Terex PT50T User manual

8/17/2016
Operation and Maintenance
Manual
PT50T
SN 00101-Current
English
Australia
Language:
Geographic Region:
Serial Number Range:
This manual is complements of
TrackLoaderParts.com
The world's best source for Terex parts.
Track Loader Parts 6543 Chupp Road Atlanta, Georgia 30058 USA [phone]

CONTENTS
Introduction .................................................. 2
Safety ........................................................ 5
Technical Data.............................................. 33
Machine Description / Controls..................... 39
Operation ..................................................... 47
Transportation .............................................. 57
Maintenance ................................................ 63
California Proposition 65 .............................. 83
Service Log .................................................. 84
1
Page
The operator must read and understand all the instructions
in this manual before operating the machine.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

1 INTRODUCTION
2
1.1 Product Identification (PIN)
The machine PIN is located on the identifi-
cation plate, behind and to the left of the
operator seat.
Please state the model of the machine and
PIN when making inquiries in regards to
parts, service, or warranty.
1.2 Introduction
Thank you for purchasing your PT-50 / PT-50T / PT-60 Compact Track
Loader. We are confident that the machine you have chosen will provide excellent
performance and efficient operation.
The information contained in this manual is intended to provide the operator with
all necessary information for the proper use of the machine.
It is imperative that this manual be provided to the end user at the time of pur-
chase, prior to operation and kept with the machine at all times. If lost or dam-
aged, contact your dealer immediately to obtain a replacement prior to resuming
operation.
It is very important that the operator read and understand the information in
this manual prior to operating the machine or performing maintenance or
service.
During operation, it is very important that the operator obey the instructions
in this manual to ensure safe and efficient operation.
Should you need clarification or further explanation of the topics in this manual,
please contact your dealer immediately for assistance.
Information describing special equipment or attachments and their operation are
not included in this manual.
This manual should be stored in the black plastic manual box located inside the
cab enclosure to protect it from the elements.
1.3 Safety Alert Symbol
The safety alert symbol is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

1 INTRODUCTION
3
1.4 Intended Use
The machine with standard dirt bucket is intended to be used solely for work con-
sistent with its design. Such work involves loosening, collecting, transporting, and
distributing soil, rock, or similar materials as well as loading these materials onto
trucks, conveyors, or other methods of transport.
After installation of compatible (see section 4.9) special working attachments, the
equipment can be used for corresponding applications.
The operator must follow the enclosed operating instructions for any externally
supplied components or attachments.
Any use varying from that described here or any lack of adherence to the operat-
ing instructions, maintenance procedures, or replacement intervals described in
this manual shall be regarded as unintended or improper use. The supplier cannot
be held responsible for any damage resulting from improper use. This risk is
borne solely by the user.
1.5 Bulletin Compliance
It is very important to comply with all safety related bulletins. Bulletins are tied to
the most current owner on record. Therefore, it is important that any new owner
contact their local dealer to register the machine in their name. This will ensure
that they will be notified in the event of a safety related bulletin affecting their
machine.
1.6 Contacting the Manufacturer
If you have questions relating to ownership including, but not limited to: accident
reporting, current owner updates, product applications and safety, standards and
regulations compliance, product modifications, transfer of ownership, please
consult your local dealer as the first point of contact.
1.7 Copyright
This manual is intended for use by personnel responsible for operation, mainte-
nance, repair, and supervision activities involving the machine described within.
This manual is copyrighted. It shall not, either in whole or in part, be reproduced,
transmitted, or used for the purpose of competition without our prior written
consent.
1.8 Warranty
Your Terex PT-50/50T/60 is warranted under the Terex Compact Track Loader and
Utility Vehicle Standard Limited New Product Warranty (“Warranty”). A copy of the
Warranty certificate is included with this manual and is also available from your
Authorized Terex Distributor.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

4
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2 SAFETY
5
2.1 Safety Alert System ................................ 7
2.2 Symbols ................................................. 8
2.3 Graphical Symbols ................................. 10
2.4 Safety Signs (ANSI) ................................ 14
2.4.1 Safety Signs (ISO)................................ 16
2.5 General Notes ........................................ 18
2.6 Personal Protection Equipment............... 19
2.7 Hazard Zone........................................... 19
2.8 Operation ............................................... 20
2.9 Stability.................................................. 21
2.10 Transport of Persons............................. 21
2.11 Fire Prevention ..................................... 22
2.12 Crush / Burn Avoidance........................ 23
2.13 Placing Into Operation .......................... 24
2.14 Starting the Machine............................ 24
2.15 Jobsite Safety ...................................... 25
2.16 Parking the Machine ............................ 26
2.17 Towing / Retrieving............................... 26
2.18 Transporting ......................................... 27
2.19 Maintenance ........................................ 28
2.20 Battery ................................................. 30
2.21 Hydraulic Lines / Hoses........................ 31
Page
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

6
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.1 Safety Alert System
Safety Alert Symbol
This symbol means: Attention! Be alert! Your safety
is involved!
The safety alert symbol is used to alert you to potential
personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or
death.
This symbol is used as an attention-getting device throughout this manual as well
as on decals and labels fixed to the machinery to assist in potential hazard recog-
nition and prevention.
NOTICE indicates a property damage
message.
Hazard Classification (applies only to ANSI safety signs)
The following signal words used with the safety alert symbol indicate a specific
level of severity of the potential hazard. Signal words used without the safety alert
symbol relate to property damage and protection only. Warnings in this publication
and on the product labels are identified by these symbols.
2 SAFETY
7
DANGER indicates a hazardous situ-
ation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous sit-
uation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert
symbol, indicates a hazardous situ-
ation which, if not avoided, could
result in minor or moderate injury.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.2 Symbols
Symbol Description
2 SAFETY
8
Engine Pre-heat
Battery
Engine Speed: Fast
Transmission Range: High
Engine Speed: Slow
Transmission Range: Low
Windshield Wiper
Beacon Light
Oil Pressure
Engine Coolant Temperature
Hydraulic Oil Temperature
Air Conditioning
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

Symbol Description
2 SAFETY
9
Work Lights
Fan
Bucket Positioning
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2 SAFETY
10
2.3 Graphical Symbols
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Skin/Oil Injection
Avoidance:
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pin-
holes.
• Use cardboard to check for leaks.
Fluid injected into skin must be
surgically removed within a few
hours by a doctor familiar with this
type of injury or gangrene will
result.
Hazard: Corrosive
Avoidance: Read and understand
the operator’s manual.
Hazard: Entanglement
Avoidance: Stop machine and
remove key before servicing.
Hazard: Burn/Scald
Avoidance: Allow to cool before
opening.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2 SAFETY
11
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Explosion/Burn
Avoidance:
• Keep all flames/sparks away!
• No Smoking!
• Read and understand all
manuals.
Hazard: Fall
Avoidance: Use the provided
access system when entering or
exiting the machine.
Hazard: Fall
Avoidance: No Riders.
Hazard: Burn
Avoidance: Do not touch hot
surfaces.
Hazard: Crush
Avoidance: Fasten seat belt.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2 SAFETY
12
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Entanglement
Avoidance: Stop machine and
remove key before servicing.
Hazard: Rollover / Ejection
Avoidance: Carry loads low, keep
heaviest end of machine uphill at
all times while operating on
inclines.
Hazard: Fall
Avoidance: Do not use the bucket
or attachment as a work platform.
Hazard: Crush
Avoidance: Stay clear of moving
machine.
Hazard: Crush
Avoidance: Keep clear of lift arms
and attachments.
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2 SAFETY
13
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Crush
Avoidance: Install lift arm brace
before servicing.
Hazard: The safety alert symbol is
used to alert you to potential per-
sonal injury hazards. Obey all safe-
ty messages that follow this sym-
bol to avoid possible injury or
death.
Avoidance: Read and understand
the operator’s manual.
Hazard: Fire
Avoidance: Read and understand
the operator’s manual.
2030-41
7
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.4 ANSI Safety Sign Location
The safety signs are located in/on the machine as indicated. (Descriptions of the
symbols are provided in section 2.3)
Key
1. Fall hazard
2. Skin (oil) injection hazard
3. Crush hazard (lift arms)
4. Fire hazard (read manual)
5. Burn hazard
6. Explosion / burn hazard (read operator’s manual)
7. Tie down location
8. Clean undercarriages notice
9. Crush hazard (run over)
10. Crush hazard (lift arm brace)
2 SAFETY
14
CRUSH HAZARD
Contact with moving machine can
result in death or serious injury.
Keep clear of moving machine.
2030-593
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Keep clear of lift arms and
attachments. 2030-592
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment. Install lift arm brace prior to servicing.
2030-594
Burn Hazard
Hot fluid under pressure can scald.
Allow the machine to cool thoroughly
before opening.
2030-595
Fall Hazard
Serious injury or death can result
from falling.
Use the provided access system when
entering or exiting the machine.
2030-597
Injection Hazard
Escaping fluid under pressure can
penetrate skin, causing serious injury.
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pinholes.
• Use cardboard to check for leaks.
Fluid injected into skin must be surgi-
cally removed within a few hours by a
doctor familiar with this type of injury
or gangrene will result. 2030-602
Fire Hazard
Flammable debris can collect near hot
components and lead to a fire.
Read Operator’s manual
Keep engine, exhaust and chassis
areas free of debris. 2030-599
Explosion/Burn Hazard
Will cause death, burns or
blindness due to ignition of
explosive gasses or contact
with corrosive acid.
• Keep all flames/sparks
away!
• No Smoking!
• Read and understand
all manuals prior to
operation. 2030-603
1
2
3
45
6
7
10 9Inspect undercarriages daily for
accumulation of debris. If debris
is present, clean thoroughly with
a pressure washer. If debris is
allowed to build up, it can cause
premature component wear and
decrease machine performance.
2085-253
NOTICE
8
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

Note:
If any of the safety signs shown in this section are missing or damaged, contact
your dealer to obtain a replacement.
Key (continued)
11. Belt/fan entanglement hazard
12. Skin (oil) injection hazard
13. Crush hazard (lift arm brace)
14. Crush Hazard (Lift arms)
15. Fall hazard / rollover Hazard / read operator’s manual
16. Crush / fall hazards
17. Crush (run over) hazard
18. Clean undercarriages notice
19. Tie down location
20. Burn hazard
2 SAFETY
15
Burn Hazard
Contact with hot surfaces can
cause burns.
• Do not touch hot
components!
• Allow the machine to
cool thoroughly prior to
servicing. 2030-601
Entanglement Hazard
Rotating parts can cause personal injury.
Keep away from fan and belt while the
engine is running. Stop engine before
servicing.
2030-600
CRUSH HAZARD
Contact with moving machine can
result in death or serious injury.
Keep clear of moving machine.
2030-593
Read Operator’s Manual
Read and understand the operator’s manual
and all safety signs prior to operating or
maintaining the machine.
Improper operation or maintenance can re-
sult in serious injury or death.
No Riders
Fall Hazard
Falling from a machine can result in serious
injury or death.
Carry loads low. Load unload and turn on
level ground. Travel on inclines with heaviest
end of machine uphill.
Rollover/Ejection Hazard
Serious injury or death can result.
2030-598
Fasten Seat Belt
Crush Hazard
Rollover can crush and result in serious injury or death.
Do not use the bucket/attachment as a work platform.
Fall Hazard
Falling can result in serious injury or death.
2030-596
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Keep clear of lift arms and
attachments. 2030-592
Injection Hazard
Escaping fluid under pressure can
penetrate skin, causing serious injury.
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pinholes.
• Use cardboard to check for leaks.
Fluid injected into skin must be surgi-
cally removed within a few hours by a
doctor familiar with this type of injury
or gangrene will result. 2030-602
20
11 12
14
15
16
17
19
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment. Install lift arm brace prior to servicing.
2030-594
13
Inspect undercarriages daily for
accumulation of debris. If debris
is present, clean thoroughly with
a pressure washer. If debris is
allowed to build up, it can cause
premature component wear and
decrease machine performance.
2085-253
NOTICE
18
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.4.1 ISO Safety Sign Location
The safety signs are located in/on the machine as indicated. (Descriptions of the
symbols are provided in section 2.3)
Key
1. Fall hazard
2. Crush hazard (lift arms)
3. Skin (oil) injection hazard
4. Fire hazard (read manual)
5. Burn hazard
6. Explosion / burn hazard (read operator’s manual)
7. Tie down location
8. Crush hazard (run over)
9. Crush hazard (lift arm brace)
2 SAFETY
16
2030-416
2030-415
2030-417
2030-418
2030-425
2030-553
2030-427
2030-565
1
3
2
45
6
7
98
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

Note:
If any of the safety signs shown in this section are missing or damaged, contact
your dealer to obtain a replacement.
Key (continued)
10. Burn hazard
11. Belt/fan entanglement hazard
12. Skin (oil) injection hazard
13. Crush hazard (lift arm brace)
14. Crush Hazard (Lift arms)
15. Fall hazards / read operator’s manual
16. Crush / rollover hazards
17. Crush (run over) hazard
18. Tie down location
2 SAFETY
17
2030-552
2030-551
2030-416
2030-426
2030-420
2030-415
2030-553
10
11
12
14
15
16
17
18
2030-417
13
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.5 General Safety Notes
• Read and understand all safety signs and operator’s manuals prior to opera-
tion.
• If safety signs are obstructed by dirt or debris, clean them using mild soap
and water prior to operation. DO NOT use solvent based cleaners, as they
may damage the safety sign material.
• If safety signs are damaged or illegible, replace them immediately, prior to
operation.
• Never jump off of the machine. Instead use the hand holds and step
designed for entering and exiting the machine. Face the machine and use
three points of contact to ensure your safety.
• Do not use any method of operation, inspection, or maintenance that may
impair safety.
• This machine is only to be used when properly equipped for the task to be
performed and when properly inspected and maintained to ensure safe
operation.
• The manufacturer’s instructions regarding operation, inspection, mainte-
nance, repair and transportation must be followed.
• Never place the machine into operation without having first performed a
thorough walk-around inspection and making any necessary repairs or
adjustments.
• Safety devices on the machine shall not be deactivated or removed.
• Do not make any changes, additions or conversions to the machine that
could have a negative effect on safety without the manufacturer’s written
approval.
• Any persons in close proximity to the machine during operation should
familiarize themselves with the safety precautions described in this manual
prior to operation.
2 SAFETY
18
PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12

2.6 Personal Protection Equipment
The machine is designed to accommodate and protect an operator during opera-
tion from foreseeable injury when used as intended and when equipped prop-
erly for the task(s) being performed. Operators should not wear rings, scarves,
open jackets, and should ensure that all clothing is tightly secured. Long hair
should be restrained. Personal Protective Equipment (PPE) must be worn in the
absence of an enclosed cab. In this case PPE would include, but not be limited to,
safety glasses. The use of some attachments may require additional PPE, such as
hearing protection, hardhat, gloves, and steel-toed shoes. In some applications
high visibility/reflective jackets are required.
Personal protection equipment is also recommended when performing mainte-
nance or service on a machine. Always wear appropriate protective equipment for
working conditions when working on or around the machine. Loose clothing
should not be worn and long hair should be restrained. Wear hard hats, protective
face/eyewear, safety shoes and any other equipment necessary to ensure your
safety and the safety of others around you as you work.
2.7 Hazard Zone
The hazard zone encompasses the area around the machine in which persons
may be injured by movements of the machine during operation, its attachments,
or by falling loads.
Do not position yourself or allow anyone else within this hazard zone during
machine operation. Keep a safe distance to ensure your safety while the machine
is in operation.
If someone enters the hazard zone, the operator must stop all work and give a
warning signal to the person who may be in danger to leave the hazard zone.
Work should not resume until all persons have vacated the hazard zone.
To minimize the possibility of a crushing hazard, a sufficient safety distance (min.
1.6 ft (0.5 m)) must be kept from solid objects, e. g. buildings, slopes, scaffolding,
other machines, etc. If that distance cannot be kept, fence off the area between
solid construction elements and the working range of the machine.
If conditions are such that the machine operator’s view of the driving and working
zone is restricted, he must be guided or the driving and working zone must be
secured by means of a solid barricade.
2 SAFETY
19 PT-50/60 US/ROW PT-50T AUS O&M
2030-778 2013-12
