USER GUIDE
Gateway VX760/VX765 Monitor

i
Using Your VX760/VX765 Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Setting up the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Adjusting settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
On-screen display menu options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Video modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety, Regulatory, and Legal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Contents

Contents www.gateway.com
ii

1
Using Your VX760/VX765 Monitor
• Setting up the monitor
• Adjusting settings
• Maintaining
• Troubleshooting
• Specifications

Using Your VX760/VX765 Monitor www.gateway.com
2
Settingupthemonitor
Read all instructions before using the monitor and save them for later use.
Follow all warnings and instructions marked on the product.
To set up the monitor:
■Attach the base
■Connect the video and power cables
To attach the base:
1Carefully set the monitor on its side.
2Hold the base with the tab facing the back of the monitor and align the
hooks on the base with the corresponding slots on the bottom of the
monitor.
3Slide the base toward the front of the monitor so all hooks are securely in
place. A retaining latch built into the base clicks into place when the base
is correctly attached.
4Carefully set the monitor upright and place it on a sturdy, level surface.
To connect the video and power cables:
1Position the monitor and your computer so you can easily get at the back
panel of each. Make sure that all power cables can reach a correctly
grounded electrical outlet.
2Connect the video cable to the matching (blue) video port on the back of
your computer.
3Tighten the screws on the video cable connector to keep it from coming
loose. Tightening the screws also prevents radio and TV interference.

Setting up the monitor
www.gateway.com
3
Caution
The openings in the monitor cabinet are
for ventilation. Do not block or cover
these openings. Do not insert anything
into these openings. If you put the
monitor in a bookcase or some other
enclosed space, make sure to leave at
least six inches (15 cm) around it for
ventilation.
4Connect the power cable that came with the monitor to the AC power
connector on the back of the monitor. Only use the power cable that came
with the monitor.
5Plug the other end of the power cable into a correctly grounded electrical
outlet.
To turn on the monitor:
1Press the power button on the front of the monitor.
2Turn on your computer.
AC power
connector
Power button MENU button
Contrast/ button
Brightness/ button
EXIT button

Using Your VX760/VX765 Monitor www.gateway.com
4
Adjustingsettings
Power button. Turns the monitor on and off.
Power indicator. Turns blue when the monitor is operating normally, then
flashes when the monitor is in energy saving mode.
MENU button. Enters the on-screen display (OSD) menu or selects an OSD
menu option.
Brightness/ button. OSD inactive: Adjusts the brightness.
OSD active: Navigates to and adjusts the OSD menu options.
Contrast/ button. OSD inactive: Adjusts the contrast.
OSD active: Navigates to and adjusts the selected OSD menu option.
Exit. Exits the OSD menu or sub-menu.
To adjust monitor settings:
1Press the MENU button. The OSD menu opens.
2Press the or buttons to highlight an OSD menu option, then press
the MENU button to select the option.
3Press the or buttons to adjust an OSD menu option.
4Press the EXIT button to save changes. Press the or buttons to
highlight a different OSD menu option.
- OR-
If you have finished making all adjustments, press the EXIT button twice
to save your settings and exit the OSD.

Adjusting settings
www.gateway.com
5
On-screendisplaymenuoptions
Icon Description
CONTRAST. Adjusts the level of white between the lightest and darkest portions of an
image.
BRIGHTNESS. Adjusts the amount of light in the darkest portion of the picture.
H. POSITION. Controls the horizontal position of the display image.
H. SIZE. Controls the horizontal size of the display image.
V. POSITION. Controls the vertical position of the display image.
V. SIZE. Controls the vertical size of the display image.
ROTATION. Rotates the display image.
PINCUSHION. Curves the sides of the display image inward or outward.
TRAPEZOID. Increases or decreases the trapezoid distortion of the display image.
PARALLELOGRAM. Slants the display image to the left or right.
PIN BALANCE. Curves the display image to the left or right.
ADVANCED SELECT. Opens a submenu that contains menu options to adjust the top
and bottom corners of the display and horizontal and vertical moire.
COLOR. Adjusts color balance. Select from two preset factory options (9300°K and
6500°K) or USER. USER lets you adjust the red, green, and blue colors separately.
OSD ADJUSTMENT. Opens a submenu that contains menu options that let you change
the position of the OSD menu on the screen and the length of time the OSD menu is
visible.
RESET. Resets the monitor settings to the factory default settings.
LANGUAGE. Changes the display language for the OSD.
EXIT. Displays current settings and exits the OSD menu.
DEGAUSS. Demagnetizes the screen.
MORE
OSD
R
EXIT

Using Your VX760/VX765 Monitor www.gateway.com
6
Videomodes
The monitor supports several video modes from 720 × 400 to 1280 × 1024. The
recommended video mode is 800 × 600 @ 85 Hz. Factory preset video modes
include:
HF- Horizontal frequency (KHz)
VF- Vertical frequency (Hz)
Maintaining
To keep the monitor in optimal working order:
■Do not block the ventilation holes.
■Do not expose the monitor to rain or use near water.
■Keep the monitor away from radiators or heat vents.
■Keep the monitor out of direct sunlight.
■Keep the monitor away from any equipment that generates a magnetic
field.
Use a screen saver to avoid permanent image burn-in. For more information
about screen savers, see the documentation that came with your computer.
Cleaning
Warning
When the monitor is turned off, a small
amount of electrical current still flows
through the monitor. To avoid electrical
shock, always unplug all power cables
and modem cables from the wall outlets
before cleaning the system.
Clean the monitor using a soft cloth lightly moistened with water. Wipe the
cabinet, glass panel, and controls.
Do not use any type of abrasive pad or glass cleaner. You will permanently
scratch the glass panel.
Mode Resolution HF VF
1720 × 400 31.47 70
2 640 × 480 31.47 60
3640 × 480 43.27 85
4 800 × 600 46.87 75
5800 × 600 37.88 60
6 800 × 600 53.67 85
7800 × 600 63.90 100
8 1024 × 768 48.36 60
91024 × 768 60.02 75
10 1024 × 768 68.67 85
11 1280 × 1024 60.30 75
