Teltonika GSM Camera User manual

Address: Žirmūnų g. 27, Vilnius LT-09105,
Office.: 370 5 2127472,
Fax: [phone], E-mail: [email protected]
Teltonika GSM Camera
Quick Start Guide v1.0
Thank you for purchasing our device! We hope it will satisfy your expectations and you will
enjoy its particular features. Please, find few minutes to read the Quick tart Guide before starting the
work. It will make the installation and usage of the device easier.

2
I N T R O D U C T I O N
Teltonika GSM Camera – is a small mobile video monitoring system, that sends data through
GSM G RS/EDGE channel. The design of this device allows to connect camera to the C through
COM port. When Teltonika GSM Camera is connected to the C, the parameters and received
images can be configured. Teltonika GSM Camera supports the following data bearers: G RS,
EDGE and SMS.
P A C K A G E C O N T E N T S
1) Cardboard box.
2) “Teltonika GSM Camera“ device.
3) ower supply
4) Connection to C cable.
5) GSM antenna.
6) Mounting bracket.
7) CD with software and User Manual.
8) “Quick Start Guide”.
Note: the manufacturer does not provide SIM card, which is necessary for connecting
to the GSM network! SIM card can be obtained from your GSM operator!
If any of the components are missing, please contact the manufacturer representative or your local distributor.
H O W T O S T A R T ?
To start the work:
• Configure camera settings using computer or by SMS
messages (read User Manual).
• Fix the mounting bracket and fasten camera on it.
• Connect to the system:
1. External GSM antenna.
2. Insert SIM card (with disabled IN code or enter it
with the help of C).
3. External sensors.
4. ower supply, plug it to the power supply source.
5. Additional external camera if needed.
• Focus camera lens gently using the C with Camera
Configurator software (before focusing the lens make sure,
that low sharpness is not the result of enlarged UV ray
amount or radio frequency interference).
Example o camera con iguration with SMS messages
• System performs the commands received from authorised phone numbers. While the numbers list
is empty, firstly authorize the main user’s number. Only the main user can enter or change the
settings, add or delete additional users who may receive alarm SMS messages and order the
filming session. Send SMS message with text " ADD " to SIM card placed in the camera and the
number from which the message was sent will be the main user.
• Access point has to be entered in order to be able to send data through GSM G RS/EDGE network
to the camera. For that matter send SMS message with the text, e.g.: " APN
gprs.internet.net ", where gprs.internet.net is the access point of your GSM network provider.
If authorization is used in your network, additionally user name (chapuser) and password
(chappasword) has to be set. For that matter use SMS command: "
CHAPUSER internet ",
" CHAPPASWORD connect ", where internet and connect stand for user name and password
that were set by your GSM network operator.
i
i
i
i

3
One of the easiest ways to receives images from camera, is to receive them into your e-mail box. For this
matter you need:
• Activate sending to e-mail mode by sending SMS message with text " EMAIL ON " to SIM card
inserted in the camera.
• Enter your GSM network e-mail server address and port (if not standard port is used) and send
SMS command " SMTPIP smtp.internet.net " or " SMTPIP smtp.internet.net:25 " to
camera where smtp.internet.net is your GSM network e-mail server address.
• Add your e-mail address to the list by sending SMS command to the camera: " ADDEMAIL
[email protected] ", where [email protected] is your e-mail address.
Several commands can be entered in one SMS message (except command " ADD ") if it does not
exceed 160 symbols. Commands must be separated by semicolon, e.g.: " apn
gprs.internet.net; chapuser internet; chappasword connect; email on; smtpip
smtp.internet.net:25; addemail [email protected]".
When camera receives commands, it returns confirmation or error message. When all confirmation
messages are received, user can order images. To do so, make a short call (up to 10 seconds) to
the camera or send the SMS message with the text " PHOTO " and wait until the images will be
sent to the e-mail box.
User can also make a phone call to camera and after 10 seconds camera will switch to area
listening mode.
If your C has a constant external I address and at least one open port, images from the camera can go
directly to the C. For this you have to:
• Send SMS command to camera " WEB ON " to enable
sending to server mode (Don’t forget to disable other
sending points! E.g. e-mail with command " EMAIL
OFF ").
• Send SMS command e.g. " WEBIP
192.168.0.1:7989 ", where 192.168.0.1 is the I
address of your C and 7989 is a selected port
number.
• Run Observation ost software with File ->
Settings, set the same port and select the
directory for pictures archive. Click
to save the settings. Click “Listen” in the main
window to start port listening.
Now make a short call (up to 10 seconds) or
send a SMS message with text " PHOTO " to
camera and receive images into your computer.
If you sent a SMS command e.g. " VIDEO 3 " to camera, you can set
camera to constant video mode for 3 minutes. Images receiving speed will
depend upon set picture format (quality). For more details about this and
other functions, please, read User Manual.

4
I N D I C A T I O N
On the back of the Teltonika GSM Camera device, there are 3 LEDs: “1“, “2“and “Status“.
“1“ and “2“ indicates which camera (internal or external) is working.
“Status“ description is given in the table:
Status Description
„Status“ LED is on Camera filming input is on and waits for a signal
„Status“ LED is off Camera filming input is off
„Status“ LED blinking Camera is in area listening mode
„Status“LED blinking in double signals Camera is in Camera Configurator mode
I M P O R T A N T
This sigh on the package means that it is necessary to read the User’s Manual, which is on the CD,
before you start using the device.
This sign on the package means that all used electronic and electric equipment should be stored
separately.
F I N A L N O T E S
For more detailed information about Teltonika G M Camera, please read the documentation which is
found on the CD. If you encounter any problems using the device and you are not able to solve them yourself,
please contact our technical support department by e-mail [email protected] We will be glad to help you.
