TEUCER TSS-WS User manual

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
TSS-WS
The TSS-WS smart socket enables you to easily control your appliance with your smartphone, tablet or
virtual assistants Google Home and Amazon Alexa.
Product Description
• No hub, bridge or gateway required
• Mobile app and voice control
• Compatible with Google Home and Amazon
Alexa
• Timer function
• Scene settings
• Backlight LED indicator
Features
Technical Specification
Controller TSS-WS
Panel material Tempered glass
Voltage Rating AC 100-250V 50-60Hz
Current Rating 10A
Load Rating 2200W
Standby power 0.25W
Wi-Fi standard 802.11b/g/n (2.4 GHz)
Wi-Fi Security WEP/WPA/WPA2
(AES-TKIP-Personal)
Wi-Fi performance
Transmission power +20dBm,11Mbps(CCK)
Wi-Fi performance Re-
ceiver sensitivity -89dBm,11Mbps(CCK)W
Size 85x85x32mm
Weight 0.3kg
Operating temperature -25 ºC to + 60 ºC
Relative humidity < 95%

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
FRONT GLASS PANEL
BACK
Power ON/OFF /
Configuration button
Socket
Power consumption indicator
WIFI indicator
85mm
NLE
49mm
62mm
58mm
32mm
49mm 49mm
85mm
9mm
85mm
NLE
Neutral terminal
Live terminal
Earth terminal
Controller layout
Installation diagram
N
N
L
E
E L

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Downloading the mobile app and creating the account
1) Search and install “Lanbon Smart Living” app from the Google Play store or iOS AppStore.
2) Select Area “Europe”. 3) Create account by
pressing the profile icon
in the top left corner.
4) Press More button
at the bottom of the
app.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
5) Press Sign up. 6) Choose username.
This can be your email.
7) Enter your email
address.
8) Enter your verification
code you have received
on your email.
9) Choose the password. 10) Login with your
email and password.
11) Check you have
logged in by pressing
the top left profile
button.
You should see your
username next to the
icon.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Connecting the smart WIFI socket to your Home WIFI network
1) Make sure you have connected your phone to your home WIFI network. This product supports only
2.4Ghz 802.11b/g/n mode.
2) Press and hold configuration button for more than 5 seconds until you hear chime and see WIFI
indicatior starts flashing rapidly.
Power ON/OFF /
Configuration button
WIFI indicator
3) Press the +in the
top right corner to add
switch.
4) Select L6 System. 5) Enter your home
network WIFI password.
6) Wait for process to
finish. You should see
socket icon pop up.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
7) Once the process has finished you will see the smart WIFI switch on the main app screen. Default name
is Socket.
Controlling the smart WIFI socket
Press the socket icon to
switch ON/OFF.
By pressing the Gear
icon in the top right
corner, you will open
the smart WIFI socket
settings.
Press the socket icon
to switch the appliance
ON/OFF. By pressing
the white background
around the socket icon
you will open the socket
control screen.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Smart WIFI socket settings
You can set up to 4
different recurring
timers.
Timer Settings
Night mode turns OFF
the sound. It can be
scheduled.
Night Mode
By turning ON
notification, you can get
the notificaton every
time socket is turned
ON/OFF.
Notification
You can rename the
socket. Voice control
will use this name to
control.
Change name
You can reset the
smart WIFI socket to
the factory defaults or
delete device from the
app.
Factory reset or Delete

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Connecting the smart WIFI socket to Google Home.
1) Press the +in the top
left corner to add the
group.
2) Press Set up device. 3) Choose “Have
something already set
up?”.
4) Choose your home.
5) Search and select
Lanbon Smart Living.
6) Login with your
lanbon credentials.
7) You will see the
message “Lanbon
Smart Living is now
linked
8) Now you can assign
the smart WIFI socket to
a room and start using
with Google Home.
You can say “Hey
Google, turn on the
bedside lamp” if you
have assigned the
switch to the bedroom
bedside light socket.
For more information
how to use voice
commands please refer
to the Google Home
user manual.
Note! Make sure you have paired smart WIFI socket with the mobile app.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Connecting the smart WIFI socket to Amazon Alexa.
1) Open the Alexa app
on your smartphone
and go to Skills & Games.
2) In the top right corner
Search for the “Lanbon
Smart Living” skill and
enable.
3) Login with your
Lanbon credentials.
4) You have now linked
Amazon Alexa with
Lanbon.
You can say “Alexa, turn on bedside lamp” if you have assigned the name to “Bedside lamp”.
For more information how to use voice commands please refer to the Amazon Alexa user manual.
Note! Make sure you have paired smart WIFI socket with the mobile app.

Smart WIFI socket
www.teucerled.co.uk
V001-11-2019
Problem Cause Corrective
Unable to switch
ON/OFF (No indicator
light)
• No power.
• Wrong connection or unsecure
connection.
• Check the power.
• Check the connection.
Cannot connect
switches to WIFI • Trying to connect to 5Ghz (802.11ac) • Connect to 2.4GHz home network (802.11b/g/n)
• Products must be installed and serviced by qualified electrician.
• Never install product whilst connected to power and double check connections before switching on to
avoid short circuits.
• Ensure all terminal screws are fully tightened and product is securely fixed to its mounting box prior to
turning on the mains supply.
Safety
Warranty
Should this product fail during the 3 year warranty period it will be
replacedfreeofcharge,subjecttothecorrectinstallationoftheoriginal
product in accordance with applicable and appropriate electrical
codes and instructions provided by Teucer, as well as subsequent
return of the faulty unit. Teucer does not accept responsibility for any
installation costs associated with the replacement of this product
and Teucer reserves the right to alter specifications without prior
notice. For further information, please see our Terms and Conditions.
www.teucerled.co.uk/terms-and-conditions/
