Tellur TLL511191 User manual

English
Table of contents
1 Introduction…………………………………………………………………………….
2 Kit Contents……………………………………………………………………………
3 Connection Diagram…………………………………………………………………..
4 How to use……………………………………………………………………………..
4.1 General function……………………………………………………………….
4.2 Pairing to mobile phone……………………………………………………….
4.3 Charging your…………………………………………………………………..
5 Technical specification………………………………………………………………..
6 Service and Support…………………………………………………………………..
7. Bluetooth Audio transmitter…………………………………………………………..
8. FAQ……………………………………………………………………………………..

1.Introduction
Congratulations, and thank you for choosing the Bluetooth Stereo Headphone. This manual will help you
operate the Bluetooth Stereo Headphone, but you should first familiarize yourself with the Bluetooth
functionality of your mobile phone or other devices before using the Bluetooth Stereo Headphone
Safety Rules
1\ Please follow the rules depicted in this manual closely to ensure your safety. Before using this Bluetooth
Stereo Headphone, we would strongly encourage you to read through this user manual.
2\ Be more wary of any edges, uneven surfaces, metal parts, accessories and its packaging so as to prevent
any possible injury or damage.
3\ Do not modify, repair or dismantle this Bluetooth Stereo Headphone. Doing so may result in fires, electric
shocks, complete breakdown of this Bluetooth Stereo Headphone, etc. All of which, are not covered under
warranty.
4\ Do not use any diluents or volatile liquid to clean the Bluetooth Stereo Headphone.
5\ Do not use the Bluetooth Stereo Headphone in a hazardous location.
2.Kit Contents
1 x Bluetooth Headphone H11
1 x USB Charger Cable
1 x Audio cable
1 x Bluetooth Audio Transmitter
1 x User Manual
3.Connection Diagram

4.How to use
4.1.General Functions
Desired Result Required Action
Turn on Press the " M F B "button for 3 seconds when
the device is off. (Red LED light and a tone
voice beep)
Enter the pairing mode In power off mode, Press the " M F B "button
and hold on for 8 seconds.(Blue LED and
Red LED quickly flash alternately with two
beep tone voice).
Pairing In pairing Mode use a mobile phone with
Bluetooth function or other Bluetooth
Master Device and to perform pairing action
(detail refer to the chapter about pairing).
Volume up Press the "+" and hold is for volume up
Volume down Press the "-" and hold is for volume down
Previous Short click "-"button for Previous music.
Next Short click "+"button for next music.
Turn off Press the "M F B" button for 3 seconds when
the device is on.(a tone voice beep and all
LED is off)

Play / pause click "M F B" button to play music when the device
is connected or pausing and click "M F B" button to
pause when the device is playing music.
Low battery warning (The red LED flash)
Charging Plug the charger to port of the device.
(Red LED is on)
Answer call Short click the "M F B" button while the
incoming call.
End call Short click the "M F B" button while ongoing
call.
Transfer call voice Double click the "M F B" button to transfer
the call voice between the mobile phone
and device while ongoing call.
last number redial Double click the "M F B" button In the connected
state or there is music
Reject call Press the "M F B" button for 1 - 2 seconds to
reject call when the call is ringing
Multi-point connection In pairing mode, short single the "M F B" to
enable the multipoint and double press the
"M F B" to disable the Multipoint.
Factory reset Long press" + " and " - "button for 5 second
at pairing mode to clear the paired device list
4.2.Pairing to Mobile phone or other device
To use your Bluetooth Headphone, you must first pair your Headphone with a phone or a computer. Once your
Bluetooth Headphone is paired to a specific mobile phone; they will remain paired and automatically recognize
each other whenever they are within range.
Pairing to a phone and Entertainment:
Turn on your phone and ensure its Bluetooth function is activated
Turn on the Bluetooth Stereo Headphone go to the paring mode
Search your Bluetooth devices on your phone by following the phone's instructions. Refer to your phone's
user manual for more information.
After a few second the phone will list the device as a discover device. Select it and follow your phone
instruction to select this pairing.
Then your phone will request a passkey or PIN, enter 0000 as your PIN or passkey.
Your phone will confirm the pairing, and then press Yes/Ok.
Finally, select to connect with device from your phone.
You can play music; watch TV/movie and play game with your phone, then your can hear all the sound or
music form the device. Also you can control the player by operating the device. Example, volume up and
next music.
Pairing to a computer and Entertainment:
If there is no Bluetooth function supported by your computer, a Bluetooth adapter is necessary. Fix the
adapter with your computer and ensure its Bluetooth function is activated.

Turn on the device go to the paring mode.
Open the Bluetooth software (such as BlueSoleil) installed on your computer, and selects“Search your
Bluetooth devices” function. Refer to user manual of the Bluetooth software for more information.
After a few second the “ device name” will list in Bluetooth software of your computer as a discover device.
Select this icon and click right button of mouse to select “pairing” item, then select “connect with audio
device” with same operation.
Open your media player soft to play music, watch TV/move and play game, then all the sound will be
playback on your device.
4.3.Charging your device
The device is convenient to connect to AC charger or a USB charger with Micro USB port marked with. Make
sure that your device is full charged for at least 6 hours before initial use. Insert one terminal of your charger to
AC main or USB port of PC and other terminal to Micro USB. While charging, he red LED light constantly.
When charging is completed, the blue LED turns on.
Warning:
You must select a qualified charger from a regular manufacturer.
You must charge the Bluetooth Headset if it has been not used for more than 12 months.
5.Technical specification
Parameter Value
Bluetooth Specification Bluetooth V4.1
Bluetooth Profile A2DP1.2 AVRCP1.4 HSP1.2 HFP1.6
DSP CVC6.0 Noise and Echo reduction
RF Range 10 m
Frequency Response 20Hz-20KHz
Loudspeaker Output 20mW
Signal-To-Noise ≥90dB
THD ≤3%
Playback Time about 12 hours
Charging Time about 2 hours
Dimension
(L×W×H) 180×70×162mm
Weight 150g

6.Service and Support
If your device is not performing as it should, please take it to your local service providers or dealer for service.
8. Bluetooth Audio Transmitter
Bluetooth version: Bluetooth V2.1 + EDR
Frequance range: 2.4 GHz – 2.4835 GHz
Receiving sensitivity: -74 4db
Operating distance: up to 10 m
Working time: up to 8 hours
Charging time: about 2~3 hours
Battery: 270 mAh
Pairing: press and hold the Bluetooth boot button for 6 seconds, until the red and blue LED alternate
flash, open your Bluetooth device and put it into matching condition; the pairing between the Bluetooth
headsets and the transmitter will be done automatically
7.FAQ
1\ Why is there no power even when the Stereo Headphone is power on?
Ans: Ensure the battery is being charged up to 6 hours for first time using. The LED is lighted when it starts
charging.
2\There is no sound when playback.
Ans: Check the connection between with phone or computer, if the connection is not established, please
reconnect again. Make sure the is paired and connected target phone or other master device. your device
Stereo Headphone device
3\How can I know the Bluetooth Stereo Headphone has been fully charged?
Ans: When the indicator LED turns red to blue when it is charging, it has been fully charged.
4\Why the Headphone cannot connect to second phone
Ans: Please set the Headphone to pairing mode and short press the" M F B " to enable multipoint mode
Connect the Headphone to phone A, Restart the Headphone to pairing mode and connect the Headphone to
phone B, and then use phone A paired device list to reconnect to the Headphone
