Tesla SMART CAMERA 360 Speed 5S User manual

SMART CAMERA 360
USER MANUAL

EN
WHAT'S IN THE BOX
Please consult this checklist for all parts.
• Smart Camera 360
• Power adapter
• USB cable
• Bracket
• Screws
• Pin
• User manual
Power
Status light
Microphone
SD card slot
Reset
Status light
Microphone
SD card slot
Reset
Power
Speaker
DC 5V ±10%
Red light solids on: the camera or network is abnormal
Blinking red light: awaing WiFi connecon (faster blinking)
Blue light solids on: camera running correctly
Blinking blue light: currently connecng (faster blinking)
Captures sound for your video
Supports local SD Card storage (Max.128G)
Press and hold for 5 seconds to reset the camera
(if you have modied sengs, they will return to factory defaults)
1

EN
INSTALL
2
1
2
Use the included mounng bracket to x the camera to a clean surface.
Or, put the camera on a at surface.

EN
CONNECT
Download
Set up router
Registraon process
QR code conguraon
Step 2
2
3
4
5
Sengs
Step 1
1
3
Tesla Smart is available for both iOS and Android
OS. Search the name 'Tesla Smart' in App Store or
Android Market, or scan the QR-Code to download
the App.
The router supports the 2.4GHz WiFi (doesn't support the 5GHz). Before connecng to the WiFi network,
please set the parameters of the router, and record the SSID and password of your WiFi. Keep the network available.
Open the Tesla Smart App, click "Register", read the "Privacy Policy" and click "Agree" .
Open the Tesla Smart App, click "Create family", and you can customize
the Family name and related sengs.
Input a legal and valid Mobile number or Email address and click "Connue". Input Vericaon Code,
then log in the app.
Connue to click "Security & Sensor" >> "Smart Camera", and then
choose" Add Device" or "+", ready to add camera.
In "Add Device" this interface,connue to click "next step", and then you should input your WiFi's passwords.
Note: 1) Camera only supports 2.4GHz WiFi network. 2) The number of bits in the ssid and passwords of the router
should not exceed 24 digits.
In this interface, you should scan the QR code in your phone with the camera, when the camera comes out
"dong dong dong". And you can complete the conguraon about 30s.
When connecng, you should make sure your router, mobile,and camera are as close as possible. When camera
added successully, click " " you could also DIY the camera's name.
In "Smart Camera" interface,click " ",you can set the camera common funcons.

EN
FAQ
FUNCTIONS
Queson
Queson
Queson
Queson
Queson
Answer
Answer
Answer
Answer
Answer
The device cannot be previewed properly?
Why is it sll in the list of devices aer reseng?
How to cut the camera network to another router?
Why doesn't the device idenfy the SD card?
Why I can’t get the nocaons with my cell phone App?
Check whether the network is normal, you can place the camera close to the router, and if not,
it is recommended to reset the device and add it again.
The reset device only resets the network conguraon of the camera, but cannot change the
conguraon on the App, remove the camera, and must be deleted by the App.
First remove and reset the device on the App and then congure the device again
by the App.
It is recommended to plug in SD card aer power cut. Conrm whether the SD card is normally
available and the format is FAT32. And the TF card can’t be idened when the internet
environment is not good.
Please conrm that the App has been running on the phone, and the relevant reminder funcon
has been opened;Message nocaon and authority conrmaon in the mobile phone system
have been opened.
4
Pan/Tilt
Video ip
Day & Night
Moon detecon
Record
Rotate your camera by sliding on your smartphone, providing you with 360 degrees of vision.
Flip your video stream up or down for maximum exibility.
Never miss a moment, even in complete darkness, with powerful night-vision technology.
Built-in moon sensors detect movement, and the camera will send you push nocaons and app alerts.
Support 24H connuous recording with high capacity SD storage or Cloud storage.

EN
TECHNICAL SPECIFICATION AND ADDITIONAL INFORMATION
5
Product name Tesla Smart Camera 360
Resolution
1920 x 1080
Power supply
DC5V, 1A
Sensor
1/3'' 2MPx, CMOS
IR Distance
Up To 10 m
Lens
3.6mm , F2.0
Dimensions
87,4 x 110 mm
Storage
MicroSD Card, Cloud
App
Tesla Smart for Android a iOS
Connectivity
Wi-Fi 2,4 GHz IEEE 802.11b/g/n
Model
Speed 5S
INFORMATION ABOUT DISPOSAL AND RECYCLING
EU DECLARATION OF CONFORMITY
This product is marked with the symbol for separate collecon. The product must be disposed of in accordance
with the regulaons for disposal of electrical and electronic equipment (Direcve 2012/19/EU on waste electrical
and electronic equipment). Disposal together with regular municipal waste is prohibited. Dispose of all electrical
and electronic products in accordance with all local and European regulaons at the designated collecon points
which hold the appropriate authorisaon and cercaon in line with the local and legislave regulaons. Correct
disposal and recycling help to minimise impacts on the environment and human health. Further informaon
regarding disposal can be obtained from the vendor, authorised service centre or local authories.
Hereby, Wiy Trade s.r.o. declares that the radio equipment type Speed 5S is in compliance with EU direcves.
The full text of the EU declaraon of conformity is available at the following internet address:
teslasmart.com/declaraon
Connecvity: Wi-Fi 2,4 GHz IEEE 802.11b/g/n
Frequency band: 2.400 - 2.4835 GHz
Max. radio-frequency power (EIRP): < 20 dBm
Wiy Trade s.r.o.
Průmyslová 1472/11, 102 00 Praha, Česká republika
www.teslasmart.com
