Teltonika BTSID1 Installation guide
BTSID1
BTSMP1
Bluetooth beacon and sensor
Quick Manual v4.7
Quick Manual v4.7 // BTSID1, BTSMP1
3
This document provides short instruction how to congure BTSID1 Beacon or BTSMP1 Sensor and FM tracker. Dur-
ing the use if you will have any questions or suggestions for improvement please feel free to contact yours Teltonika
account manager or write to technical support team over VIP helpdesk.
Wireless solutions open up new horizons for your business and help to keep an eye on your assets. Discover our
certied Bluetooth Low Energy ID beacon and sensor models from Teltonika with robust waterproof casing and a
long-lifetime battery. The models designed for a low-cost fast and easy conguration and integration to save pre-
cious time, resources, and ensure accountability.
About BTSID1:
Perfect for traceability use cases, delivery tracking, monitoring of various movable objects in logistics (trailers, con-
tainers), agriculture (tractor attachments), and constructions (tools and inventory). Also, it suitable for indoor track-
ing solutions for items tracking in warehouses, hospitals, transport hubs and other types of industrial areas. EYE
beacon supports iBeacon and Eddystone protocols. The device is fully compatible with the Teltonika rmware plat-
form which provides extended functionality.
INTRODUCTION
About BTSMP1:
Perfect for traceability use cases, delivery tracking, monitoring of various movable objects in logistics (trailers, con-
tainers), agriculture (tractor attachments), and constructions (tools and inventory). Sensors data makes it especially
suitable for cold chain refrigerator use cases. The built-in accelerometer can detect item movement, pitch and roll
of the device. Magnet detection can be used for wireless open/close detection and notications such as trailer door
events, etc. EYE sensor supports iBeacon and Eddystone protocols. The device is fully compatible with the Teltonika
rmware platform which provides extended functionality.
Quick Manual v4.7 // BTSID1, BTSMP1
4
KNOW YOUR DEVICE
MEMBRANE
ONLY WITH
BTSMP1 SENSORS
MOUNTING HOLES
Quick Manual v4.7 // BTSID1, BTSMP1
5
What you get:
• Bluetooth BTSID1 Beacon or BTSMP1 Sensor designed for easy & fast conguration and integration.
• Quick Manual
•Mobile application for Android and iOS* phones. Congure, scan, and update anytime anywhere with a EYE
APP - Teltonika.
*iOS doesn’t show devices with iBeacon protocol
Quick Manual v4.7 // BTSID1, BTSMP1
6
CONFIGURATION
Devices work constantly and are ready to perform out of the box. Default basic Eye Beacon and Sensor settings
are set to:
• Transmitting at 2 dBm power.
• Data advertising at 5 second intervals.
• Eddystone protocol (EYE Beacon) Eddystone and Sensors (EYE Sensor)
• PIN 123456
If you would like to change these settings you will need to:
1) Download and install EYE APP - Teltonika application to change sensor settings.
*iOS doesn’t show devices
with iBeacon protocol
Quick Manual v4.7 // BTSID1, BTSMP1
7
1
2
3
Short list On/O
Devices in view:
In this window you will see all visible devices. You have options to see devices in Short list (1) or in default list. When
looking at devices in default list you will be able to open Detailed view (2) of devices and check transmitted data
statuses. Additionaly if you are looking for specic devices you will be able to use Search (3) function to lter search
options. When in this window select a device of your choice to connect and after passing pin code (default pin code
is 123456) you will go to device overview window.
Detailed view On/O
Search
Quick Manual v4.7 // BTSID1, BTSMP1
8
1
2
3
Device details
Overview window
In overview window you can see device details (1), check rmware version and update if available (2), go to device
conguration settings.
If you select to Congure (3) device new window will open with Basic and Advanced settings.
Firmware version
Device conguration
Quick Manual v4.7 // BTSID1, BTSMP1
9
1
3
2
2.1
2.2
2.3
2.4
Save conguration
Select to congure Ad-
vanced settings.
Congure Basic Settings
Congure device broadcast-
ed name
Congure signal
strength
Congure device adver-
tising interval
Packet settings
In this window you can check and change device conguration settings. In main tab Basic Settings (1) you can
change main settings. Change Device name (2.1), Power signal strength (2.2), Advertising interval (2.3) and Packet
(2.4) transmition type. For more settings go to Advanced settings (3) tab to enable various events.
Congure window
Quick Manual v4.7 // BTSID1, BTSMP1
10
MOUNTING RECOMMENDATIONS
12
3
Placing: Directly place the monitor
on the surface such as table, shelf
Using screws: Place device on the
surface and secure it to the surface
using two screws
Using the adhesive sticker: Remove
the release liner from one side of
the adhesive sticker to stick it on the
back of the device, then remove the
release liner from the other side to
stick it at the desired place on the wall
Quick Manual v4.7 // BTSID1, BTSMP1
11
4 5
Ziptie: Lead ziptie thru both device
holes and around an object you want
device secured to
Note: Adhesive sticker, screws, lanyard, zipties are not included and sold separately
Hanging: Attach lanyard’s snap hook
to one of the holes
Quick Manual v4.7 // BTSID1, BTSMP1
12
Dimensions and weight
Dimensions 56,6 x 38 x 13 mm (L x W x H)
Weight 18 grams
Technical specications
Model CR2450 CR2450
Type Lithium, Manganese
Dioxide (Li/MnO2)
Lithium, Manganese
Dioxide (Li/MnO2)
Total Capacity 600 mAh 600 mAh
Replaceable battery No No
Battery life (Tx=2 dBm; interval: 3 s) 4+ years 2.5+ years
Battery life (Tx=2 dBm; interval: 5 s) 8+ years (Default) 4+ years (Default)
Battery life (Tx=2 dBm; interval: 10 s) 10+ years 5+ years
Microcontroller ST Microelectronics
BlueNRG-2
ST Microelectronics
BlueNRG-2
Bluetooth
Bluetooth 4.2 compliant,
Bluetooth 5.2 certied
Bluetooth Operating
Frequency 2.402 - 2.480 GHz
Antenna gain 1.2dBi
Bluetooth 4.2 compliant,
Bluetooth 5.2 certied
Bluetooth Operating
Frequency 2.402 - 2.480 GHz
Antenna gain 1.2dBi
Range 80 m 80 m
Available transmission power levels Up to 8 dBm Up to 8 dBm
PRODUCT INFORMATION
EYE BEACON
EYE SENSOR
Quick Manual v4.7 // BTSID1, BTSMP1
13
Technical specications
Sensitivity -88 dBm -88 dBm
Protection IP67 IP67
Mounting Two holes to screw/
leash/strip, tape
Two holes to screw/
leash/strip, tape
Customization
Custom logo
upon request*
* Special conditions
Custom logo
upon request*
* Special conditions
Operational temperature -20°C / +60°C
(-4°F / +140°F)
-20°C / +60°C
(-4°F / +140°F)
Humidity (non-condensing) From 0% to 100% From 0% to 100%
Certicates
CE RED (EU)
FCC (USA)
UKCA (UK)
RoHS
E-mark
EAC (TBD)
ANATEL
REACH EU
SIRIM QAS
SDPPI POSTEL
TELEC
CE RED (EU)
FCC (USA)
UKCA (UK)
RoHS
E-mark
EN12830 (TBD)
EAC (TBD)
ANATEL
REACH EU
SIRIM QAS
SDPPI POSTEL
TELEC
Temperature measuring range -20 to +60°C
Quick Manual v4.7 // BTSID1, BTSMP1
14
CERTIFICATION
15C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or trans-
mitter.
(15B)This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
• The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or trans-
mitter and must be installed to provide a separation distance of at least 20cm from all persons.
08591-21-18913
Para maiores informações, consulte o site da ANATEL www.gov.br/anatel/pt-br
Este equipamento não tem direito à proteção contra interferência prejudicial e não
pode causar interferência em sistemas devidamente autorizados.
For more information, see the ANATEL website www.gov.br/anatel/pt-br.
This equipment is not entitled to protection awwst harmful interference and must
not cause interference in duly authorized system.
Quick Manual v4.7 // BTSID1, BTSMP1
15
This message contains information on how to operate BTSID1 safely. By following these requirements and
recommendations, you will avoid dangerous situations. You must read these instructions carefully and fol-
low them strictly before operating the device!
1. To avoid mechanical damage, it is advised to transport the device in an impact-proof package.
2. In case of malfunction contact yours Teltonika account manager or write to technical support team over
VIP helpdesk.
SAFETY INFORMATION
Quick Manual v4.7 // BTSID1, BTSMP1
16
Opening and self xing devices is
strictly forbidden
All wireless data transferring
devices produce interference that
may aect other devices which
are placed nearby.
The device must be connected
only by qualied personnel.
Installation and/or handling
during a lightning storm is pro-
hibited.
Risk of explosion if battery is
replaced by an incorrect type. Dis-
pose of used batteries according
to the instructions.
This marking on the product,
accessories or literature indicates
that product ant its electronic ac-
cessories should not be disposed
of with other household waste.
This Marking on the battery, man-
ual or packaging indicates that
batteries in this product should
not be disposed with other
household waste.
The device must be rmly fas-
tened in a predened location.
Quick Manual v4.7 // BTSID1, BTSMP1
17
WARRANTY
We guarantee our products 24-month warranty1 period.
All batteries carry a 6-month warranty period.
Post-warranty repair service for products is not provided.
If a product stops operating within this specic warranty time, the product can be:
• Repaired
• Replaced with a new product
• Replaced with an equivalent repaired product fullling the same functionality
• Replaced with a dierent product fullling the same functionality in case of EOL for the original product
1 Additional agreement for an extended warranty period can be agreed upon separately.
WARRANTY DISCLAIMER
• Customers are only allowed to return products as a result of the product being defective, due to order assembly or
manufacturing fault.
• Products are intended to be used by personnel with training and experience.
• Warranty does not cover defects or malfunctions caused by accidents, misuse, abuse, catastrophes, improper maintenance
or inadequate installation – not following operating instructions (including failure to heed warnings) or use with equipment
with which it is not intended to be used.
• Warranty does not apply to any consequential damages.
• Warranty is not applicable for supplementary product equipment (i. e. PSU, power cables, antennas) unless the accessory is
defective on arrival.
• More information on what is RMA1
1 wiki.teltonika-gps.com/view/RMA_guidelines
