The Net Return SIMULATOR Series User manual

• 23 Color-coded aluminum tubes
(1 Tube with sleeved net).
Simulator Screen•
• Left & Right Side Barriers
• Left & Right Side Panels
(not pictured).
• Top-Back Drape
• Front Valance (9”)
• Sand Bags (6) -sand not included.
• Duffel Bag
Find the 4 tubes labeled BASE, and connect them to each
assemble the base, make sure the label that says “BASE” is
other by simply matching the colors stripes together. When you
facing up and can be read.
CONTENTS BASE
1
C) Now connect the upper-most tubes, the last of
which will be the one with the sleeved net (red and
black stripes). Then, disconnect the velcro stripes
holding the net.
FRAME
2
So let’s get started.
SIMULATOR
ASSEMBLY
Thank you for purchasing our product. In this pamphlet you’ll
Net Return Simulator. In about 15 minutes you should have
something that looks like the picture to the right.
find simple, easy to follow instructions for assembling your new
For even easier to follow video instructions on how to assemble or disassemble any
of our products, go on-line to TheNetReturn.com/Assembly .
A) Once the base is complete, locate the 2
upright tubes (with the welds), and connect them
vertically to the frame base. Continue to build up
your frame by connecting the tubes with the
identical colored stripes.
B) After you connect the tubes with the yellow and
white colored stripes, tip the frame onto its back
(see above) allowing easy assembly of the
upper-most tubes.
9

SLEEVE
SCREEN
3
4
Slide the screen onto the support tubes from Step 4B
F) Seal the opening between the screen and the net
using the large Velcro strip on the front and the smaller
one on the back. You may need to lift the frame for this.
E)
Connect the tubes with the screen onto the rest of
the frame.
E)
D)
B) Carefully slide the net all the way down the left
and right side.
A) Begin sliding the sleeve onto the frame, one
side at a time. There are slits sewn into the sleeve
so that it fits over the dual tubes on the left and
right side. Make sure these are exposed.
C) Secure it in place with the Velcro tabs on the
bottom of each side of the net.
C) Fold out the screen and lay it down on the
net with the larger of the two Velcro strips
facing up, feeding it through the rear opening
of the net.
B) Assemble the rest of the screen support that
will go onto the top of the frame. Leave one side
open for now to sleeve the screen onto the tube.
A) Locate the two pairs of tubes for the left and
right sides now (from step 3A) and slide them into
position to the bottom of the base. There are no
push-buttons for these tubes.
10

THANK YOU
ENJOY YOUR PURCHASE
SHADES
+ side barriers
ACCESSORIES
FOR YOUR SIMULATOR
5
For more detailed side barrier installation instructions
as well as all our other products, visit us on-line at
TheNetReturn.com/Assembly.
www.TheNetReturn.com
••4
A) Locate the red tab in the middle of the top/rear
drape and align it with the red tab in the middle of
the Velcro strip on the top of the net and connect
the entire fabric.
B)There are two side barriers.The color tabs (Blue
on the left and red on the right) are connected at
the 90º angle on the top/front of the net
C) Attach the remaining larger Velcro tabs across the
top on each side - and the two smaller tabs on the
back of the net.
D) Each Side Panel has Velcro strips that attach to the
top of the Side Barrier netting toward the front on one
side and to the rear upright pole toward the back.
E) Connect the front valance (aligning once again the red tab to
the middle) to the front of the net, opposite the top-back drape.
F) Carefully stand up the frame (watch your
ceilings), and continue the assembly of your side
barriers by attaching the Velcro tabs to the rear
of the net.
G) Connect the two green tabs on the rear of
each side barrier, and the tabs at the end to a
sand bag on each side.
Visit us at TheNetReturn.com to purchase
any of the following accessories for your
simulator (and more!):
• PROJECTOR MOUNT KIT
• LIGHT BAR KIT
• RUNNER TURF (2’6” X 9)
• PRO TURF (6’ X 10’)
(pictured to the right and on first page)
Enjoy your Simulator Series NetReturn and please
don’t hesitate to contact us with any questions.
11
