TI2000 GPU-24
(#)*"*&'-.

WARNING
*******SHOCK HAZARD POTENTIAL*******
IMPROPER USE/FAILURE TO FOLLOW INSTRUCTIONS IN OPERATORS MANUAL CAN
RESULT IN UNIT FAILURE AND/OR POSSIBLE INJURY, OR DEATH, BY ELECTRI-
CAL SHOCK.
THE TI2000GPU-24 IS A MAINTENANCE FREE, SEALED UNIT
NO REPAIRS ARE AUTHORIZED.
WARRANTY WILL BE VOID IF
UNIT IS TAMPERED WITH.
FOR TECHNICAL SUPPORT CONTACT:
TESLA INDUSTRIES INC.
109 CENTERPOINT BLVD.
CENTERPOINT INDUSTRIAL PARK
NEW CASTLE,DELAWARE 19720
PH.[phone]
FAX [phone]
WARNING
*******SHOCK HAZARD POTENTIAL*******
ATTEMPTS TO OPEN OR ENTER THE INSIDE OF THIS UNIT (BY USING ANY TOOL
OR DEVICE; i.e. PROBE, BORESCOPE, etc.) CAN RESULT IN UNIT FAILURE
AND/OR POSSIBLE INJURY BY ELECTRICAL SHOCK. THIS UNIT IS MAINTENANCE
FREE AND SHALL NOT BE OPENED OR DISASSEMBLED FOR ANY REASON.
***SHIPPING HAZARDS***
“NONE”
“DRY” Non-spillable, POWER CELL (battery),
No Free liquids, to leak or toxic gases.
Always protect unit from short circuit.
Return Power cells to Tesla for Recycling.

i
TABLE OF CONTENTS
TITLE Page
CHAPTER 1 INTRODUCTION 1-1
CHAPTER 2 UNIT DESCRIPTION AND OPERATION 2-1
Section I Unit 2-1
Section II Description 2-2
CHAPTER 3 OPERATING LIMITS AND RESTRICTIONS 3-1
Section I General 3-1
Section II Operational Restrictions and Safety Limits 3-1
CHAPTER 4 OPERATING PROCEDURES 4-1
Section I Unit Operation 4-1
Section II Operating Procedures 4-2
Section III Functional Check Procedures 4-5
CHAPTER 5 PERFORMANCE DATA 5-1
Section I Introduction 5-1
Section II Data Criteria 5-2
CHAPTER 6 CARE AND MAINTENANCE 6-1
Section I Unit Care 6-1
Section II Maintenance 6-2
INDEX Index 1
LIST OF ILLUSTRATIONS
Figure Title Page
2-1 Dimensions 2-3
2-2 General Details 2-2
2-3 Fuse Setting Procedures 2-4
5-1 Temperature Conversion Chart 5-3
5-2 Discharge Load Curve 5-4
5-3 Maximum Output Current 5-5

ii
CHAPTER 1
INTRODUCTION
1-1. GENERAL
These instructions are for use by the owner/operator. They apply to
handling and operation of the TI2000GPU-24 (Turbo Start 2000) ground
power unit.
1-2. WARNING, CAUTION, AND NOTE DEFINED
A warning, caution, or note is used to emphasize important and criti-
cal instructions as defined for the following conditions:
WARNING
An operating procedure, practice, etc., which,
if not correctly followed, could result in
personal injury or loss of life.
CAUTION
An operating procedure, practice, etc., which,
if not strictly observed, could result in
damage to or destruction of equipment.
NOTE
An operating procedure, condition, etc., which
is essential to highlight.
1-3. DESCRIPTION
This manual contains the complete operating instructions and proce-
dures for the TI2000GPU-24 (Turbo Start 2000) ground power unit. The
Turbo Start 2000 is intended to provide DC electrical ground power
for aircraft flight line and maintenance ground support operations.
The unit is designed to provide 24 volt DC electrical power output
for aircraft engine starting and 24 or 28.5 volts DC electrical sup-
port for ground maintenance, avionics/electrical trouble shooting and
testing. The observance of procedures, limitations and performance
criteria is essential to ensure peak operating efficiency and to
maximize operational capabilities and life of the Turbo Start 2000
ground power unit.

1-1
1-4. INDEX
The index lists, in alphabetical order, every titled paragraph and
figure contained in this manual.
1-5. ABBREVIATIONS AND SYMBOLS
Abbreviations and symbols are used within text, headings and titles.
Unless otherwise indicated, the following list of abbreviations and
symbols are used in this manual:
LIST OF ABBREVIATIONS AND SYMBOLS
Abbreviation Definition
amp Ampere
AC Alternating Current
C Celsius
cont Continuous
DC Direct Current
F Fahrenheit
Ft Feet
FWD Forward
GPU Ground Power Unit
Hr Hour
Hz Hertz
Kg Kilograms
Kw Kilowatts
°Degree
LED Light Emitting Diode
MAX Maximum
MIN Minimum
VAC Volts, Alternating Current
VDC Volts, Direct Current
Explosion Hazard Potential
Shock Hazard Potential
Guard from moisture
Guard from incorrect power source
䩢䩰䩜䩭䩟䨻䩡䩭䩪䩨䨻䩤䩩䩞䩪䩭䩭䩠
䩞䩯
䩫䩪䩲䩠䩭䨻 䩮䩪䩰䩭䩞䩠

Guard from incorrect power source
1-2
1-6. FORMS AND RECORDS
NONE REQUIRED.
1-7. USE OF WORDS SHALL, SHOULD, AND MAY.
Within this technical manual the word “shall” is used to indicate a
mandatory requirement for proper operation and warranty purposes.
The word “should” is used to indicate a non-mandatory but preferred
method of accomplishment. The word “may” is used to indicate an ac-
ceptable method of accomplishment.

1-3
CHAPTER 2
UNIT DESCRIPTION AND OPERATION
SECTION I. UNIT
2-1. GENERAL
The TI2000GPU-24 (Turbo Start 2000) (Figure 2-1 and 2-2) is a compact, portable
and highly versatile 24/28.5 VDC electrical ground power unit. The unit incor-
porates a 120-240 VAC to 28.5 VDC converter, a 24 volt unique (dry) power cell
and an internal intelligent 120 to 240 volt AC charger to recharge the power
cells. These built-in features give the Turbo Start 2000 self-sufficiency and
mobility for short-term operations without AC electrical power or long term
operations with AC electrical power. Short term operations rely solely on
power cell output and the fast recharge rates that the unit’s internal charger
provides from any standard 120 or 240 VAC electrical outlet. Longer term op-
erations incorporate the continuous 20 amp output of the 120-240 VAC to 28.5
VDC converter, or a combination of converter and power cell output to provide
24 VDC output. The following are the unit’s four (4) main operational support
capabilities:
a. 24 VDC 3000 amp peak power output for engine starting or constant (one
hour) rated power output (without a 120-240 VAC power source) for short term
trouble shooting and flexible flight line support ground power.
b. 24 VDC constant (one hour) rated power output or variable high load de-
mand output (less than one hour) with a 120-240 VAC power source for extended
maintenance (hangar) and routine flight line maintenance, ground support
power.
c. 28.5 VDC continuous rated (AC to DC converter) power output with a 120-
240 VAC power source for hangar and routine flight line maintenance support,
and avionics bench testing.
d. Rapid recharge of the unit’s power cells from any 120-240 VAC common
power source. This feature eliminates the need for special recharge equip-
ment and dedicated maintenance support man-hours.
WARNING
Check fuse holder window to ensure the fuse setting reads either 120 or
240 prior to connecting recharge cord to AC power source. Fuse setting (120/
240) must match AC power source (hangar wall, flight line AC power) prior to
connecting TURBO START for recharging.
(SEE PAGE 2-4 FOR
FUSE SETTING PROCEDURES)

120 VAC Setting 2-1 240 VAC Setting
SECTION II DESCRIPTION
2.2. GENERAL SPECIFICATIONS
WEIGHT
UNIT: 111 lbs (50.39 Kg)
DC POWER CABLE: 8.5 lbs (3.86 Kg)
AC POWER CORD: 0.4 lbs (0.18 Kg)
INPUT POWER AC
TI2000GPU-24: 105-125 VAC 60 Hz 6.50 amps max.
TI2000GPU-24-UNV: 210-250 VAC 50/60 Hz 3.25 amps max.
TI25000-U01 NORTH AMERICAN LINE CORD
105-125 VAC 60 Hz 6.50 amps max.
TI25000-U04 OLD BRITISH LINE CORD
210-250 VAC 50/60 Hz 3.25 amps max.
TI25000-U03 EUROPEAN 10A/250V
210-250 VAC 50/60 Hz 3.25 amps max.
TI25000-U05 ENGLAND 10A/250V
210-250 VAC 50/60 Hz 3.25 amps max.
OUTPUT POWER DC
CONVERTER: 28.5 VDC TO 20 AMPS, 24 VDC 21 AMPS AND ABOVE.
POWER CELLS: 24 VDC
PEAK OUTPUT: 3000 AMPS
POWER CELL
DRY, HIGH RATE DISCHARGE, RECHARGEABLE, MAINTENANCE-FREE
DC POWER CABLE
LENGTH: 8 FT
AIRCRAFT CONNECTOR: 3 PIN RECEPTACLE (MS25488)

2-3

2-4
7) Replace the
white clip back into
the fuse clip. Take
care not to damage
the tabs.
8) Completely insert
white clip in to fuse
clip (GENTLY) until
it snaps into place.
9) Insert fuse clip
back into fuse housing
EVENLY on both sides.
DO NOT FORCE, if fuse
clip does not go in easy,
it means fuses are mis-
aligned, realign fuses and
insert again.
10) Snap fuse clip
back into the housing
(GENTLY). DOUBLE
CHECK VOLTAGE
WINDOW PRIOR
TO PLUGGING UNIT
INTO AC POWER
5) Completely remove
the white clip from the
fuse clip.
6) Ensure that the
proper voltage is selected
on the white clip. (See
Enlargement 2 & 3)
1) Grab both tabs
on left and right side
of the fuse clip. Press
tabs inward and pull
fuse clip out of housing
GENTLY.
2) Completely pull
fuse clip from housing,
being careful not to
drop the fuses from
the fuse clip.
3) Note: The fuses
are not fastened into
the fuse clip, they are
lose. Take care to ensure
fuses are not dropped or
lost.
4) GENTLY pull the
white clip from the
fuse clip, taking care
not to bend any of
the tabs. (See
enlargement 1)
Fuse Setting Procedures
for Switching Voltages or Changing Blown Fuses
ENLARGEMENT 1
TABS
ENLARGEMENT 2 120 VAC SETTING
ENLARGEMENT 3 240 VAC SETTING

2-2
CHAPTER 3
OPERATING LIMITS AND RESTRICTIONS
SECTION I. GENERAL
3-1. PURPOSE
Chapter 3 includes all important operating limits and restrictions
that must be observed for proper and safe operation of the TI2000GPU-
24 (Turbo Start 2000) ground power unit.
3-2. GENERAL
The operating limitations set forth in this chapter are the direct
result of design analysis, testing, and operating experience. Com-
pliance with these limitations and restrictions will ensure that own-
ers/operators obtain maximum continued capability from the Turbo
Start 2000 ground power unit.
SECTION II. OPERATIONAL RESTRICTIONS AND SAFETY LIMITS
3-3. POWER CELL RECHARGE LIMITS
Any time the unit’s power cells are fully discharged the unit shall
be recharged within 24 hours to prevent performance degradation and
ensure maximum life.
CAUTION
Unit’s power cells may be damaged if recharged by NiCad or Lead Acid-
type battery chargers. Power cells should only be charged by either
the TURBO START internal charger and the AC power cord furnished with
the equipment, or when connected aircraft external DC power recep-
tacle.

3-1
3-4. 120-240 VAC CHARGER AND AC TO DC CONVERTER LIMITS
The unit is designed with a single point AC receptacle for external
power to operate both the internal charger and converter. The units
AC voltage range can be factory set from 105 to 250 VAC at 50 to 60
Hz depending upon customer requirements. The AC power cord provided
with the unit is the mechanism that ensures the specified AC power
source is properly supplied to the unit (see paragraph 3-5).Use no
others
INTERNAL CHARGER: NO LIMIT AC power cord can remain connected
when power cells are fully charged. When the power cells are fully
charged the unit’s intelligent charger will go to a stand-by mode,
monitor the power cells state of charge, and only charge the power
cells to ensure they stay at maximum capacity.
INTERNAL AC TO DC CONVERTER: LIMITED (see paragraph 3-6, 3-8 and
3-10). AC power cord does not have to be disconnected when con-
verter power output is no longer required. Once DC power demand
is terminated the unit’s intelligent charger will remain on line to
ensure power cells are charged to maximum capacity.
CAUTION
Unit will be damaged if unapproved AC power is applied.
3-5 AC POWER CORD LIMITS
The AC power cord governs which AC power source the unit is set to
operate from. The Turbo Start 2000 is supplied with a single cus-
tomer specified AC power cord. Some customers may specify a univer-
sal AC option (for worldwide mobility), which comes with two (2)
power cords, one for 120 VAC 60 Hz and the other for 240 VAC 50 Hz
(SEE APPENDIX A). Each power cord is marked accordingly. Below are
the following three (3) types of AC power cords available and their
limits.
120 VAC 60 Hz power cord (USA): LIMITED TO 105-125 VAC 60 Hz power
source only.
120 VAC 60 Hz power cord (Universal): LIMITED TO 105 VAC to 250 VAC
50/60 Hz power source using proper cord set.
240 VAC 50 Hz power cord (European): LIMITED TO 210-250 VAC 50-60 Hz
power source only.
FOR MORE INFORMATION ON POWER CORDS SEE APPENDIX A
*8 $5’ )52 0 ,1&255( &7
32: (5 6285&(

3-2
AC Line Cords
Cont. Europe U.K. Old British North American
CAUTION
Unit will be damaged if unapproved AC power is applied by fitting
120 or 240 VAC power cord with any kind of unapproved modification or
adapter that changes the specified input power characteristics.
WARNING
********SHOCK HAZARD POTENTIAL*********
Failure to use proper grounding can cause a potential shock hazard!
In different countries, the 240 VAC 50 Hz power cord may require
the use of a plug adapter to achieve plug style compatibility for
240 VAC 50 Hz operation. Use only adapters with proper grounding
mechanism.
3-6. ONE (1) HOUR RATE, 24 VDC CONSTANT OUTPUT
46 amp hour (without AC power connected), power cell output.
(see Figure 5-2)
66 amp hours (with AC power connected), both power cell and AC to
DC converter output.
NOTE
If power output is greater than rated amp hour rate, power cell
discharge rate will increase correspondingly.
3-7. RATED PEAK OUTPUT (ENGINE STARTING)
3000 peak amps at 25oC (77oF) (See Figure 5-3).
乊乘乄乕乇丣义乕乒乐丣乌乑乆乒乕乕么
乆乗
乓乒乚么乕丣 乖乒乘乕乆么

3-3
3-8. CONTINUOUS OUTPUT RATE, 28.5 VDC CONSTANT OUTPUT
20 amp hours (with AC power connected)
NOTE
If current demand exceeds 20 amps, converter output voltage will drop
below 28.5 VDC and two or more LED status indicator bars will illumi-
nate. If all LED status indicator bars illuminate, both the con-
verter and power cells are supplying 24 VDC power output (see para-
graph 3-4 and 4-7.4.).
3-9. ENGINE STARTING POWER
Operators should always ensure the unit is charged above 80% prior to
ground support engine starting. However, circumstances may exist
during use where unit recharge is not readily available and immediate
external engine starting power is required. The following provides
minimum states of charge necessary to provide ample power for an ef-
ficient engine start under specific current load demands.
ENGINE START CURRENT LOAD DEMAND MINIMUM CHARGE
650-850 peak starting amps 40% charged
850-1000 peak starting amps 50% charged
1000-1500 peak starting amps 60% charged
1500-1800 peak starting amps 70% charged
1800-2500 peak starting amps 80% charged
2500-3000 peak starting amps 90% charged
3-10. TEMPERATURE
Temperatures refer to the unit’s cold/heat soaked temperature. A
unit’s cold/heat soaked temperature shall be established by the ambi-
ent temperature that a unit is exposed to for one (1) hour or more.
If unit’s cold/heat soaked temperature exceeds operating temperature
range, unit shall be stabilized prior to operation as follows: COLD
SOAKED, warmed for a minimum of 3 hours above +10Co(+41oF) or 2
hours above +20Co(+68oF); WARMED SOAKED, cooled for 1 hour below
+38Co(+100oF).
Operating range:
without AC power -40Co(-40oF) TO +60Co(+140oF)
with AC Power -30Co(-22oF) TO +50Co(+124oF)

Storage range:
-60Co(-76oF) TO +60Co(+140oF)
(C0NTINUED ON NEXT PAGE)
3-4
CAUTION
Unit may be damaged if operated when unit’s cold or heat soaked tempera-
ture exceed the specified limit. If unit is operated when cold or heat
soaked temperature limit is exceeded, a full functional check should be
accomplished prior to continued use.
NOTE
If unit should overheat, an over-temperature sensor will shut down 120-
240 VAC functions (charger and converter) until unit cools to normal
operating temperatures.
3-11. ENVIRONMENTAL
Operating any electrical equipment in the presence of moisture cre-
ates possible safety hazards and/or potential for equipment damage.
Every effort has been made, within the scope of existing technology
to prevent foreseeable safety hazards and make the Turbo Start 2000
moisture resistant to prevent damage or failure. If the Turbo Start
3000 is exposed to moisture, preventive measures and precautions
shall be taken to:
a. prevent accumulation of moisture on AC and DC con-
nectors/receptacles
b. minimize moisture entering FWD inlet and AFT out-
let cooling fan vent ports
The limits and operational constraints listed below shall apply for
the following environmental (weather) conditions:
Heavy or steady rain: OPERATION NOT RECOMMENDED
Light rain, drizzle: NO CONVERTER OR CHARGER 120-240 VAC
fog, snow or sleet: POWER SHALL BE APPLIED.
Unit inlet and outlet vent ports shall be covered from exposure.
Unit shall be kept horizontal.

3-5
WARNING
********SHOCK HAZARD POTENTIAL*********
Severe injury, or Death, from electrical shock is possible when per-
sonnel and/or Turbo Start 2000 are wet during use and when 120-240
VAC power is being supplied to unit.
CAUTION
Damage may occur if unit is operated after exposure to moisture
(rain, drizzle, fog, sleet or snow) or moisture contamination is sus-
pected. DO NOT USE until unit’s exterior and receptacles are dried.
Operation shall be restricted to use without 120 or 240 power cord .
DO NOT CONNECT 120 or 240 VAC power cord until unit has been dried
for a MINIMUM of one (1) hour, prior to use.
Blowing sand or dust: Minimize exposure to sand and dust
when 120-240 AC power is used. Unit shall be kept horizontal dur-
ing use.
3-12. OPERATING POSITION
Without 120-240 VAC power cord: Horizontal or vertical.
Horizontal only , for propper unit ventilation, when 120-240 VAC line
cord is plugged in and exhaust fan is running.
CAUTION
Unit may be damaged if blown over by propeller, rotor or jet wash, or
accidentally knocked over. Unit should be kept horizontal during
use.

3-6
CAUTION
Unit damage may occur if inlet and outlet vent ports are obstructed
and/or cooling air flow is restricted.
3-13. UNIT OPERATION DURING AIRCRAFT FUELING/DEFUELING
Power output is restricted to 24 VDC power cell output only. DO
NOT CONNECT 120 or 240 VAC POWER SUPPLY. 120-240 VAC power
(charger or AC-DC converter) functions of unit shall not be oper-
ated during any aircraft fuel handling operation.
WARNING
*******FIRE/EXPLOSION HAZARD POTENTIAL********
Severe injury, or Death, may occur from fire or explosion, as a
result of electrical sparks produced near fuel vapors.

3-7
CHAPTER 4
OPERATING PROCEDURES
SECTION I. UNIT OPERATION
4-1. GENERAL
Correct operation of the TI2000GPU-24 (Turbo Start 2000) includes
both pre-use and operational checks of the unit. Knowledge of the
operating limits, restrictions, performance, unit capabilities and
functions is fundamental to correct and safe operation. The operator
shall ensure compliance with the instructions in this manual that
affect operational safety and the warranty of the unit.
4-2. OPERATING LIMITS AND RESTRICTIONS
The minimum, maximum and normal operating ranges result from careful
engineering and evaluation of test data. These limitations must be
adhered to during all phases of operation. Refer to Chapter 3, Sec-
tion II, OPERATING LIMITS AND RESTRICTIONS, for detailed information.
4-3. PERFORMANCE
Refer to Chapter 5, PERFORMANCE DATA to determine the capability of
the Turbo Start. Consideration must be given to changes in perfor-
mance resulting from variations in ambient temperature, mode of op-
eration, state of charge (with or without 120 or 240 VAC power), and
aircraft DC bus system inefficiency (voltage drops).

4-1
SECTION II. OPERATING PROCEDURES
4-4. OPERATING PROCEDURES
This section deals with normal procedures, and includes all steps
necessary to ensure safe and efficient operation of the TI2000GPU-24
(Turbo Start 3000). As experience is gained with the Turbo Start
3000, the user will be able to maximize the unit’s unique capabili-
ties to enhance the flexibility of aircraft maintenance and support
operations.
NOTE
When the TURBO START 2000 is not in use, it should always remain
plugged into a suitable AC power source to insure operational readi-
ness at all times. REMEMBER,when the AC line cord is plugged in, the
unit must be placed in the horizontal position to allow the cooling
fan to operate properly!
4-5. BEFORE OPERATION CHECK
1. CHECK FUSE WINDOW FOR PROPER SETTING (120/240 ) BEFORE PLUGGING
UNIT INTO THE AC POWER SOURCE TO BE USED . REMEMBER,when the AC line
cord is plugged in, the unit must be placed in the horizontal posi-
tion to allow the cooling fan to operate properly!
NOTE:
A full charge is indicated by Either a steady lighted green bar or a
blinking green bar at the bottom of the bar graph column.The fan will
also exhibit ratcheting but will not come on when the unit is fully
charged.
2. CHECK UNIT FOR EVIDENCE OF DAMAGE - Check for dents, punctures,
case distortion or misalignment, cracked or loose connectors, and
STATUS

that cooling fan is functioning.
4-2
CAUTION
REMEMBER,when the AC line cord is plugged in, the unit must be placed
in the horizontal position to allow the cooling fan to operate prop-
erly!
Unit may overheat if cooling fan fails. Do not operate if cooling
fan fails.(More than one green bar present on bar graph)
3. CHECK DC POWER CABLE/CONNECTORS FOR DAMAGE - Check cable for
cuts, chafing or evidence of being crushed. Check connectors for
cracks, cuts, distortions, excessive wear, broken/loose fasteners or
loose cable attachment.
4-6. 24 VDC GROUND POWER (NO 120 OR 240 VAC POWER SUPPLY) ENGINE
STARTING OR DC SYSTEM POWER
1. TRANSPORT UNIT - The Turbo Start 2000 is easily transported using
the wheels that are incorparated into the unit. The AXEL EXTENTION
kit (included with the unit) ensures that the Turbo Start 2000 is
stable. The unit is engineered to be pushed rather than pulled.
2. CONNECT DC POWER CABLE TO UNIT - Ensure power cable connector is
fully seated into unit’s connector. Set the unit down horizontally
ensuring vent ports are un-blocked.
3. CONNECT DC POWER CABLE TO AIRCRAFT - Ensure ground power
cable connector is fully seated into aircraft ground power recep-
tacle. DC bus power should come on and aircraft volt meter should
indicate 24 VDC to 23.5 VDC (23 VDC minimum).
4. ENGINE STARTING - Check power cable for security and correct
installation prior to engine start. Follow ground power engine
