Telos XP50 User manual

Telos
Manual

Content
Specifications
About the device
Description
Package Contents
Components and Controls
Features
Power supply
Precautions
Recommendations for Battery Use
Battery Charging
Battery Installation
External Power Supply
Getting Started
Powering on and Image Settings
Button Operation
Interface
Status Bar
Quick Menu
Main Menu
Enter the Main Menu
Amplification Level
Colour Modes
Smoothing Filter
User Mode
Icon Brightness
PiP Mode
Wi-Fi Activation
Wi-Fi Settings
Microphone
Calibration Mode
General Settings
Defective Pixel Repair

Defective Pixel Repair
Restore Default Pixel Map
Device Information
Functions
Video Recording and Photography
Digital Zoom
PiP Function
Display-Off Function
Wi-Fi Function
Stadiametric Rangefinder
Installing the Device on a Tripod
USB Connection
Software
Stream Vision 2
Firmware Update
Maintenance
Technical Inspection
Technical Maintenance and Storage
Troubleshooting
Legal Compliances and Disclaimers

Specifications
You can learn more about the main parameters here.
XP50
Model XP50
SKU 77493
Microbolometer 
Type uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 17
NETD, mK < 18
Frame Rate, Hz 50
Optical
Characteristics 
Magnification, x 2.5
Smooth Digital
Zoom, x 2.5-10
Digital Zoom, x x1 - x4
Lens Focus, mm 50
Relative Aperture,
D/f' 1.0
Minimum Focus
Distance, m/y 5 / 5.5

Exit Pupil
Diameter,
mm/inch 4 / 0.16
Angular Field of
View (Horizontal x
Vertical), degree 12.4х9.3
Linear Field of
View, m at 100 m 21.8
Eyepiece Focus
Range, Dioptre +4 / -5
Detection
Distance for Deer-
Sized Objects, m/y 1800 / 1969
Display 
Type AMOLED
Resolution, Pixels 1024x768
Operational
Characteristics 
Power Supply, V 3 - 4.2
Battery
Type/Capacity/Nominal
Output Voltage
LPS7i Li-ion Battery Pack / 6400 mAh / DC
3.7 V
External Power
Supply 5 V, 9 V (USB Type-C)
Battery Run Time
at t=22°C, hours* 8.5
Degree of
Protection, IP
Code (IEC60529) IPX7
Operating
Temperature
Range, °C / °F -25 … +40 / -13 – +104

Dimensions,
mm/inch 238x72x62 / 9.37x2.83x2.44
Weight (with
battery), kg/oz 0.67 / 23.6
Video Recorder 
Photo/Video
Resolution, Pixels 1024x768
Video/Photo
Format .mp4 / .jpg
Built-in Memory 64 GB
Wi-Fi Channel** 
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.

Description
Telosthermal imaging monoculars are designed for use both at night-time
and during the day and provide exceptional image quality even in adverse
weather conditions (fog, smog, rain) and beyond obstacles like branches,
tall grass, dense foliage, etc. known to hinder target detection.
Unlike night-vision devices based on electron-optical converters, thermal
imaging devices do not need an external light source and are resistant to
bright light.
Telosthermal imagers are designed for various applications including
hunting, observation, security, terrain orientation, search and rescue
operations, etc.
To get started, see the sections:
Battery Charging
Battery Installation
Powering on and Image Settings
Stream Vision 2

Package Contents
Telos thermal imager
LPS7i battery pack with protective cover
Spare battery compartment cover
Power adapter
USB Type-C cable with USB Type-A adapter
Case
Hand strap
Quick start guide
Lens cloth
Warranty card

Components and Controls



1. Lens cover
2. Lens focus ring
3. Digital zoom adjustment ring
4. Tripod socket
5. Battery compartment
6. LPS7i battery
7. Battery compartment cover
8. Battery protective cover
9. ON/OFF/Calibration button
10. UP/REC button
11. MENU button
12. DOWN/MODE button
13. Eyepiece diopter adjustment ring
14. Operation status LED indication
15. Microphone
16. USB Type-C connector
17. LED indication of battery charge in the device
LED indicator (14) displays the current status of the device:
LED Indicator Operating Mode
Device is turned on
The device is turned on/video
recording
The device is turned on/battery
charge < 10%
The device is turned on/video
recording/battery charge <
10%

Features
Compact and lightweight
Functional and ergonomic design
8-colour display palette
3 calibration modes: Manual, Semi-Automatic, Automatic
Detection range up to 1800 m/1969 yds
Smooth digital zoom 2.5-10x
Three levels of sensitivity enhancement: Normal, High, Ultra
Stadiametric Rangefinder
Display-Off function
Defective pixel repair
Updatable firmware
Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
Fully waterproof (IPX7 rated)
Tripod mount
Video/Audio Recording
Built-in video and sound recorder
Integration with iOS and Android devices
Wi-Fi remote control and viewing using a smartphone
Storing photos and videos in Cloud when using the Stream Vision 2 App
Battery Pack
Quick Change Li-Ion Battery Pack LPS7i
Charging from USB Power Bank
Quick-Charge power delivery󰾬

Precautions
It is not recommended to charge the battery with the USB cable and
wireless charger at the same time. This will not increase the charge rate
and may damage the battery.
Use the USB Type-C cable and power adapter supplied with the device
(or purchased separately) to charge the LPS 7i batteries.
Follow the safety precautions described in its Manual when using the
wireless charger.
Do not place any foreign objects between the battery and wireless
charger platform.
Do not charge the battery immediately after brining it from cold to
warm. Wait at least 30 minutes for the battery to warm up.
Do not leave the battery unattended while charging.
Do not use the power adapter and wireless charger if they have been
modified or damaged.
Do not leave the battery plugged in after charging is complete.
Do not expose the battery to high temperatures and naked flame.
Do not use the battery as a power source for devices that do not support
LPS 7i batteries.
Do not disassemble or deform the battery.
Do not drop or strike the battery.
Do not submerge the battery.
Keep the battery out of the reach of children.

Recommendations for
Battery Use
The battery should be partially charged (50 to 80 %) for long-term
storage.
Charge at an ambient temperature of 0°C to +35°C (32°F to 95°F) or
the lifespan of the battery will decrease significantly.
Using the battery at sub 0°C (<32°F) ambient temperature decreases
battery capacity. This is normal and not a defect.
Using the battery at temperatures outside the range of -25°C to +50°C (-
13°F to 122°F) may reduce battery life.
The battery is short-circuit protected. Any situation that may cause
short-circuiting should be avoided.

Battery Charging
The Telosthermal imager comes with an LPS7i rechargeable Lithium-ion
battery. LPS7i batteries support USB Power Delivery fast charging
technology when using a standard charging set (USB Type-C cable, power
adapter). Before first use, make sure the battery is fully charged. LPS 7i
batteries also support wireless charging.
The icon in the status bar will flash when the battery is low. The battery
needs to be charged.
Option1.USB Charging

Image not found or type unknown


1. Install the LPS7i battery in the battery compartment of the device.
2. Connect the USB cable (20) to the USB Type-C connector (16) of the
device.
3. Connect the other end of the USB cable (20) to the Power Adapter (21)
by removing the USB Type-A adapter.
4. Plug the Power Adapter (21) into a 100-240 V socket.
5. Wait until the battery is fully charged (indication in the status bar:
Image not found or type unknown
).
If the device is off, the LED indicator (17) will display the battery
charge status:
LED indication Battery charge status
Battery defective. Do not use
the battery!
Battery charge level is from
0% to 50%

Battery charge level is from
51% to 75%
Battery charge level is from
76% to 99%
Battery is full
Option 2.Charging the battery via USB
Image not found or type unknown

1. Remove the protective cover(8).
2. Connect the plug of the USB Type-C cable (20) to the USB Type-C
connector (18) of the battery.
3. For fast charging, connect the second end of the USB Type-C cable (20)
to the Type-C connector of the power adapter (21) by removing the
Type-A adapter from the plug. When connected to a computer or a
Type-A power adapter, the battery will charge at normal speed.
4. Plug the power adapter (21) into a 100-240 V socket.
5. LED (19) will display battery charge level (see Table).
LED indication Battery charge status
Battery defective. Do not use
the battery!
Battery charge level is from
0% to 50%
Battery charge level is from
51% to 75%
Battery charge level is from
76% to 99%
Battery is full
Option 3.WirelessCharging
