Tesla 43T320SFS User manual

MKD S LV SRBENG BiH/
MNE HRV
43T320SFS
43T320BFS
TV
USER
MANUAL

OPERATING INSTRUCTION
Please read these instructions before operating
your set and retain them for future reference.
UPUTSTVO ZA UPOTREBU
Prije upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
UPUTE ZA KORIŠTENJE
Prije korištenja uređaja pažljivo pročitati
upute i sačuvati ih za buduću upotrebu.
NAVODILA ZA UPORABO
Pred uporabo pozorno preberite navodila
in jih shranite za morebitno uporabo v prihodnosti.
UPUTSTVO ZA UPOTREBU
Pre upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
УПАТСТВО ЗА КОРИСТЕЊЕ
Ве молиме прочитајте го ова упатство пред да го
инсталирате и употребувате вашиот уред.
ENG
BiH/
MNE
HRV
MKD
S LV
SRB

3
ENG
Read all of the instructions before operating the set. Keep these instructions well for future use.
• Do not block or cover the ventilation openings on the back cover.
• Do not push objects of any kind into this unit through the cabinet slots as they could touch the current carrying
parts or short-circuit parts, resulting in fire, electric shock, or damage to the unit.
• Do not attempt to open the cabinet as this may cause damage. There are no parts inside you can service by
yourself. Refer all servicing to qualified personnel.
• Do not touch the screen surface with fingers as this may scratch or mar the TV screen.
• Do not impact the TV screen with hard pressure as this may damage the TV screen severely.
Unplug the set under the following conditions:
• If the set will not be used for a long period of time.
• If the power cord or the power outlet/plug is damaged.
• Follow the instructions to install and adjust the product. Adjust those controls that are covered in this operating
instructions as improper adjustment of other controls may result in damage. If this happens, unplug the set and
refer to the service personnel.
• If the set is subject to impact or has been dropped to have the cabinet damaged.
• Do not allow anything to rest on or roll over the power cord and the signal cable.
• Protect the power cord and the signal cable from being trampled.
• Do not overload the power cord or the power outlet.
• Do not expose the power cord and the signal cable to moisture.
• Do not place the set on an unstable cart, stand, or table.
• Place the set on a place that allows good ventilation.
• Do not use the set near damp, and cold areas. Protect the set from overheating.
• Keep the set away from direct sunlight.
• Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall
be placed on the apparatus.
• Do not use the set near dust place.
• Dust the set by wiping the screen and the cabinet with a soft,clean cloth or some special liquid cleaner.
• Do not apply excessive force to the screen when cleaning.
• Do not use water or other chemical cleaner to clean the screen as this may damage the surface of the TV screen.
Warning: This operation requires two people.
To ensure a safe installation, observe the following safety notes:
• Check that the wall can support the weight of the TV set and wall mount assembly.
• Follow the mounting instructions provided with the wall mount.
• The TV set must be installed on a vertical wall.
• Make sure to use only screws suitable for the material of the wall.
Make sure that the TV set cables are placed so that there is not danger of tripping over them.
All other safety instructions about our TV sets are also applicable here.
INTRODUCTION
Precautions
Product
Power and Plug
Power Cord and Signal Cable
Use Environment
Cleaning
Hanging the TV Set on the Wall

4
ENG
Buttons on the TV
Sockets
Take a certain model for an example:
button
1. Turn on the TV.
2. The TV is on, press it to display Button menu.
3. In the Button menu, short press it to select the menu, long
press it to confirm the selection.
1. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way
that it does not require a safety connection to electrical earth.
2. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable.
3. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
4. A warning that batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
5. No naked flame sources, such as lighted candles, should be placed on the apparatus;
6. Attention should be drawn to the environmental aspects of battery disposal;
Note: Illustrations within this publication are provided for reference only.
Note: The location and names of the sockets on the TV may vary according to TV model, and some sockets may not
available for some models.
ETHERNET
ETHERNET
This socket can be used to connect to external modem or network access
equipment.
SPDIF(coax.) SPDIF(coax.) socket (output)
This socket can be used to connect a compatible digital audio receiver.
HDMI 1
or HDMI 2
HDMI 1/HDMI 2 socket (input)
The HDMI (High-Definition Multimedia Interface) socket lets you connect a device,
such as a Blu-ray player, with a HDMI output for best picture quality. It also provides an
uncompressed digital connection that carries both video and audio data by way of an
integrated mini-plug cable.
USB 2.0
USB 2.0 socket (input)
This socket can be used to connect a USB device.
(Note: Please don’t turn on the unit when USB 3.0 drive is inserted,as it might cause
compatibility problems. )
SAT IN SAT in - IN socket (input)
This socket can be used to connect the satellite receiver port.
ANT/CABLE IN ANT/CABLE IN socket (input)
This socket can be used to connect the outside aerial or cable network.

5
ENG
Remote Control Functions
Most of your television’s functions are available on the menu that appear on the screen. The remote control
supplied with your set can be used to navigate through the menus and to configure all the general settings.
Note: The location and names of the buttons on the remote control may vary according to TV model, and not all
buttons available on all models.
MINI AV IN
MINI AV IN socket (input)
The MINI AV IN sockets can be used to connect a range of equipment, including video
recorders, camcorders, decoders, satellite receivers, DVD players, or games consoles.
The VIDEO IN socket provides composite video connection.
CI+ CI+ socket
This CI socket can be used to put the CI card in to accept the Scrambled programs.
HEADPHONE
HEADPHONE socket (output)
Allow you to connect earphones to listen to the sound coming from the TV .
Note: Excessive sound pressure from earphones can cause hearing loss.
1. q(POWER button) Turns the TV on or standby.
2. (MUTE button) Turns the volume off or on.
3. 0 ~ 9 (Numeric buttons) Enters channel numbers.
4. SUBTITLE Press to display the Subtitle Language menu.
5. Goes to the YouTube homepage.
6. VOL +/VOL- (VOLUME UP/DOWN) Increases or decreases the
TV’s volume.
7. TV In the other sources, presses to back TV.
8. SOURCE Brings up the SOURCE menu.
9. USB Goes to the multimedia files in USB.
10. CH ./ ,(CHANNEL UP/DOWN) Scans up or down through
the current channel list.
11. To display the option menu.
12. To display program information, if available.
13. ECO To select desired power saving mode.
14. (SETTING button) Brings upthe main menu.
15. (HOME button) Goes to the smart TV homepage.
16. ( Up, down, left and right direction buttons) High
lights different items in the menu system and adjusts
the menu controls.
17. OK When in the menu system, confirms your selection or
changes settings.
18. (BACK button) In menu mode, goes back to the
previous menu or interface.
19. EXIT Exits the menu system.
20. Goes to the Netflix homepage.
21. COLOURED
BUTTONS
(Red/Green/Yellow/Blue) Selects tasks.
22. SLEEP Press to set the TV to turn off after a given amount
of time. To cancel the sleep timer, press until off
appears.
23. ZOOM-/ZOOM+ Press to select the desired screen format.
Note: This function is not available in USB mode.

6
ENG
24. CH LIST Displays the channel list menu.
25. TEXT Turn On/Off Teletext. Press to turn on/off the teletext
function.
26. GUIDE Toggles the Electronic Programme Guide between
on and off.
Note: This function is only available in DTV mode.
27. PRE-CH To return to the previous channel.
28. FAV Brings up your favorite channel list.
29. 5Searches backward.
30. 6Searches forward.
31. (Previous) Goes to the previous chapter.
32. 3(Stop) Stops viewing.
33. u2(Play/Pause) Starts, pauses or resumes viewing.
34. (Next) Goes to the next chapter.
Note: The above six buttons can be used for playing
music, pictures and videos in the USB menu.
35. 4PVR function.
36. (LANG) display audio language list.
Switching on
GENERAL OPERATION
Follow the instructions on this page on how to switch on your TV set and the remote control before going on to
following pages describing how to use the channel set-up procedure.
1. To fix the double support base on the unit by screws,the installation is completed.
- To bring you better visual experience, please remove all labels, if any, from TV front panel and screen before
use.
- Figures and illustrations in this User Manual are provided for reference only and may differ from actual product
appearance.Product design and specifications may be changed without notice.
2. Insert two AAA batteries in the remote control.
Precautions on using batteries:
Only use the battery types specified.
Make sure you use the correct polarity.
Do not mix new and used batteries.
Do not use rechargeable batteries.
Do not expose batteries to excessive heat such as sunshine, fire or the like, throw them in a fire, recharge them
or try to open them, as this could cause them to leak or explode.
Remove the batteries from the remote control if you are not using it for a long period of time.
3. Connect the power cable FIRST to the television, THEN to a mains socket.
(Note: If the power cable is connected to the television, please only connect the power cable to the mains
socket.)

7
ENG
Switching off
Network Connection
Connectinq to a wired network
Connectinq to a wireless network
To put the TV set into standby mode, press the button on the remote control or on the TV, the TV set remains
powered up, but with low energy consumption.
To switch off the TV set, unplug the mains socket from the mains outlet.
Note: For some models, press the power button to switch off the TV set.
To access the Internet, you must subscribe to high speed broadband Internet service with your Internet service
provider (lSP).
Your TV can be connected to your home network in two ways:
• Wired, using the RJ45 (LAN) connector on the back panel.
• Wireless, using the internal wireless and your home wireless network.
Note: Instructions below are just the usual ways to connect your TV to the wired or wireless network. The connection
method may be different depending on your actual network configuration. If you have any questions about your
home network, please refer to your lSP.
To connect to a wired network:
1. Ensure you have:
• An Ethernet cable long enough to reach your TV
• A router or modem with an available Ethernet port
• A high-speed Internet connection
• An Ethernet (LAN) port on the back of the TV
2. Connect your Ethernet cable to the router and to the
Ethernet port on the back of the TV.
3. Use the Network menu to configure the TV.
To connect to a wireless network:
1. Ensure you have:
• A router broadcasting a high-speed wireless
signal
• A high-speed Internet connection
2. Use the Network menu to configure the TV.
Your TV set should only be connected to an AC supply. It must not be connected to a DC supply. If the plug
is detached from the cable, do not, under any circumstances, connect it to a mains socket, as there is a risk of
electric shock.
Note: The figures are for representation only. The location of the power socket at the back of the television might
differ depending on the model.
4. Connect an outside aerial to the ANT/CABLE IN or SAT IN socket at the back of the TV set. The aerial socket (75
OHM - VHF / UHF / cable) can be used for connecting an external aerial or other equipment fitted.
5. When powered on, the TV will be turned on directly or be in standby.
Note: For some models, switch the TV on by pressing the power button.
If the power indicator lights up, the TV set is in standby mode. Press the button on the remote control or on the
TV set to turn on the TV.

8
ENG
Using Homepage
Menu Function
MENU OPERATION
Note: This manual is for common use. Figures and illustrations in this User Manual are provided for reference only
and may differ from actual product appearance. And for some models, certain options are not available.
You can select all the features from homepage.
1. Press to display homepage.
2. Press ///uto select icons from the screen list.
3. Press OK to enter each option.
4. To exit the menu, press EXIT.
WARNING:
• Configure the network settings before using Smart TV.
• Slow responses and/or interruptions may occur, depending on your network conditions.
• If you experience a problem using an application, please contact the content provider.
• According to circumstances of the contents provider, an application’s updates or the application itself may be
discontinued.
• Depending on your country’s regulations, some applications may have limited service or not be supported.
Homepage-Source
Source: Select the input source from devices connected to TV through different ports.
Homepage-Smart
Smart: Displays the smart menu.
Homepage-Apps
Many useful and entertaining apps for using. After entering the Apps Store, you will see the recommendations.
Press /uto select, press OK to enter.
This section explores the system settings menu of your TV. Each menu is outlined and detailed to help you get
the most from your TV. Please note that some function might be unavailable in certain input source. To access the
menu system:
1. Press on remote control to display the main menu.
2. Press /to select Picture, Sound, Channel, Smart TV, Network, System or Support, then press OK or uto enter
the submenu.
3. In the submenu, press /to select options, press OK or uto set functions or change values, press OK to open
the corresponding submenu or activate a setting.
4. To return the previous menu, press . To close the menu, press EXIT.

9
ENG
Picture Sound
1. Press to display the main menu.
2. Press /to select Picture, then press OK or uto
enter the submenu.
Picture preset
Adjusts the picture setting that best suits your viewing
environment.
Backlight
Adjusts the backlight levels of the picture.
Brightness
Adjusts the brightness of the picture.
Contrast
Adjusts the difference between the light and dark areas
of the picture.
Saturation
Adjusts the richness of color.
Tint
Adjusts the balance between the red and green levels.
Sharpness
Adjusts the crispness of the edges in the picture.
Color temperature
Adjusts the color temperature of the picture.
Auto format
Enables/disables the aspect ratio selection
automatically.
Screen mode
Selects the picture size.
Overscan
Selects On or Off to turn on/off this option.
ECO settings
Configures engergy saving options.
Micro Dimming
Selects On or Off to turn on/off micro dimming.
Advanced Settings
Selects more picture advanced settings.
Picture reset
Restores the current picture settings to default.
1. Press to display the main menu.
2. Press /to select Sound, then press OK or uto
enter the submenu.
Sound preset
Selects a preset audio option optimized for different
sounding conditions.
Note: When Sound preset is set to different mode, five
Sound options (100 Hz, 500 Hz, 1.5 KHz, 5 KHz, and 10
KHz) will be adjusted, which enable you to adjust the
frequency levels desired. You can also set the options to
your desired levels.
Balance
Adjusts the amount of audio sent to the left and right
speakers.
Auto volume control
Selects On to reduce the annoying blasts in volume
during commercial breaks and also amplifies softer
sounds in program material. Eliminates the need to
constantly adjust the volume.
SPDIF type
This option is used to control the type of audio stream
sent to the Digital Audio Output (SPDIF) socket.
SPDIF delay
This option is used to synchronize the sound with the
picture. If the sound is slower/quicker than the action
of the picture, you can press /uto adjust the
numerical value.
Audio delay
if the sound output does not match the picture,
press /uto adjust the delay time to synchronize the
sound with the picture.
TV placement
Selects Desk top or Wall mount mode.
Advanced Settings
Selects more sound advanced settings.

10
ENG
Channel Smart TV
1. Press to display the main menu.
2. Press /to select Channel, then press OK or uto
enter the submenu.
Note: This function is only available in TV mode.
Channel scan
Allows you to scan for all available analog and digital
channels.
Channel List
Shows all the searched channel in a list.
EPG
Press OK/uto enter the Program Guide menu.
Channel organiser
This option allows you to organise channels.
Channel diagnostics (on digital TV channels)
Press OK/uto display some signal information on
current digital channel, such as signal strength,
Frequency, etc.
Timeshift
Note: This Option is only available when Timeshift is set
to On: In TV mode, press , select Settings> Channel>
Timeshift, press OK to enter and use /to set
Timeshift to On or Off.
Subtitle
press OK/uto enter, press /to turn On or Off the
subtitles. When Subtitle is set to On, you can enable
subtitle languages on digital TV channels.
-Digital subtitle language:
Press /to select Digital subtitle language. Press
OK/uto enter, press /to select a subtitle language
as your preferred language.
-Digital subtitle language 2nd:
Press /to select Digital subtitle language 2nd.Press
OK/uto enter,press /to select a secondary subtitle
language.Press to return to previous menu.
-Subtitle type:
Press OK/uto to enter,press /to select a subtitle
type. You can select Hearing impaired to display the
hearing impaired subtitle with your selected language.
Teletext
Press OK/uto display its submenu.
Decoding page language:select a proper type of
language in which Teletext will display.
Digital teletext language:for digital TV channels, your TV
could zap to a service with multiple initial Teletext pages
in different languages. This function allows you to select
an available language as primary language which relates
to different initial Teletext page.
PVR
Press OK/uopen PVR.
1. Press to display the main menu.
2. Press /to select SmartTV, then press OK or uto
enter the submenu.
Smart TV portal
Allows you to enjoy Internet Applications (Apps),
specially adapted Internet websites for your TV. You
can control the Apps with the TV remote control.
Share&See
With Share&See, you can enjoy recorded video, picture,
music saved on your PC.
Fast Cast
Press OK/uto enter the Fast Cast.
Wireless display
Displays your smartphone contents on the TV.
Note: This function may be unavailable for some
models.
Terms and Conditions
Press OK or uto read the Terms and Conditions.
Privacy Notice
Press OK or uto read the Privacy Notice.
Cookie Notice
Press OK or uto read the Cookie Notice.
Networked standby
Press OK or uto select off or on.
Netflix settings
In Netflix Setting menu, Netflix Deactivation can
deactivate your device form Netflix.
HbbTV Setting
HbbTV (Hybrid broadcast broadband TV) is a service
offered b by certain broadcasters and available only on
some digital TV channels. HbbTV delivers interactive
television over broadband Internet. These interactive
features are added to and enrich the normal digital
programmes, and include services such as digital
teletext, electronic programme guide, games, voting,
specific information related to the current programme,
interactive advertising, information magazines, catchup
TV, etc.
To use HbbTV please ensure your TV is connected to
Internet and HbbTV is switched on.
Reset smart TV
Reset the settings of smart TV.

11
ENG
Network
System
1. Press to display the main menu.
2. Press /to select Network, then press OK or uto
enter the submenu.
Internet connection
Press OK or uto select On, then you can adjust the
options below.
Interface
Press OK or uto select Ethernet or Wireless.
Ethernet
Connects your ethernet cable to the router and to the
Ethernet port on the back of the TV.
Wireless
Wireless, using the internal wireless and your home
wireless network.
IP setting
Sets Address type to Auto, it will acquire and enter the
needed IP address automatically.
Information
Press OK/uto display the information on current
connection.
Connection test
Press OK/uto test the internect connection.
1. Press to display the main menu.
2. Press /to select System, then press OK or uto
enter the submenu.
Menu Language
Press OK/uto display the language list and use /
to select a language.
Timer
Press OK or uto enter the submenu.
-Time zone
Selects the local time zone.
-Clock
Select on to turn on the Auto synchronization, the TV
will get the time automatically from DTV signals, and
the Time item cannot be adjusted. If you select off, you
should set the options manually.
-Sleep timer
Sets a period of time after which the TV set goes into
standby mode.
-Auto standby
When Auto Standby is set to your desired time, TV and
device will be in standby mode at the same time.
Note: Without any operation in TV interface when the
Auto standby mode is on, the set will be entering
standby mode automatically.
Lock
This menu can control the special function for TV.
The factory default code is 1234. And the super
password is 0423. If you forget your code, enter it to
override any existing codes.
Input Settings
User can select the device name of the input source
here, easy to identify the source.
Location
Selects Home or Shop with demo depending on
your viewing environment.
Common Interface
Press OK or uto enter the Common Interface.
T-Link
Use this function to turn on the ARC function and search
for CEC devices connected to the HDMI sockets in your
TV.
Auto source
Press OK or uto select On or Off.
Note: This function is only available in HDMI Source.
Sports mode
Press OK or uto select On or Off.
LED Indicator
Press OK or uto select Flashing, Normal or Off.
Instant power on
Press OK or uto select On or Off.
Restore Factory Default
Press OK or uto enter password.

12
ENG
You can enjoy viewing pictures from your USB storage
device.
Note: Some options may unavailable in some models.
In USB state, if USB device didn’t connected, the USB
interface will be not displayed.
How to enter USB mode
1.Connect the USB storage device into the USB Input
terminal.
2.Press USB button to enter USB mode.
3.Select your USB device to enter.
All
To browse picture or video or music if available.
1.Press OK or uto enter, then press /to selectthe
folder, press OK to enter.
2.Press /to select your desired file, then press OK
to play.
To browse pictures if available.
1.Press OK or uto enter, then press ///uto
select the folder, press OK to enter.
2.Press ///uto select your desired file, then press
OK to play.
1. Under the following conditions, this system cannot
decode the file and the file cannot be play normally:
-The parameters of file, such as the pixel of picture,
code rate of audio and video file, sampling rate of
audio file, exceed the limit of the system;
-The format of file is not matched or the file is
harmed.
2. Hot plug: Do not disconnection when the system is
reading or transmitting data, avoid damaging the
system or the device.
3. Pay attention to the power supply of the device when
you are using a mobile hard disk or a digital camera.
If the power supply is not sufficient or not stable,
you may encounter problems during operating or
can not operate at all. In this case, please restart the
device, or unplug the device and plug it again, and
ensure that its power supply is normal.
4. The system supports standard USB1.1 and USB2.0
devices, such as standard U-disks, MP3 players,
mobile hard disks, etc..
5. For obtaining better audio and video quality,
suggests to use the external device which accords
with USB2.0 standard.
6. When playing the video with high compression ratio,
these phenomenons, such as picture standstill and
menu long time response, are normal.
7. For some USB device with power supply, such as
large size hard disk, MP4, etc., suggests using it with
power to avoid electric power shortage.
USB Function
Frequently Asked Questions
Support
1. Press to display the main menu.
2. Press /to select Support,, then press OK or uto
enter the submenu.
Software update
You can update software by USB, network or channel.
-By USB
Enables you to install the latest version of the software
from your USB ports.
-By network
Enables you to download and install the latest software
version from the Internet. Make sure to set up a wired or
wireless network connection first. Press OK/uto enter.
Follow the on-screen instructions to continue.
-By channel
Enables you to update a new software on the air.
Video
To watch video if available.
1. Press OK or uto enter, then press ///uto
select the folder, press OK to enter.
2. Press ///uto select your desired file, then press
OK to play.
Music
To playback music if available.
1.Press OK or uto enter, then press /to select the
folder, press OK to enter.
2.Press /to select your desired file, then press OK
to play.
1. Some non-standard mobile storage device may not
be recognized. Please change to use the standard
device.
2. This system supports the following file formats:
Picture format: JPEG, BMP, PNG etc..
Video format: H.264, MPEG4, MPEG2,
MPEG1, etc..
Audio format: MP3 etc..
Note: For coding files, there are many kinds
nonstandard coding method, so this system can not be
guaranteed to support the file formats using any coding
method.

13
ENG
* Do not touch or be close to the ANT/CABLE IN, HDMI, USB, SPDIF terminals, and prevent electrostatic
discharge to disturb these terminals while in USB, WIFI and LAN operation mode, or it will cause the TV
to stop working or abnormal status.
OTHER INFORMATION
Troubleshooting
Most problems you encounter with your TV can be
corrected by consulting the following troubleshooting
list.
No picture, no sound
1. Check if the fuse or circuit breaker is working.
2. Plug another electrical device into the outlet to make
sure it is working or turned on.
3. Power plug is in a bad contact with the outlet.
4. Check the signal source.
No color
1. Change the color system.
2. Adjust the saturation.
3. Try another channel. Black-white program may be
received.
Remote control does not work
1. Change the batteries.
2. Batteries are not installed correctly.
3. Main power is not connected.
No picture, normal sound
1. Adjust the brightness and contrast.
2. Broadcasting failure may happen.
Normal picture, no sound
1. Press the Vol+ button to increase volume.
2. Volume is set to mute, press the mute button to
restore sound.
3. Change the sound system.
4. Broadcasting failure may happen.
Unorderly ripples on the picture
It is usually caused by local interference, such as cars,
daylight lamps and hair driers. Adjust the antenna to
minimize the interference.
Snowy dots and interference
If the antenna is located in the fringe area of a television
signal where the signal is weak, the picture may be
marred by dots. When the signal is extremely weak,
it may be necessary to install a special antenna to
improve the reception.
1. Adjust the position and orientation of the indoor/
outdoor antenna.
2. Check the connection of antenna.
3. Fine tune the channel.
4. Try another channel. Broadcasting failure may
happen.
Ignition
Black spots or horizontal streaks appear, or the picture
flutters or drifts. This is usually caused by interference
from car ignition system, neon lamps, electric drills, or
other electrical appliance.
Ghost
Ghosts are caused by the television signal following
two paths. One is the direct path, the other is reflected
from tall buildings, hills, or other objects. Changing the
direction or position of the antenna may improve the
reception.
Radio frequency interference
This interference produces moving ripples or diagonal
streaks, and in some case, loss of contrast in the picture.
Find out and remove the radio interference source.

14
ENG
LICENSES
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC
STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.
MPEGLA.COM
This product contains one or more programs protected under international and U.S. copyright laws as
unpublished works. They are con dential and proprietary to Dolby Laboratories. Their reproduction or
disclosure, in whole or in part, or the production of derivative works therefrom without the express permission
of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby Laboratories. All rights reserved.
THIS PRODUCT IS SOLD WITH A LIMITED LICENSE AND IS AUTHORIZED TO BE USED ONLY IN
CONNECTION WITH HEVC CONTENT THAT MEETS EACH OF THE THREE FOLLOWING QUALIFICATIONS:
(1) HEVC CONTENT ONLY FOR PERSONAL USE;
(2) HEVC CONTENT THAT IS NOT OFFERED FOR SALE; AND
(3) HEVC CONTENT THAT IS CREATED BY THE OWNER OF THE PRODUCT. THIS PRODUCT MAY NOT BE
USED IN CONNECTION WITH HEVC ENCODED CONTENT CREATED BY A THIRD PARTY, WHICH THE
USER HAS ORDERED OR PURCHASED FROM A THIRD PARTY, UNLESS THE USER IS SEPARATELY GRANTED
RIGHTS TO USE THE PRODUCT WITH SUCH CONTENT BY A LICENSED SELLER OF THE CONTENT. YOUR
USE OF THIS PRODUCT IN CONNECTION WITH HEVC ENCODED CONTENT IS DEEMED ACCEPTANCE OF
THE LIMITED AUTHORITY TO USE AS NOTED ABOVE.
Tesla declares that the equipment complies with the European Directive 2014/30/EU (EMC) and the Low
Voltage Directive 2014/35/EU (LVD) and the ErP Directive 2009/125/EC and Radio Equipment Directive
2014/53/EU and the RoHS Directive 2011/65/EU in accordance with the following technical standards:
ELECTROMAGNETIC COMPATIBILITY
EN55032:2015;EN55035:2017;EN 61000-3-2:2014;EN 61000-3-3:2013
LOW VOLTAGE
EN60065:2014
ENERGY RELATED PRODUCTS
Commission regulation (EC) No 642/2009; 801/2013;EN 50564:2011;IEC 62087:2011
RED
EN 303 340 V1.1.2(2016-09);EN 303 372-2 V1.1.1(2016-04);EN 300 328 V2.1.1(2016-11);
EN 301 489 -1 V2.1.1 (2017-02);EN 301 489 -17 V3.1.1(2017-02);
EN 62311:2008; EN 62479:2010
RoHS
EN50581:2012
Subject to alterations.In consequence of continuous research and development technical speci cations, design
and appearance of products may change. Manufactured under license from Dolby Laboratories. Dolby Audio
and the double-D symbol are trademarks of Dolby Laboratories. HDMI, the HDMI logo and High-De nition
Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries. All product names are trademarks or registered trademarks of their respective owners.
© Tesla 2020. All rights reserved.

15
BIH/
MNE
Pročitajte ovo uputstvo za upotrebu prije korištenja uređaja. Sačuvajte ovo uputstvo za buduću upotrebu
• Ne blokirajte i ne pokrivajte otvore za ventilaciju sa zadnje strane uređaja.
• Ne gurajte predmete bilo koje vrste u ovaj uređaj kroz otvore na uređaju, jer može doći do kontakta sa dijelovima pod
naponom ili do kratkog spoja, što može rezultirati požarom, električnim udarom ili oštećenjem uređaja.
• Ne pokušavajte da otvorite uređaj jer može doći do oštećenja. Uređaj nema dijelove koje možete sami da zamijenite.
Prepustite cjelokupno servisiranje kvalificiranom osoblju.
• Ne dodirujte ekran prstima jer može doći do grebanja ili prljanja TV ekrana.
• Ne izlažite TV ekran jakom pritisku jer to može značajno oštetiti TV ekran.
Isključite napravu iz struje u sljedećim okolnostima:
• Ukoliko se uređaj neće koristiti tokom dužeg vremenskog perioda.
• Ukoliko je kabal za napajanje ili utičnica/utikač oštećen.
• Pratite uputstva za instalaciju i podešavanje proizvoda. Podesite one komande koje su opisane u ovom uputstvu za
upotrebu jer pogrešno podešavanje može ostalih komandi može dovesti do oštećenja. Ukoliko se to desi, isključite
uređaj iz struje i obratite se servisnom osoblju.
• Ukoliko je uređaj pretrpio udarac ili pad koji je doveo do oštećenja kućišta.
• Ne dozvolite da bilo šta stoji na ili prelazi preko kablova za napajanje i signal.
• Zaštite kablove za napajanje i signal od gaženja.
• Ne preopterećujte kabal za napajanje ili utičnicu.
• Ne izlažite vlazi kabal za napajanje i kabal za signal.
• Ne stavljajte uređaj na nestabilna kolica, podlogu ili sto. Postavite uređaj na mjesto koje omogućava dobro
provjetravanje.
• Ne koristite uređaj blizu vlažnih i hladnih sredina. Zaštite uređaj od pregrijavanja.
• Držite uređaj dalje od direktne sunčeve svjetlosti
• Uređaj ne treba izlagati kapanju i prskanju, i ne treba postavljati predmete ispunjene tečnošću, na primjer vaze, na uređaj.
• Ne koristiti uređaj blizu prašnjave sredine.
• Prebrišite prašinu sa uređaja brisanjem ekrana i kućišta mekom, čistom krpom ili specijalnom tečnošću za čišćenje.
• Ne koristiti preveliku silu prilikom čišćenja ekrana.
• Ne koristiti vodu i druga kemijska sredstva za čišćenje prilikom čišćenje ekrana jer može doći do oštećenja površine TV ekrana.
Upozorenje: Ova radnja može zahtijevati dvoje ljudi.
Da biste se pobrinuli za sigurnu instalaciju, poštujte sljedeće sigurnosne savjete:
• Provjerite da zid može da izdrži težinu uređaja i kompleta zidnog TV nosača.
• Pratite uputstva za postavljanje koja su došla uz zidni nosač.
• Televizor mora biti postavljen na vertikalan zid.
• Koristite samo vijke pogodne za materijal od kog je zid napravljen.
• Provjerite da li su kablovi televizora namješteni tako da ne postoji opasnost od saplitanja.
• Sva ostala sigurnosna uputstva za naš televizor važe i u ovom slučaju.
UVOD
Mjere opreza
Proizvod
Napajanje i uključivanje u struju
Kabal za napajanje i kabal za signal
Korisnička sredina
Čišćenje
Postavljanje televizora na zid

16
BIH/
MNE
Dugmići na TV-u
Priključci
Uzmite sljedeći model kao primjer:
1. Ova oprema je Klase II ili dvostruko izoliran električni uređaj. Dizajniran je tako da ne zahtjeva uzemljenje.
2. Kada se koristi mrežni utikač ili priključak za isključivanje uređaja, sustav za isključivanje uređaj je uvek spreman za
koričenje.
3. Uređaj ne treba izlagati kapanju i prskanju, i ne treba postavljati predmete ispunjene tečnošću, na primjer vaze, na uređaj.
4. Upozorenje: baterija (komplet baterija ili instalirane baterije) ne treba izlagati prevelikoj toploti, kao što je sunčeva
svjetlost, vatra i slično.
5. Izvori otvorenog plamena, kao što su zapaljene svijeće, ne smiju se stavljati na uređaj.
6. Obratite pažnju na uticaj odlaganja baterija na životnu sredinu.
Napomena: Ilustracije u ovom izdanju služe isključivo za referencu.
Napomena: Lokacija i imena priključaka na televizoru mogu varirati u ovisnosti od modela i neki priključci ne moraju biti
dostupni za neke modele.
ETHERNET
ETERNET
Ovaj priključak se može koristiti za povezivanje na vanjski modem ili na opremu za pristupanje
mreži.
SPDIF(coax.) SPDIF(koaks.) priključak (izlaz)
Ovaj priključak se može koristiti za priključivanje kompatibilnog digitalnog audio prijemnika.
HDMI 1
ili HDMI 2
HDMI 1/HDMI 2 priključak (ulaz)
HDMI (High-Definition Multimedia Interface – Multimedijski interfejs visoke definicije)
omogućuje povezivanje uređaja, kao što je Blu-ray plejer, sa HDMI izlaz za najbolja kvaliteta
slike. Također omogućuje nekompresovanu digitalnu konekciju koja nosi i video i audio
podatke putem integrisanog mini-plug kabla.
USB 2.0
USB 2.0 priključak (ulaz)
Ovaj priključak se može koristiti za povezivanje na USB uređaj.
(Napomena: Nemojte uključivati uređaj kada se ubacuje USB drajv 3.0 jer može doći do
problema kompatibilnosti.)
SAT IN SAT IN priključak (ulaz)
Ovaj priključak se može koristiti za povezivanje na satelitski prijemnik.
ANT/CABLE IN ANT/CABLE IN priključak (ulaz)
Ovaj priključak se može koristiti za povezivanje na vanjsku antenu ili kablovsku mrežu.
MINI AV IN
MINI AV IN priključak (ulaz)
MINI AV IN priključak se može koristiti za povezivanje na širok opseg opreme, uključujući
video-rekordere, video-kamere, dekodere, satelitske prijemnike, DVD plejeri, igračke konzole.
VIDEO IN priključak omogućuje kompozitnu video konekciju.
dugme
1. Uključite TV.
2. Kada je TV uključen, pritisnite dugme kako bi se prikazao Meni dugmeta.
3. U Meniju, kratko pritisnite da biste odabrali, dugo pritisnite da biste potvrdili izbor.

17
BIH/
MNE
Funkcije daljinskog upravljača
Većina funkcija televizora je dostupna u meniju koji se pojavljuje na ekranu. Daljinski uređaj koji ide uz televizor se može
koristiti za navigaciju kroz menije i za konfiguriranje svih općih podešavanja.
Napomena: Lokacija i imena dugmića na daljinskom upravljaču može varirati u ovisnosti od modela televizora, pri čemu neki
modeli nemaju sve dugmiće.
CI+
CI+ priključak
Ovaj priključak se može koristiti za ubacivanje CI kartice radi prihvatanja skremblovanih
programa.
HEADPHONE
Priključak za SLUŠALICE (izlaz)
Omogućuje povezivanje slušalice radi slušanja zvuka koji potiče sa TV uređaja.
Napomena: Previsok zvuk na slušalicama može dovesti do oštećenja sluha.
1. q(dugme za UKLJUČIVANJE) TV se uključuje/u pripravnosti je.
2. (dugme za ZVUK) Uključuje ili isključuje zvuk.
3. 0 ~ 9 0- 9 (numerički dugmići) Unos brojeva kanala.
4. SUBTITLE SUBTITLE Pritisnite za prikazivanje menija za titlove.
5. Odlazak na YouTube početnu stranicu.
6. VOL +/VOL- (VOLUMEN GORE/DOLJE) Povećava ili smanjuje volumen.
7. TV Kod ostalih izvora, vraća nazad na TV.
8. SOURCE Ulazi u meni SOURCE (IZVOR).
9. USB Ide na multimedijske fajlove na USB-u.
10. CH ./ ,(KANAL GORE/DOLJE) Skenira gore/dolje kroz trenutnu listu
kanala.
11. Prikazuje meni sa opcijama.
12. Prikazuje informacije o programu, ako su dostupne.
13. ECO Biranje željenog režima za štednju struje.
14. (dugme za PODEŠAVANJE) Pokreće glavni meni.
15. (dugme za POČ. STRANICU) Ide na početnu stranicu smart TV-a.
16. (dugmići za gore, dolje, lijevo i desno) Označava različite
stavke u sustavskom meniju i podešava kontrole menija.
17. OK U sustavskom meniju, potvrđuje izbor ili mijenja podešavanja.
18. (NAZAD) U sustavskom meniju, vraća se na prethodni meni ili
interfejs.
19. EXIT Izlaz iz sustavskog menija.
20. Odlazak na Netflix početnu stranicu.
21. OBOJENI
DUGMIĆI
(crveno/zeleno/žuto/plavo) Odabir zadataka.
22. SLEEP Pritisnite da biste podesili isključivanje TV-a nakon određenog
vremena. Za isključivanje SLEEP tajmera, držite dugme dok se ne
pojavi OFF.
23. ZOOM-/ZOOM+ Pritisnite za biranje željenog formata ekrana.
Napomena: Ova funkcija nije dostupna u USB režimu.
24. CH LIST Prikaz liste kanala.
25. TEXT Uključuje/isključuje teletekst. Pritisnite za uključivanje /
isključivanje funkcije teleteksta.
26. GUIDE (De)aktiviranje elektronskog programskog vodiča.
Napomena: Ova funkcije je dostupna samo u DTV režimu.

18
BIH/
MNE
27. PRE-CH Vraćanje na prethodni kanal.
28. FAV Prikazuje omiljenu listu kanala.
29. 5Traži unazad.
30. 6Traži unapred.
31. (Prethodno) Ide na prethodno poglavlje.
32. 3(Stop) Zaustavlja pregledanje.
33. u2(Pokretanje/pauza) Pokreće, zaustavlja i nastavlja pregledanje.
34. (Slijedeće) Ide na slijedeće poglavlje.
35. 4PVR funkcija
36. (JEZIK ) Prikazuje audio jezičke liste.
Uključivanje
OPĆE OPERACIJE
Pratite instrukcije sa ove strane o uključivanju TV uređaja i daljinskog upravljača prije prelaska na slijedeće strane sa opisima
procedure za podešavanje kanala.
1. Fiksiranjem dvostruke potporne osnove uređaja pomoću vijaka završava se instalacija uređaja.
*Da biste omogućili bolje vizuelno iskustvo, pre upotrebe molimo uklonite sa ekrana i prednjeg panela sve deklaracije,
ukoliko ih ima.
*Slike i ilustracije u ovom uputstvu za upotrebu služe isključivo za referencu i mogu se razlikovati od stvarnog izgleda
proizvoda. Dizajn i specifikacije proizvoda se mogu menjati bez prethodnog obaveštenja.
2. Ubacite dve AAA baterije u daljinski upravljač. Mere opreza pri korištenju baterija:
-Koristite samo baterije ovde navedenog tipa.
-Proverite da li se polaritet pravilno postavljen.
-Ne mešajte nove i korištene baterije.
-Ne koristite punjive baterije.
-Ne izlažite baterije visokim temperaturama, kao što su sunčeva svjetlost, vatra i slično, nemojte ih bacati u vatru, puniti ili
otvarati jer može doći do curenja baterija ili eksplozije.
-Uklonite baterije iz daljinskog upravljača ukoliko ga nećete koristiti tokom dužeg vremenskog perioda.
3. Uključite kabal za napajanje PRVO u televizor, a ZATIM u utičnicu. (Napomena: Ukoliko je kabal za napajanje povezan sa
televizorom, molimo povežite samo kabal sa utičnicom).
Vaš TV uređaj treba da bude priključen isključivo na naizmeničnu struju. Ne smije biti povezan na jednosmernu struju.
Ukoliko je utikač odvojen od kabla, ni u kom slučaju ga nemojte ubacivati u utičnicu zbog postojanja rizika od strujnog
udara.
Napomena: Slike su isključivo simbolični prikazi. Lokacija priključka za napajanje sa zadnje strane televizora može da
varira u ovisnosti od modela.
4. Povežite vanjsku antenu na ANT/CABLE IN ili SAT IN priključak sa zadnje strane TV uređaja.
Priključak za antenu (75 OHM - VHF / UHF / kablovsku) se može koristiti za povezivanje sa vanjskom antenom i drugom
postavljenom opremom.
5. Kada se uključi, televizor će se uključiti direktno ili biti u pripravnosti. Napomena: Za neke modele, uključite televizor
pritiskom na dugme za uključivanje/isključivanje.
Ukoliko indikator napajanja zasvijetli, TV je u režimu pripravnosti. Pritisnite dugme na daljinskom upravljaču ili na samom
uređaju da biste ga uključili.

19
BIH/
MNE
Isključivanje
Povezivanje na mrežu
Povezivanje na LAN mrežu
Povezivanje na bežičnu mrežu
Da biste TV ubacili u režim pripravnosti, pritisnite dugme na daljinskom upravljaču ili na samom uređaj; televizor ostaje
uključen, ali sa malom potrošnjom struje.
Da biste isključili TV uređaj, izvadite utikač i utičnice.
Napomena: Za neke Da biste isključili TV uređaj, izvadite utikač i utičnice.
Da biste pristupili internetu, morate se pretplatiti na širokopojasnu internet uslugu velike brzine kod Vašeg internet
provajdera (ISP).
Vaš TV se može povezati na kućnu prežu na dva načina:
• Putem kabla, korištenjem RJ45 (LAN) konektora na zadnjem panelu.
• Bežično, korištenjem bežičnog interneta i kućnog bežičnog interneta.
Napomena: Dolje navedene instrukcije su uobičajeni načini povezivanja televizora na LAN ili bežičnu mrežu. Metode
povezivanja se mogu razlikovati u ovisnosti od internet konfiguracije. Ukoliko imate pitanja o Vašoj kućnoj mreži, molimo
obratite se ISP-u.
Da biste se povezali na LAN mrežu:
1. Morate imati:
• Eternet kabal dovoljne dužine da dosegne do
televizora
• Ruter ili modem sa dostupnim Eternet portom
• Internet vezu velike brzine
• Eternet (LAN) priključak sa zadnje strane televizora
2. Povežite Eternet kabal na ruter i na Eternet priključak
sa zadnje strane televizora.
3. Koristite Network (mrežni) meni za konfigurisanje
televizora.
Da biste se povezali na bezićnu mrežu:
1. Morate imati:
• Ruter koji emituje bežični signal velike brzine
• Internet vezu velike brzine
2. Koristite Network (mrežni) meni za konfiguriranje
televizora.

20
BIH/
MNE
Korištenje početne stranice
Funkcije menija
OPERACIJE U MENIJU
Napomena: Ovo uputstvo za upotrebu je za svakodnevnu upotrebu. Slike i ilustracije služe za referencu i mogu se razlikovati
od izgleda stvarnog uređaja. Određene opcije nisu dostupne kod pojedinih modela.
Možete birati sve funkcije sa početne stranice.
1. Birajte za prikazivanje početne stranice.
2. Pritisnite ///uza biranje ikonica sa liste na ekranu.
3. Pritisnite OK da biste ušli u svaku od opcija.
4. Za izlaz iz menija, pritisnite EXIT.
UPOZORENJE:
• Konfigurirajte mrežna podešavanja prije korištenja smart TV-a.
• Može doći do sporog reagiranja i/ili prekida, u ovisnosti od uslova internet mreže.
• Ukoliko iskusite problem za korištenjem aplikacija, molimo obratite se internet provajderu.
• U skladu sa okolnostima internet provajdera, ažuriranje aplikacije ili sama aplikacija može biti ukinuta.
• U ovisnosti od zakonske regulative države, neke aplikacije mogu biti ograničene ili nepodržane.
Početna strana - Izvor
Izvor: Odaberite ulazni izvor sa naprave povezanih na televizor putem različitih priključaka.
Početna strana - Smart
Prikazuje se smart menu.
Početna strana – Aplikacije
Mnoštvo korisnih i zabavnih aplikacija. Nakon ulaska u Apps Store, vidjet ćete preporuke.
Pritisnite /uza mijenjanje aplikacija, pritisnite OK za ulazak.
Ovaj odjeljak prikazuje meni sustavskih podešavanja za Vaš televizor. Svaki meni je detaljno opisan da biste iskoristili
najbolje od svog uređaja. Molimo upamtite da neke funkcije mogu biti nedostupne u ovisnosti od ulaznog izvora. Da biste
pristupili sustavskom meniju:
1. Birajte na daljinskom upravljaču radi prikaza glavnog menija.
2. Pritisnite /da biste izabrali Sliku, Zvuk, Kanal, Smart TV, Mrežu, Sustav ili Podršku, zatim pritisnite OK ili uda biste ušli
u podmeni.
3. U podmeniju, pritisnite /da biste izabrali opcije, pritisnite OK iliuda biste podesili funkcije ili promijenili vrijednosti,
pritisnite OK da biste otvorili odgovarajući podmeni ili aktivirali podešavanje.
4. Za vraćanje na pret. meni, pritisnite . Da zatvorite meni, pritisnite EXIT.
This manual suits for next models
1
Table of contents
Other Tesla Smart TV manuals

Tesla
Tesla 32T320BHS User manual

Tesla
Tesla TSL-TV-T2KYD55 Operation and maintenance manual

Tesla
Tesla 32T300BHS User manual

Tesla
Tesla 32T310BHS User manual

Tesla
Tesla 9 series User manual

Tesla
Tesla 32T303BHS User manual

Tesla
Tesla 32S605BHS User manual

Tesla
Tesla TV T319 SMART User manual

Tesla
Tesla 32T313BHS User manual

Tesla
Tesla T319 User manual
