The box PA 110 User manual

Owner‘s Manual
PASSIVE 2-WAY
FULL RANGE SPEAKER
PA 110
10/1.5“

2
Intended use
This speaker box is exclusively meant for the reproduction of audio signals
according to instructions and specications given in this manual. We‘re not
liable for any damage caused by unintended use.
Safety instructions
For your own safety you must read through this chapter at rst
completely, before you connect the device!
Never submerse the speaker box in water. Liquid getting into the box •
will risk a short circuit and will be hazardous.
Do not expose the speaker box to direct precipitation and never use it in•
a damp or wet environment. This speaker box was developed for indoor
use only. Do not use it outdoors.
Do not place the speaker box in locations that are subject to high•
temperatures, direct sunlight, or excessive dust.
Never operate the speaker box in the vicinity of heat sources such as•
cookers, heating elements or other heat producing installations.
Keep children away from the speaker box. Children frequently •
underestimate the dangers of electrical devices.
Keep sufcient distance from the speaker box when operated •
with high volume level. Listening to music with high sound
pressure level may cause permanent damage to your hearing!
Flying and installation of this speaker cabinet must be carried out by•
suitably qualied personnel following the approved safety standards.
Do not attempt to clean the plastic enclosure with solvents or•
petrochemical based cleaners.
Do not place objects which are sources of heat on the speaker cabinet•
such as lighting equipment or smoke machines.
Do not stack the speaker cabinet in a manner that could cause injury•
should a cabinet become dislodged.
Before connecting or operating this speaker box, please study and follow•
the instruction manuals of all devices connected to the box, paying
particular attention to the operating precautions and wiring procedure.
Disposal
Never throw the device into the regular household waste at the
end of its useful life. This product is subject to the European
Directive 2002/96/EC.
Dispose of the device through an approved disposal centre or at your•
community waste facility.
Observe the current existing regulations. In case of doubt contact your •
disposal facility.

3
The packaging is certied via a dual system. Take all packaging •
materials to an environmentally friendly disposal facility in
compliance with the local regulations.
Features
Two-way passive speaker with one 10” woofer and one 1.5” driver.•
Cabinet is made from polypropylene and special high-tech material in •
large injection mold. It’s durable, shock-resistant and has good damping
characters.
Voice coil in the 10” woofer is made from Ø 75mm copper cladding •
aluminium ribbon wire.
Heavy duty protective grille.•
The high frequency driver is protected by special design circuit to avoid •
being damaged when overload.
Rotatable 90° x 60° (HxV) dispersion horn makes it suitable for any•
performance purposes.
Arrayable vertically in 4 layers or horizontally in more than 8 columns.•
Technical measurements
Frequency response, SPL/2.83v Impedance curve
Harmonic distortion 106dB/2.5m, Waterfall spectrum analysis
nominal impedance

Technical specifications
System ........................................................ : Built-in Crossover Two Way
..................................................................... : Full Range Speaker
Cabinet ....................................................... : Polypropylene, Trapezoid
Drivers ........................................................ : 1 x 10“ (Bass)
..................................................................... : 1 x 34mm Ø (Driver)
Frequency Response ................................. : 55Hz - 18kHz (-3dB)
Frequency Response ................................. : 50Hz - 20kHz (-10dB)
Sensitivity (1W/1m) ..................................... : 95 dB
Impedance .................................................. : 8 Ohm
Power handling capacity (RMS) ................. : 250 W
Max Sound Level (dB/1M) .......................... : 119 dB
Tweeter Dispersion (H x V) ......................... : 90° x 60°
Harmonic Distortion .................................... : ≤ 1%
Connectors ................................................. : 2 x NL4
Dimensions (W x D x H mm) ...................... : 321 x 321 x 464 mm
Packing Dimensions (W x D x H mm) ........ : 375 x 355 x 535 mm
Net Weight .................................................. : 10 kg/ps
Gross Weight .............................................. : 12 kg/ps
Our products are subject to a process of continual further development.
Therefore modications to the technical features remain subject to change
without further notice.
