Tesco IRS77 User manual

IRS77
Steam Iron
User Guide

User Guide
Steam Iron IRS77
0
MAX
1
2
3
1) Spray Nozzle
2) Water Tank Filling Inlet
3) Variable Steam Control Knob
4) Burst of Steam Button
5) Spray Button
6) Temperature Control Dial
7) Indicator Light
8) Swivelling Power Cord Protector
9) Heel
10) Metal Soleplate
11) Transparent Water Tank
DESCRIPTION
This IRS77 is an electric steam iron that includes features such as variable
temperature, variable steam, a burst of steam facility and a water spray to help
with ironing heavy or creased material.
1
2
3
4
5
6
7
9
8
PRELIMINARIES
Unpack the iron carefully. Remove all protective film from the soleplate. Do not
leave any film adhering to the soleplate.
We suggest you retain the packaging. If you dispose of it, please do so with
regards to any recycling regulations in your area.
Check that the voltage marked on the rating plate matches your mains voltage.
Please read all instructions, especially the Safety Guide. If you pass the appliance
to a third party, include these instructions.
Important Note: Maintaining the finish of the iron’s soleplate is essential for good
results. Keep the soleplate smooth; do not scratch it on metal objects (e.g. the
edge of the ironing board, zippers etc.) and clean as described (see Cleaning).
32
10
11
Thankyou for purchasing a Tesco IRS77 Steam Iron. For your safety, please
ready this User Guide carefully, paying particular attention to the
Safety Guide section.
SAFETY GUIDE
Before using the iron, please read these safety notes carefully.
• Young children should NOT use this iron.
• Do not touch the soleplate of the iron when it is hot. Always hold the iron by the
handle. Be aware that the iron heats up quicker than it cools down.
• Keep the iron away from surfaces and objects that can be damaged by heat.
• The iron must be used,
or stood upright on its heel, on a stable surface.
• When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
• Ensure there is adequate room to operate the iron.
• Ensure that the iron cannot fall into water.
• Disconnect the mains supply before filling or emptying the iron, before cleaning
any components, and when it is not in use.
• Do not immerse the power cord in water or other liquids.
• Do not let the power cord overhang the edge of the work surface or allow it to
touch hot surfaces, or sources of heat or flame.
• Do not use the iron if any part of it, including the power cord or mains plug, is
damaged or malfunctions. Seek expert assistance.
• The iron is not to be used if it has been dropped, there are visible signs of
damage, or if it is leaking.
• Children must be warned not to touch hot iron parts. Close supervision is
necessary when the iron is used near children.
• Do not leave the iron face down at any time. Stand it upright, on its heel, in
between use.
• This iron is for indoor domestic use only. Do not use it outdoors.
• Do NOT use this iron for any purpose not covered by the instructions.
• Use caution when inverting the iron, there may be hot water in the tank.
• The iron must not be left unattended while it is connected to the mains supply.
WARNING: Contact with hot metal parts, hot water and steam can cause burns.
Exercise care when handling this iron!
IMPORTANT NOTICE TO UK USERS
The power cord is terminated with a UK approved mains plug fitted with a 13A
fuse. If the fuse needs to be replaced, an ASTA or BSI approved BS1362 13A fuse
must be used. If you need to change the mains plug, remove the fuse, cut the plug
from the cord and dispose of it safely. Fit the new plug as instructed in Replacing
the Main Plug.

User Guide
Steam Iron IRS77
CONNECTING AND USING THE STEAM IRON
Filling the Iron with Water
Ensure the iron is unplugged from the mains and set the variable steam control to
the no steam position, indicated with: .
Open the water tank filling inlet and fill the water tank through the filling inlet. Do
NOT exceed the MAX marks on the side of the iron.
When filling, use the utensil provided with the appliance. Do NOT fill directly from
the tap.
If the water is very hard, it is advisable to fill the iron with distilled water or a 50:50
mix of distilled water and tap water. The harder the water, the more the iron should
be cleaned (see Cleaning).
Ironing
• Ensure that the mains socket is switched off at the wall.
• Fill the iron with water as described.
• Place the iron on the ironing rest of the ironing board, on its heel in an upright
position. Connect the plug to the wall socket.
• On the iron, use the temperature control dial to select the appropriate
temperature for the fabric (See Ironing Temperatures).
• Switch on the power at the wall socket.
The indicator light will turn off when the iron reaches the selected temperature. The
iron is now ready for use.
During use the indicator light will turn on and off as the thermostat maintains the
iron at the selected temperature.
Note: Some parts of the iron have been slightly greased and as a result might
smoke slightly when the iron is switched on for the first time. This will cease after a
short while.
Using Steam
If steam ironing is required, turn the variable steam control to the correct level of
steam for the fabric. Turn the knob clockwise to increase the steam setting.
If dry ironing, turn the knob fully anti-clockwise to the no steam setting, indicated
with: .
Note: Steam ironing is only possible at the highest temperature setting, as
indicated by MAX on the temperature control dial. Do NOT attempt to use steam at
lower temperatures as water will leak from the soleplate.
Spraying Steam
The burst of steam facility provides
additional steam for removing
stubborn wrinkles. It may be used
when steam ironing or dry ironing.
Press the burst of steam button
to release a burst of steam. You may
need to press the button several
times to prime the burst system.
Wait a few seconds for the steam to
penetrate the fabric before pressing
the button again.
The burst of steam facility may be
used when the iron is in a vertical
position, to remove wrinkles/creases
from hanging garments, curtains etc.
Note: For optimum steam quality, do
not apply more than three
successive bursts.
Spraying Water
Press the spray button to spray a thin jet of water on the material being ironed.
This may be used when steam ironing or dry ironing.
Variable Steam Control
Descaling
No steam
Burst of Steam Button
Spray Button
4 5
Temperature Control Dial

User Guide
Steam Iron IRS77
IRONING TEMPERATURES
Check the ironing instructions attached to the article to be ironed (they are usually
on a label showing a symbol of an iron). Always follow these instructions. The
indications on the iron’s temperature dial and the table below will help you.
If there are no ironing instructions but you know the fabric, then use the table
below. The table is valid only for the actual materials and does not take into
account of any finish which may have been applied to the fabric. Textiles to which
a finish has been applied (gloss, wrinkle relief, printed T-shirts etc.) should be
ironed at somewhat lower temperatures.
If the fabric consists of mixed fibres, always select the lowest ironing temperature
of the composition, e.g. a 60% polyester/40% cotton mix should be ironed at the
temperature for polyester.
Sort fabrics into groups according to temperature; wool with wool, cotton with
cotton, etc. Start by ironing articles requiring low temperature settings and progress
to higher ones.
Note: Do not iron garments that are dirty or stained. The iron’s heat may set the
stain.
Pure wool fabric (100% wool) may be pressed with the iron set to a steam position
and the wool surface protected by a dry cotton cloth.
Do not iron
Synthetics, Nylon,
Acrylics, Polyester, Rayon
Wool, Silk
Cotton, Linen
MAINTENANCE
Unplug the iron from the mains and allow to cool down fully before pouring away
any excess water.
Cleaning
To remove starch or other deposits from the soleplate, apply a small amount of
mild cleaner to a damp cloth, forming a paste on the cloth. Gently rub the
soleplate, then wipe with a damp cloth.
The body of the iron may be cleaned with a barely damp cloth and then dried
thoroughly. Do not wet the iron body, power cord or mains plug.
CAUTION: Never use scouring pads, abrasives or harsh cleaners on the iron body
or the soleplate as this may scratch the surface.
Anti-Scale
The iron is fitted with and anti-scale cartridge which will reduce the build-up of
limescale that occurs during steam ironing. This will prolong the working life of the
iron.
Self Cleaning
The anti-scale cartridge will not completely stop the build-up of scale. The following
procedure should therefore be carried out at least once a month or more often in
hard water areas:
• Fill the iron with cool water.
• Set the temperature to MAX.
• Set the steam control knob to by turning fully anticlockwise.
• Place the iron on its heel in an upright position.
• Plug the iron into a mains supply and switch it on.
• Wait until the iron has reached the MAX temperature setting.
• Carefully hold the iron horizontally over a sink and turn and hold the variable
steam control at the (descaling) position, pressing down slightly.
• Steam and boiling water will drain from the soleplate, washing away the scale
and minerals that have built up inside the steam chamber.
• Gently shake the iron back and forth until the water tank is empty.
• When self-cleaning is complete, release the variable steam control.
• Place the steam iron back on its heel rest and allow to fully cool down.
• Wipe the soleplate with a cold damp cloth.
STORAGE
Unplug the iron and allow it to fully cool before putting it away. Store the iron on its
heel, with the power cord very loosely coiled up. Do NOT tightly wrap the power
cord around the iron, as it can become damaged and expose the live conductors.
PLEASE SAVE THESE INSTRUCTIONS.
6 7

WARRANTY
This TESCO iron is covered by a warranty for 12 months from the date of
purchase. If a fault develops during this period, please return the unit to your
nearest Tesco store together with the original receipt as proof of purchase. This
warranty in no way affects your consumer rights.
SPECIFICATIONS
Model Number: IRS77
Voltage Rating: 220 - 240V AC, 50Hz
Power Consumption: 1600W - 2000W
Net Weight: 1.1kg
IMPORTANT: THIS APPLIANCE MUST BE EARTHED
Steam Iron IRS77
Tesco Stores Ltd,
Delamare Road, Cheshunt,
Herts, EN8 9SL
Made in China
DISPOSAL
(Waste Electrical and Electronic Equipment Directive)
If at any time you need to dispose of this product please note that waste
electrical products should not be disposed off with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Replacing the Mains Plug
The wires in the mains lead are coloured in accordance with a code. As these colours may
not correspond to the coloured markings identifying the terminals in your plug, proceed as
follows:
The wire coloured BLUE must be connected to the
terminal marked with the letter N or coloured BLUE or
BLACK. The wire coloured BROWN must be connected to
the terminal marked with the letter L or coloured BROWN
or RED. The wire coloured GREEN & YELLOW must be
connected to the terminal marked with the letter E or
coloured GREEN or GREEN & YELLOW or marked with
the Earth Symbol:
GREEN
&
YELLOW
(Earth)
BLUE
(Neutral)
FUSE
13A
BS 1362
BROWN
(Live)
