Teng YuanZhi Shenzhen Electronics ST-700 User manual

Teng YuanZhi Shenzhen Electronics Co., Ltd
ST-700 The small & portable wireless video & audio transmission
equipment instruction manual
Page 1 of 5
Ⅰ. Summary
ST-700 Portable wireless video transmission equipment is an excellent all aspects of
performance are more varieties, and its large power margin, small current consumption，normal
operation power is only about 500mA。Small size，Long transmission distance，more suitable
for complex physical environment。While used 0dB omni antenna ( original small antenna)，It
can transmission about 500m in the open air, and block in the general case about 100 to 200m
transmission distance. The product design ideas in this paragraph is mainly targeted at the
needs to carry, inconvenience exposure situations.
It is very small, ease to
clip on the waist

Teng YuanZhi Shenzhen Electronics Co., Ltd
ST-700 The small & portable wireless video & audio transmission
equipment instruction manual
Page 2 of 5
Ⅱ. Features
1、 wireless transmission: no need to set up communications cable
2、 Image, audio sync, color black and white compatible
3、 Small size, light weight, easy to carry, good installation
4、 Responsive, timely, send and receive real-time transmission
5、 Using FM mode, anti-interference ability, good image quality
6、 Highly integrated, stable and reliable transmission distance
7、 DC power supply, ease to operation.
Ⅲ. Technical Parameter
1、 Transmitter
2、 Receiver
Channel number 4
Supply voltage 12V DC
Transmitting power 700mw
Antenna input impedance 50Ω
Audio Subcarrier frequency
Dual sound 6.0MHz/6.5MHz
Video input impedance 75Ω
Audio input impedance 600Ω
Transmission distance Over 500m （ line of sight,
transmitting
Distance 100~200m with block.）
Size: Transmitter:74*41*14mm
Channel number 29
Supply voltage 12V DC
Receiver sensor -80dB
Antenna input impedance 50Ω
Audio subcarrier frequency Dual ound 6.0MHz/6.5MHz
Video input level 1Vp-p(75 Ω )
Audio input level 1Vp-p(600 Ω)
Size: 116*80*21mm

Teng YuanZhi Shenzhen Electronics Co., Ltd
ST-700 The small & portable wireless video & audio transmission
equipment instruction manual
Page 3 of 5
Ⅳ.Panel description
1.Transmitter panel description
2．Receiver panel description
Ⅴ.Operation instruction
Properly installed, connect the transmitting and receiving system (see installation instructions).
Determine the circumstances connected correctly (must connect the transmitter antenna at first),
respectively the power connected to the transmitter and receiver.
Powered, no press in the transmitter and receiver channel selection key, then the transmitter and
receiver are automatically locked in a channel (usually the factory set to 5 channel). If you use
other channels, as long as the transmitter of the channel adjustment buttons gently press the
button, and then transferred to the receiver and transmitter channels corresponding to the next
channel can be.
Antenna
interface
Camera interface
Power input
interface
Channel
selection dial
Power input
interface
Audio output
Video output

Teng YuanZhi Shenzhen Electronics Co., Ltd
ST-700 The small & portable wireless video & audio transmission
equipment instruction manual
Page 4 of 5
Ⅵ. Installation methods and procedures
1．Take out the transmitter, receiver, antenna etc from the packing box;
2．To fix the transmitter, transmitter antenna and receiver antenna separately;
3．To connect the camera with the transmitter, receiver with monitor (TV etc);
4．Powered;
5．Regulate transmitter, receiver channel, through monitor, so that the receiver's audio
and video effects to achieve the best
Corresponding channel as follows：
Transmitter Channel
Display
29Channel
Receiver
4Channel
Receiver(Taiwan
)
1 4 1
2 6 2
3 8 3
New Channel
4 10 4
1 5 1
2 7 2
3 9 3
Old Channel
4 11 4
Ⅶ. Packing list
Transmitter
X 1pc
Receiver X 1pc
Antenna X 2pcs
Connect
Cable X 2pcs
Manual X 1pcs
Ⅷ. Notes
1. Before the antenna is not installed well, do not boot, or it may damage the system!
2. Such as the DC power supply, recommended 12V regulated power supply power supply,
Within the power of positive things for the negative polarity! Do not mistake!
3. If the transmitter signal source is mono, the audio transmitter receiver audio input and
output channels should be chosen uniform.

Teng YuanZhi Shenzhen Electronics Co., Ltd
ST-700 The small & portable wireless video & audio transmission
equipment instruction manual
Page 5 of 5
Ⅸ. Optional small battery:
As a portable device, it also requires small-size peripheral accessories; it’s advised to
select and use the high capacity portable lithium batteries as mentioned below:
8000mA
Portable Lithium Battery
Size: 105*52*30mm
Weight: 480g
Working hours: about 10
hours
93.0USD/PCS
5000mAh
Portable Lithium Battery
Size: 100*60*25mm
Weight: 340g
Working hours: about 6 hours
86.0USD/PCS
3000mAh
Portable Lithium Battery
Size: 70*60*15mm
Weight: 180g
Working hours: about 3 hours
63.0USD/PCS
2500mAh
Portable Lithium Battery
Size: 60*50*255mm
Weight: 200g
Working hours: about 2.5
hours
62.0USD/PCS
Ⅹ. Optional Camera :
1. Mini Color button camera 2. Mini White black button camera
Model:ST-C01
Mini Color button video recorder
1/4” SONY CCD chipset
480 wire, 300,000 pixels
Built-in audio pickup unit
Power consumption: 12V 50mA
Weight: 50g
Support: NTSC/PAL
Size: 28*24mm
80.0USD/PCS
Model:ST-C03
Black-and-white button video recorder
1/4” CMOS 380 wire
PAL(H*V):500*582
NTSC( H*V ) : 510*492
Power consumption: 12V 10mA
Weight: 20g
Size: 15*15mm
35.0USD/PCS
