TEX VISIONS EVENT TENT BASIC User manual

EVENT TENT BASIC
ASSEMBLY
ASSEMBLY HARDWARE
A. B.
C. D.
E.
DISCLAIMER: Tents should always be staked down with Premium Tent Stake Kit and weighed down. Tents should not be used in inclement
weather, including thunderstorms, heavy rains, lightning, and high winds. No grill or any type of open flame is to be used under or near the
tent. User must read and observe assembly instructions. If this is not done correctly, it may result in damage to the unit, injury, or death, and
all warranties will be void. All warranties will be void if hardware is used with any print not produced by us. Properly care for prints to keep
them in great condition. Prints should never be dragged along the ground or stored without being properly folded and free from moisture.
Make sure print is completely dried from any weather, and fold and store in a clean, dry place. We don’t recommend storing print on frame.
A. Frame
B. Carrying Case*
C. Middle Support Pole*
D. Support Poles*
E. Clamps*
*Optional
Assembly Instructions R1.042716
NOTE: It is recommended to use 2+ people for tent assembly.
1. Place the frame on the location chosen for assembly.
Make sure the feet of the frame are on the ground.
2-3. Expand the frame outward, but not fully, and place
the tent print over the frame. Make sure the print is
facing the correct direction and that the corners of the print
line up with the correct corners of the frame.
4. Attach the loop adhesive, located on the inside of the print,
to the hook adhesive around the top of the main posts.
5-6. Completely expand the frame outward. The locking
clips will snap into place to indicate full expansion of
the frame.
7. Pull up the legs of the frame to the desired height,
making sure the locking clips snap into place. Standing
and using your foot to hold down the tent foot makes this
step easier.
8. Extend the canopy to its full height by using the rooftop
crank adjustment. This will also tighten the print for a
wrinkle-free display.
NOTE: Remove print prior to collapsing and storing the
frame. Do not store the frame with the print
attached. Treat printed canopy with care to
avoid scratching.
1.
3.
5.
7. 8.
6.
4.
2.

DISCLAIMER: Tents should always be staked down with Premium Tent Stake Kit and weighed down. Tents should not be used in inclement
weather, including thunderstorms, heavy rains, lightning, and high winds. No grill or any type of open flame is to be used under or near the
tent. User must read and observe assembly instructions. If this is not done correctly, it may result in damage to the unit, injury, or death, and
all warranties will be void. All warranties will be void if hardware is used with any print not produced by us. Properly care for prints to keep
them in great condition. Prints should never be dragged along the ground or stored without being properly folded and free from moisture.
Make sure print is completely dried from any weather, and fold and store in a clean, dry place. We don’t recommend storing print on frame.
ASSEMBLY OF WALL(S) - OPTIONAL
EVENT TENT BASIC Assembly Instructions R1.042716
ASSEMBLY OF HALF WALL(S) - OPTIONAL
1. When adding the tent wall(s), the legs of the frame
must be at their maximum extension height.
2. Attach the wall’s loop adhesive to the hook adhesive on
the tent valance.
3-4. Secure the sides of the wall by wrapping the
hook-and-loop adhesive tabs around the tent legs.
5-6. If the tent wall features zippers, walls can be connected
by closing the zipper from bottom to the top.
NOTE: If attaching two or more half walls, you must
stagger the height of the adjoining half walls
or use a 90° corner clamp.
1. Slide one support pole with the click button into the
center support pole. Once the button snaps through
the first hole, repeat this step with the second pole.
Slide the half wall support bar through the print’s pole
sleeve. The support bar should go through the entire pole
sleeve, with both ends of the pole sticking out from either
end of the half wall.
2-3. Attach the half wall clamps. Unscrew the knobs
completely from the clamps and slip the clamps around
the tent legs.
4. Place the appropriate end of the half wall support bar
through the opening of the clamp. Place the tightening
knob into the open holes and hand tighten the knob.
Repeat this step with the second clamp and support pole.
5-6. Secure the hook-and-loop adhesive tabs of the half wall
around the tent legs.
1.
3. 4.
5. 6.
2.
1.
3. 4.
5. 6.
2.

EVENT TENT PLUS Assembly Instructions R1.060215
NOTE: It is recommended to use at least two people for the
tent assembly.
1. Place the frame (A) into the location chosen for assembly.
Make sure the feet of the frame (A) are on the ground.
2. Expand the frame (A) outward, but not fully, and place
the print over the frame (A). Make sure the print is facing the
correct direction and the corners of the print line up with the
correct corners of the frame (A).
3. Wrap the hook-and-loop adhesive tabs, located on the inside
of the print, around all the main posts on the frame (A).
ASSEMBLY
ASSEMBLY HARDWARE
4. Completely expand the frame (A) outward. The locking
clips will snap into place to indicate full expansion of the
frame (A).
5. Pull up the legs of the tent to the desired height, making
sure the locking clips snap into place. Standing on
base during this step makes it easier.
6. Extend the canopy to full height by using the rooftop crank
adjustment. It will also tighten the print for a wrinkle-free
display.
NOTE: Remove print prior to collapsing and storing frame.
Do not store with print on. Treat printed canopy with
care to avoid scratching.
A. B.
C. D.
E.
DISCLAIMER: Tents should always be staked down with Premium Tent Stake Kit and weighed down. Tents should not be used in inclement
weather, including thunderstorms, heavy rains, lightning, and high winds. No grill or any type of open flame is to be used under or near the
tent. User must read and observe assembly instructions. If this is not done correctly, it may result in damage to the unit, injury, or death, and
all warranties will be void. All warranties will be void if hardware is used with any print not produced by us. Properly care for prints to keep
them in great condition. Prints should never be dragged along the ground or stored without being properly folded and free from moisture.
Make sure print is completely dried from any weather, and fold and store in a clean, dry place. We don’t recommend storing print on frame.
A. Frame
B. Carrying Case*
C. Middle Support Pole*
D. Support Poles*
E. Clamps*
*Optional

DISCLAIMER: Tents should always be staked down with Premium Tent Stake Kit and weighed down. Tents should not be used in inclement
weather, including thunderstorms, heavy rains, lightning, and high winds. No grill or any type of open flame is to be used under or near the
tent. User must read and observe assembly instructions. If this is not done correctly, it may result in damage to the unit, injury, or death, and
all warranties will be void. All warranties will be void if hardware is used with any print not produced by us. Properly care for prints to keep
them in great condition. Prints should never be dragged along the ground or stored without being properly folded and free from moisture.
Make sure print is completely dried from any weather, and fold and store in a clean, dry place. We don’t recommend storing print on frame.
1. When adding the wall(s) to the tent, the legs on the
frame (A) must be at their maximum extension height.
2. Attach the wall(s) to the valance on the tent roof using
the hook-and-loop adhesive.
3. Secure the sides of the wall(s) by wrapping the
hook-and-loop adhesive tabs around the tent legs.
4. If the tent wall features zippers, walls can be connected by
closing the zipper from bottom to the top.
ASSEMBLY OF WALL(S) - OPTIONAL
EVENT TENT PLUS Assembly Instructions R1.060215
ASSEMBLY OF HALF WALL(S) - OPTIONAL
NOTE: If attaching two or more half walls, you MUST
stagger the height of ADJOINING half walls.
1. Slide one support pole (D) with the click button into the
pole with just holes (C). Once the buttons snap through
the first hole repeat this step with the second
support pole (D).
2. Slide the half wall support bar through the print’s pole
sleeve. The support bar should go through the entire pole
sleeve, with both ends of the pole sticking out from either
end of the half wall.
3. Attach the half wall clamps. Unscrew the knobs completely
from the clamps (E) and slip the clamps (E) around the
tent legs.
4. Place the appropriate end of the half wall support bar
through the opening of the clamp. Place the tightening
knob into the open holes and hand tighten the knob.
Repeat this step with the second clamp and support pole.
5. Secure the hook-and-loop adhesive tabs of the half walls
around the tent legs.
