Icom IC-A24E User manual

INSTRUCTION MANUAL
iA6E
iA24E
VHF AIR BAND TRANSCEIVER
IC-A24E IC-A6E
IC-A24E_A6E_ENG-4.qxd 2008.08.01 9:14 AM Page i

i
FOREWORD
Thank you for purchasing this Icom product. The
IC-A24E/A6E VHF AIR BAND TRANSCEIVER is designed
and built with Icom’s state of the art technology and crafts-
manship. With proper care this product should provide you
with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAVE THIS INSTRUCTION MANUAL—This in-
struction manual contains important operating instructions for
the IC-A24E/A6E.
EXPLICIT DEFINITIONS
SUPPLIED ACCESSORIES
Accessories included with the transceiver: Qty.
qAntenna .......................................................................... 1
wBelt clip ........................................................................... 1
eHandstrap ....................................................................... 1
rBattery pack* or battery case .......................................... 1
tWall charger* .................................................................. 1
yCarrying case* ................................................................ 1
uHeadset adapter* ........................................................... 1
*The battery pack, wall charger, headset adapter or carrying case
may differ depending on version. Some versions do not include a
battery pack, wall charger, headset adapter or carrying case.
qw e
t
r
y
u
WORD DEFINITION
RWARNING
CAUTION
NOTE
Personal injury, fire hazard or electric shock
may occur.
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
Equipment damage may occur.
IC-A24E_A6E_ENG-4.qxd 2008.08.01 9:14 AM Page ii

ii
FOREWORD ··················································································· i
IMPORTANT ···················································································· i
EXPLICIT DEFINITIONS ································································· i
SUPPLIED ACCESSORIES ···························································· i
TABLE OF CONTENTS ·································································· ii
PRECAUTIONS·············································································· iii
1 ACCESSORY ATTACHMENT ·················································· 1
2 PANEL DESCRIPTION ······················································ 2 –7
■Panel description ··································································· 2
■Function display ···································································· 6
3 BASIC OPERATION ························································· 8 –11
■Setting a frequency ······························································· 8
■Setting a squelch level ·························································· 8
■ANL function ········································································· 8
■Receiving ·············································································· 9
■Transmitting ··········································································· 9
■Low battery indicator ··························································· 10
■Recall function ···································································· 10
■Accessing the 121.5 MHz emergency frequency ················ 11
■Lock function ······································································· 11
■Side tone function ······························································· 11
■Setting beep tone ································································ 11
4 MEMORY OPERATION ·················································· 12 – 15
■Memory channel selection ·················································· 12
■Transferring memory contents ············································· 12
■Programming a memory channel ········································ 13
■Memory names ··································································· 14
■Clearing the memory contents ············································ 14
5 SCAN OPERATION ························································ 16 –17
■Scan types ·········································································· 16
■COM band scan ·································································· 16
■Memory scan ······································································ 16
■“TAG” channel setting ························································· 17
6 VOR NAVIGATION (IC-A24E only)································· 18 –24
■VOR indications ··································································· 18
■VOR functions ····································································· 19
■Flying to a VOR station ······················································· 20
■Entering a desired course ··················································· 22
■Crosschecking position ······················································· 22
■Duplex operation ································································· 24
7 BATTERY PACKS ·························································· 25 –27
■Battery charging ·································································· 25
■Battery cautions ·································································· 25
■Optional battery case ·························································· 26
■Optional battery chargers ···················································· 27
8 CLONING ··············································································· 29
9 TROUBLESHOOTING ··························································· 30
10 SPECIFICATIONS ·································································· 31
11 OPTIONS ················································································ 32
12 OPTIONAL HEADSET CONNECTION ·································· 33
13 ABOUT DOC ·········································································· 34
TABLE OF CONTENTS 1
2
3
4
5
6
7
8
9
10
11
12
13

iii
PRECAUTION
RWARNING! NEVER hold the transceiver so that the
antenna is very close to, or touching exposed parts of the
body, especially the face or eyes, while transmitting. The
transceiver will perform best if the microphone is 5 to 10 cm
away from the lips and the transceiver is vertical.
RWARNING! NEVER operate the transceiver with a
headset or other audio accessories at high volume levels.
Hearing experts advise against continuous high volume op-
eration. If you experience a ringing in your ears, reduce the
volume level or discontinue use.
NEVER connect the transceiver to an AC outlet or to a
power source of more than 11.5 V DC. Such a connection
will damage the transceiver.
NEVER connect the transceiver to a power source that is
DC fused at more than 5 A. Accidental reverse connection
will be protected by this fuse, higher fuse values will not give
any protection against such accidents and the transceiver
will be ruined.
NEVER short the terminals of the battery pack. Also, cur-
rent may flow into nearby metal objects, such as a necklace,
etc. Therefore, be careful when carrying with, or placing near
metal objects, carrying in handbags, etc.
DO NOT allow children to play with any radio equipment
containing a transmitter.
DO NOT allow children to play with any radio equipment
containing a transmitter.
DO NOT operate the transceiver near unshielded electri-
cal blasting caps or in an explosive atmosphere.
DO NOT use or place the transceiver in direct sunlight or
in areas with temperatures below –20°C or above +55°C.
CLEAN and wipe dry the battery terminals after using the
transceiver in wet conditions. The terminals may rust if not
dried.
The use of non-Icom battery packs/chargers may impair
transceiver performance and invalidate the warranty.
Even when the transceiver power is OFF, a slight current still
flows in the circuits. Remove the battery pack or case from
the transceiver when not using it for a long time. Otherwise,
the battery pack or installed Alkaline cell batteries will be-
come exhausted.
IMPORTANT!: IC-A24E/A6E is for GROUND STATION
USE ONLY. The IC-A24E/A6E CAN NOT and SHOULD
NOT be used in an aircraft or as the MAIN RADIO.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor-
porated (Japan) in Japan, the United States, the United Kingdom, Germany,
France, Spain, Russia and/or other countries.
All other products or brands are registered trademarks or trademarks of their
respective holders.

1
1
ACCESSORY ATTACHMENT
1
DAntenna
CAUTION: DO NOT transmit without an antenna. Other-
wise the transceiver may be damaged.
Insert the supplied antenna into the antenna connector and
screw down the antenna as shown below.
DBelt clip
Conveniently attaches to your belt.
Attach the belt clip with the supplied screws as below.
NOTE: Use the supplied screws only.
DBattery pack replacement
Before replacing the battery pack, push [PWR] for 2 sec. to
turn the power OFF.
Slide the battery release button forward, then pull the battery
pack upward with the transceiver facing away from you.
Supplied screws
NOTE: About water resistant construction
The water resistant construction provides reliable operation
in wet conditions.
•Equivalent to IPX4 of corresponding international stan-
dard IEC 60529 (2001).
IC-A24E_A6E_ENG-4.qxd 2008.08.01 9:14 AM Page 1

2
2PANEL DESCRIPTION
■Panel description
ert
u
y
i
o
Microphone
Speaker
!6
!5
!7
q
w
!1
!0
!2
!3
!4
IC-A24E
!7
!7
IC-A6E
IC-A24E_A6E_ENG-4.qxd 2008.08.01 9:14 AM Page 2

3
2
PANEL DESCRIPTION
qBACKLIGHT SWITCH [LIGHT]
Turns the backlight for display and keypad ON or OFF.
wPTT SWITCH [PTT] (p. 9)
Push and hold to transmit; release to receive.
• “ ” appears on the function display while transmitting.
eVOLUME [VOL] (p. 9)
Adjusts the audio level.
rTUNING DIAL [DIAL] (pgs. 8–12)
➥Rotate [DIAL] to select the desired frequency, BANK
number and memory channel.
➥Rotate [DIAL] to set the squelch level and beep tone
level.
tANTENNA CONNECTOR [ANT] (p. 1)
Connect the supplied antenna here.
yRECALL CHANNEL UP/DOWN KEYS [Ω]/[≈] (p. 10)
➥Push to enter the recall function mode.
➥Push to call the stored frequency in the recall
mode.
➥Push , then push [Ω]/[≈]to replace stored
recall frequencies to back or front.
uSQUELCH KEY [SQL] (p. 8)
➥Push [SQL], then rotate [DIAL] to select the
squelch level.
• 24 squelch levels and squelch open (0) are available.
iPOWER SWITCH [PWR] (pgs. 9, 29)
➥Push and hold for 2 sec. to turn the power ON
or OFF.
➥While pushing and holding [MR•MW], push
[PWR] to enter the cloning function mode.
oEXTERNAL SPEAKER AND MICROPHONE JACKS
[MIC/SP] (p. 33)
If desired, connect an OPC-499 HEADSET ADAPTER and
headset.
!0 FUNCTION KEY [ ]
Push to call up the function indicator, “ ”, then
push another key to access its secondary func-
tion.
• “” appears for 3 sec. after is pushed; at this
time pushing again cancels the indication.
NOTE: In general, “ ” disappears when an-
other key is pushed to activate a secondary
function. However, some keys which have more
than one secondary function, (such as [DUP]),
do not cancel “ ”. In this case, “ ” automati-
cally disappears after 3 sec.
2

4
2PANEL DESCRIPTION
!1 CLEAR KEY [CLR•DEL] (pgs. 8–17)
➥Push to return to the frequency mode, when
memory channel, 121.5 MHz, squelch level set-
ting or beep tone setting is selected.
➥Push , then push and hold [CLR•DEL] to
delete a recall frequency data.
➥Push to clear the entered comment of memory
name while programming.
➥Push to stop the scan function to return to the
frequency mode while the scan function is op-
erating.
!2 ANL KEY [ANL•SCAN] (pgs. 9, 16, 17)
➥Push to turn the ANL function ON or OFF.
➥Push , then push [ANL•SCAN] to start the
scan function.
!3 EMERGENCY KEY [121.5 MHz] (p. 11)
Push for 2 sec. to select the 121.5 MHz emer-
gency frequency.
!4 DC POWER JACK
Connect the AC adapter or optional cable, to charge the
battery pack or to operate by external power. (see right il-
lustration)
!5 MEMORY MODE KEY [MR•MW] (pgs. 12–15)
➥Push to select the memory channel mode.
➥Push , then push [MR•MW] to program the
contents into the memory channels.
!6 ENTER KEY [ENT] (pgs. 8, 14)
➥Push to store the numeral input. Enters con-
secutive zero digits. (p. 8)
➥Push to program the memory name. (p. 14)
NOTE: Some functions may not be available depending on
versions. Ask your authorized dealer for details.
Wall charger
To [DC 11V]
IC-A24E/A6E
CP-20 (for 11 24 V)
(optional)
To the cigarette
lighter socket
• DC POWER CONNECTION
CAUTION
• DO NOT modify the CP-20. A modifica-
tion could cause a fire or electrocution.
• BE CAREFUL not to cut or fray the
CP-20’s power cable when disconnecting/
connecting the CP-20 from/to the cigarette
lighter socket.

5
2
PANEL DESCRIPTION
!7 DIGIT KEYS
➥Input the specified digit during frequency input, mem-
ory channel selection, etc.
➥In addition, each key has one or more secondary func-
tions after pushing as follows:
Push , then push [0•BANK], and rotate [DIAL]
to select the memory BANK number during mem-
ory mode operation. (p. 12)
Push , then push [1•DVOR] to select the DVOR
display from the CDI display in the NAV band. (p. 19)*1
➥Push , then push [2•TO] to change the
course indicator characteristics to a “TO” flag in
the DVOR display in the NAV band. (p. 19)*1
➥Corrects the deviation while using the “TO” flag.*1
➥Push , then push [3•FROM] to change the
course indicator characteristics to a “FROM” flag
in the DVOR display in the NAV band. (p. 19)*1
➥Corrects the deviation while using the “FROM”
flag.*1
Push , then push [4•CDI] to select the CDI dis-
play from the DVOR display in the NAV band.
(p. 19)*1
Push , then push [5•DUP-W] to set the duplex
frequency in the NAV band. (p. 24)*1
Push , then push [6•DUP] to turn the duplex
function ON/OFF in the NAV band. (p. 24)*1
Push , then push [7• ] to turn the key lock
function ON/OFF. (p. 11)
Push , then push [8•BEEP] to turn the beep
tone setting mode ON. (p. 11)
•Adjustable level; 0 to 9
Push , then push [9•TAG] to set the displayed
memory as a “TAG” channel. (p. 17)
*1 These functions are available on the IC-A24E only.
2

6
2PANEL DESCRIPTION
■Function display
qFUNCTION INDICATOR (p. 3)
Appears when is pushed.
wTX INDICATOR (p. 9)
Appears while transmitting.
eRX INDICATOR (p. 9)
Appears when receiving a signal, or when the squelch
opens.
rDUPLEX INDICATOR (IC-A24E only) (p. 24)
➥“DUP” appears when the duplex function is activated in
the NAV mode.
➥“DUP” blinks while setting the duplex frequency.
tLOW BATTERY INDICATOR (p. 10)
➥Appears when the battery is nearing exhaustion. The
attached battery pack requires recharging.
➥Appears and flashes when battery replacement is nec-
essary.
yLOCK INDICATOR (p. 11)
Appears while the lock function is in use.
uFREQUENCY DISPLAY (pgs. 8, 14)
➥Shows the operating frequency.
➥Shows the channel name when the memory name
function is selected.
i
qw e r t y
o
!0
!1!1 !2!3
!4
u
!5

7
2
PANEL DESCRIPTION
iTAG CHANNEL INDICATOR (p. 17)
“” appears when the selected memory channel is set
as a TAG channel.
oMEMORY CHANNEL INDICATOR (pgs. 12–15)
Shows the selected memory channel number.
!0 MEMORY BANK NUMBER INDICATOR (p. 12)
Shows the selected memory bank number.
!1 OVERFLOW INDICATOR (IC-A24E only) (pgs. 18–22)
Appears when the deviation between the desired course
and flying course is over 10 degrees.
!2 ANL INDICATOR (p. 9)
Appears while the ANL (Automatic Noise Limiter) function
is in use.
!3 COURSE DEVIATION NEEDLES (IC-A24E only)
(pgs. 18–22)
Indicates every 2 degree deviation between the desired
course and your actual flying course.
!4 COURSE INDICATORS (IC-A24E only) (p. 19)
➥Indicates where your aircraft is located on a VOR radial
in the DVOR mode.
➥Indicates where your desired course is located on a
VOR radial in the CDI mode.
!5 TO-FROM INDICATOR (IC-A24E only) (p. 19)
Indicates whether the VOR navigation information is
based on a course leading to the VOR station or leading
away from the VOR station.
2

8
3BASIC OPERATION
■Setting a frequency
ïUsing keypad
qPush [PWR] for 2 sec. to turn power ON, then push [CLR
•DEL] to select the frequency mode when memory CH
number appears on the function display.
wPush 5 appropriate digit keys to input the frequency.
• Push [1•DVOR] as the 1st digit.
• When a wrong digit is input, push [CLR•DEL] to clear,
then repeat step wagain.
• Push [ENT] to enter consecutive zero digits.
• Only [2•TO], [5•DUP-W], [7• ] and [0•BANK] can be
entered as the 5th and final digit.
[EXAMPLE]
• 111.225 MHz: Push
• 117.250 MHz: Push
• 120.000 MHz: Push
• 125.300 MHz: Push
ïUsing the tuning dial
qPush [PWR] for 2 sec. to turn power ON, then push [CLR
•DEL] to select the frequency mode when memory CH
number appears on the function display.
wRotate [DIAL] to set the desired frequency.
• To select the 1 MHz tuning step, push ,then rotate
[DIAL]. Push again to return to the normal tuning.
■Setting a squelch level
The transceiver has a noise squelch circuit to mute unde-
sired noise while receiving no signal.
qPush [SQL], then rotate [DIAL] to select the squelch level.
• ‘SQL--0’ is open squelch and ‘SQL--24’ is tight squelch.
• “ ” appears while the squelch is open.
w Push [SQL] or [CLR•DEL] to exit the squelch set mode.
■ANL function
While receiving, the ANL (Automatic Noise Limiter) function
reduces noise components such as those that are caused
by engine ignition systems.
• Push [ANL•SCAN] to turn the ANL function ON/OFF.
“ ” appears on the display while the ANL function is ON.

9
3
BASIC OPERATION
■Receiving
qPush [PWR] for 2 sec. to turn the power ON.
wPush [SQL], then rotate [DIAL] counterclockwise to select
the squelch level 0.
eRotate [VOL] to adjust the audio level.
rPush [SQL], then rotate [DIAL] clockwise until the noise is
muted.
•“ ”indicator disappears.
tSet the desired frequency using [DIAL] or keypad.
yWhen a signal is received on the set frequency:
•“ ”indicator appears.
•Squelch opens and audio is emitted from the speaker.
When [SQL] setting is too “tight,”squelch may not open for
weak signals. To receive weaker signals, loosen the squelch.
■Transmitting
qSet the desired frequency in COM band using [DIAL] or
keypad.
•COM band frequency range: 118.00–136.975 MHz
wPush and hold [PTT] to transmit.
•“ ”indicator appears.
eSpeak into the microphone at a normal voice level.
•DO NOT hold the transceiver too close to your mouth or speak
too loudly. This may distort the signal.
rRelease [PTT] to return to receive.
CAUTION: Transmitting without an antenna may damage
the transceiver.
NOTE: To prevent interference, listen on the frequency be-
fore transmitting. If the frequency is busy, wait until the
channel is clear.
3
IC-A24E_A6E_ENG-4.qxd 2008.08.01 9:14 AM Page 9

10
3BASIC OPERATION
■Low battery indicator
Low battery indicator appears
when the battery power has de-
creased to a specified level. The
attached battery pack requires
recharging.
■Recall function
The recall function stores the last 10 frequencies used.
The function stores frequencies when the frequency is pro-
grammed and transmitted on (except memory and emer-
gency channels).
DRecalling the stored frequencies
➥Push to recall the 1st stored frequency.
➥Push to recall the 10th stored frequency.
➥Push [CLR•DEL] to exit the recall function.
DDeletes the stored recall channel
qPush or to select the channel to be deleted.
wPush , then push [CLR•DEL] for 2 sec. to delete it.
• (e.g.) When the “r0” recall channel which is stored 120.450 MHz
is deleted, the “r1” recall channel which is stored 123.450 MHz
move up to “r0”.
DReplaces the stored recall channel
qPush or to select the recall channel to be re-
placed.
wPush , then push or to replace it.
• Replaces the selected channel into the previous channel when
is pushed and then is pushed.
• Replaces the selected channel into the next channel when
is pushed and then is pushed.
• (e.g.) To replace “r0” which is stored as 121.375 MHz into “r1”,
push , then push .
NOTE:
When the number of stored frequencies reaches
10, channels are automatically deleted as needed, in the
order they were entered, beginning the oldest.
Low battery indicator
Recall number appears.
: Push
: Push
• Recall number rotation

■Accessing the 121.5 MHz
emergency frequency
The IC-A24E and IC-A6E can set to the121.5 MHz emer-
gency frequency quickly. This function can be activated even
when the key lock function is in use.
qPush [121.5] for 2 sec. to select the emergency frequency.
wPush [CLR•DEL] to exit the emergency frequency.
■Lock function
The lock function prevents accidental frequency changes
and accidental function activation.
qPush , then push [7• ] to turn the lock function ON.
• “ ” appears.
wTo turn the function OFF, repeat step qabove.
• “ ” disappears.
■Setting beep tone
If desired, the beep tone, which sounds at the push of a
switch, can be set.
q Push ,then push [8•BEEP] to enter the beep tone
setting mode.
w Rotate [DIAL] to set the beep level.
• ‘BEP-- 0’ is OFF and ‘BEP-- 9’ is maximum level.
• ‘2 beeps sound tone to verify set beep tone level.
e Push [CLR•DEL] to exit the beep tone setting mode.
■Side tone function
When using an headset (other manufacture’s product),
the transceiver outputs your transmitted voice to the head-
set for monitoring. Connect the optional headset with the
transceiver when using this function (OPC-499 HEADSET
ADAPTER and headset are required). (p. 33)
DSetting the side tone level
qPush [PTT] to turn the transmit mode ON.
wDuring transmit mode, rotate [DIAL] to adjust the monitor-
ing level.
• ‘ST--0’ is OFF and ‘ST--10’ is Max. level.
NEVER operate the transceiver with a headset at high
volume levels for long period. A ringing in your ears may
occur. If so, reduce the monitor level or discontinue use.
11
3
BASIC OPERATION
3

12
4MEMORY OPERATION
■Memory channel selection
The transceiver has 200 memory channels for storage of
often-used frequencies, along with 6-character notes.
q Push [MR•MW] to select the memory mode.
• The Memory BANK number and memory CH number appears.
Using [DIAL]:
w Push , then push [0•BANK], and rotate [DIAL] to select
the desired memory BANK number, then push [ENT] (or
[CLR•DEL]) to exit the BANK selection mode.
e Rotate [DIAL] to select the desired memory CH number.
• If no memory CH is programmed in the selected BANK, no
memory CH selection is available.
Using the Keypad:
w Push , then push [0•BANK], and push the appropriate
digit key ([0•BANK] to [9•TAG]) to select the desired mem-
ory BANK number, then push [ENT] (or [CLR•DEL]) to exit
the BANK-selection mode.
e Push [MR•MW], then push 2 appropriate digit key (00 to
19) to select the desired memory CH number.
• If no memory CH is programmed in the selected BANK, no
memory CH selection is available.
NOTE: Comments appear first when programmed, how-
ever, the transceiver can be programmed by your dealer
to show the operating frequency first. Push [MR•MW] to
display the comment in this case.
■Transferring memory
contents
This function transfers a memory channel’s contents into the
frequency mode. This is useful when searching for signals
around a memory channel’s frequency.
qPush [MR•MW] to select memory mode.
wSelect the desired memory channel to be transferred
using [DIAL] or keypad.
ePush , then push [MR•MW] to transfer the memory
channel’s contents into the frequency mode.
• BANK number and memory CH number disappears as fre-
quency mode is automatically selected and the memory con-
tents are transferred.
Memory mode Frequency mode

13
4
MEMORY OPERATION
■Programming a memory
channel
The transceiver has 200 (20 CH ×10 BANK) memory chan-
nels for storage of often-used frequencies.
q Push [CLR•DEL] to select the frequency mode, if neces-
sary.
w Select the desired frequency.
• Set the desired frequency using [DIAL] or keypad.
ePush ,then push [MR•MW] to enter the memory pro-
gramming mode.
• “M”, memory BANK and memory channel number are blink.
rRotate [DIAL] to select the desired memory channel
number.
• Push , then push [0•BANK] to select the BANK number if
desired.
• Push [CLR•DEL], [ENT] or push then push [0•BANK] to exit
the BANK selection mode.
tPush [ENT] to program the information into the channel
and return to the frequency mode.
(or rotate [DIAL])
(or rotate [DIAL])
Push
Push
Push
Push
or
Push
Push
Push
or
• EXAMPLE: Programming 118.250 MHz into memory
BANK 3/ memory channel 9.
4

NOTE: When programming the memory name to the pre-
programmed memory channel do the following.
q Follow the same steps as in “Transferring memory con-
tents” (see p. 12).
w Follow steps w–yin “Programming memory names”
(see left column).
■ Clearing the memory contents
Unwanted memory channels can be cleared.
qSelect the memory channel to be cleared.
wPush ,then push and hold [CLR•DEL] for 1 sec.
• “-- -- -- -- -- --” appears momentarily, then the next selectable
channel appears.
14
4MEMORY OPERATION
■Memory names
ïProgramming memory names
The memory channel can display a 6-character name in-
stead of the programmed frequency.
q In the frequency mode, rotate [DIAL] to select the desired
frequency.
w Push , then push [MR•MW] to program the contents
into the selected memory channel.
e Rotate [DIAL] to select the desired memory channel to be
programmed.
• Push , then push [0•BANK], and rotate [DIAL] to select the
BANK number, if desired. Push [CLR•DEL] to exit the BANK se-
lection mode.
r Push [MR•MW] to enter the memory name programming
mode.
• “-- -- -- -- -- -- ” appears on the display.
t Push the appropriate digit key several times to select the
desired character, as listed to the right.
• To erase a character, overwrite with a space (displayed as _).
• To move the cursor forwards or backwards, use [DIAL].
y Push [ENT] to program the name.
• The memory name stops flashing.
• When no name is programmed, the display shows the operat-
ing frequency.
• To clear the entered memory names, push [CLR•DEL] before
pushing [ENT].
Key Character Key Character Key Character
1 1, Q, Z 2 2, A, B, C 3 3, D, E, F
4 4, G, H, I 5 5, J, K, L 6 6, M, N, O
7 7, P, R, S 8 8, T, U, V 9 9, W, X, Y
ENT Program 0 0, space, -

15
4
MEMORY OPERATION
Push
Push
Push
Push
Push
Push
Push
Push Push
Push
Push
(or rotate [DIAL])
(or rotate [DIAL])
• EXAMPLE: Programming 125.000 MHz into memory BANK 1/ memory channel 17 with “AIR-23” as a comment.
4

16
5SCAN OPERATION
■Scan types
The transceiver has 2 scan types to suit your needs.
■COM band scan
qPush [CLR•DEL] to select the frequency mode.
wPush [SQL], then rotate [DIAL] to set the squelch level to
the point where noise is just muted.
ePush , then push [ANL•SCAN] to start the scan.
• When a signal is received, the scan pauses until it disappears.
• To change the scanning direction, rotate [DIAL].
r To stop the scan, push [CLR•DEL].
■Memory scan
q Push [MR•MW] to select the memory mode.
• Push , then push [0•BANK] to select the BANK number, if
desired. Push [CLR•DEL] to exit the BANK selection mode.
wPush [SQL], then rotate [DIAL] to set the squelch level to
the point where noise is just muted.
e Push , then push [ANL•SCAN] to start the scan.
• When a signal is received, the scan pauses until it disappears.
• To change the scanning direction, rotate [DIAL].
r To stop the scan, push [CLR•DEL].
NOTE: Program 2 or more memory channels to start the
memory scan.
MEMORY SCAN
Repeatedly scans all se-
lected memory BANK’s
“TAG” memory channels.
Used for checking often-
used channels and bypass-
ing usually busy channels
such as control-tower fre-
quencies.
COM BAND SCAN
Repeatedly scans
all frequencies
over the entire
COM band.
10 .00
M
Scan
ump
11 .00
M
16. 5
M
non-TAG
channel
non-TAG channel
Mch 2 Mch Mch 6
MchMch 1
MchMch 10Mch 1
