TEQ-C7989M, C7489, C7489M,
C6989 Projectors
User’s Manual (concise)
Thank you for purchasing this projector. Please read through this manual to ensure proper
safety and operation.
WARNING
nBefore using this product, be sure to read the entire manual. After reading the manual, store it in
a safe place for future reference.
nHeed all the warnings and cautions in the manual or on the product.
nFollow all the instructions in the manual or on the product.
NOTE
In this manual, unless any comments are accompanied, “the manuals” means all the
documents provided with this product, and “the product” means this projector and all the
accessories came with the projector.
Contents
Introduction....................... 2
Entries and graphical symbols explanation ......2
Important Safety Instruction ...............2
Regulatory Notices ................. 3
About Electro-Magnetic Interference. . . . . . . . . .3
About Waste Electrical and Electronic Equipment..3
Contents of package ................ 4
Preparations ...................... 5
Loading batteries into the remote control.......5
Arrangement ...................... 6
Connecting your devices............. 8
Connecting the power supply ........ 10
Turning on the power .............. 11
Adjusting the projector’s elevator feet . 12
Displaying the picture.............. 13
Turning off the power .............. 14
Replacing the lamp ................ 15
Cleaning and replacing the air lter ... 17
Replacing the internal clock battery... 19
Specications .................... 20
Troubleshooting................... 21

2
INTRODUCTION
Warnings
The following entries and graphical symbols are used for the manuals and the product, for
safety purposes. Please know their meanings beforehand, and heed them.
WARNING This entry has a risk of serious personal injury or even death.
CAUTION This entry has a risk of personal injury or physical damage.
NOTICE This entry notices a fear of causing trouble.
Important Safety Instruction
The following are important safety instructions. Be sure to follow them when handling the
product. The manufacturer assumes no responsibility for any damage caused by mishandling the
product beyond normal usage dened in these manuals.
WARNING
nNever use the product in or after an abnormality (ex. smoke, strange smell, foreign liquid or
object lodged inside, malfunction, etc.) If an abnormality should occur, unplug the projector
immediately.
nSituate the product away from children and pets.
nUnplug the projector from the power outlet if the projector is not being used for an extended
period.
nDo not open or remove any portion of the product, unless the manuals direct it. For internal
maintenance, contact Teq.
nOnly use the accessories specied or recommended by Teq.
nDo not modify the projector or accessories.
nDo not let any objects or liquids get inside the product.
nDo not wet the product.
nDo not place the projector where any oils, such as cooking or machine oil, are used. Oil may
harm the product, resulting in malfunction, or falling from the mounted position.
nDo not apply a shock or pressure to this product.
- Do not place the product on an unstable place such as an uneven surface.
- Remove all the attachments, including the power cord and cables, when carrying the projector.
nDo not look into the lens and the openings on the projector, while the lamp is on.
nDo not approach the lamp cover and the exhaust vents while the projection lamp is on. After the
lamp goes out, do not touch it until the projector cooled sufciently.

3
REGULATORY NOTICES
About Electro-Magnetic Interference
IN CANADA
This Class B digital apparatus complies with Canadian ICES-003.
IN THE US AND OTHER PLACES WHERE THE FCC REGULATIONS ARE APPLICABLE
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment causes harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on. The user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from the receiver.
- Consult the dealer or an experienced radio/TV technician for help.
Instructions to Users
This equipment complies with the requirements of FCC (Federal Communication
Commission) equipment provided that the following conditions are met. Some cables have
to be used with the core set. Use the accessory cable or a designated-type cable for the
connection. For cables that have a core only at one end, connect the core to the projector.
CAUTION
Unapproved changes or modications may void the user’s authority to operate the
equipment.

4
REGULATORY NOTICES (continued)
About Waste Electrical and Electronic Equipment
The mark is in compliance with the Waste Electrical and Electronic Equipment
Directive 2002/96/EC (WEEE). The mark indicates that you must dispose the
equipment, including any spent or discarded batteries or accumulators, as
unsorted municipal waste. Use the return and collection systems available.
If the batteries or accumulators included with this equipment display the
chemical symbol Hg, Cd, or Pb, it means the battery has a heavy metal content
of more than 0.0005% Mercury, or more than, 0.002% Cadmium, or more than
0.004% Lead.
CONTENTS OF PACKAGE
Your projector should come with the items shown
below. Make sure all the items are included. If any
items are missing, contact Teq.
(1) Remote control with the two AA batteries
(2) Power cord
(3) Computer cable
(4) Lens cover
(5) Security label
(6) Application CD
NOTE
Keep all original packing materials for future reshipment. Be sure to use the original
packing materials when moving the projector. Use special caution for the lens.

5
WARNING
Always handle the batteries with care and use them only as directed. Improper
use may result in battery explosion, cracking or leakage, which may result in
re, injury and/or pollution of the surrounding environment.
• When replacing the batteries, replace both of the batteries with new batteries
of the same type. Do not use a new battery with a used battery.
• Be sure to only use the batteries specied. Do not use batteries of different
types at the same time. Do not mix a new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading
a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
• Do not place a battery in a re or water. Keep batteries in a dark, cool and
dry place.
• If you observe battery leakage, wipe out the leakage and then replace a
battery. If the leakage adheres to your body or clothes, rinse well with
water immediately.
• Obey the local laws on disposing the battery.
PREPARATIONS
Loading batteries into the remote control
Please insert the batteries into the remote control before use. If the remote control starts to
malfunction, try to replace the batteries. If you will not use the remote control for an extended
period, remove the batteries from the remote control and store them in a safe place.
1. Hold the hook part of the battery
cover and remove it.
2. Align and insert the two AA
batteries according to their plus
and minus terminals, as indicated
in the remote control.
3. Replace the battery cover in the
direction of the arrow and snap it back into place.

6
ARRANGEMENT
Refer to the illustrations and tables below to determine screen size and projection
distance. The values shown in the table are calculated for a full size screen: 1024 x 768
a Screen size (diagonal)
b Projection distance (±10%)
c1 , c2 Screen height (±10%)
On a horizontal surface
Suspended from the ceiling
nKeep a space of 30 cm or
more between the sides of the
projector and other objects
such as walls. Do not place
or attach anything that would
block the lens or vent holes.
nIn the case of a specialty
installation such as ceiling
mount, the specied mounting
accessories (20) and
service may be required.
Before installing the projector,
consult Teq about your
installation.
16:9 screen
b
Projection distance c1
Screen height
c2
Screen height
min. max.
m inch m inch cm inch cm inch
1.0 38 1.1 45 39 15 -1 0
1.3 51 1.5 60 51 20 -2 -1
1.6 64 1.9 76 64 25 -2 -1
1.9 77 2.3 91 77 30 -2 -1
2.3 90 2.7 106 90 35 -3 -1
2.6 103 3.1 122 103 41 -3 -1
2.9 116 3.5 137 116 46 -4 -1
3.3 129 3.9 153 129 51 -4 -2
3.9 155 4.7 183 154 61 -5 -2
4.9 194 5.8 229 193 76 -6 -2
6.6 259 7.8 306 257 101 -8 -3
8.2 324 9.7 383 322 127 -10 -4
9.9 389 11.7 460 386 152 -12 -5
4.3 screen
a
Screen size
(diagonal)
b
Projection distance c1
Screen height
c2
Screen height
min. max.
type
(inch)
m m inch m inch cm inch cm inch
30 0.8 0.9 34 1.0 41 41 16 5 2
40 1.0 1.2 46 1.4 55 55 22 6 2
50 1.3 1.5 58 1.8 69 69 27 8 3
60 1.5 1.8 70 2.1 83 82 32 9 4
70 1.8 2.1 82 2.5 97 96 38 11 4
80 2.0 2.4 94 2.8 112 110 43 12 5
90 2.3 2.7 106 3.2 126 123 49 14 5
100 2.5 3.0 118 3.6 140 137 54 15 6
120 3.0 3.6 142 4.3 168 165 65 18 7
150 3.8 4.5 178 5.3 211 206 81 23 9
200 5.1 6.0 237 7.1 281 274 108 30 12
250 6.4 7.5 297 8.9 352 343 135 38 15
300 7.6 9.1 357 10.7 422 411 162 46 18

7
ARRANGEMENT (continued)
WARNING
nInstall the projector in a stable horizontal position.
nPlace the projector in a cool place, and make sure there is sufcient ventilation.
nDo not place the projector anyplace where it may get wet.
nOnly use the specied mounting accessories, and leave installing and removing the projector
with Teq.
nRead and keep the user’s manual.
CAUTION
nAvoid placing the projector in a smoky, humid or dusty place.
nPrevent light from directly hitting the projector’s remote sensor.

8
CONNECTING YOUR DEVICES
Be sure to read the device manuals before connecting them to the projector. Make sure
all the devices are suitable to be connected with this product, and prepare the cables to
connect. Please refer to the following illustrations to connect the cables:
nWhen AUTO is selected for the COMPUTER IN1 or COMPUTER IN2 port in
COMPUTER IN of the INPUT menu, that port will accept component video signals.
nTo use the projector’s network functions, connect the LAN port to the computer’s LAN
port, or to an access point that is connected to the computer with wireless LAN, using a
LAN cable.
nIf you insert a USB storage device, such as a USB memory drive, into the USB TYPE A
port and select the port as the input source, you can view images stored in the device.
nYou can connect a dynamic microphone to the MIC port with a 3.5 mm mini-plug. In this
case, the built-in speaker will output the sound from the microphone, even while the
sound from the projector is output.

9
CONNECTING YOUR DEVICES (continued)
WARNING
nOnly use the appropriate accessories. Otherwise, it may cause a re or damage to the device and
the projector.
- Only use the accessories specied or recommended by the projector’s manufacturer. Consult
Teq when the required accessory did not come with the product or the accessory is damaged.
It may be regulated under some standard.
- For a cable with a core at only one end, connect the end with the core to the projector. That
may be required by EMI regulations.
- Do not disassemble or modify the projector or the accessories.
- Do not use a damaged accessory. Be careful not to damage the accessories. Route a cable so
that it is neither stepped on nor pinched out.
CAUTION
nDo not turn on or off the projector while connected to a device in operation, unless it is
directed in the manual of the device.
nBe careful not to insert a connector incorrectly.
nBefore connecting the projector to a network, be sure to obtain the consent of the
administrator of the network.
nDo not connect the LAN port to any network that might have the excessive voltage.
nBefore removing the USB storage device from the port of the projector, be sure to use
the REMOVE USB function on the thumbnail screen to secure your data.
NOTE
nIf a loud feedback noise is produced from the speaker, move the microphone away from
the speaker. This projector does not support plug-in power for the microphone.

10
CONNECTING POWER SUPPLY
1. Put the connector of the power cord into the AC IN
(AC inlet) of the projector.
2. Firmly plug the power cord’s plug into the outlet.
After a few seconds, the POWER indicator will light
steady orange.
Please remember that when the DIRECT POWER ON
function is activated, the connection of the power
supply will turn on the projector.
WARNING
nPlease use extra caution when connecting the power cord, as incorrect or faulty connections may
result in re and/or electrical shock.
nOnly use the power cord that came with the projector. If it is damaged, consult Teq to get a new
one.
nOnly plug the power cord into an outlet that matches the voltage of the power cord. The power
outlet should be close to the projector and easily accessible. Remove the power cord for
complete separation.
nNever modify the power cord.

11
TURNING ON THE POWER
1. Make sure the power cord is rmly and correctly
connected to the projector and the outlet.
2. Make sure the POWER indicator is steady orange.
Then remove the lens cover.
3. Press the STANDBY/ON button on the projector
or the remote control.
The projection lamp will light up and the POWER
indicator will begin blinking in green. When the
power is completely on, the indicator will stop
blinking and light in steady green.
WARNING
nA strong light will emit when the projector’s power is on. Do not look into the lens of the projector
or look inside of the projector through any of the projector’s openings.
NOTE
nPlease power on the projector prior to the connected devices.
nThe projector has the DIRECT POWER ON function, which can automatically turn on the
projector.

12
ADJUSTING THE PROJECTOR’S ELEVATOR
If the projector is placed on an uneven surface, use
the elevator feet to place the projector horizontally.
The feet can also tilt the projector to project at
a suitable angle to the screen by elevating the
front side within 14 degrees. This projector has 2
elevator feet and 2 elevator buttons. An elevator
foot can be adjusted by pushing the elevator button on the same side.
1. Hold the projector, and push the elevator buttons to loosen the feet.
2. Position the front side of the projector to the desired height.
3. Release the elevator buttons to lock the elevator feet.
4. After making sure the elevator feet are locked, put the projector down gently.
5. If necessary, the elevator feet can be manually twisted to make more precise
adjustments. Hold the projector when twisting the feet.
CAUTION
nDo not handle the elevator buttons without holding the projector, since the projector may
drop down.
nDo not tilt the projector, other than elevating its front within 14 degrees using the adjuster feet.
A tilt of the projector exceeding the restriction may cause a malfunction, or shorten the lifetime
of the projector.
To loosen an elevator foot, push the
elevator button on the same side. Twist the foot, to nely adjust.

13
DISPLAYING THE PICTURE
1. Activate your signal source. Turn on the signal source,
and make it send the signal to the projector.
2. Use the VOLUME + / VOLUME - buttons to adjust the
volume. To silence the projector, press the MUTE button
on the remote control.
3. Press the INPUT button on the projector. Each time
you press the button, the projector will switch its input
port. You can also use the remote control to select an
input signal. Press the VIDEO button to select an input
signal from the HDMI, COMPONENT (Y, Cb/Pb, Cr/
Pr), S-VIDEO or VIDEO port, or the COMPUTER button
to select an input signal from the COMPUTER IN1,
COMPUTER IN2, LAN, USB TYPE A or USB TYPE B
port.
4. Press the ASPECT button on the remote control. Each
time you press the button, the projector will switch the
mode for aspect ratio.
5. Use the zoom ring to adjust the screen size.
6. Use the focus ring to focus the picture.
CAUTION
nIf you wish to have a blank screen while the projector’s lamp is on, use one of methods below:
-Use the supplied lens cover.
-Use the BLANK function.
nTaking any other action may cause the damage on the projector.
NOTE
nThe ASPECT button will not work without the proper signal.

14
TURNING OFF THE POWER
1. Press the STANDBY/ON button on the
projector or the remote control. The message
“Power off?” will appear on the screen for
about 5 seconds.
2. Press the STANDBY/ON button again when
the message appears. The projector lamp will
go off, and the POWER indicator will begin
blinking in orange. Then the POWER indicator
will stop blinking and light in steady orange
when the lamp cooling is complete.
3. Attach the lens cover, after the POWER
indicator turns in steady orange.
Do not turn on the projector for about 10
minutes or more after turning it off. Turning the projector on again too soon may shorten
the lifetime of some consumable parts.
WARNING
nDo not touch around the lamp cover or the exhaust vents during use or just after use, since it is
too hot.
nRemove the power cord for complete separation. The power outlet should be close to the
projector and easily accessible.
NOTE
nPlease power off all connected devices before powering off the projector.
nThe AUTO POWER OFF function can make the projector turn off automatically.

15
REPLACING THE LAMP
A lamp has a nite product life. Using the lamp for long periods of time may cause the
pictures to darken or compromise the color tone. Note that each lamp has a different
lifetime, and some may burst or burn out soon after you start using them. Preparation of a
new lamp and early replacement are recommended. To prepare a new lamp, make contact
Teq with the lamp type number:
Type number : DT01021
1. Turn off the projector, and unplug the power cord. Allow the
projector to cool for at least 45 minutes.
2. Prepare a new lamp. If the projector is mounted on a wall or
ceiling or if the lamp has broken, ask Teq to replace the lamp.
If you choose to replace the lamp yourseslf, consult the
following procedure.
3. Loosen the screw (marked by arrow) of the lamp cover and
then slide and lift the lamp cover to the side to remove it.
4. Loosen the 3 screws (marked by arrow) of the lamp, and slowly
pick up the lamp by the handles. Never loosen any other
screws.
5. Insert the new lamp, and rmly retighten the 3 screws of the lamp
that were loosened in the previous process to lock it in place.
6. While putting the interlocking parts of the lamp cover and the
projector together, slide the lamp cover back in place. Then
rmly fasten the screw of the lamp cover.
7. Turn on the projector and reset the lamp time using the LAMP
TIME item in the OPTION menu.
(1) Press the MENU button to display a menu.
(2) Point at the ADVANCED MENU in the menu using the /button, then press the button.
(3) Point at the OPTION in the left column of the menu using the /button, then press
the button.
(4) Point at the LAMP TIME using the /button, then press the button. A dialog will appear.
(5) Press the button to select “OK” on the dialog. This will reset the lamp time.
CAUTION
nDo not touch any inner space of the projector, when the lamp is out.
NOTE
nOnly reset the lamp time when you have replaced the lamp.

16
REPLACING THE LAMP (continued)
HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE
WARNING
nThe projector uses a high-pressure mercury glass lamp. The lamp can break with a loud
bang, or burn out if jolted or scratched, handled while hot, or worn over time. Note that
each lamp has a different lifetime, and some may burst or burn out soon after use. If
the bulb bursts, it is possible for shards of glass to y into the lamp housing, and for gas
containing mercury and dust containing ne particles of glass to escape from the projector’s
vent holes.
nAbout disposal of a lamp: This product contains a mercury lamp; do not put it in a trash.
Dispose of it in accordance with environmental laws.
nFor lamp recycling, go to www.lamprecycle.org (in the US).
nFor product disposal, consult your local government agency or www.eiae.org (in the US) or
www.epsc.ca (in Canada). For more information, ask Teq.
nIf the lamp should break (it will make a loud bang when it does), unplug the power
cord from the outlet, and make sure to request a replacement lamp from Teq. Note that
shards of glass could damage the projector’s internals, or cause injury during handling,
so please do not try to clean the projector or replace the lamp yourself.
nIf the lamp should break (it will make a loud bang when it does), ventilate the room
well, and make sure not to inhale the gas or ne particles that come out from the
projector’s vent holes. Do not to get particles into your eyes or mouth.
nBefore replacing the lamp, turn off the projector and unplug the power cord, then wait
at least 45 minutes for the lamp to cool sufciently. Handling the lamp while hot may
cause burns, as well as damage to the lamp.
nNever unscrew anything except the appointed (marked by an arrow) screws.
nDo not open the lamp cover while the projector is mounted on a wall or ceiling. This is
dangerous, since if the lamp’s bulb has broken, the shards will fall out when the cover
is opened. Working in high places is dangerous, so ask Teq to have the lamp replaced,
even if the bulb is not broken.
nDo not use the projector with the lamp cover removed. At the lamp replacing, make sure
the screws are screwed in rmly. Loose screws may result in damage or injury.
nOnly use the lamp of the specied type. Use of a lamp that does not meet the lamp
specications for this model may cause a re, damage, or shorten the life of this product.
nIf the lamp breaks soon after the rst time it is used, it is possible there are electrical
problems. If this happens, consult Teq.
nHandle with care: jolting or scratching may cause the lamp bulb to burst during use.
nUsing the lamp for long periods of time, may cause it to darken, burn out, or burst.
When the pictures appear dark or when the color tone is poor, please replace the lamp
as soon as possible. Do not use old (used) lamps; this is a cause of breakage.
Disconnect
the plug
from the
power
outlet

17
CLEANING AND REPLACING THE AIR FILTER
Please check and clean the air lter periodically. When the indicators or a message
prompts you to clean the air lter, comply with it as soon as possible. If the lters are
damaged or heavily soiled, replace them with the new ones. To prepare the new lters,
contact Teq with the following type number:
Type number : MU06481 (Filter set)
When you replace the lamp, please replace the air lter. An air lter of specied type will
come together with a replacement lamp for this projector.
1. Turn off the projector, and unplug the power cord. Allow
the projector to sufciently cool down.
2. Use a vacuum cleaner on and around the lter cover.
3. While supporting the projector with one hand, use your
other hand to pull the lter cover forward in the direction
of the arrow.
4. Use a vacuum cleaner for the lter vent of the projector
and the outer side of the lter unit.
5. Take out lters while holding the lter cover.
6. Use a vacuum cleaner on both sides of the lters. When
vacuuming up the ne meshed lter, hold it so it will not
be sucked in. If the lters are damaged or heavily soiled,
replace them with the new ones.
7. Put the lters back into the lter cover. Put the coarse
meshed lter into a lter cover rst. Then put the ne
meshed lter on the coarse meshed one, turning its
stitched side up.
8. Put the lter unit back into the projector.
9. Turn on the projector and reset the lter time using the
FILTER TIME item in the EASY MENU.
(1) Press the MENU button to display a menu.
(2) Point at the FILTER TIME using the /button, then press the button. A dialog
will appear.
(3) Press the button to select “OK” on the dialog. This will reset the lter time.

18
CLEANING AND REPLACING THE AIR FILTER (continued)
WARNING
nBefore taking care of the air lter, make sure the power cable is unplugged. Then, allow the
projector to cool sufciently.
nOnly use the air lter of the specied type. Do not use the projector without the air lter or the
lter cover. This may result in a re or a malfunction.
nClean the air lter periodically. If the air lter becomes clogged, internal temperatures will rise
and may cause a re, burn or malfunction.
NOTE
nOnly reset the lter time when you have cleaned or replaced the air lter.
nThe projector may display the message such as the “CHECK THE AIR FLOW” or turn off
the projector, to prevent the internal heat level rising.

19
REPLACING THE INTERNAL CLOCK BATTERY
This projector has an internal clock that uses a battery. When the clock of the network
function does not work correctly, please try replacing the battery.
1. Turn off the projector, and unplug the power cord. Allow
the projector to cool sufciently.
2. After making sure the projector has cooled adequately,
slowly turn over the projector so that the bottom is
facing.
3. Turn the battery cover fully in the direction indicated
“OPEN” using a coin or the like, and pick the cover up to
remove it.
4. Pry up the battery using a athead screwdriver or the like.
While prying it up, lightly put a nger on the battery since it
may pop out of the holder.
5. Replace the battery with a new one. Slide the battery
under the plastic claw, and push it into the holder until
it clicks.
6. Replace the battery cover, then turn it in the direction
indicated “CLOSE”using a coin.
NOTE
nThe internal clock will be initialized when the battery is
removed.
WARNING
nBe careful handling a battery, as a battery may cause explosion, cracking or leakage, which may
result in a re, an injury and environment pollution.
nOnly use the specied and perfect battery. Do not use a battery with damage, such as a scratch,
a dent, rust or leakage.
nWhen replacing a battery, always replace it with a new one.
nIf a battery leaks, wipe the leakage out with a waste cloth. If the leakage adheres to your body,
immediately rinse it well with water. If a battery leaks in the battery holder, replace the batteries
after wiping the leakage.
nMake sure the plus and minus terminals are correctly aligned when loading a battery.
nDo not work on a battery; for example recharging or soldering.
nKeep a battery in a dark, cool and dry place. Never expose a battery to a re or water.
nKeep a battery away from children and pets. If swallowed, consult a physician immediately for
emergency treatment.
nObey the local laws on disposing a battery.

20
SPECIFICATIONS
Item Specication
Product name Liquid crystal projector
Liquid Crystal Panel 786,432 pixels (1024 horizontal x 768 vertical)
Lamp <CP-X2011N> 190 W UHP
<CP-X2511N, CP-X3011N, CP-X4011N> 210 W UHP
Speaker 16 W mono (8 W x 2)
Power supply/Rated current <CP-X2011N> AC 100-120 V/3.2 A, AC 220-240 V/1.7 A
<CP-X2511N, CP-X3011N, CP-X4011N> AC 100-120 V/3.4 A, AC 220-240 V:310 W
Power consumption <CP-X2011N> AC 100-120 V: 310 W, AC 220-240 V:290 W
<CP-X2511N, CP-X3011N, CP-X4011N> AC 100-120 V: 330 W, AC 220-240 V:310 W
Temperature range 5 ~ 35°C (Operating)
Size 317 (W) x 98 (H) x 288 (D) mm
* Not including protruding parts. Please refer to the following gure:
Weight (mass) approx. 3.5 kg
Ports Computer input port
COMPUTER IN1
D-sub 15 pin mini x1
COMPUTER IN2
D-sub 15 pin mini x1
Computer output port
MONITOR OUT
D-sub 15 pin mini x1
Video input port
Y, Cb/Pb, Cr/Pr (Component video)......RCA ×3
S-VIDEO...............mini DIN 4 pin x1
VIDEO ................................RCA x1
HDMI input port
HDMI.............................HDMI connector x1
Audio input/output port
AUDIO IN1...........Stereo mini x1
AUDIO IN2...........Stereo mini x1
AUDIO IN3 (R, L) ......RCA x2
AUDIO OUT (R, L). . . . . .RCA x2
Others
USB TYPE A..........USB-Ax1
USB TYPE B..........USB-Bx1
CONTROL. . . . . . . . . . . .D-sub 9 pin x1
LAN ................RJ45 x1
MIC ................Stereo mini x1
Optional Parts Lamp: DT01021
Filter set: MU06481
Mounting accessary: HAS-3010 (Bracket for ceiling mount)
HAS-204L (Fixing adaptor for low ceilings)
HAS-304H (Fixing adaptor for high ceilings)
Laser remote control: RC-R008
Soft case: CA3010
*For more information, please consult Teq.
