Terrasat Rx 1+1 User manual

Receive Redundant Systems

Operations Manual

24-Hour Technical Support: +1 408.782.2166

This document is provided to customers who have purchased Terrasat Communications, Inc.

equipment. This document is copyright protected and no part of this manual may be reproduced,

transcribed, or translated into any language or transmitted in any form whatsoever without the

prior written consent of Terrasat Communications, Inc.

Technical information contained in this publication is for reference purposes only and is subject

to change without notice. Every effort has been made to supply complete and accurate

information; however, Terrasat Communications, Inc. assumes no responsibility and will not be

liable for any errors, omissions, damage, or loss that might result from any use of this manual or

the information contained therein (even if this information is properly followed and problems still

arise).

Part Number: O&M-22064-0001

Revision: C

235 Vineyard Court Phone: +1 408.782.5911

Morgan Hill, CA 95037 FAX: +1 408.782.5912

www.terrasatinc.com

TABLE OF CONTENTS

Preface

Conventions and References .....................................................................................................P-1

Cautions and Warnings ......................................................................................................P-2

Trademarks.........................................................................................................................P-2

Electrical Safety Notice .....................................................................................................P-2

Chapter 1, Introduction

Receive Redundant Systems .....................................................................................................1-1

Reference Documents ...............................................................................................................1-1

Warranty Information................................................................................................................1-4

Chapter 2, Functional Description

System Components..................................................................................................................2-1

Low-Noise Block Converter .................................................................................................2-2

DC Supply.............................................................................................................................2-4

AC Supply.............................................................................................................................2-7

RF Signal Flow .....................................................................................................................2-10

LED Indicators......................................................................................................................2-10

Emergency Switches .............................................................................................................2-10

User Interfaces ......................................................................................................................2-11

Software ................................................................................................................................2-11

System Configurations ..............................................................................................................2-12

Chapter 3, Installation

General Requirements ...............................................................................................................3-1

Unpacking ..........................................................................................................................3-1

Furnished Items..................................................................................................................3-2

Accessories.........................................................................................................................3-2

Installing the Rx 1+1 System ....................................................................................................3-3

Tools and Test Equipment ....................................................................................................3-3

Site Considerations ...............................................................................................................3-4

Mounting Considerations......................................................................................................3-4

Power Requirements .............................................................................................................3-4

Grounding .............................................................................................................................3-6

Antenna Recommendations ...............................................................................................3-6

Cable and Waveguide Connections ......................................................................................3-7

Applying the Anti-Seize Lubricant ....................................................................................3-8

Water-Resistant Wrap ........................................................................................................3-9

Antenna Mounting .............................................................................................................3-10

System Cabling Requirements ..............................................................................................3-12

Physical Connections .........................................................................................................3-16

Waveguide Connections.....................................................................................................3-19

Antenna Alignment ...............................................................................................................3-21

Setting the Rx Frequency......................................................................................................3-21

Receive L-band Output Measurements..............................................................................3-21

Chapter 4, Operations

Introduction ...............................................................................................................................4-1

Initial Readings .....................................................................................................................4-1

Possible Alarms.....................................................................................................................4-2

Input Low Threshold..........................................................................................................4-2

Supply Voltage...................................................................................................................4-2

Current Consumption.........................................................................................................4-2

Setting Threshold Levels....................................................................................................4-3

10 MHz Low Alarm ...........................................................................................................4-3

Rx Input Level Low Threshold Alarm...............................................................................4-3

Chapter 5, Monitor and Control Features and Functions

Monitor and Control Interfaces .................................................................................................5-1

RS232....................................................................................................................................5-1

Hand-held Terminal ..............................................................................................................5-2

Multifunction LEDs ..............................................................................................................5-4

Frequency Shift Keying (FSK) .............................................................................................5-6

Ethernet .................................................................................................................................5-6

Determining the IP Address of Your Rx 1+1 System........................................................5-7

Telnet..................................................................................................................................5-11

Embedded Web Pages........................................................................................................5-11

SNMP.................................................................................................................................5-11

RS485....................................................................................................................................5-13

ASCII Mode .......................................................................................................................5-14

Chapter 6, Troubleshooting

Maintenance ..............................................................................................................................6-1

Fault Isolation............................................................................................................................6-1

Receive L-band Output Verification..................................................................................6-1

Power Supply Checks ........................................................................................................6-2

AC Power Problems/Conditioning.....................................................................................6-2

Site-Related Problems........................................................................................................6-3

M&C Checks......................................................................................................................6-3

Common Problems................................................................................................................6-3

Repair Policy .............................................................................................................................6-4

Returned Material Authorization (RMA)..............................................................................6-4

iii

Appendix A, Part Numbering Schema

Identifying the Part and Serial Numbers................................................................................... A-1

Appendix B, Rx 1+1 Hand-held Terminal Menu Tree

Menu Options ........................................................................................................................... B-1

Info & Sensors ................................................................................................................... B-4

Alarm ................................................................................................................................. B-4

Thresholds ......................................................................................................................... B-4

Interface ............................................................................................................................. B-5

SNMP ................................................................................................................................ B-6

System ............................................................................................................................... B-6

Redundancy ....................................................................................................................... B-6

Appendix C, Using HyperTerminal

Establishing a HyperTerminal Session ..................................................................................... C-1

Using a Saved Connection........................................................................................................C-7

Ending a HyperTerminal Session ............................................................................................. C-8

Appendix D, ASCII Command/Response Structure

Command Set............................................................................................................................ D-1

Common Commands ............................................................................................................ D-3

Receive-only Commands...................................................................................................... D-18

Appendix E, Web Pages

Screen Shots.............................................................................................................................. E-1

Login.................................................................................................................................. E-5

Information Tab.................................................................................................................E-6

Alarm Tab.......................................................................................................................... E-8

Sensor Tab ......................................................................................................................... E-11

Rx Configuration Tab........................................................................................................ E-12

Interface Configuration Tab .............................................................................................. E-14

System Configuration Tab................................................................................................. E-17

Alarm Configuration Tab .................................................................................................. E-19

Redundancy Configuration Tab......................................................................................... E-23

Alarm Log Tab .................................................................................................................. E-25

Appendix F, Reference Drawings and Component Specifications

Reference Drawings.................................................................................................................. F-1

Data Sheets ............................................................................................................................... F-7

Appendix G, Glossary

Glossary of Terms..................................................................................................................... G-1

Index

LIST OF FIGURES

Figure 2.1 Rx 1+1 Redundant System Diagram.......................................................................... 2-2

Figure 2.2 LNB Block Diagram of System With an Externally Referenced 10 MHz Signal..... 2-3

Figure 2.3 Rx 1+1 Block Diagram (for +48 VDC-powered Systems)........................................ 2-5

Figure 2.4 Rx 1+1 Block Diagram (for -48 VDC-powered Systems)......................................... 2-6

Figure 2.5 Rx 1+1 Block Diagram (for Single-input AC-powered Systems) ............................. 2-8

Figure 2.6 Rx 1+1 Block Diagram (for Two-input AC-powered Systems) ................................ 2-9

Figure 2.7 Location of Access Panel........................................................................................... 2-11

Figure 2.8 Typical System Configuration for DC-powered Systems ......................................... 2-13

Figure 2.9 Typical System Configuration for Single-input AC-powered Systems..................... 2-14

Figure 2.10 Typical System Configuration for Two-input AC-powered Systems........................ 2-15

Figure 3.1 Contents of Shipping Carton...................................................................................... 3-3

Figure 3.2 Latching (Shown in Position A) ................................................................................ 3-8

Figure 3.3 Applying the Anti-Seize Lubricant............................................................................ 3-9

Figure 3.4 Actual Installation of Rx 1+1 System on Antenna Boom Arm ................................. 3-10

Figure 3.5 Location of Mounting Holes...................................................................................... 3-11

Figure 3.6 Location of Mounting Slots ....................................................................................... 3-12

Figure 3.7 Front Panel of a DC-powered Rx 1+1 System........................................................... 3-13

Figure 3.8 Front Panel of a Single-input AC-powered Rx 1+1 System...................................... 3-13

Figure 3.9 Front Panel of a Two-input AC-powered Rx 1+1 System......................................... 3-14

Figure 3.10 Information on Top Cover of an AC-powered Rx 1+1 System................................. 3-15

Figure 3.11 Back Panel of an Rx 1+1 System............................................................................... 3-15

Figure 3.12 Side Panel of an Rx 1+1 System................................................................................ 3-16

Figure 5.1 Hand-held Terminal Illustration ................................................................................ 5-3

Figure 5.2 Side Panel of an Rx 1+1 System................................................................................ 5-4

Figure 5.3 Location of Downloads on Terrasat Website............................................................. 5-7

Figure 5.4 Download Instructions for .zip File ........................................................................... 5-8

Figure 5.5 Contents of the IBUCUpgrade_v122 .zip File........................................................... 5-8

Figure 5.6 Extracting the .zip Files ............................................................................................. 5-9

Figure 5.7 Security Warning Dialog Box.................................................................................... 5-9

Figure 5.8 Results Window ......................................................................................................... 5-10

Figure 5.9 Blank Results Window .............................................................................................. 5-10

Figure A.1 Identifying the Part and Serial Numbers.................................................................... A-1

Figure A.2 Part Numbering Schema for IBUC Gs, IBUC 2s, and IBRs .................................... A-2

Figure A.3 Part Numbering Schema for IBUCs .......................................................................... A-3

Figure A.4 Part Numbering Schema for Transmit Redundant (Tx 1+1) Systems....................... A-4

Figure A.5 Part Numbering Schema for Receive Redundant (Rx 1+1) Systems ........................ A-5

Figure A.6 Part Numbering Schema for IBUC with PSUI Systems............................................ A-6

Figure A.7 Part Numbering Schema for IFU Systems................................................................. A-7

Figure A.8 Part Numbering Schema for LNBs............................................................................ A-8

Figure A.9 Part Numbering Schema for SSPAs .......................................................................... A-9

Figure A.10 Part Numbering Schema for Redundant SSPA 1+1 Systems................................... A-10

Figure B.1 Rx 1+1 Hand-held Terminal Menu Tree Structure................................................... B-2

Figure B.2 Sample Hand-held Terminal Initial Display ............................................................. B-3

Figure B.3 Sample Main Menu Window .................................................................................... B-3

Figure C.1 New Connection Description Window ..................................................................... C-2

Figure C.2 Connect To Window ................................................................................................. C-3

Figure C.3 COM1 Properties Window........................................................................................ C-4

Figure C.4 Invalid Password Error Message............................................................................... C-5

Figure C.5 ASCII Setup Window ............................................................................................... C-5

Figure C.6 Invalid Value Error Message .................................................................................... C-6

Figure C.7 Active HyperTerminal Window................................................................................ C-7

Figure E.1 Choosing Network Connections ............................................................................... E-2

Figure E.2 Choosing the Internet Protocol (TCP/IP) Properties................................................. E-2

Figure E.3 Typing the IP Address............................................................................................... E-3

Figure E.4 Invalid Subnet Mask Error Message......................................................................... E-4

Figure E.5 Login......................................................................................................................... E-5

Figure E.6 Information Tab ........................................................................................................ E-6

Figure E.7 Alarm Status Tab ...................................................................................................... E-8

Figure E.8 Sensor Tab ................................................................................................................ E-11

Figure E.9 Rx Configuration Tab ............................................................................................... E-12

Figure E.10 Interface Configuration Tab...................................................................................... E-14

Figure E.11 System Configuration Tab ........................................................................................ E-17

Figure E.12 Alarm Configuration Tab.......................................................................................... E-19

Figure E.13 Redundancy Configuration Tab................................................................................ E-23

Figure E.14 Alarm Log Tab.......................................................................................................... E-25

Figure F.1 Fabrication Drawing, FBD-21012-XXXX, Rev. A.................................................. F-2

Figure F.2 Fabrication Drawing, FBD-20786-XXXX, Rev. A.................................................. F-3

Figure F.3 Assembly Drawing, ASD-10713-0010, Rev A ........................................................ F-4

Figure F.4 Top View of Rx 1+1 System Showing Connector Locations................................... F-5

Figure F.5 Outline Drawing, OLD-10801-0005, Rev A ............................................................ F-6

vii

LIST OF TABLES

Table P.1 Typographical Conventions ........................................................................................ P-1

Table 1.1 Satellite Operation Standards...................................................................................... 1-1

Table 2.1 LNB Input Types ........................................................................................................2-3

Table 2.2 Receive Frequency Plans ............................................................................................ 2-4

Table 3.1 DC-powered Rx 1+1 Interface Module Connector Schedule ..................................... 3-16

Table 3.2 AC-powered Rx 1+1 Interface Module Connector Schedule ..................................... 3-17

Table 3.3 Pin Assignments for the J1 User Interface Connector ................................................ 3-17

Table 3.4 Pin Assignments for the J2 and J3 DC Power Connectors ......................................... 3-18

Table 3.5 Pin Assignments for the J2 and J3 AC Power Connectors ......................................... 3-18

Table 3.6 Pin Assignments for the Y-cable Connector............................................................... 3-19

Table 5.1 Default Alarm Configuration...................................................................................... 5-5

Table 5.2 Receiver Link Specifications ...................................................................................... 5-6

Table 5.3 ASCII Mode Command Format.................................................................................. 5-14

Table D.1 Alarm Mask ................................................................................................................ D-1

Table D.2 Miscellaneous Alarm Flags......................................................................................... D-2

Table D.3 Error Response Table.................................................................................................. D-2

viii

This page intentionally left blank

for double-sided printing.

REVISION HISTORY

Revision Date Description

AMay 2011 Preliminary Release

BMay 2013 Initial Release

CMay 2014

• Added information about waveguide switch positions in Chapter 3 and in Appendix F

• Added information about AC-powered redundant systems with two inputs

This page intentionally left blank

for double-sided printing.

PREFACE

This guide provides information about the Terrasat Communications, Inc. line of

receive redundant (Rx 1+1) systems.

Conventions and References

Before you start using this guide, it is important to understand the typographical

conventions and terms used in the documentation.

Table P.1 describes typographical conventions used in Terrasat Communications, Inc.

documentation. For definitions of specialized terms used in the documentation, see

Appendix G, Glossary.

Table P.1

Typographical Conventions

Convention Description/Example

Emphasis

Used to emphasize the importance of a point.

The IP Address must be a unique number.

Internal cross-references

References to a section in the same document are marked in blue and

are hyperlinked.

See Warranty Information on page 1-4.

Product and feature

names

Named Terrasat products and features are identified on first use.

...line of intelligent block upconverters (IBUCs).

Technical Publication

References

References to other Terrasat publications. If the reference is hyperlinked,

it is also underscored.

For detailed information, see the Terrasat Communications, Inc. IBUC

Operations Manual.

User-entered values

A special font marks text that you type.

At the password prompt, type MyPassword.

P-2 | Preface

Cautions and Warnings

Trademarks

Other product names mentioned in this manual may be trademarks or registered

trademarks of their respective companies and are hereby acknowledged.

Electrical Safety Notice

This equipment has been designed to minimize exposure of personnel to hazards. All

operators and technicians must

• Know how to work around, with, and on high-voltage equipment.

• Exercise every precaution to ensure safety of personnel.

• Exercise extreme care when working near high voltages.

• Be familiar with the warnings in this manual.

CAUTION

CAUTION indicates a hazardous situation

that, if not avoided, could result in minor or

moderate injury. CAUTION might also be

used to indicate other unsafe practices or

risks of property damage.

HIGH VOLTAGE

HIGH VOLTAGE indicates the presence of a

high-voltage hazard.

WARNING

WARNING indicates a potentially

hazardous situation that, if not avoided,

could result in death or serious injury.

CHAPTER

HAPTER

NTRODUCTION

This User Guide is intended for users of Terrasat Communications, Inc. receive

redundant (Rx 1+1) systems.

Receive Redundant Systems

The Rx 1+1 system enables switching of low-noise block converters (LNBs) via a

waveguide switch that switches the RF receive signal, and an RF relay (internal to the

interface module) that switches the IF signal. The Rx 1+1 system includes a separate

outdoor interface module that does not require an indoor controller. It can be powered

by the same power supplies used with Terrasat intelligent block upconverters (IBUCs)

or via AC mains and performs all the required functions for redundant operation of

LNBs.

This manual provides information about:

• Installation, operation, and maintenance of Rx 1+1 systems

• Use of user interface protocols for remote monitor and control

Reference Documents

Use the satellite operation standards listed in Table 1.1 as reference documents.

Table 1.1

Satellite Operation Standards

Earth Station Standards

Intelsat IESS 308/309 Performance Characteristics for Intermediate Data Rate Digital

Carriers Using Convolutional Encoding and QPSK Modulation

Eutelsat EESS 502

Minimum Technical and Operational Requirements for Earth Stations

Transmitting to a Eutelsat Transponder for Non-Standard Structured

Types of SMS Transmissions. Standard M.

1-2 | Introduction

Earth Station Standards

ETSI EN 301 427

Satellite Earth Stations and Systems (SES); Harmonized EN for Low

Data Rate Mobile Satellite Earth Stations (MESs) except aeronautical

mobile satellite earth stations, operating in the 11/12/14 GHz

frequency bands covering essential requirements under article 3.2 of

the Radio & Telecommunications Terminal Equipment (R&TTE)

directive

ETSI EN 301 428

Satellite Earth Stations and Systems (SES); Harmonized EN for Very

Small Aperture Terminal (VSAT); Transmit-only, transmit/receive or

receive-only satellite earth stations operating in the 11/12/14 GHz

frequency bands covering essential requirements under article 3.2 of

the Radio & Telecommunications Terminal Equipment (R&TTE)

Directive.

ETSI EN 301 430

Satellite Earth Stations and Systems (SES); Harmonized EN for

Satellite News Gathering Transportable Earth Stations (SNG TES)

operating in the 11-12/13-14 GHz frequency bands covering essential

requirements under article 3.2 of the R&TTE directive

ETSI EN 301 443

Satellite Earth Stations and Systems (SES); Harmonized EN for Very

Small Aperture Terminal (VSAT); Transmit-only, transmit/receive, or

receive-only satellite earth stations operating in the 4 GHz and 6 GHz

frequency bands covering essential requirements under article 3.2 of

the R&TTE Directive.

MIL-STD-188-164A

with Change 3

Interoperability of SHF Satellite Communications Terminals for

tactical and long-haul communications.

MIL-STD 810F

Materiel acquisition program planning and engineering direction for

considering the influences that environmental stresses have on

materiel throughout all phases of its service life.

ANSI/TIA/EIA 568 Commercial Building Telecommunications Cabling Standard

Environmental Standards

ETS 300 019-1-1
