– Use the original shipping materials if they are available.
– Place individual components in electrostatic bags.
– Write the RMA number on the exterior of the box to ensure proper tracking.
NOTE: Do not return any components to GainSpan Corporation unless you have
first obtained an RMA number. GainSpan reserves the right to refuse shipments
that do not have an RMA. Refused shipments will be returned to the customer by
collect freight.
CAUTION! Do not stack any of the components.

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 16 of 69 2018-01-10
Accessing the GainSpan Portal
To find the latest version of GainSpan documentation supporting the GainSpan product
release you are interested in, you can search the GainSpan Portal website by performing the
following steps:
1. Visit http://www.telit.com, go to Products> Wi-Fi and Blue-tooth, then scroll down
the Telit Wi- Fi Portal.
2. Click Access the Portal Here icon which will direct you to the GainSpan portal
http://www.gainspan/secure/login.com
3. Log in using your customer Email and Password.
4. Click the Getting Started tab to view a Quick Start tutorial on how to use various
features within the GainSpan Portal.
5. Click the Agreements tab to download and upload the SLA for ADK and SDK
respectively.
6. Click on the Documents tab to search, download, and print GainSpan product
documentation.
7. Click the Software tab to search and download the latest software versions.
8. Click the Kits Purchased tab to view customer account history.
9. Click the Legal Documents tab to view GainSpan Non-Disclosure Agreement
(NDA).
10. Click the Certifications tab to view GainSpan certifications.
Ordering Information
To order GainSpan’s GS2011Mxx low power module contact a GainSpan Sales/Distributor
Representative. Table 6, page 16 lists the GainSpan device information.
NOTE: You must first contact GainSpan to set up an account, and obtain a
customer user name and password before you can access the GainSpan Portal.
Table 6 GS2011Mxx Ordering Information
Device Description Ordering Number Revision
Low power module with on-board antenna GS2011MIZ 3.3
Low power module with external antenna GS2011MIE 3.3

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 17 of 69 2018-01-10
NOTE: Modules ship with test code ONLY. Designers must first program the
modules with a released firmware version. Designers should bring out GPIO27
pin (option to pull this pin to VDDIO during reset or power-on) and UART0 or SPI0
pins to enable programming of firmware into the module. For details refer to the
Programming the GainSpan Modules document.

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 18 of 69 2018-01-10

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 19 of 69 2018-01-10
Chapter 1 GS2011M Overview
This chapter describes the GainSpan® GS2011M low power module hardware specification
overview.
• Product Overview, page 19
• GS2011M Module Product Features, page 19
1.1 Product Overview
The GS2011M low power based module provides cost effective, low power, and flexible
platform to add Wi-Fi connectivity for embedded devices for a variety of applications, such
as wireless sensors and thermostats. It uses GS2000 SoC, which combines ARM® Cortex
M3-based processors with a 802.11b/g/n Radio, MAC, security, and PHY functions, RTC
and SRAM, up to 4 MB FLASH, and on board and off module certified antenna options.
The module provides a Wi-Fi and regulatory certified IEEE 802.11b/g/n radio with
concurrent network processing services for variety of applications, while leverage existing
802.11 wireless network infrastructures.
1.2 GS2011M Module Product Features
• Family of modules with different antenna and output power options:
• GS2011MIx 22.8mm (0.90in) x 32.5 mm (1.28in) x 3.63mm (0.143in) 48-pin
PCB Surface Mount Package. Two SKU’s are:
– GS2011MIZ (on-board antenna)
– GS2011MIE (external antenna)
• The two SKUs are pin to pin compatible, and the user has to account only for
power consumption, and on-board antenna keep out (if used) to accommodate
“one size fits all” for various end applications.
• Simple API for embedded markets covering a large range of applications
• Fully compliant with IEEE 802.11b/g/n and regulatory domains:
– 802.11n: 1x1 single stream, 20 MHz channels, 400/800ns GI, MCS0 – 7
– Data rates of 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65.0, 72.2 Mbps
– 802.11g: OFDM modulation for data rates of 6, 9, 12, 18, 24, 36, 48 and 54
Mb/s
– 802.11b: CCK modulation rates of 5.5 and 11 Mbps; DSSS modulation for
data rate of 1 and 2 Mbps

GS2011M Low Power Wi-Fi Module Hardware User Guide
1VV0301482 Rev. 5.0 Page 20 of 69 2018-01-10
• Wi-Fi Solution:
• Wi-Fi security (802.11i)
– WPA™ - Enterprise, Personal
– WPA2™ - Enterprise, Personal
– Vendor EAP Type(s):
– EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2,
PEAPv1/EAP-GTC, EAP-FAST, EAP-TLS
• Hardware-accelerated high-throughput AES and RC4 encryption/decryption
engines for WEP, WPA/WPA2 (AES-CCMP and TKIP).
• Additional dedicated encryption HW engine to support higher layer encryption
such as IPSEC (IPv4 and IPv6), SSL/TLS, HTTPs, PKI, digital certificates, RNG,
etc.
• Dual ARM Cortex M3 Processor Platform:
•1
st Cortex M3 processor (WLAN CPU) for WLAN software
– Implements 802.11b/g/n WLAN protocol services
– 320 KB dedicated SRAM
– 512 KB dedicated ROM
•2
nd Cortex M3 processor (APP CPU) for networking software
– Implements networking protocol stacks and user application software
– 384 KB dedicated SRAM
– 512 KB dedicated ROM
• 64KB shared dual ported SRAM for inter-processor communications
• 320KB assignable (under SW control) SRAM
• Support processor clock frequencies for both CPU of up to 120MHz
• Based on Advanced Microprocessor Bus Architecture (AMBA) system
– AMBA Multilayer High-Speed Bus (AHB)
– AMBA Peripheral Bus (APB)
• On-module controller
– Manages read/write/program/erase operations to the 4 MB flash memory
device on the module
– Supports higher performance QUAD SPI protocol operations
– Active power management
