Texi Smart S+B User manual

Texi Smart S+B
Instruction manual

TEXI SMART S+B 2
SAFETY RULES
• Before operating the machine read the instruction manual carefully. It contains important advices for safe
and efficient use and maintenance of the machine.
• Please keep the manual, warranty card, proof of purchase and, where possible, the original packaging. If
you want to pass the machine to another person - give it together with instruction manual and warranty card.
• After unpacking, make sure that the machine is not damaged. In case of doubt, contact an authorized
service.
• Do not leave plastic bags, pieces of foam, staples, etc., remaining after unpacking the machine within the
reach of children or persons with reduced psychophysical efficiency.
WARNING! Do not allow children to play with foil. Danger of suffocation!
• Safe use of this machine will only be possible when it is properly connected to a grounded electrical
system. Supplier / Distributor shall not be liable for any damages arising from connecting to the installation,
which fails to meet safety requirements.
• Before connecting the machine make sure that the voltage on the rating plate complies with the mains
voltage. In case of doubt, contact a qualified electrician.
• It is not recommended to use adapters, splitters and extension cords. If necessary, use only certified,
accessories, corresponding to current safety standards, making sure they are appropriate for your electrical
system and comply with the technical parameters of the machine.
• Connecting the machine in a manner inconsistent with the instructions threatens your safety and may
cause voiding the warranty.
• Remember:
- Do not use the machine for purposes other than those described in this manual,
- Do not use the machine barefoot or with wet hands or feet,
- Do not use the machine outside,
- Do not expose the machine to weathering (sun, rain, wind, ...),
- Do not allow children or persons with reduced psychophysical efficiency to use the machine,
- Never pull the power cord or the machine to disconnect it from the electric network,
- Do not leave the machine connected to the mains, without supervision,
- Never immerse the machine in water or other liquids.
• User cannot exchange electric cable on his own. Contact an authorized service or qualified personnel, if the
exchange is necessary.
• Turn off and unplug the machine if it breaks down or works incorrectly. Contact an authorized service for
repair with use of original spare parts. Do not attempt repairs yourself.
• To prevent the continued use of the machine after its worn, unplug it from the mains and cut the electric
cord. Follow local rules for disposal of waste.
• Seller / Distributor shall not be liable for any damage caused to persons, animals or things by improper
connection or resulting from misuse, improper or excessive use.
• This machine is not a toy!

TEXI SMART S+B 3
GENERAL INFORMATION
Texi Smart S+B is a suction and blowing ironing table with steam station and iron.
1. SPECIFICATIONS:
MODEL:
Texi Smart S+B
POWER SUPPLY:
220-240 V–50-60 Hz
TOTAL INSTALLED POWER:
2388 W
POWER OF IRON:
800 W
BOARD POWER:
200 W
VACUUM/BLOWING POWER:
40 W
BOILER POWER:
1300 W
PUMP POWER:
48 W
BOILER CAPACITY:
1.9 L.
NET BOILER CAPACITY:
0.95 L.
WATER TANK CAPACITY:
1.1 L.
IRONING ENDURANCE:
CONTINUOUS
OPERATING STEAM PRESSURE:
2.8 BAR
WEIGHT:
26 kg.
OVERALL DIMENSIONS (OPEN):
136x44x105 h. cm
OVERALL DIMENSIONS (CLOSED):
136x44x24 h. cm
MADE IN ITALY
LEGEND
1
COVER
2
IRONING ARM
3
CABLE SUPPORT SPRING
4
IRON CABLE SUPPORT
5
IRON
6
IRON HOLDER
7
SLEEVE ARM FIXING KNOB
8
POWER SUPPLY CABLE
9
IRON REST
10
WATER DISCHARGE SCREW
PLUG. WARNING: HOT WATER
11
WHEELS
12
ELECTRIC + STEAM PLUG
WITH SECURITY BLOCK-CAP

TEXI SMART S+B 4
2. IMPORTANT
Before installing Texi Smart S+B, it is necessary to set up the following:
1. Protected electrical outlet suitable to its power (itisrecommendedtouseanearthprotectorthermo-
magnetic switch 16 A and Id 30mA).
2. Flat,evensurfaceontowhichthemachinewillbeplaced.
3. OPENINGTHEPACKAGE
1. Open the box containing the Texi Smart S+B, take out the instruction manual and read it very
carefully.
2. Remove Texi Smart S+B from the box and insert the cable support deep into the special hole
(fig.1).
3. Fix the cable support spring to the cable support, avoiding twining.
4. Put the iron on the iron rest. (fig. 1).
4. CONNECTING AND STARTING
FUNCTIONS OF KEYS
Main ON/OFF key
Boiler ON/OFF key
Iron ON/OFF key
ON/OFF
Vacuum / blowing motor ON/OFF key
Manual / automatic mode switch
Note: in manual mode the vacuum/blowing motor works continuously, in automatic mode the
vacuum/blowing motor works upon pressing the micro-switch of the iron.
Key to change the motor function from vacuum to blowing and
vice-versa.

TEXI SMART S+B 5
ON/OFF
To access the internal menu press both keys together.
With Texi Smart S+B switched off and disconnected plug:
1. Vertically hold the ironing board, being sure that the boiler is towards the floor;
2. Pull the board legs until the desired height has been reached (fig. 2);
3. Install the electric + steam plug in the socket placed on a side of the steam generator
(Fig. 1.12). Block it with the security cap of the outlet.
4. Take off the water plug of the Texi Smart S+B (fig. 3), and fill the water tank (roughly 1 liter).
Once this has been done, replace the water plug.
5. Insert the plug (Fig. 1.8) into a 230V 16 A socket and turn on the machine by pressing the green
key;
6. Select the desired function (iron, boiler, working mode, etc.).
WARNING: the electronic board automatically performs a check of
the software installed.
If an error or fault is found, the “safety” device blocks the electronic
board and does not allow normal functioning. “SOFTWARE
ERROR”will be displayed. Contact the Authorized Service Centre
to update the software.
WATER FILLING
Fig. 3
5. MEANING OF ICONS
INTERMITTENT LIGHT: indicates that the boiler is on and water is being heated to
obtain steam
FIXED LIGHT: indicates that the boiler is on and its pressure is optimum Texi Smart
S+B is ready for ironing
Indicates that the iron is functioning
INTERMITTENT LIGHT + SOUND ALARM: indicates that water is missing inside
the water tank.
FIXED LIGHT: indicates that the pump is pumping water into the boiler.
Indicates –when the light is on, the vacuum / blowing motor is on.
Light is off –motor does not work.
Fig. 2

TEXI SMART S+B 6
When the light is on, the machine works in manual mode (the vacuum / blowing
motor works continuously). When the light is off –the machine works in automatic
mode (the vacuum / blowing motor works upon pressing the micro-switch of the
iron).
Indicates a malfunction which requires technical assistance or that the maximum
number of hours set for the cover changing has been exceeded.
NOTE:
During ironing the icon will start flashing. This is normal and indicates that the heater is working,
restoring the optimum pressure inside the boiler.
If the icon turns on every now and then, this indicates that the Texi Smart S+B is pumping
water into the boiler. It is therefore important to always fill the water tank (fig. 3).
It is possible to change the motor function (vacuum or blowing) and the functioning (continuous or
with iron micro-switch) anytime by using the keys indicated in “FUNCTIONS OF KEYS”.
6. MENU
To access the MENU, press both keys for a few seconds as shown on the left. To
exit the MENU, press ESC or wait for 5 seconds. To scroll up or down use the
arrows.
AVAILABLE SETTINGS:
HOURS OF
WORK
TOTAL HOURS:
Cannot be zeroed
To exit
or wait for 5
seconds
ON/OFF
PARTIAL HOURS:
Zeroing of hours
Press for 6 sec.
TOTAL HOURS: computation of the total hours the machine has worked for. This data cannot be
zeroed.
PARTIAL HOURS: computation of the hours the machine has worked since last zeroing. This data
can be zeroed (see table). To zero the data, follow instructions as per below table.
ON/OFF

TEXI SMART S+B 7
RESET OF WARNINGS is necessary in order to delete the warnings from the display once the cover
has been changed.
Example: WARNING: CHANGE COVER is displayed.
1. Access the MENU
2. find RESET WARNINGS, press OK and find CHANGE COVER
3. press RESET until you hear an acoustic signal
4. ESC to exit the SET menu.
KEY TONE
KEY TONE ON
To confirm
To exit
or wait for 5
seconds
ON/OFF
KEY TONE OFF
KEY TONE is used to activate or deactivate the acoustic signal when keys are pressed.
If you wish the acoustic signal to be deactivated, press KEY TONE OFF.
MAINTENANCE
Password needed. Service Centre authorized access only
MANUFACTURER
Password needed. Manufacturer authorized access only
WARNING: AFTER 10 ATTEMPTS TO ACCESS THE “MAINTENANCE” OR
“MANUFACTURER” MENU WITHOUT TYPING IN THE PASSWORD, AND/OR EVERY TIME
THE WRONG PASSWORD IS TYPED, THE MENU WILL BE BLOCKED. “PASSWORD
BLOCKED” will be displayed. To unblock the menu, contact the Authorized Service Centre or the
manufacturer.
LANGUAGE
ITALIAN
To confirm language
To exit
or wait for 5
seconds
ENGLISH
GERMAN
FRENCH
POLISH
RESET OF
WARNINGS
CHANGE COVER
(the number of hours
elapsed since the last
change will be displayed)
To zero, press the key
until you hear an
acoustic signal
To exit press
or wait for 5
seconds

TEXI SMART S+B 8
ON/OFF
RUSSIAN
LANGUAGE allows to set operating language (see table). Languages may be different according to
the country of destination.
DELAY
DELAY
ON
0...12
seconds
To confirm
To exit
or wait for 5
seconds
ON/OFF
DELAY
OFF
ON/OFF
DELAY works only in the automatic mode. You can set the vacuum / blowing motor on delay (DELAY
ON)as well as off delay (DELAY OFF), in the range from 0 to 12 seconds. The settings are saved in
the memory. You can change the values according to your requirements.
The factory settings are: delay of the motor on –2 seconds, delay of the motor off –6 seconds.
7. WARNING LIGHT AND SOUND ALARM SIGNAL
The intermittent warning light , the sound alarm
signal with quick intermittency and the written warning
“WATER” are activated when there is no water inside the
water tank. Upon refilling the water tank the light and
sound alarm signal will switch off.
The fixed warning light together with , the
sound alarm signal with slow intermittency and the
written warning “WATER PUMPING” are activated: to
indicate a malfunction of Texi Smart S+B (the boiler is
without water and it is not possible to restore the correct
water level). In this case turn off the boiler and then turn it
on once again. If the warning light does not turn off - do
not insist, unplug the Texi Smart S+B from the mains and
contact authorized personnel.
WATER FILLING
Fig. 3

TEXI SMART S+B 9
8. PRINCIPLES OF SAFE AND EFFICIENT WORK
1. Use only normal tap water.
2. Never add additives to water.
3. Connect Texi Smart S+B to a suitable and protected socket.
4. Keep out of reach of children, both when it is on and off.
5. Do not iron garments directly on persons or things.
6. Never leave the iron on the board or on garments when it is on.
7. Never leave garments on the board when it is on, in order to avoid them from
getting spoilt or burnt.
8. ATTENTION: Texi Smart S+B may be switched on only when the ironing board
is open.
9. ATTENTION: put away Texi Smart S+B as shown (fig. 4). Never put it away
upside down (fig. 5).
9. WORKING WITH MANUAL AND AUTOMATIC MODE
1. When you choose the manual mode, the vacuum / blowing motor works continuously, unless it’s
switched off. To switch on or switch off the motor, use the key . To change the motor
function from vacuum to blowing or opposite use the key .
Note: While you first run your machine, the vacuum / blowing motor is off.
2. When you choose the automatic mode, the vacuum/blowing motor works upon pressing the
micro-switch of the iron. The way of working is showed on the below exemplary picture:
Example: The delay of the vacuum / blowing motor on, after pressing iron’s micro-switch, is set on 2
sec. The delay of the motor off, after releasing the iron’s micro-switch, is set on 6 sec.
Press the micro-switch of the iron and start ironing. After 2 seconds the vacuum / blowing motor will
start working. 6 seconds after releasing the micro-switch, the motor will stop working. By extended
time of the motor work, moisture is sucked out of the material and the effect of ironing is fixed.
Note: After pressing the micro-switch the steam will come out of the iron, after releasing –it will stop.
Fig. 4
Fig. 5

TEXI SMART S+B 10
10. IRONING
1. Seize the iron by the cork handle and press the micro-switch of the iron (fig. 7)
4-5 times sothat steam comes out. This is necessary in order to warm the hoses and avoid water
dripping from the iron.
2. Start ironing by pressing micro-switch of the iron (fig. 7), activating steaming. As a result, the
fibers of the ironed element are damped. Release the micro-switch to smoothen all creases. For
a good result, set the thermostat (fig. 6) on “cotton”.
3. For delicate, black or blue garments we suggest to use the anti-shine shoe.
4. During ironing, always put the iron on its rubber rest (fig. 1) and pay attention to the position of
the wires: if they twine or get in touch with the ironing board, they might cause short circuits.
5. For dry ironing it is possible to adjust the thermostat (fig. 6) on various positions according to the
type of fabric (check garment label). For steam ironing, set the thermostat on “cotton” or “flax”.
6. It is advisable to replace the padding (fig. 1) as soon as the vacuum of the ironing board is
unsatisfactory or when the padding presents some marks or rings of water.
11. REFILLING OF THE WATER TANK
It is possible to fill the water tank at any time, even when the boiler is functioning. Lift the water plug
and add water, paying attention not to spill it onto the machine (fig. 3). Water is required when the
intermittent warning “WATER” appears and the sound alarm signal switches on (chapter 7).
It is suggested to immediately add water once the sound alarm signal switches on. This avoids the
drop of pressure and therefore it is not necessary to wait for water heating.
12. REPLACEMENT OF COVER
After a certain number of hours the machine will signal that the board cover needs to be replaced.
This procedure must be carried out ONLY when the boiler and ironing board are cold and
disconnected from the mains.
Note: it is possible to wash the cover.
ATTENTION: It is necessary to reset the hour-counter (see chapter 6) every time the cover is
replaced. This will permit its correct functioning.
Note: The “CHANGE COVER” warning timing is based on an average use of the ironing board.
However, the wear and tear also depends on how ironing is done. It may therefore be necessary to
replace it even earlier, especially if vacuum/blowing performances have diminished.
Fig. 6
Fig. 7
ELECTRIC
CABLE
THERMOSTAT
MICROSWITCH
FOR IRON
STEAM HOSE

TEXI SMART S+B 11
13. EMPTYING OF WATER FROM BOILER
After a certain number of hours the machine will signal
the need to empty thewater from the boiler. The warning
will be visible only during the first minute the machine is
switched on. “EMPTY WATER FROM BOILER” will be
displayed. After one minute the warning will disappear,
no matter whether the water has been emptied or not.
This procedure is very important and should be done
regularly in order to eliminate limestone residue, which
may damage the machine.
In order to empty the water, unscrew the water discharge
screw plug. Empty the water into a proper container.
Once the water has been emptied re-assemble the
screw plug, paying attention not to tighten it too much
and checking that there are no water leakages (in this case change the gasket of the screw plug).
WARNING: EMPTY WATER ONLY WHEN THE BOILER IS COLD AND THE ELECTRIC
PLUG IS DISCONNECTED FROM THE MAINS.
14. COMPULSORY PERIODICAL MAINTENANCE
(TO BE CARRIED OUT EXCLUSIVELY BY AUTHORIZED SERVICE CENTERS, QUALIFIED
TECHNICIANS OR BY THE MANUFACTURER.)
Compulsory maintenance is signaled by the icon . GENERAL MAINTENANCE will be
displayed. Contact only your reseller, Authorized Service Centers or the manufacturer in order to
carry out the necessary maintenance. Once the check has been completed, the authorized
personnel will reset the “general maintenance” icon which is shown on the display.
It is also compulsory to change the electric-steam hose or electric cable, if damaged.
15. GOOD FUNCTIONING
Once ironing is finished, leave Texi Smart S+B switched on for 10 minutes. Cool off the ironing board
by activating the vacuum function before switching off the machine. This procedure eliminates water
stagnation and assures long lasting performances.

TEXI SMART S+B 12
16. CLOSING OF THE IRONING BOARD
Switch off Texi Smart S+B, take the electric plug (Fig.1.8) out of the power supply socket and the
electric + steam plug of the iron out of the socket (Fig. 1.12) and wait until it cools down. Put the iron
in a storage place. Press the ironing board handle and at the same time lift the narrow end of the
board upwards (fig. 8). Now Texi Smart S+B may be put away vertically. Texi Smart S+B is also
equipped with wheels which simplify this operation (fig. 9).
17. RELEASING OF STEAM STATION
It is possible to separate the steam station from the ironing board.
Disconnect the plug, which connects the steam station to the ironing board,
loosen four knobs and pull the steam station outwards (fig. 10).
Fig. 8
Fig. 9
1
2
Fig. 10

TEXI SMART S+B 13
18. ELECTRICAL RISK
The following situations are considered dangerous for the operator:
1. earth protector switch is activated upon turning on the main switch;
2. using Texi Smart S+B during thunderstorms;
3. using Texi Smart S+B without proper protection for feet (without shoes) or with wet feet;
4. damaged electrical cables;
5. loss of water from iron;
6. iron overheating;
7. cleaning or washing the iron using water;
8. loss of water from Texi Smart S+B.
IMPORTANT: While filling the tank with water, keep extreme caution –do not let the water spill onto
electronic panel.
19. MECHANICAL RISKS
The following situations are considered dangerous for the operator:
1. using Texi Smart S+B for purposes other than ironing.
20. THERMAL RISKS
The following situations are considered dangerous for the operator:
1. touching the iron base when in function;
2. directing the steam jet towards people or animals.
Do not iron garments directly on persons
Never leave the iron on garments when it is on
After use, always put the iron on its rubber rest
21. PACKAGING, STORAGE AND TRANSPORT
Texi Smart S+B is packed in cardboard box, which cannot be turned upside down and should be
handled with utmost care. Do not use the boxes as a stool or support and do not pile Texi Smart
S+B one on top of another (Handle with care).
22. WARRANTY
Warranty does not apply to damage resulting from:
Tampering with the machine or repairs carried out by non-authorized personnel;
Total or partial inobservance of the instructions contained in this manual;
Improper maintenance or wrong assembly/connection;
Use of non-original spare parts;
Use of the machine for purposes other than those written in this manual.
ATTENTION: THERMIC
DANGER:
INCANDESCENT
IRON BASE

TEXI SMART S+B 14
23. DISPOSAL
Information for the correct disposal in accordance with EC directives 2002/96/EC
and 2003/108/EC.
Texi Smart S+B is mainly made of iron material and must therefore not be disposed of
as urban waste but in proper waste collection centers. The crossed dustbin symbol
indicates that the product must be disposed of separately from other refuse in order to
avoid negative consequences for the environment and health.
The correct disposal and recycling of the machine’s components assures protection of
the natural environment.

TEXI SMART S+B 15

TEXI SMART S+B 16
Distributor:
