Texas Instruments BOOSTXL-K350QVG-S1 User manual

User's Guide
SLAU601A–March 2015–Revised July 2015
BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™
Plug-in Module
The BOOSTXL-K350QVG-S1 Kentec QVGA Display BoosterPack™ is an easy-to-use plug-in module for
adding a touch-screen color display to your LaunchPad™ design. MCU LaunchPad developers can use
this BoosterPack to start developing applications using the 320×240-pixel SPI-controlled QVGA display
with resistive touch screen.
Figure 1. BOOSTXL-K350QVG-S1 BoosterPack
Contents
1 Getting Started............................................................................................................... 2
2 Hardware...................................................................................................................... 3
3 Software Examples.......................................................................................................... 5
4 Additional Resources........................................................................................................ 6
5 Schematics ................................................................................................................... 8
List of Figures
1 BOOSTXL-K350QVG-S1 BoosterPack................................................................................... 1
2 BOOSTXL-K350QVG-S1 Overview....................................................................................... 3
3 BoosterPack Pinout (View From Bottom of PCB) ....................................................................... 3
4 MSP430 Image Reformer................................................................................................... 6
5 BOOSTXL-K350QVG-S1 Software Examples in TI Resource Explorer.............................................. 7
6 Schematics ................................................................................................................... 8
BoosterPack, LaunchPad, Code Composer Studio, E2E are trademarks of Texas Instruments.
All other trademarks are the property of their respective owners.
1
SLAU601A–March 2015–Revised July 2015 BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Getting Started www.ti.com
1 Getting Started
1.1 Introduction
The BOOSTXL-K350QVG-S1 Kentec QVGA Display BoosterPack is an easy-to-use plug-in module for
adding a touch-screen color display to your LaunchPad kit design. MCU LaunchPad developers can use
this BoosterPack to start developing applications using the 320×240-pixel SPI-controlled TFT QVGA
display with resistive touch screen.
1.2 Key Features
• Kentec TFT LCD (part number: K350QVG-V2-F)
– 3.5-inch QVGA (320×240 resolution)
– SPI communication
– 4-wire resistive touch screen
– White LED backlight
• LED backlight driver circuit
• Complies with the BoosterPack standard for use with 20- and 40-pin LaunchPads
1.3 What's Included
1.3.1 Kit Contents
• One BOOSTXL-K350QVG-S1 BoosterPack Plug-in module
1.3.2 Software Examples
• MSP-EXP432P401R LaunchPad + BOOSTXL-K350QVG-S1 demos (see Section 3)
– Graphics Library Example
1.4 Next Steps: Looking Into the Provided Code
After the EVM features have been explored, the fun can begin. It's time to open an integrated
development environment (IDE) and start looking at the code examples. Section 3 describes the example
projects available to make it easy to understand the provided software.
2BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module SLAU601A–March 2015–Revised July 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Hardware
2 Hardware
Figure 2. BOOSTXL-K350QVG-S1 Overview
2.1 Hardware Features
2.1.1 BoosterPack Pinout
Figure 3. BoosterPack Pinout (View From Bottom of PCB)
3
SLAU601A–March 2015–Revised July 2015 BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Hardware www.ti.com
The Kentec QVGA Display BoosterPack adheres to the 40-pin LaunchPad and BoosterPack pinout
standard. A standard was created to aid compatibility between LaunchPad and BoosterPack tools across
the TI ecosystem.
The 40-pin standard is compatible with the 20-pin standard that is used by other LaunchPad kits like the
MSP-EXP430FR4133. However, this BoosterPack is intended for use with 40-pin LaunchPad kits. If
compatibility is needed with a 20-pin LaunchPad, some modifications must be made for access to certain
pins and to provide 5 V for the LCD backlight circuitry.
More information about compatibility can also be found at http://www.ti.com/launchpad.
2.1.2 Kentec QVGA Display (K350QVG-V2-F)
The Kentec TFT display has the following features:
• 3.5-inch diagonal screen
• 320×240-pixel resolution
• Full color (262000 colors) RGB display
• 4-wire resistive touch screen
• Integrated SSD2119 LCD driver/controller
• SPI interface by default, but supports many interface types
Additional information about the K350QVG-V2-F display can be found on the Kentec website.
2.1.3 SSD2119 LCD Driver
The SSD2119 LCD driver is integrated into the display. In order to use the display effectively, a deep
understanding of this driver is required. The SSD2119 data sheet contains information about the
communication interface and the supported commands.
2.1.4 LCD Backlight Circuitry
Most of the circuitry seen on the BoosterPack is a boost converter to power the LCD backlight. The LCD
requires approximately 20 V to power the LCD backlight due to the serial voltage drops of the LEDs. This
power is derived from the 5-V (VUSB) power rail.
2.1.5 SPI Configuration
By default the BOOSTXL-K350QVG-S1 comes configured as a "4-wire" 8-bit SPI. This is the standard SPI
on most MCUs with a hardware SPI peripheral. The user can reconfigure R2/R3 and R8/R9 to instead use
"3-wire" 9-bit SPI. In this configuration, each SPI write is 9 bits instead of 8, allowing one fewer GPIO pin
to be used.
Table 1. SPI Resistor Configuration
LCD Interface Resistor Configuration
R2 R3 R8 R9
4-wire SPI, 8-bit (default) DNP 0 DNP 0
3-wire SPI, 9-bit 0 DNP 0 DNP
Pins PS0, PS1, PS2, PS3 as indicated in LCD data sheet.
Other (such as parallel) This may require cutting and soldering these traces (not common)
4BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module SLAU601A–March 2015–Revised July 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Hardware
Table 2 describes the SPI configuration pin functions.
Table 2. SPI Pin Definition
LCD Interface Pin Name
LCD_SCS LCD_SCL LCD_SDI LCD_SDC
GPIO to indicate data or command
4-wire SPI, SPI Data In
SPI Chip Select SPI Clock Data = 1
8-bit (default) (no support for data out) Command = 0
SPI Data In
3-wire SPI, 9-bit SPI Chip Select SPI Clock N/A – controlled by extra bit (first bit)
(no support for data out)
2.2 Design Files
2.2.1 Hardware
Schematics can be found in Section 5. All design files including schematics, layout, bill of materials
(BOM), Gerber files, and documentation are available in a zip folder (SLAR098). This hardware design
was done in Altium Designer, a free viewer is available from
http://techdocs.altium.com/display/ADOH/Altium+Designer+Viewer.
2.2.2 Software
All design files including TI-TXT object-code firmware images, software example projects, and
documentation are available in the LaunchPad specific software folders. To see which LaunchPad kits
feature BOOSTXL-K350QVG-S1 examples, refer to the "What's Included" section on the tool folder.
2.3 Hardware Change log
Table 3. Hardware Change Log
PCB Revision Description
Rev 1.0 Initial Release
3 Software Examples
3.1 BOOSTXL-K350QVG-S1 + MSP-EXP432P401R Graphics Library Example
This software is available in the MSP-EXP432P401R Software Examples or is more easily accessible
through MSPWare (see Section 4.3).
The demo shows how to use the MSP Graphics Library ("grlib") in a project with the Kentec display. This
demo shows the user how to enable the touch screen, create buttons, and use graphics primitives
including colors and images.
The program begins by calibrating the touch screen. There is a routine that detects the four corner
coordinates to determine if an eligible rectangle boundary is formed. If the calibration was incorrect, a
message displays on the screen indicating the calibration failed. When successful, the calibration provides
a reference for all button presses throughout the rest of the program.
The next step is to select the mode of the program: display primitives or images. Each mode simply cycles
through without user interaction to show features of the display. In the graphics primitives mode, the
following primitives are shown:
• Pixels
• Lines
• Circles
• Rectangles
5
SLAU601A–March 2015–Revised July 2015 BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Additional Resources www.ti.com
• Text
The application is heavily commented to ensure it is very clear how to use the grlib APIs. The above
primitives are shown as well as the underlying concepts of grlib including background and foreground
colors, context, fonts, opacity, and more.
The images mode shows the drawing of a few different images both compressed and uncompressed.
Image compression can have a big impact to drawing speeds for simple images. To draw images with the
MSP Graphics Library, they must first be converted into the right file format. These files can be generated
by the Image Reformer tool that comes packaged with grlib. Launch this tool (.exe) from the grlib folder or
directly from TI Resource Explorer.
File Path: <grlib root>\utils\image-reformer\imagereformer.exe
TI Resource Explorer > MSPWare > Libraries > Graphics Library > MSP430 Image Reformer
The Image Reformer tool allows you to import images and output into grlib specific files to add to your
grlib project. Image Reformer does not manipulate any images (including color modifications, rotation, and
cropping)—any image manipulation must be done before importing into the Image Reformer tool. More
information about MSP grlib and the Image Reformer tool can be found in the application report Design
Considerations When Using MSP430 Graphics Library (SLAA548).
Figure 4. MSP430 Image Reformer
4 Additional Resources
4.1 TI LaunchPad Portal
More information about LaunchPad kits, supported BoosterPack modules, and available resources can be
found at:
•TI's LaunchPad portal: information about all LaunchPad kits from TI for all MCUs
4.2 Download CCS, IAR, Keil, or Energia
Although the files can be viewed with any text editor, more can be done with the projects if they are
opened with a development environment like Code Composer Studio™ (CCS) IDE, IAR Embedded
Workbench, Keil, or Energia.
6BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module SLAU601A–March 2015–Revised July 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Additional Resources
4.3 MSPWare and TI Resource Explorer
MSPWare is a complete collection of libraries and tools. It includes a driver library (driverlib), graphics
library (grlib), and many other software tools. MSPWare is optionally included in a CCS installation or can
be downloaded separately. IAR users must download it separately.
Figure 5. BOOSTXL-K350QVG-S1 Software Examples in TI Resource Explorer
Inside TI Resource Explorer, these examples and many more can be found and easily imported into CCS
with one click.
4.4 The Community
4.4.1 TI E2E™ Community
Search the forums at http://e2e.ti.com. If you cannot find your answer, post your question to the
community.
4.4.2 Community at Large
Many online communities focus on the LaunchPad and BoosterPack ecosystem – for example,
www.43oh.com. You can find additional tools, resources, and support from these communities.
7
SLAU601A–March 2015–Revised July 2015 BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

1 1
2 2
3 3
4 4
D D
C C B B
A A
Title
Number RevisionSize
A4
Date: 2014/12/12 Sheet of File: D:\KentecDisplay\..\BOOSTXL-K350QVG-S1_03.SchDocDrawn By:
1 2 3 4 5 6 7 8 9 10
J1
1 2 3 4 5 6 7 8 9
10
J2
1 2 3 4 5 6 7 8 9
10
J3
1 2 3 4 5 6 7 8 9 10
J4
LED-K
LED-A
L1 10uH
C3 68uF
C2 2.2uF
R14
NC
R10 NC
R13 68R
5V0
SW
D2
ZMM24
LED-A
LED-K
R11 0R
LED_PWM
TOUCH_XP TOUCH_YP
TOUCH_XN TOUCH_YN
AGND
3V3 5V0
GND
LED-K
LED-A
GND
TOUCH_XP TOUCH_YN TOUCH_XN TOUCH_YP
GND
LCD_RST
LCD_SCS
GND GND
GND
0RR15
3V3
3V3
0RR9 NCR8
GND
3V3
GND
100pF C1
GND
3V3
BOOSTXL-K350QVG-S1 circuit diagram
10nF C4
10nF C5
10nF C6
10nF C7
GND GND GND GND
LED_K
1
LED_K
2
LED_A
3
LED_A
4
GND
5
XR
6
YB
7
XL
8
YT
9
GND
10
NC
11
NC
12
NC
13
RESET
14
CS
15
SPCLK
16
SDA-SDI
17
NC
18
NC
19
B0(D0)
20
B1(D1)
21
B2(D2)
22
B3(D3)
23
B4(D4)
24
B5(D5)
25
NC
26
NC
27
G0(D6)
28
G1(D7)
29
G2(D8)
30
G3(D9)
31
G4(D10)
32
G5(D11)
33
NC
34
NC
35
R0(D12)
36
R1(D13)
37
R2(D14)
38
R3(D15)
39
R4(D16)
40
R5(D17)
41
HSYNC
42
VSYNC
43
DCLK
44
AVDD
45
AVDD
46
VDD
47
VDD
48
RS
49
RD
50
WR
51
PS0
52
PS1
53
PS2
54
PS3
55
WSYNC
56
NC
57
DE
58
GND
59
GND
60
CN1 K350QVG-V2-F
PS0
RST
SCLK
SDA
LED Backlight Driver Circuit
0RR1
03
0RR7
0RR6
LCD_SCL
LCD_SDI
CS
0RR5
0RR4
0RR3
LX 1
GND 2
FB 3
SHDN
4
SS
5
IN
6
U1 AIC1896
R12 1K
C8
33nF
LCD_SCL
LCD_SDI LCD_SCS
D1
MBR0520LT1G
LCD_RST
PS3
PS2
PS1
GND
LED_PWM
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
LCD_SDC
LCD_SDC
NCR2
NC
PS0
0 13-wire, 9-bit SPI interface (SCS, SCL, SDI)
4-wire, 8-bit SPI interface (SCS, SCL, SDI, SDC)
Interface Mode
0RR16
0RR17 0RR18
Default R9=>R8 R3=>R2
Schematics www.ti.com
5 Schematics
Hardware design files can be downloaded from www.ti.com/lit/zip/slar098.
Figure 6. Schematics
8BOOSTXL-K350QVG-S1 QVGA Display BoosterPack™ Plug-in Module SLAU601A–March 2015–Revised July 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Revision History
Revision History
Changes from March 19, 2015 to July 20, 2015 .............................................................................................................. Page
• Changed the link destination for the MSP-EXP432P401R Software Examples .................................................. 5
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
9
SLAU601A–March 2015–Revised July 2015 Revision History
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products Applications
Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive
Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications
Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers
DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps
DSP dsp.ti.com Energy and Lighting www.ti.com/energy
Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial
Interface interface.ti.com Medical www.ti.com/medical
Logic logic.ti.com Security www.ti.com/security
Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com
Wireless Connectivity www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2015, Texas Instruments Incorporated
