The box MA150 User manual

MA150
active 2 way
full-range monitor
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
18.05.2016, ID: 209257

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 6
3 Features....................................................................................................................................................... 11
4 Installation.................................................................................................................................................. 12
4.1 Pin assignment.................................................................................................................................. 13
5 Connections and operating elements........................................................................................... 15
6 Technical specifications....................................................................................................................... 19
7 Protecting the environment.............................................................................................................. 21
Table of contents
MA150
3

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
active 2 way full-range monitor
4

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General notes
MA150
5

2 Safety instructions
This device is intended to be used in a sound reinforcement system. Use the device only as
described in this user manual. Any other use or use under other operating conditions is consid‐
ered to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety instructions
active 2 way full-range monitor
6

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
MA150
7

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
CAUTION!
Risk of injury due to heavy weight
Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.
Safety instructions
active 2 way full-range monitor
8

NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
MA150
9

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
active 2 way full-range monitor
10

3 Features
Special features of this active 2-way full-range monitor:
n1 × 15" woofer, 1 × cone tweeter
nOutput power 150 W
nFrequency response 45 Hz … 18 kHz
n3-band equalizer
nLine and microphone inputs (XLR), line out (XLR), NL4 out for passive speakers
nGain and level control
nTripod mounting flange
nTrapezoid wooden cabinet with felt cover
nStandby feature
Features
MA150
11

4 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
Installation
active 2 way full-range monitor
12

4.1 Pin assignment
You can use XLR plugs with balanced or unbalanced wiring. In the following, we will give you
an overview of the various options.
XLR mounting sockets serve as signal inputs, XLR mounting plugs serve as signal outputs.
Drawing and table indicate the XLR pin assignment.
Balanced wiring:
1 Ground, shielding
2 Positive signal (+)
3 Negative signal (–)
XLR connections for signal in
and outputs
Installation
MA150
13

Unbalanced wiring:
1 Ground, shielding
2 Signal
3 Bridged to pin 1
Installation
active 2 way full-range monitor
14

5 Connections and operating elements
Connections and operating elements
MA150
15

1ON/OFF
Use the mains switch to turn the unit on or off.
2STANDBY
Push button to enable or disable the energy saving mode.
When the box receives no signal for 60 minutes, it switches to standby mode. When it receives a signal again, it auto‐
matically switches back to normal mode.
LED ACTIVE
Power indicator LED. This LED is permanently on in normal mode. It goes off when the energy-saving mode is ena‐
bled and the box enters the standby mode.
LED STANDBY
Standby mode. This LED lights up when the energy saving mode is enabled and the box enters the standby mode. It
goes off again when the box switches back to normal.
3 IEC chassis connector for operating voltage supply with fuse holder.
Connections and operating elements
active 2 way full-range monitor
16

4SPEAKER OUTPUT
NL4 output to connect a passive monitor.
5LINE OUTPUT
XLR output to connect another active monitor.
6LINE INPUT
XLR input for line signals (PA, preceded speakers etc.).
7MIC INPUT
XLR microphone input.
8LF
Control to attenuate or increase the low frequencies. Turn it clockwise / counter-clockwise to increase / decrease the
lows by ± 6 dB.
9MF
Control to attenuate or increase the mid frequencies. Turn it clockwise / counter-clockwise to increase / decrease the
mids by ± 6 dB.
Connections and operating elements
MA150
17

10 HF
Control to attenuate or increase the high frequencies. Turn it clockwise / counter-clockwise to increase / decrease the
treble by ± 6 dB.
11 LINE VOL
Control to adjust the volume of the line input (Gain). Turn the knob clockwise / counter-clockwise to increase /
decrease the volume of the input.
12 MIC VOL
Control to adjust the volume of the microphone input (Level). Turn the knob clockwise / counter-clockwise to
increase / decrease the volume of the input.
13 LED PEAK
Indicates clipping. If the LED flickers or lights up during operation, the input level is too high. In this case, reduce the
volume of the input signal.
Connections and operating elements
active 2 way full-range monitor
18

6 Technical specifications
System Active 2-way full-range monitor with built-in crossover
Speakers 1 × 15" woofer
1 × cone tweeter
Connections NL4 outlet for passive speakers
LINE in and out (XLR)
MIC input (XLR)
Frequency response 45 Hz … 18 kHz (–3 dB)
Sound pressure level (1 m) 120 dB
Level adaptation Treble: ± 6 dB, 10 kHz
Mids: ± 6 dB, 500 Hz
Bass: ± 6 dB, 100 Hz
Output power 150 W
Technical specifications
MA150
19

THD Line: 0.02 %
Microphone: 0.04 %
Load impedance 4 Ω
Input impedance 10 kΩ
Operating voltage supply AC 230 V , 50/60 Hz
Housing Wood, trapezoid, black felt cover
Dimensions (W × H × D) 715 mm × 450 mm × 505 mm
Weight 25 kg
Technical specifications
active 2 way full-range monitor
20
