User’s Guide
DLP® Display DLPC7540 4K UHD EVM
ABSTRACT
This guide explains the hardware and software features of the DLP® Products DLP471TEEVM, DPL650TEEVM,
and DLPC7540EVM evaluation modules (EVMs). The EVM architecture and connectors will be described
along with a quick start guide on how to operate the DLP471TEEVM, DPL650TEEVM, and DLPC7540EVM
EVMs using the DLPDLC-GUI. Specific DLP chip details and operation can be found in related component
documentation.
Note
Power supply, optics, illumination source, and cables are not included. See Other Items Needed for
Operation.
Figure 1-1. DLP Products DLPC7540EVM and DLP471TEEVM Evaluation Modules
www.ti.com
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 1
Copyright © 2021 Texas Instruments Incorporated

Table of Contents
1 DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview.........................................................................................3
1.1 Welcome............................................................................................................................................................................ 3
1.2 What is in the DLP471TEEVM, DLP650TEEVM, and DLPC7540EVM Evaluation Modules?...........................................3
1.3 EVM Boards....................................................................................................................................................................... 5
1.4 Other Items Needed for Operation.....................................................................................................................................6
1.5 DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM EVM Flex Cable......................................................................... 6
2 Quick Start...............................................................................................................................................................................7
2.1 Downloading the Software................................................................................................................................................. 7
2.2 Connecting the DLP471TEEVM, or DLP650TEEVM, to the DLPC7540EVM....................................................................7
2.3 Powering-up the DLPC7540EVM and Preparing to Program the DLPC7540EVM............................................................8
2.4 Programming the DLPC7540EVM and Displaying a SPLASH Image............................................................................... 9
2.5 Troubleshooting................................................................................................................................................................12
3 Connections.......................................................................................................................................................................... 13
3.1 DLPC7540EVM Connections...........................................................................................................................................13
3.2 DLP471TEEVM and DLP650TEEVM Connections......................................................................................................... 15
4 Power Supply Requirements............................................................................................................................................... 16
4.1 External Power Supply Requirements............................................................................................................................. 16
5 Safety..................................................................................................................................................................................... 17
5.1 Caution Labels................................................................................................................................................................. 17
5.2 If You Need Assistance.................................................................................................................................................... 17
6 Related Documentation........................................................................................................................................................17
List of Figures
Figure 1-1. DLP Products DLPC7540EVM and DLP471TEEVM Evaluation Modules................................................................ 1
Figure 1-1. DLPC7540EVM Formatter Board..............................................................................................................................3
Figure 1-2. DLPC7540EVM Front-end Board..............................................................................................................................4
Figure 1-3. DLP471TEEVM......................................................................................................................................................... 4
Figure 1-4. EVM System Block Diagram..................................................................................................................................... 5
Figure 2-1. Formatter Board and DMD EVM Connected.............................................................................................................8
Figure 2-2. ON/OFF Switches......................................................................................................................................................9
Figure 2-3. Command Interface Settings...................................................................................................................................10
Figure 2-4. Loading the Flash Image......................................................................................................................................... 11
Figure 2-5. Splash Image Displayed on DMD............................................................................................................................11
Figure 3-1. DLPC7540EVM Formatter Board Connectors........................................................................................................ 13
Figure 3-2. DLPC7540EVM Front-end Board Connectors........................................................................................................ 14
Figure 3-3. DLP471TEEVM and DLP650TEEVM Test Points and Connectors.........................................................................15
List of Tables
Table 2-1. Flash Image Compatibility Summary.......................................................................................................................... 7
Table 2-2. Flex Cables Connection Assignment..........................................................................................................................7
Table 2-3. Reference Designators............................................................................................................................................... 8
Table 2-4. Troubleshooting the Problem and the Possible Solutions.........................................................................................12
Trademarks
DLP® is a registered trademark of Texas Instruments.
All trademarks are the property of their respective owners.
Table of Contents www.ti.com
2DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

1 DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview
1.1 Welcome
The DLP Products DLPC7540EVM, DLP471TEEVM and DPL650TEEVM evaluation modules (EVMs) offer a
reference design to enable faster development cycles for users of the DLPC7540 chips and allow evaluation of
TI’s DLP471TE and DLP650TE UHD chipsets. These consist of one controller EVM (DLPC7540EVM) and two
DMD EVMs (DLP471TEEVM and DLP650TEEVM).
These evaluation kits bring together a set of components providing a great starting point to evaluate a UHD DLP
system for:
• Laser TV
• Enterprise Projectors
• Digital Signage
• Gaming Machines
• Smart Projectors
• Stage Lighting Systems
1.2 What is in the DLP471TEEVM, DLP650TEEVM, and DLPC7540EVM Evaluation Modules?
The DLP471TEEVM, DLP650TEEVM and DLPC7540EVM are designed to be used in pairs. The DMD EVMs
cannot be operated without the Controller EVM, DLPC7540EVM.
The DLP471TEEVM, which includes the DLP471TE display chip, and the DLP650TEEVM, which includes the
DLP650TE display chip, include the two flex cables required to connect to the DLPC7540EVM. DLPC7540EVM
includes all circuitry required to drive the DLP471TE and DLP650TE display chips.
The DLPC7540EVM which consists of a formatter board (Figure 1-1) and an HDMI input processing front-end
board (Figure 1-2), includes a DLPC7540 controller, three DLPA100s which serve as the power management
and motor drivers, and other system circuitry such as the Vx1 interface front-end and system fan control.
The DLPC7540EVM can be programmed with either the DLP471TE or DLP650TE firmware which is available on
the DLPC7540 product page. This firmware allows the DLPC7540EVM to drive either display chip. Figure 1-1,
Figure 1-2, and Figure 1-3 show the top side of all boards making up the EVMs.
Note
Figure 1-1, Figure 1-2, and Figure 1-3 do not show the necessary flex cables needed to pair to
DLPC7540EVM.
Figure 1-1. DLPC7540EVM Formatter Board
www.ti.com DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 3
Copyright © 2021 Texas Instruments Incorporated

Figure 1-2. DLPC7540EVM Front-end Board
Figure 1-3. DLP471TEEVM
DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview www.ti.com
4DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

1.3 EVM Boards
The DLP471TEEVM, DLP650TEEVM, and DLPC7540EVM EVMs contain the electronics required to drive either
DLP471TE or DLP650TE DMD. The DLPC7540EVM offers several interface options for USB, I2C, and trigger
inputs and outputs.
The system block diagram Figure 1-4 details the functionality and control when using the DLP471TEEVM and
DLPC7540EVM.
DLPC7540
Controller
Included with EVM
Not included with EVM
(3)VBIAS
VOFFSET
VRESET
2x FFC included with DMD EVM
2-Port HSSI
LS Interface
ITE IT6807
Front End Chipset
Vx1:
3840 × 2160 @ 60 Hz
Actuator
Driver
4-Position
Actuator
Parallel Flash Memory
(24) (18)ADDR DATA
DLP471TE
or
DLP650TE
4K UHD DMD
EEPROM
TPS65145
Voltage
Regulator
PWM
Illumination
Driver
TPS56121
Voltage
Regulator
(3) RGB_PWM
DLPA100
PMIC
LMR33630
Voltage
Regulator
LMR33630
Voltage
Regulator
DLP® DMD EVM
12 V
Power Adapter
DLP®Controller EVM
12 V
PROJ_ON
I2C
I2C_BUSY
Vx1
SPI (4)
3D L/R
1.21 V
1.8 V
3.3 V
1.15 V
1.8 V
(3) RGB_EN 3.3 V
I2C
Figure 1-4. EVM System Block Diagram
The major components of the DLPC7540EVM are:
• One DLPC7540 controller
• Three DLPA100 power management and motor driver chips
• One Vx1 front-end capable of processing inputs up to 4K at 60Hz at 600MHz pixel clock
The major components of the DLP471TEEVM are:
• DLP471TE 0.47-inch 4K UHD DMD
• Two flex cables designed to connect the DLP471TEEVM to the DLPC7540EVM
• TPS65145 used to generate the DMD's offset, reset and bias voltages
The major components of the DLP650TEEVM are:
• DLP650TE 0.65-inch 4K UHD DMD
• Two flex cables designed to connect the DLP650TEEVM to the DLPC7540EVM
• TPS65145 used to generate the DMD's offset, reset and bias voltages
www.ti.com DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 5
Copyright © 2021 Texas Instruments Incorporated

1.4 Other Items Needed for Operation
The DLP471TEEVM, DLP650TEEVM, and the DLPC7540EVM are evaluation modules (EVM) that are capable
of displaying images on to the DMD. However, these EVMs do not ship with optics, illumination source, cables,
power supplies, or additional hardware components. These are system parameters that are left for the user to
design, the EVMs are meant to accelerate initial system design.
• Power supply - Required for EVM operation (See Section 4.1)
• Micro-USB cable: A to Micro B USB cable - Required for GUI interface
• Optics
• Illumination module and source
• XPR actuator
The firmware provided on ti.com is for the sole purpose of operating the electronic components that make up the
DLP471TEEVM, DLP650TEEVM, and the DLPC7540EVM evaluation modules. Any additions made to the EVMs
such as illumination, optics, actuator, and so on will require contacting Texas Instruments for additional support
in including these elements specific to customer application.
1.5 DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM EVM Flex Cable
Electrical malfunctions can occur by stressing the flex cable(s) connecting the DMD circuit board to the
DLPC7540EVM formatter board. Stressing the flex cable can be caused by:
• Bending sharply the flex cable(s).
• Repeatedly bending the flex cable(s).
• Excessive insertion and extraction of flex cables to/from board connectors.
Note
Minimize any handling/movement on the flex cables during operation
DLPC7540EVM, DLP471TEEVM, and DLP650TEEVM Overview www.ti.com
6DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

2 Quick Start
This chapter offers a quick start guide on how to connect the DLP471TEEVM or DLP650TEEVM to the
DLPC7540EVM, how to power up the DLPC7540EVM, and how to program the DLPC7540EVM to display a
SPLASH image on the DMD.
2.1 Downloading the Software
Before programming the DLPC7540EVM, ensure the DLPDLC-GUI and DMD firmware are both downloaded
on the PC. The DLPDLC-GUI will allow for operation of the EVM. The DMD firmware is required so the
DLPC7540EVM knows which DMD is being controlled. The DLP471TEEVM comes with a DLP471TE DMD
which is for 4K display applications. The EVM when installed with DLP471TE DMD can operate using
DLP471TE (4K) or DLP471NE (1080p) based firmware. Similarly, the DLP650TEEVM comes with a DLP650TE
DMD for 4K display applications and can operate with DLP650TE (4K) or DLP471NE (1080p) based firmware.
Any of the two types of DMD EVMs can also be retrofitted with their corresponding 1080p DMDs (DLP471NE/
DLP651NE) but will not have XPR operation enabled. See Table 2-1 for summary of firmware compatibility.
Table 2-1. Flash Image Compatibility Summary
DLP471TEEVM DLP650TEEVM
Flash image1DLP471TE DMD DLP471NE DMD DLP650TE DMD DLP651NE DMD
Flash_DLPC7540_DLP471TE_LED.img ✓ ✓2
Flash_DLPC7540_DLP471TE_LPCW.img ✓ ✓2
Flash_DLPC7540_DLP471NE_LED.img ✓2✓
Flash_DLPC7540_DLP471NE_LPCW.img ✓2✓
Flash_DLPC7540_DLP650TE_LED.img ✓ ✓2
Flash_DLPC7540_DLP650TE_LPCW.img ✓ ✓2
Flash_DLPC7540_DLP651NE_LED.img ✓2✓
Flash_DLPC7540_DLP651NE_LPCW.img ✓2✓
1. The DMD supporting firmware and DLPDLC-GUI can be found in the EVM tool folder and in the product
pages on TI.com. These are the product pages for the DLP471TE, DLP471NE, DLP650TE, DLP651NE, and
the DLPC7540.
2. XPR operation which is required for 4K resolution is disabled.
2.2 Connecting the DLP471TEEVM, or DLP650TEEVM, to the DLPC7540EVM
Before connecting the DLP471TEEVM/DLP650TEEVM to the DLPC7540EVM, locate the two flex cables that
are packaged with the DLP471TEEVM/DLP650TEEVM. Ensure the flex cables are not torn or damaged before
connecting the DMD EVMs or the DLPC7540EVM.
The flex cables are exactly the same, meaning there is not a right or left cable. The cables are interchangeable.
Connect the DLP471TEEVM or DLP650TEEVM to the DLPC7540EVM formatter board by connecting the two
flex cables matching the board connectors as listed in Table 2-2.
Table 2-2. Flex Cables Connection Assignment
DLPC7540EVM (Formatter Board) DLP471TEEVM/DLP650TEEVM
J7 J1
J10 J2
www.ti.com Quick Start
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 7
Copyright © 2021 Texas Instruments Incorporated

Figure 2-1. Formatter Board and DMD EVM Connected
2.3 Powering-up the DLPC7540EVM and Preparing to Program the DLPC7540EVM
There's only one jumper that is included with the DLPC7540EVM. This jumper is installed on J67 during normal
operation between formatter and front-end boards. Before powering up the EVM for programming, ensure the
included jumper is installed on J9 instead. The jumper locations are listed in Section 3.1.
Table 2-3. Reference Designators
Jumper Description (Bold Indicates Default Position)
J67 - Front End 5 V Uninstalled - 5 V not supplied to J3
Installed - Formatter board provides 5 V to Front-end board over J3 connection
J9 - Hold in Boot Loader Uninstalled - Normal Operation
Installed - Hold in Boot Loader
Jumper J9 is the Hold BL jumper. This jumper is used to put the DLPC7540EVM into boot loader mode, which
allows the DLPC7540 controller to be programmed. Connect this jumper to prepare the DLPC7540EVM to be
programmed.
To power up the DLPC7540EVM, a 12-V, 5-A power supply is needed. Ensure the power supply is functional and
the switch SW5 and SW1 on the formatter board are set to off before connecting the power supply to the EVM.
Connecting the power supply when the switch is in the off position may prevent damage to the DLPC7540EVM
from poor power connections. The image below shows SW5 and SW1 and their operating positions.
Quick Start www.ti.com
8DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

Figure 2-2. ON/OFF Switches
Once the power supply has been connected to the DLPC7540EVM, the switches SW5 and SW1 in that order
can be flipped to the on position. You can then plug in the USB cable to J2 of the board to prepare for
programming the board. Verify that D5, D6, D7 and D15 LEDs are on.
2.4 Programming the DLPC7540EVM and Displaying a SPLASH Image
Follow these steps in order to download and configure the DLPDLC-GUI for DLPC7540 operation:
1. Download the DLPDLC-GUI and the Firmware SW package that includes the Firmware binary (.img) files for
DLP471TE and DLP650TE.
2. Install and open the DLPDLC-GUI
3. Setting up Communication Preferences:
a. DLPDLC-GUI supports USB and I2C communication. To change these settings in GUI, please go to
Debug screen and select Connection tab.
b. For USB, please select the USB interface and click Connect Figure 2-3. Note: USB is the preferred
interface to download the firmware flash image to the EVM as it is much faster than I2C and won't
require any additional hardware.
www.ti.com Quick Start
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 9
Copyright © 2021 Texas Instruments Incorporated

Figure 2-3. Command Interface Settings
c. Verify that EVM Status shown at bottom left of GUI says Connected, Bootloader Mode indicating you are
ready to load image file into EVM.
4. Flash Loader Configuration:
a. Go to Firmware screen, select Update Firmware tab. Click on the folder icon to browse for the applicable
firmware depending on the actual DMD that is connected to DLPC7540EVM. Once firmware image file is
selected, click on Start Update Figure 2-4.
b. Wait for the programming progress to indicate that firmware update is complete.
c. Turn off the EVM by toggling the SW1 and SW5 switches in that order to off position. Remove the
jumper from J9 and install it back to J67.
d. Turn on the EVM by toggling the SW5 and SW1 switches in that order to on position. After about 3
seconds you should see D5, D6, and D7 LEDs steadily on and D15 LED flashing. The DLP Texas
Instruments logo should be visible on the DMD Figure 2-5.
Quick Start www.ti.com
10 DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

Figure 2-4. Loading the Flash Image
Note
If there is an issue with USB communication, turn off DLPC7540EVM and disconnect then
reconnect USB cable and power on board.
Figure 2-5. Splash Image Displayed on DMD
www.ti.com Quick Start
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 11
Copyright © 2021 Texas Instruments Incorporated

2.5 Troubleshooting
Table 2-4. Troubleshooting the Problem and the Possible Solutions
Problem Possible Solutions
EVM Status: Not Connected
1. USB cable not connected.
2. Command interface not set to USB. Go to Debug screen, Connection tab
and select USB as the Command Interface, click Connect.
3. If the user has gone from using Advanced mode back to the DLPDLC-GUI,
then user will need to click on EVM Status message on bottom left of
DLPDLC-GUI screen to reestablish connection with GUI.
Quick Start www.ti.com
12 DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

3 Connections
This chapter introduces all the connections and test points available on the DLPC7540EVM and
DLP471TEEVM/DLP650TEEVM.
3.1 DLPC7540EVM Connections
Figure 3-1 depicts the switches and connectors with their respective locations. Note that neither cables nor the
power supply are included with the module.
Figure 3-1. DLPC7540EVM Formatter Board Connectors
Formatter Board Connectors
1. J2 – Micro-USB
2. J3 – V-By-One Input
3. J4 – 12V Fan
4. J5 – 12V Fan
5. J6 – Test Points Header
6. J7 – DMD HSSI0 Flex Cable Connector
7. J8 – 12V Fan (Heatsink)
8. J9 – Hold Bootloader
9. J10 – DMD HSSI1 Flex Cable Connector
10. J12 – I2C1 Bus
11. J16 – I2C0 Bus
12. J17 – Actuator PWM Interface
www.ti.com Connections
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 13
Copyright © 2021 Texas Instruments Incorporated

13. J20 – JTAG Boundary Scan
14. J67 - 5V Enable for V-By-One Front-end Board
15. J102 - RS232
16. J120 - Actuator DAC Driver A/B
17. J121 - Actuator DAC Driver C/D
18. J122 - Actuator DAC Driver Enable
19. J529 - 12V Input
20. J536 - I2C2 Bus
21. SW1 – Projector On Switch
22. SW5 - Main Power Switch
Figure 3-2. DLPC7540EVM Front-end Board Connectors
Front-end Board Connectors
1. J1 - HDMI Input
2. J3 - V-By-One Input
Connections www.ti.com
14 DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

3.2 DLP471TEEVM and DLP650TEEVM Connections
Figure 3-3 depicts the switches and connectors with their respective locations.
Figure 3-3. DLP471TEEVM and DLP650TEEVM Test Points and Connectors
3.2.1 Test Points
1. TP1 - VRESET
2. TP10 - GND
3. TP18 - DMD_VDD (1.8V)
4. TP25 - 3.3V
5. TP27 - GND
6. TP32 - VBIAS
7. TP33 - VOFFSET
3.2.2 Connectors
1. J1 - DMD HSSI0 Flex Cable Connector
2. J2 - DMD HSSI1 Flex Cable Connector
www.ti.com Connections
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 15
Copyright © 2021 Texas Instruments Incorporated

4 Power Supply Requirements
4.1 External Power Supply Requirements
The DLPC7540EVM does not include a power supply. The external power supply requirements are:
• Nominal voltage: 12-V DC -5%/+10%
• Maximum Output Current: 7 A
• DC connector size:
– Inner diameter: 2.5 mm
– Outer diameter: 5.5 mm
– Shaft: 9.5-mm female, center positive
• Efficiency level: V
• A recommended power supply is Digi-Key part number 993-1009-ND, or equivalent
Note
External Power Supply Regulatory Compliance Certifications: Recommend selection and use of an
external power supply, which meets TI’s required minimum electrical ratings in addition to complying
with applicable regional product regulatory and safety certification requirements such as (by example)
UL, CSA, VDE, CCC, PSE, and so forth.
Power Supply Requirements www.ti.com
16 DLP® Display DLPC7540 4K UHD EVM DLPU109 – MAY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

5 Safety
5.1 Caution Labels
CAUTION
The kit contains ESD-sensitive components.
Handle with care to prevent permanent damage.
5.2 If You Need Assistance
Refer to the DLP E2E Community support forums.
6 Related Documentation
1. Texas Instruments, DLP471TE Digital Micromirror Device (DMD) data sheet.
2. Texas Instruments, DLP650TE Digital Micromirror Device (DMD) data sheet.
3. Texas Instruments, DLPC7540 DLP Display Controller data sheet.
4. Texas Instruments, DLPA100 Power Management and Motor Driver data sheet.
www.ti.com Safety
DLPU109 – MAY 2021
Submit Document Feedback
DLP® Display DLPC7540 4K UHD EVM 17
Copyright © 2021 Texas Instruments Incorporated

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, or other requirements. These resources are subject to change without notice. TI grants you
permission to use these resources only for development of an application that uses the TI products described in the resource. Other
reproduction and display of these resources is prohibited. No license is granted to any other TI intellectual property right or to any third party
intellectual property right. TI disclaims responsibility for, and you will fully indemnify TI and its representatives against, any claims, damages,
costs, losses, and liabilities arising out of your use of these resources.
TI’s products are provided subject to TI’s Terms of Sale (https:www.ti.com/legal/termsofsale.html) or other applicable terms available either
on ti.com or provided in conjunction with such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s
applicable warranties or warranty disclaimers for TI products.IMPORTANT NOTICE
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2021, Texas Instruments Incorporated
