Tennant B10 Operating and installation instructions

B10
9010736
Rev. 01 (5-2013)
www.tennantco.com
Rider Burnisher
North America / International
To view, print or download
the latest parts or operator’s
manual, visit:
www.tennantco.com/manuals
Service Information Manual
QA Controls®Supervisor Settings
TennantTrue®Parts
*9010736*

INTRODUCTION
This manualprovides necessary service and mainten-
ance instructions.
Read thismanual completely and
understand the machine before
servicing it.
This machinewill provide excellent service. However,
the best results will be obtained at minimum costs if:
SThe machine is operated with reasonable care.
SThe machine is maintained regularly-per the
maintenance instructions provided.
SThe machine is maintainedwith manufacturer
supplied or equivalentparts.
To view, print or download manualsonline visit
www.tennantco.com/manuals
PROTECT THE ENVIRONMENT
Please dispose of packaging materials
and used machine components such
as batteries inasafe environmentally
way according to yourlocal waste
disposal regulations.
Always remember to recycle.
Tennant Company
PO Box 1452
Minneapolis, MN 55440
Phone: [phone] or (763)513--2850
www.tennantco.com
QA Contols and 1--STEP are US registered andunregistered trademarks of
Tennant Company.
Trojan and HydroLINK are registered trademarks of Trojan Battery Company.
Specificationsandparts are subject to change withoutnotice.
OriginalInstructions. CopyrightE2012 Tennant Company.
All rights reserved. Printed in U.S.A.
INTENDED USE
The B10 Rider Burnisher machine is intended for
commercial use, for example in hotels, schools,
hospitals, factories, shops, offices and rental
businesses. It is designed to burnish dry hard floor
surfaces in an indoorenvironmentand is not
constructed for any other use. Use only recommended
burnishingpadsintended for machineapplication.
MACHINE DATA
Please fillout at time of installation
for future reference.
ModelNo. --
SerialNo. --
InstallationDate --

B10 Service Information (5-13) 3
CONTENTS
Safety PrecautionS .......................1-1
General information ..................... 21
COMPONENT LOCATOR.................... 22
ELECTRICAL SCHEMATIC, MASTER ......... 23
ELECTRICAL SCHEMATIC SYMBOLS ..... 25
OPERATIONAL MATRIX..................... 26
SPECIFICATIONS ........................... 27
FASTENER TORQUE ..................... 27
GENERAL MACHINE DIMENSIONS/
CAPACITIES .......................... 28
ELECTRICAL COMPONENTS............. 29
MACHINE DIMENSIONS................210
maintenance
MAINTENANCE CHART..................... 32
AFTER EVERY USE....................... 33
AFTER WEEKLY USE ..................... 34
AFTER EVERY 50 HOURS OF USE ........ 34
AFTER EVERY 200 HOURS OF USE ....... 34
BATTERY MAINTENANCE .................. 35
SEALED/AGM BATTERIES ............... 35
WET/LEADACID BATTERIES ............ 35
HYDROLINK™BATTERY WATERING
SYSTEM OPTION ................... 35
MACHINE JACKING ........................ 36
PUSHING TOWING AND TRANSPORTING
THE MACHINE .......................... 37
STORING MACHINE ........................ 37
troubleShootinG
CONFIGURATION MODES .................. 42
HEAD SELECT MODE.................... 42
BATTERY SELECT MODE ................ 43
BURNISH PROPEL SPEED
SELECT MODE ....................... 43
REVERSE ALARM SELECT MODE......... 44
DOWN PRESSURE SELECT MODE........ 44
SUPERVISOR MODE..................... 45
ACTIVE DUST CONTROL
SETUP MODE ........................ 46
DIAGNOSTIC MODES ...................... 47
DISPLAY SOFTWARE
REVISION MODE ..................... 47
SELFTEST MODE ....................... 47
MANUAL MODE ........................ 49
INPUT DISPLAY MODE .................. 49
PROPEL DIAGNOSTICS MODE..........411
FAULTS ..................................413
BATTERY CHARGER .......................417
SUBSYSTEM TROUBLESHOOTING .........418
BACKUP ALARM ......................418
BATTERY CHARGER ON BOARD.......420
Contents Page
BATTERY CHARGER OFF BOARD ......422
PARKING BRAKE,
ELECTROMAGNETIC ................424
BURNISH MOTOR ......................426
POWERUP CIRCUIT....................428
PROPEL................................430
BURNISH HEAD LIFT ...................432
ADC ACTIVE DUST CONTROL.........434
Service
MAIN BURNISH HEAD...................... 52
LIFT ACTUATOR......................... 52
REMOVAL............................ 52
INSTALLATION ....................... 53
BURNISH HEAD ASSEMBLY. . . . . . . . . . . . . . 54
REMOVAL............................ 54
INSTALLATION ....................... 55
BURNISH MOTOR ....................... 56
REMOVAL............................ 56
INSTALLATION ....................... 56
CARBON BRUSHES................... 56
WHEEL DRIVE ASSEMBLY .................. 58
STEERING ASSEMBLY ................... 58
REMOVAL............................ 58
INSTALLATION ......................510
WHEEL DRIVE ASSEMBLY ..............510
REMOVAL...........................510
INSTALLATION ......................511
CARBON BRUSHES..................512
DRIVE TIRE.............................513
REMOVAL...........................513
INSTALLATION ......................514
PARKING BRAKE, ELECTROMAGNETIC..515
CHECKING AIR GAP .................515
CHECKING ROTOR ..................516
TESTING BRAKE RESISTANCE........517
LOGIC BOARD ............................517
REMOVAL...........................517
INSTALLATION ......................518
THROTTLE/BRAKE SENSOR................519
Contents Page

CONTENTS
4B10 Service Information (5-13)

B10 Service Information (5-13) 1-1
SAFETY PRECAUTIONS
IMPORTANTSAFETY INSTRUCTIONS -- SAVE THESE INSTRUCTIONS
The followingwarning precautions are used throughout
this manual as indicated in theirdescription:
WARNING: To warn of hazards or unsafe
practiceswhich couldresult in severe personal
injury or death.
FOR SAFETY: To identify actionswhich must be
followed for safe operation of equipment.
The followinginformation signalspotentially
dangerous conditions to the operator. Knowwhen
these conditions can exist. Locate all safety devices on
the machine.Report machinedamage or faulty
operation immediately.
WARNING: To Reduce the Risk of Fire,
Explosion, Electric Shock or Injury:
-- Readmanual before operatingmachine.
-- Do not use or pick up flammablematerials.
-- Do not use near flammableliquids, vapors or
combustibledusts.
Thismachineisnot equipped with an
explosion proof motor. The electric motor will
sparkupon start up and duringoperation
which couldcauseaflash fire or explosion if
machine is usedinanareawhere flammable
vapors/liquids or combustibledusts are
present.
-- Batteries emit hydrogen gas. Explosion or fire
canresult. Keep sparks and open flame away
when charging.Open battery compartment for
ventilation.
-- Disconnect batterycables and charger cord
before cleaning and servicingmachine.
-- Do not charge batteries with damaged cord. Do
not modify plug.
If the charger supply cord is damaged or
broken, it must be replaced by the
manufacturer or its service agent orasimilarly
qualified person in order to avoid a hazard.
The use of unapproved battery chargersmay
damage the battery and potentiallycauseafire
hazard.
-- Do not use outdoors or on wet surfaces. Store
indoors.Thismachine is for dry use only.
-- Thismachineisnot suitable for picking up
hazardousdust.
FOR SAFETY:
1. Do notoperate machine:
-- Unless trained and authorized.
-- Unlessoperator manual is readand
understood.
-- Unlessmentally and physicallycapable of
followingmachineinstructions.
-- Under the influence of alcohol or drugs.
-- While using a cell phone or other types of
electronic devices.
-- If not in proper operating condition.
-- In outdoor areas.Thismachine is for
indoor use only.
-- With pads or accessories not supplied or
approved by Tennant. The use of other
pads may impair safety.
-- In areaswith possible fallingobjects.
-- In areas that are too dark to safely see the
controlsoroperate machine.
-- With brakedisabled.
-- Withoutdust bag and/or filters in place.
2. Before operatingmachine:
-- Make sure all safety devicesare in place
and operate properly.
-- Check brakes and steering for proper
operation.
-- Inspect charger cord regularly for signs of
damage or aging.
3. When operatingmachine:
-- Useonly as described in thismanual.
-- Report machine damage or faulty operation
immediately.
-- Reduce speedwhen turning.
-- Drive slowly on inclines and slippery
surfaces.
-- Do notoperate on inclines that exceed a
7% grade level.
-- Keep all parts of bodyinsideoperator
stationwhilemachine is moving.
-- Do notcarry passengers on machine.
-- Keep hands away from spinning pad.
-- Usecarewhen reversingmachine.
-- Never allow childrentoplay on or around
machine.
-- Keep children and unauthorized persons
away from machine.
-- Do not allow to be used asatoy.
SAFETY PRECAUTIONS

1-2 B10 Service Information (5-13)
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
4. Before leavingmachine:
-- Stop on level surface.
-- Turn off machine and remove key.
5. When servicingmachine:
-- Disconnect batterycables and charger plug
before workingonmachine.
-- All work must be donewith sufficient
visibility and lighting.
-- All repairs must be performed byatrained
service mechanic.
-- Usemanufacturer supplied or approved
replacement parts.
-- Do not modify the machine from its original
design.
-- Avoid moving parts. Do not wearloose
clothing or jewelry. Secure long hair when
workingaroundmachinery.
-- Do notdisconnect the off--board charger’s
DC cord from the machine’s receptacle
when the charger is operating.Arcingmay
result. If the charger must be interrupted
during charging,disconnect the AC power
supply cord first.
-- Keepwork area well ventilated.
-- Avoid contactwith batteryacid.
-- Do notpower sprayorhose off machine.
-- Do notpush or tow the machine on inclines
with the brakedisabled.
-- Jackmachine up at designated locations
only. Block machine up with jack stands.
-- Block machine tires before jackingmachine
up.
-- Use jackorhoist that will support machine
weight.
-- Wear appropriate personal protection
equipment as needed and where
recommended in thismanual.
For Safety: wear protective gloves.
For Safety: weareye protection.
For Safety: wear protective dust mask.
6. When loading/unloadingmachineonto/off
truck or trailer:
-- Usearamp that can support the machine
weight and operator.
-- Do notoperate the machine on a ramp
incline that exceedsa19.5% grade level.
-- Useawinch if rampinclineexceeds a
19.5% grade level.
-- Do notpush or tow the machine on inclines
with the brakedisabled.
-- Lower the pad driver after loading.
-- Turn machine off.
-- Block machinewheels.
-- Use tie--down straps to secure machine.

B10 Service Information (5-13) 1-3
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
SAFETY LABELS
The safety labelsappear on the machine in the locationsindicated.Replace labels if they are missing or become
damaged or illegible.
WARNING LABEL -- Located on steering column.
FOR SAFETY LABEL --
Readmanual before
operatingmachine.
-- Located on seatpanel
WARNING LABEL --
Disconnect battery
cables before servicing
machine.
-- Located behind kick
panel on control board
cover.
WARNING LABEL --
Batteries emit hydrogen gas. Explosion or fire
canresult. Keep sparks and open flame away
when charging.
-- Located on backside of seatpanel.

1-4 B10 Service Information (5-13)
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS

GENERAL INFORMATION ..................... 21
COMPONENT LOCATOR.................... 22
ELECTRICAL SCHEMATIC, MASTER ......... 23
ELECTRICAL SCHEMATIC SYMBOLS ..... 25
OPERATIONAL MATRIX..................... 26
SPECIFICATIONS ........................... 27
FASTENER TORQUE ..................... 27
GENERAL MACHINE DIMENSIONS/
CAPACITIES .......................... 28
ELECTRICAL COMPONENTS............. 29
MACHINE DIMENSIONS................210
GENERAL INFORMATION
SECTION 2
Contents Page
2-1
B10 Service Information (5-13)

2-2 B10 Service Information (5-13)
GENERAL INFORMATION
COMPONENT LOCATOR
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
Components
AActive Dust Control Vacuum*
BSeat Switch
CBurnish Motor
DContact Switch, Pad Change Mode
ECircuit Breaker-3 (150A Resettable)
Hour Meter, Circuit Breaker-1 (5A),
Circuit Breaker-3 (5A)
FWheel Drive Assembly,
Electromagnetic Parking Brake
GM1 and M2 Contactors,
Current Shunt (Burnish Motor)
D1 and D2 Diodes
HThrottle/Brake Sensor
ICircuit Board
JFlashing Light*
KModule, IRIS™ Telemetry*
LOn-Board Battery Charger*
MCurrent Shunt (IRIS™)*
NActuator, Burnish Head Lift
OThrottle/Brake Sensor
PKey Switch, E-Stop Switch,
Directional Switch, BDI (Battery
Discharge Indicator)
QTouch Panel
RBattery Compartment
* Optional Equipment

B10 Service Information (5-13) 2-3
GENERAL INFORMATION
PEDAL SENSOR
NO
COM
NC
B10 Control Board
46/BLU
36/BLU
56/BLU
A
B
C
D
ELECTRICAL SCHEMATIC (1 of 2)

2-4 B10 Service Information (5-13)
GENERAL INFORMATION
ELECTRICAL SCHEMATIC (2 of 2)
NC
B10 Control Board
HEAD LIFT ACTUATOR A
HEAD LIFT ACTUATOR
HEAD LIFT ACTUATOR (INTERNAL)
HEAD LIFT ACTUATOR B
B C D
34/YEL
45/GRN
36/BLU
A
B
C
D

B10 Service Information (5-13) 2-5
GENERAL INFORMATION
ELECTRICAL SCHEMATIC SyMbOLS
1
2
2
1
+ -
+ -
Switched B+
From Buss Bar
Switched B+
B- From
Stando
B- From
Stando
S-5 Seat Switch (N.O.)
Amer
Encoder
Cable
C1 Capacitor (0.01Uf)
R1
(11 Ω/40W)
+ -
MTR
ecH2O
Pump
J3-2 Brush RT-
J3-5 Brush LT+
J3-6 Brush LT-
Right/Rear Brush
Left/Front* Brush
* Cylindrical = Uses Adaptor
ecH2O
Control
Module
T16
Control
Board
VCC_A
Alarm
Com N.C.
N.O.
S-14 Pressure Sw.
N.C. Opens @ 25 +/- 2 psi
Enable
GND_A
GND_B
Pressure IN
(ECH2O SW)
(ECH2O SW)
VCC_B
VCC_C
Pump
(SOL-A)
ecH2O Valve
Sparger
e-Cell
65EA/BLU
5EA/GRN
8EA/GRY
7EA/PUR
3EA/ORA
4EA/YEL
(SOL-B)
(SPA-A)
(SPA-B)
(CELL-A)
(CELL-B)
(LED GND)
(LED RED)
(LED GRN)
Squeegee
Actuator
Battery Positive +
Battery Negative -
D-8
FU2
100A
70/TAN
M4A
86 85
B+
J7-1 B+ Control
B-
Cable
8/GRY
FU1
100A
FU1
100A
102/BRN
Sweep OFF/Down = 2-1, 6-5
Sweep ON/Center = 2-3, 6-7
Vac & Sweep ON/Up = 3-4, 7-8
Cable
Pre-Sweep
Brush Relay
CB3 (2.5A)
CB19 (25A)
CB16 (15A)
J7-4 Sweep
Note:
ecH2O Enable:
J7-10 Low=Turn ON ecH2O
Note:
Pre-Sweep Enable:
J6-10 B+ = Sweep Enable ON
Sweep Enable J6-10
37/PUR
38/GRY
CB9 (2.5A) 79/WHT
CB10 (2.5A)
Note:
ecH2O Side Brush
J7-12 Low=SV3 H20 Valve ON
ecH2O Pump ON 100%
13/BLK
88/GRY
9EA/WHT
S-15
Flush Switch
13EA/BLK
21/PNK
Extend
Limit Sw.
22/BRN
MTR 26/BLU
25/GRN
2/BRN
Switched B+
From Buss Bar
Switched B+
From Buss Bar
Switched B+
To: CAN Open-
(J6-14)
To: Throttle
Sensor (GND)
To: Curtis 1234
(I/O GND)
To: CAN Open+
(J6-13)
To: Back-Up
Light Circuit
To: Back-Up
Alarm Circuit
80/TAN
PMC001
12
12
MTR
10 4
1
3
2
7
9
6-4
6-8
5
6
11
12
8
6-1
6-2
6-3
6-6
6-5
6-7
ON
OFF
6
2
8
5
4
1
FWD
REV
6
2
8
BA
5
4 J1-33
GND Cable
J1-34
J1-21
W/WHT
V/GRN
U/ORN
J1-3
J1-4
J1-13
J1-11
BLU2 J1-32
J1-26
J1-31
J1-7
J1-18 J1-15
66/BLU 61/PNK
62/BRN 12/BRN
17/PUR
Propel Motor Assembly
17/PUR
15/GRN
87/PUR
Temp Sender
Brake Solenoid
59/WHT
58GRY
RED1 WHT5 BLK6
YEL
T2
B1 B2
T1
YEL
J1-16 J1-35 J1-23
P1-C
BLU
YEL
P1-B
P1-D
BLK
P1-A
RED
J1-22
J1-9
J1-1
B+
J1-29
J1-28
J1-25
1
1
3
5
7
2
4
6
8
Pre-Sweep Switch
Sweep OFF/Down = 2-1, 6-5
Sweep ON/Center = 2-3, 6-7
Vac & Sweep ON/Up = 3-4, 7-8
1
3
5
7
2
4
6
8
M3B
MTR
MTR
MTR
MTR
FaST/ES Pump
D-9
D-6
D-7
D-12
67/PUR
64/YEL 81/PNK
Pre-Sweep
Vacuum Fan
LH Side Broom Motor
Main Broom Motor
13/BLK
13/BLK
65/GRN
65/GRN
65/GRN
68/GRY
69/WHT
D-11
30 87
M3A
Curtis 1234
Controller
PROG +
TX
RX
B+
KSI
INTERLOCK
FWD
FWD/REV Switch
Throttle Sensor
REV
B -
GND
B+
THROTTLE
BRAKE
CAN TERM L
CAN TERM H
U
DRV3
DRV4
DRV1 THERMISTOR I/O GND PHASE A PHASE B +5V DRV2
COIL RETURN
V
W
BRAKE IN
(0-5 vdc)
(0-5 vdc) THROTTLE
CAN L
8/GRY 8/GRY
18/GRY
16/BLU
94/YEL
9/WHT
11/PNK
14/YEL
58/GRY
58/GRY
CAN H
6 Volt
IGN
15
ACC
30
BAT T
75
50 Start
ST
To: Back-Up
Alarm Circuit
+ -
Com N.C.
N.O.
1
3
5
7
2
4
6
8
MTR MTR
M3B
30 87
M3B
30 87a
M3A
IGN ST
+ -
Note: Key Switch ON
Key Switch
Battery
DPDT Switch
Pressure Switch
Motor
3 Phase AC
Induction Motor
Motor Encoder
Momenary Switch N.O.
Contact Switch N.C.
Solenoid Valve
Sensor
(Variable Resistor)
Circuit Breaker
Fuse
Diode
Single Continuation Tab
Double Continuation Tab
Relay Coil
N.C. Relay Contacts
N.O. Relay Contacts
Horn or Alarm
Light
Connected
Not Connected
Connector
Energized
Adaptor Harness
Notes
Assembly
AC Plug
Capacitor
Electro-
Magnetic
Brake
Enabled (Applied)
• Key O
• Neutral - Ready State
• Brake Command
• Seat Switch Open
• Curtis 1234 Fault
(See Troubleshooting)
• Throttle Command
• Seat Switch Closed
Disabled (Released)
Operational Matrix:
Propel
Enabled
•Seat Switch Closed
• Foot Throttle
Command
• Fwd/Rev Switch Input
• Seat Switch Open
• Neutral-Ready State
• Brake Command
• Curtis 1234 Fault
Disabled
Operational Matrix:
* SV2 Water Valve Voltage
Range
Low 1-LED
2-LEDs
3-LEDs
1-LED
2-LEDs
3-LEDs
1-LED
2-LEDs
3-LEDs
20%
30%
45%
30%
55%
80%
55%
80%
100%
7.2 Volts
10.8 Volts
16.2 Volts
10.8 Volts
19.8 Volts
28.8 Volts
19.8 Volts
28.8 Volts
36 Volts
Med
(Default)
High
Level PWM% @ Nominal
36 VDC

2-6 B10 Service Information (5-13)
GENERAL INFORMATION
FUNCTION ENABLED
B10 OPERATIONAL MATRIX
DISABLED
Burnish Motor - On • 1-STEP Burnish ON
• Fwd/Rev Throttle Command
• 1-STEP Burnish OFF
• Neutral - Ready State
• Low Battery Voltage
• Load Current Fault
Active Dust Control • 1-STEP Burnish ON
• Vacuum ON
• 1-STEP Burnish OFF
• Vacuum OFF
• Low Battery Voltage
• Load Current Fault
Pad Change Mode • 1-STEP Burnish ON
• Pad Change Button OFF
• Low Battery Voltage
• Load Current Fault
• Pad Change Button ON
Burnish Head Down
(completely - pad ON)
• 1-STEP Burnish ON
• Fwd/Rev Throttle Command
• 1-STEP Burnish OFF
• Neutral - Ready State
• Low Battery Voltage
• Load Current Fault
Burnish Head - Ready State
(slightly o oor - pad OFF)
• 1-STEP Burnish ON
• Neutral Throttle Command
• 1-STEP Burnish OFF
• Fwd/Rev Throttle Command
• Low Battery Voltage
• Load Current Fault
MOM001
Back-Up Alarm • Reverse Switch Input • Forward Switch Input
• Hospital Mode - Silent
• Load Current Fault
Electromagnetic Parking
Brake
• Key OFF
• Emergency Stop Switch Open (Down)
• Battery Charger ON
• Neutral (1-2 Second Delay)
• Seat Switch Open
• Load Current Fault
• Key ON
• Emergency Stop Switch Closed (Up)
• Fwd/Rev Throttle Command
• Seat Switch Closed
Propel • Seat Switch Closed
• Fwd/Rev Throttle Command
• Fwd/Rev Switch Input
• Seat Switch Open
• Battery Charger ON
• Neutral - Ready State
• Pad Change Mode
• Brake Command
• Load Current Fault

B10 Service Information (5-13) 2-7
GENERAL INFORMATION
FASTENER TORQUE
Thread
Size
SAE
Grade 1
SAE
Grade 2
Carriage
Bolts
Thread
Cutting
Thread
Rolling
SAE
Grade 5
Socket &
Stainless
Steel
SAE
Grade 8
Headless
Socket Set
Screws
Square
Head Set
Screws
4 (.112) (5) - (6.5) (4) - (6)
Inch Pounds
5 (.125) (6) - (8) (9) - (11)
6 (.138) (7) - (9) (20) - (24) (9) - (11)
8 (.164) (12) - (16) (40) - (47) (17) - (23)
10 (.190) (20) - (26) (50) - (60) (31) - (41)
1/4 (.250) 4 - 5 5 - 6 7 - 10 7 - 10 10 - 13 6 - 8 17 - 19
Foot Pounds
5/16 (.312) 7 - 9 9 - 12 15 - 20 15 - 20 20 - 26 13 - 15 32 - 38
3/8 (.375) 13 - 17 16 - 21 27 - 35 36 - 47 22 - 26 65 - 75
7/16 (.438) 20 - 26 26 - 34 43 - 56 53 - 76 33 - 39 106 - 124
1/2 (.500) 27 - 35 39 - 51 65 - 85 89 - 116 48 - 56 162 - 188
5/8 (.625) 80 - 104 130 - 170 171 - 265 228 - 383
3/4 (.750) 129 - 168 215 - 280 313 - 407 592 - 688
1 (1.000) 258 - 335 500 - 650 757 - 984 1281 - 1489
Thread
Size
4.8/5.6 8.8
Stainless Steel
10.9 12.9 Set
Screws
M3 43 - 56 Ncm 99 - 128 Ncm 139 - 180 Ncm 166 - 215 Ncm 61 - 79 Ncm
M4 99 - 128 Ncm 223 - 290 Ncm 316 - 410 Ncm 381 - 495 Ncm 219 - 285 Ncm
M5 193 - 250 Ncm 443 - 575 Ncm 624 - 810 Ncm 747 - 970 Ncm 427 - 554 Ncm
M6 3.3 - 4.3 Nm 7.6 - 9.9 Nm 10.8 - 14 Nm 12.7 - 16.5 Nm 7.5 - 9.8 Nm
M8 8.1 - 10.5 Nm 18.5 - 24 Nm 26.2 - 34 Nm 31 - 40 Nm 18.3 - 23.7 Nm
M10 16 - 21 Nm 37 - 48 Nm 52 - 67 Nm 63 - 81 Nm
M12 28 - 36 Nm 64 - 83 Nm 90 - 117 Nm 108 - 140 Nm
M14 45 - 58 Nm 102 - 132 Nm 142 - 185 Nm 169 - 220 Nm
M16 68 - 88 Nm 154 - 200 Nm 219 - 285 Nm 262 - 340 Nm
M20 132 - 171 Nm 300 - 390 Nm 424 - 550 Nm 508 - 660 Nm
M22 177 - 230 Nm 409 - 530 Nm 574 - 745 Nm 686 - 890 Nm
M24 227 - 295 Nm 520 - 675 Nm 732 - 950 Nm 879 - 1140 Nm
METRIC
SAE (STANDARD)

2-8 B10 Service Information (5-13)
GENERAL INFORMATION
MODEL 24 in / 610 mm 27 in / 686 mm
Length 58.5 in / 1486 mm 58.5 in / 1486 mm
Width 30 in / 762 mm 31.5 in / 800 mm
Height 55 in / 1397 mm 55 in / 1397 mm
Weight 596 lb / 270 kg 600 lb / 272 kg
Weight with batteries 1,346 lb / 610 kg 1,350 lb / 612 kg
GVWR 1648 lb / 747 kg 1650 lb / 748 kg
Burnish path width 24 in / 610 mm 27 in / 686 mm
Productivity rate (max.) 30,250 ft/hr / 2,813 m/hr 34,375 ft/hr / 3,197 m/hr
Burnishing speeds (standard settings) Low: 150 fpm / 45.7 mpm
Med: 175 fpm / 53.3 mpm
High: 200 fpm / 61.0 mpm
Low: 150 fpm / 45.7 mpm
Med: 175 fpm / 53.3 mpm
High: 200 fpm / 61.0 mpm
Transport speed (max.) Fwd: 435 fpm/ 8 Kpmh
Rev: 240 fpm/ 4.4 Kpmh
Fwd: 435 fpm/ 8 Kpmh
Rev: 240 fpm/ 4.4 Kpmh
Aisle turn (min.) 70 in / 1,778 mm 70 in / 1,778 mm
Grade level (max.) Transport: 19.5%, Burnishing: 7% Transport: 19.5%, Burnishing: 7%
Propel Motor 24 V, 41 A, 1.1 hp / 0.82kW 24 V, 41 A, 1.1 hp / 0.82kW
Pad motor 36 V, 100 A, 9.4 hp max / 7 kW 36 V, 100 A, 9.4 hp max / 7 kW
Pad Pressure Low: 45 lb/ 20.4 Kg
Med: 65 lb/ 29.5 Kg
High: 85 lb/ 38.5 Kg
Low: 45 lb/ 20.4 Kg
Med: 65 lb/ 29.5 Kg
High: 85 lb/ 38.5 Kg
Pad speed 1500-1600 rpm 1500-1600 rpm
Vacuum motor (Active Dust Control) 36 V, 12 A, 1400W / 1.4 kW 36 V, 12 A, 1400W / 1.4 kW
HEPA ltration 99.97% @ 0.3 micron 99.97% @ 0.3 micron
Dust bag capacity 6 qt / 5.7 l 6 qt / 5.7 l
Machine Voltage 36 VDC 36 VDC
Battery capacity Six 6V, 435 Ah Wet/lead-acid (std.)
Six 6V, 390 Ah AGM (opt.)
Six 6V, 435 Ah Wet/lead-acid (std.)
Six 6V, 390 Ah AGM (opt.)
Total power consumption 120A / 4.3 kw nominal 120A / 4.3 kw nominal
Run time (max.) 3.0 hours 3.0 hours
Battery charger 120 VAC, 60 Hz, Output 36 VDC, 25 A 120 VAC, 60 Hz, Output 36 VDC, 25 A
220/240 VAC, 50/60 Hz
Output 36 VDC, 25 A
220/240 VAC, 50/60 Hz
Output 36 VDC, 25 A
Protection grade IPX3 IPX3
Sound pressure level LpA 69 dB(A) 69 dB(A)
Sound uncertainty KpA 3.0 dB(A) 3.0 dB(A)
Sound power level LwA + uncertainty KwA xx dB(A) xx dB(A)
Machine vibration at hand-arm <2.5 m/s <2.5 m/s
Machine vibration at operator seat <2.5 m/s <2.5 m/s
Machine vibration uncertainty K 0.2 m/s 0.2 m/s
Ambient operating temperature Min: 32°F/0°C
Max: 110°F/43°C
Min: 32°F/0°C
Max: 110°F/43°C
GENERAL MACHINE DIMENSIONS/CAPACITIES
Values per IEC 60335-2-72
Specications are subject to change without notice.

B10 Service Information (5-13) 2-9
GENERAL INFORMATION
Component Measure
Contactor Coil, M1 77 Ω +/- 10%
Contactor Coil, M2 77 Ω +/- 10%
Actuator, Scrub head lift 1 - 3 Amps Continuous
Motor, Vacuum Fan 2.5 +/- 5% Amps (3.0 +/- 5% Amps Economy Mode)
Motor, Propelling
(transport speed)
14-18 Amps Continuous, 41Amps Max
Brake, Parking 29 Ω +/- 5%
Motor, Main - 24 in Pad Low Range Medium - Default Range High Range
Down Pressure 1 LED 65 Amps 70 Amps 75 Amps
Down Pressure 2 LEDs 73 Amps 78 Amps 83 Amps
Down Pressure 3 LEDs 80 Amps 85 Amps 90 Amps
Motor, Main - 27 in Pad Low Range Medium - Default Range High Range
Down Pressure 1 LED 65 Amps 70 Amps 75 Amps
Down Pressure 2 LEDs 73 Amps 78 Amps 83 Amps
Down Pressure 3 LEDs 80 Amps 85 Amps 90 Amps
ELECTRICAL COMPONENTS (For Reference Only)
SPECIFICATIONS
Specications are subject to change without notice.

2-10 B10 Service Information (5-13)
GENERAL INFORMATION
SPECIFICATIONS
MACHINE DIMENSIONS
30 in / 762 mm
(24 in / 610 mm Model)
58.5 in / 1,486 mm
55 in
1,397 mm
31.5 in / 800 mm
(27 in / 686 mm Model)

MAINTENANCE
SECTION 3
3-1
B10 Service Information (5-13)
Maintenance
MAINTENANCE CHART..................... 32
AFTER EVERY USE....................... 33
AFTER WEEKLY USE ..................... 34
AFTER EVERY 50 HOURS OF USE ........ 34
AFTER EVERY 200 HOURS OF USE ....... 34
BATTERY MAINTENANCE .................. 35
SEALED/AGM BATTERIES ............... 35
WET/LEADACID BATTERIES ............ 35
HYDROLINK™BATTERY WATERING
SYSTEM OPTION ................... 35
MACHINE JACKING ........................ 36
PUSHING TOWING AND TRANSPORTING
THE MACHINE .......................... 37
STORING MACHINE ........................ 37
Contents Page

3-2 B10 Service Information (5-13)
MAINTENANCE
MAINTENANCECHART
9
1
3
5
6
7
8
2
Interval/
Hours
Person
Resp.KeyDescription Procedure
DailyO 1 BatteriesCharge
O 2 BurnishingpadCheck, rotate or replace
O
O
3Dust collectionbagCheck, replace
5 VacuumHose Check, clean
Weekly O 1 Battery electrolyte level Check
50 Hours O 6 Burnishingheaddust skirt Check for wearanddamage
O 6 BurnishingHeadCleanwith air pressure hose
O 7 MachineCleanwith damp cloth
200Hours O 1 Batteries, terminalsand cablesCheck, clean
O 3 Vacuum HEPA filter Check, clean, replace
O 3 Vacuum exhaust filter Check, clean, replace
T 7 Steering chainandpivot points Lubricate with grease
750Hours T 8 Propel Motor Replace carbon brushes
1000Hours T 9 Pad Motor Replace carbon brushes
O = Operator T = Trained Personnel
