Tesco BB112DB User manual

BB112DB
CD Boombox with docking for iPod/iPhone
User Guide

1
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a slightly damp cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
Do not install or operate near any heat sources such as radiators,
stoves, or other apparatus that produce heat.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as the power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
IMPORTANT
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communication. However, this is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit dierent•
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for•
help.
ELECTRICAL INFORMATION
Warning: Please refer to the electrical and safety information on
the exterior bottom enclosure before installing or operating the
apparatus.
Warning: The mains plug is used as disconnect device, the
disconnect device shall remain readily operable.
NOTICE
“Made for iPod/iPhone” means that an electronic accessory has
been designed to connect specically to iPod or iPhone and has
been certied by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this
device or its compliance with safety and regulatory standards.
iPhone shown not included.
Warning: To reduce the risk of re or electrical shock, do not
expose this product to rain or moisture. The product must not
be exposed to dripping and splashing and no object lled with
liquids such as a vase of owers should be placed on the product.
No naked ame sources such as candles should be placed on the
product.
Caution:
Changes or modications not expressly approved by the
manufacturer could void the user’s authority to operate this device.
Caution: Usage of controls or adjustments or performance
of procedures other than those specied herein may result in
hazardous exposure.
Caution: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Warning: The battery (battery or batteries or battery pack) shall
not be exposed to excessive heat such as sunshine, re or the
like.
Warning: Only use attachments and accessories specied or
provided by the manufacturer such as the power cord, mains
supply adapter, batteries etc.
Do not install this equipment in a conned or enclosed space such
as a book case or similar unit, and ensure that the location is well-
ventilated. The ventilation must not be impeded by covering the
ventilation openings with items such as newspaper, table-cloths,
curtains etc.
WARNING: DANGER OF RADIATION
This symbol indicates that there are important
operating and maintenance instructions in
the literature accompanying this unit.
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within this unit.
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
IMPORTANT SAFETY INFORMATION
These labels tell you that the unit contains a laser component.
Opening the CD compartment lid and defeating the safety
interlocks will expose the user to radiation from the laser beam.
Do not stare into the laser while it is operating.

2
INDEX
Important safety information..................................1
Introduction ............................................................2
Unpacking ...............................................................2
Controls and connections.........................................3
Display.....................................................................4
Fitting batteries.......................................................5
Battery operation ....................................................5
Connecting power ...................................................6
Power control ..........................................................6
Setting the clock......................................................6
Function select ........................................................6
Adjusting the volume..............................................6
Listening to the radio ..............................................7
Preset stations.........................................................7
iPhone/iPod adaptors..............................................8
Docking and playing an iPhone/iPod.......................9
Playing a CD...........................................................10
CD program play....................................................11
Playing Aux sources ...............................................11
Troubleshooting ....................................................12
Care & Maintenance...............................................12
Specications ........................................................12
Warranty ...............................................................12
PRELIMINARIESINTRODUCTION
The BB112DB is a full-function mains powered CD
boombox with iPod docking station.
The radio receives FM stereo stations and an AUX
jack on the back panel enables connection of other
external sources such as personal audio equipment
and computers.
The BB112DB may be powered from the AC mains or by
batteries for portable use.
UNPACKING
Carefully unpack the unit. If it is damaged, please
return it to your nearest Tesco store for replacement.
Remember to take your purchase receipt with you.
Retain the User Handbook. If you pass the unit on to a
third party make sure you pass on the handbook.
We suggest you retain the packaging. If you dispose of
it, do so having regard to any recycling regulations in
your area.
CONTENTS
The carton should contain:
The BB112DB Boombox•
Power cord•
Operating Manual•
If any items are missing or damaged, contact your
nearest TESCO store for a replacement. Have your
receipt ready when you call. Retain the packaging. If
you dispose of it, do so having regard to any recycling
regulations in your area.
LOCATION
Place the unit on dry stable surface away from heat
and damp and where it is unlikely to fall or be knocked
over.

3
FM aerial1.
CD door2.
Carrying handle3.
Press this area to open the CD door4.
Play/Pause button5.
Previous track/preset button6.
Next track/preset button7.
Stop button8.
Tune up button9.
Time/Scan button10.
Tune down button11.
iPod/iPhone docking connector12.
Repeat button13.
Function select button14.
Program button15.
Volume control16.
Standby button17.
CONTROLS AND CONNECTIONS
TOP VIEW
TUNING
TIME/
PROG
REPEAT
FUNCTION
VOL+VOL-
SKIP
SCAN
h
b
ac d
i
1)
1!
g
e
f
1@
1%
1$
1#
1^
1&

4
a b
a
FRONT VIEW
CONTROLS AND CONNECTIONS
Display1.
BACK VIEW
Aux in jack1.
AC mains inlet2.
:
29 54
REP. ALL PROG.
FM MHz
AUX
b
cd e g
f
a
h
1!1@ 1) i
FM radio mode indicator1.
Play indicator2.
FM radio mode indicator3.
CD mode indicator4.
Aux mode indicator5.
FM stereo indicator6.
iPod mode indicator7.
Program indicator8.
MHz indicator (for FM)9.
Track/Frequency display10.
Repeat all indicator11.
Repeat indicator12.
DISPLAY

5
FITTING BATTERIES
The battery compartment is on the underside of the
unit.
Press the battery catches in the direction shown,1.
then lift o the battery cover..
FITTING BATTERIES
Referring to the previous section, t 6 x ‘C’/’UM2’
batteries into the battery compartment.
Remove the batteries if the unit will not be used for a
long time to avoid the danger of leakage.
BATTERY REPLACEMENT
If the sound is distorted or poor quality when battery
powered, the batteries may require replacement.
NOTE: Never mix old and new batteries or batteries of
dierent types. Batteries should always be replaced as
sets.
CLOCK OPERATION IN STANDBY MODE
When set to Standby, the clock will continue to display.
This will consume a little power from the batteries
when battery powered.
To save battery power, always remove the batteries
when in Standby mode unless you need the clock to
be displayed.
BATTERY OPERATION BATTERY DISPOSAL
Dispose of used batteries with regard to the recycling
regulations in your area. Do NOT short circuit batteries
or throw them into water, the general rubbish or in a
re.
Weak batteries can leak and damage the unit. Replace
them in good time!
Fit six ‘C’/’UM2’ batteries into the battery2.
compartment, observing polarity as shown.
Re-t the battery cover.3.
OPEN OPEN
OPEN OPEN

6
CONNECTING POWER
Check that the mains voltage marked on the rating•
plate on the base of the unit is the same as the
voltage in your area.
Plug the AC power cord into the AC inlet.•
Plug the mains plug into the wall socket and switch•
the mains power on.
The display will light, ashing --:-- until the clock is set.
SETTING THE CLOCK
Check that the unit is set to Standby before setting the
clock.
Press and• hold the TIME/SCAN button.
The display will ash 24H (24 hour display).
Press the• }button repeatedly to choose 24 hour
or 12H (12 hour) clock display.
Press the• TIME/SCAN button to conrm.
The time will be displayed, the hour digits will ash.
Press the• }or {button repeatedly to set the
hour digits to the correct time.
Press the• TIME/SCAN button to conrm.
The time will be displayed, the minutes digits will ash.
Press the• }or {button repeatedly to set the
minute digits to the correct time.
Press the• TIME/SCAN button to conrm.
Your time settings will be saved and the time displayed.
POWER CONTROL
To switch the unit on:
Press the• button.
The unit will switch on.
To switch the unit o:
Press the• button.
The unit will switch o and the time will be displayed.
NOTE: When the unit is operational, the display can
be switched to display the time by pressing the TIME/
SCAN button briey.
Environmental protection:
The unit will automatically turn o if left in standby
mode for more than 15 minutes. If you disconnect the
power from the unit during this period you need to
wait for 15 seconds before re-connecting the unit to
the power.
ADJUSTING THE VOLUME
To increase the volume:
Turn the• VOLUME control knob on the top panel
clockwise.
To decrease the volume:
Turn the• VOLUME control knob on the top panel
anti-clockwise.
When the volume level is changed, the volume level
is displayed in the range ‘U00’ (minimum) to ‘U30’
(maximum).
FUNCTION SELECT
Press the• FUNCTION button repeatedly to select
one of the functions available.
An indicator is displayed to show the function selected.
:
29 54
AUX
Radio
CD Aux
iPod

7
LISTENING TO FM RADIO
If you can hear a lot of background noise when playing
the station, the signal may be weak.
You may be able to improve the signal strength by
adjusting the position of the telescopic aerial or moving
the radio to a dierent position.
PRESET STATIONS
Your radio can store up to 20 of your favourite stations
as presets for quick recall.
To automatically store the station presets:
Press and hold the• TIME/SCAN button.
The radio will scan the FM band and store each station
found as a preset. Up to 20 stations will be stored.
To manually store a preset:
Tune to the station you want to store as a preset.•
Press the• PROG. button.
The Preset Indicator ‘P’ and a ashing preset number will
be displayed.
Press the• }or {button to change to the preset
number you want to store.
When the correct preset number is displayed, press•
the PROG. button to store the station.
To browse preset stations:
Press the• }or {button to step through the
preset stations stored.
The radio will re-tune to the preset station number
selected.
To listen to FM radio:
Lift the carrying handle, then lift and fully extend•
the telescopic aerial at the back of the unit.
Press the• FUNCTION button repeatedly until FM
mode is selected.
Station search:
Press and hold the• TUNING or button to
search up or down the band. The radio will stop
automatically when the next station is reached.
Manual step tuning:
Press the• TUNING or button briey to tune
up or down the band in 50kHz steps.
Fine adjust the tuning so that the station plays clearly.

8
iPhone/iPod ADAPTORS FINDING AN ADAPTOR
Before docking your iPhone/iPod you must rst check
if it has a docking connector. Early iPod models do
not have one and cannot be docked to your unit. The
docking connector is located on the base of the iPhone/
iPod as shown below.
If you don’t have a dock adaptor
If your iPhone/iPod was not supplied with a standard
dock adaptor, or if you have lost the adaptor, you can
buy one from Apple on-line. To determine the exact
model of your iPhone/iPod, refer to this web-link -
http://support.apple.com/kb/HT1353. You can then
browse the iPhone/iPod accessories page on the Apple
website to nd an adaptor for your iPhone/iPod model
that can be purchased on-line.
When your iPhone/iPod was new it may have
been supplied with a standard dock adaptor in the
packaging. If so, t the adaptor by pressing it gently
into the Docking Bay as shown.
Docking Connector
iPhone/iPod
adaptor
Docking bay
Before docking your iPhone/iPod, you must rst t the
correct adaptor to the docking bay. Each iPhone/iPod
adaptor matches the shape of a particular iPhone/iPod
and is necessary to ensure that your iPhone/iPod is
securely held when docked.
FITTING THE ADAPTOR
NOTE: Do not dock an iPhone/iPod without tting the
correct adaptor, you may damage the iPhone/iPod and
your unit.

9
DOCKING AN iPhone/iPod PLAYING FROM AN
iPhone/iPod
To dock your iPod:
Check that the correct iPod adaptor is tted to the•
docking bay.
Locate the iPod on the Docking Connector and•
press it gently home.
To remove your iPod from the dock:
Grip the iPod at the sides.•
Lift the iPod gently from the dock.•
Playing from a docked iPod:
Press the• FUNCTION button repeatedly until iPod
mode is selected.
Set the iPod to play.•
You can also operate some iPod functions from the
control panel.
iPod playback functions:
Press the• /, button to switch between Play and
Pause mode at any time.
Press the• }or {button to select the next or
previous track on your iPod.
To change repeat modes:
Press the• REPEAT button repeatedly to step
through the repeat mode options available.
The repeat mode set will show on the iPod display.
CHARGING AN iPhone/iPod
When an iPod is docked and power is connected to the
unit, the iPod will charge automatically.
If you own an iPod Shue, a model without dock
connector or prefer to connect your iPhone/iPod by
cable, you can connect the sound output to the Aux In
jack on the rear panel.
CONNECTING OTHER iPod
MODELS (INC SHUFFLE)
Using a 3.5mm stereo jack to jack cable (not•
supplied), connect one end of the cable to the
headphone socket of the iPhone/iPod, and the
other end to the Aux In jack on the back panel.
TolistentoyouriPhone/iPod,followtheinstructions•
on page 11 for playing equipment connected to the
Aux In jack.
NOTE:-The volume control of the iPhone/iPod must be
turned up when playing through the Aux In jack.
Headphone socket
To the Aux In jack

10
PLAYING A CD
Selecting CD operation:
Press the• FUNCTION button repeatedly until CD
mode is selected.
Loading a disc:
Press the‘OPEN/CLOSE’area on the CD door to open•
the door.
Holding the disc by the edges, place the disc on the•
turntable in the centre of the CD loading bay with
the label uppermost. Press the centre of the disc
into place on the turntable with a click.
Close the CD door and lock it shut by pressing the•
‘OPEN/CLOSE’area.
The unit will read the CD, display the total number of
tracks on the disc, then start playing from the start of
the disc.
Removing a disc:
Ensure that the disc is stopped.•
Press the‘OPEN/CLOSE’area on the CD door to open•
the door.
Holding the disc by the edges, lift the disc o the•
turntable and place it back in the case.
Close the CD door and lock it shut by pressing the•
‘OPEN/CLOSE’area.
Play/Pause:
Press the• /, button at any time to switch between
Play and Pause modes.
The play indicator will appear on the display when
playing. This display will ash during pause.
Stopping CD play:
Press the• .button while the CD is playing.
The CD will stop.
Selecting tracks:
Press the• }or {button to select the next or
previous track.
NOTE:- When pressing {while playing a track, the
rst press will replay the current track.
Fast search:
Press and• hold the }or {button to fast search
forward or backward through a track.
The track will search at high speed.
:
29 54
REP. ALL
:
29 54
REP.
Repeat play:
Press the• REPEAT button to step through the
available repeat modes - ‘Repeat’, ‘Repeat all’ or
‘Repeat o’.
The mode selected will be shown on the display.
Selecting ‘Repeat’ will continuously repeat the current
track.
Selecting ‘Repeat all’ will repeat the entire disc
continuously.
NOTE: If play is stopped, repeat modes are cleared.

11
CD PROGRAM PLAY
You can load a disc and store a programmed selection
of up to 20 tracks to play from the disc in your preferred
sequence.
To set a program:
Programs are stored when the disc is stopped.
Load a disc and stop play.•
Press the• PROG. button.
The display will ash P01 (the position of this track in
the program).
The AUX IN jack may be used to connect sound sources
with a Line or Headphone analogue output to play
through your unit. These may include -
iPod models that cannot be docked to the unit•
MP3 players•
CD walkman players•
Tape walkman players•
Personal computers or laptops•
Connecting to the AUX IN jack
Connect a stereo 3.5mm jack cable (not supplied)
between the headphone or LINE/AUX output of the
personal audio player and the AUX IN jack on the top
panel.
Playing the AUX source:
Press the• FUNCTION button repeatedly until AUX
mode is selected.
Set your personal audio player/computer to PLAY.•
Set the listening volume to the level you want with•
the volume control.
If there is no sound or if the volume level is not loud
enough, you may need to increase the volume setting
on your personal audio player/computer.
AUX SOURCES
P
PROG.
Select the track number you want to program by•
pressing the }or {button.
To save this track into the program sequence, press•
the PROG. button.
The display will ash P02 (this is the second track in the
program).
Repeat these two steps until you have stored all the•
tracks in the program sequence.
Playing the program:
Press the• /, button to start the program playing.
The program will begin to play and PROG. will show on
the display to show that a program is being played.
:
02 28
PROG.
Selecting tracks:
You can navigate through the tracks stored in the•
program by pressing the }or {button.
Clearing the program:
Press the• .button to stop play.
Press the• .button again.
Repeat modes:
Repeat modes may be selected when a program is
playing.

12
CARE AND CLEANING
All care and cleaning operations should be carried out
with the unit unplugged from the mains power.
The surface of the unit can be cleaned with a barely
damp cloth and then dried carefully. Never use
abrasives, abrasive cloths or chemical solvents .
SPECIFICATIONS
Supply Voltage, AC mains :. 100 - 240 V~, 50/60 Hz
Supply Voltage, Battery :.... 9V (C/UM2 x 6)
Power consumption ........... 15W
Frequency range ................ 87.5-108.0MHz (FM)
Net Weight:........................ 1.48 kg
Class II construction double insulated.
This product must not be connected to earth.
CARE AND MAINTENANCE
SPECIFICATIONS
Your Tesco appliance is covered by a warranty for 12
months from the date of purchase. If a fault develops
during this period, please contact the TESCO electrical
help line on 0845 456 6767. Please have your original
purchase receipt with you when you call.This warranty
in no way aects your consumer rights.
TROUBLESHOOTING
Poor quality radio reception
Theaerial signal maynotbeadequate.Try repositioning
the telescopic aerial.
No sound/low volume from AUX source:
Check that the volume control is turned up on the AUX
source.
Poor quality radio reception when an iPhone is
docked:
You may need to set the iPhone to ‘airplane’ mode
when docked.
Poor quality or distorted sound when battery
operated:
The batteries may need replacement..
WARRANTY
UK: Waste electrical products/batteries
should not be disposed of with household
waste. Separate disposal facilities exist, for
your nearest facilities see www.recycle-
more.co.uk or in-store for details.
ROI: Produced after 13th August 2005.
Waste electrical products/batteries should
not be disposed of with household waste.
Please recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.

Tesco Stores Ltd, Delamare Road, Cheshunt, Herts, EN8 9SL
BB112DBV0.5
Tesco technical helpline: 0845 456 6767 (calls cost up to 5p per minute from a BT landline, other providers mayvary).
