Thermador CGB30RCULP Guide

Page 27
for
ThermadorChar Glo®Outdoor Barbecues
Models:
CGB30RCULP • CGB36RU
CGB48RU • CGB48RSBU
Care &Use Manual

Page 26
A Special Message to Our Customers
ThankyouforselectingtheThermador®CharGlo®outdoorbarbecue.We
recommendthatyoutaketimetoreadthisentirebookletbeforeusingyour
new appliance for the first time.
This booklet contains suggestions we believe will be helpful as well as
directionsforusingallthefeaturesofyourappliance.Keepitinahandyplace
as it has the answers to questions that may occur when you start to cook.
Letusknowifwecanhelpyou.Whenyouwritepleaseincludethemodeland
serial numbers of your barbecue.
Sincerely,
Thermador Test Kitchen Consumer Scientists

Page 1
TABLE OF CONTENTS
Warnings for Safe Gas Installations .......................................................... 2
ForYour Safety ........................................................................................................... 2
WhatTo Do IfYou Smell Gas ................................................................................. 2
Important Information ............................................................................................. 3
Warnings for Safe Gas Gas Installations .............................................................. 3
Warning: California Proposition 65 B.................................................................. 3
Section 1: Safety Practices toAvoid Personal Injury ....................... 4
Important Safety Instructions............................................................................. 4,5
Section 2: Model and Parts Identification ............................................. 6
Model CGB48RSBU.................................................................................................. 6
Model CGB48RU....................................................................................................... 7
Model CGB30RCULP............................................................................................... 8
Installation of LP (Propane) GasTank ................................................................... 9
LP Lighting Instructions............................................................................................ 9
Model CGB36RU.....................................................................................................10
Section 3: UsingYour Char Glo®Barbecue.........................................11
BeforeThe First Use...............................................................................................11
Lighting Instructions withAutomatic Ignition...................................................12
Lighting Instructions for Manual Lighting...........................................................13
Section 4: The Grill ........................................................................................ 14
General Grill Information......................................................................................14
Using the Grill ..........................................................................................................14
General Smoker Information................................................................................15
Using the Smoker ....................................................................................................15
Grilling Chart .................................................................................................... 16,17
Section 5: The Rotisserie .............................................................................18
Using the Rotisserie................................................................................................18
General Rotisserie Information ...........................................................................18
RotisserieAssembly ................................................................................................18
Trussing Poultry .......................................................................................................19
Rotisserie Chart ......................................................................................................20
Thermometer Gauge..............................................................................................20
Section 6: Extra Features........................................................................... 21
General Side Burner Information........................................................................21
Using the Side Burners.......................................................................................21
Side Shelf....................................................................................................................21
Section 7: CareAnd Maintenance...........................................................22
Quick Clean Method for Grates .........................................................................22
Quick Clean Method for the Grill.......................................................................22
Quick Clean Method for the DripTray..............................................................22
Cleaning Chart.........................................................................................................23
Section 8: Service............................................................................................24
Before Phoning for Service ...................................................................................24
Troubleshooting .......................................................................................................24
Section 9: Warranty .......................................................................................25

Page 2
TESTED IN ACCORDANCE WITH ANSI Z21.58-1995, STANDARD FOR OUTDOOR
COOKING GAS APPLIANCES AND CAN/CGA 1.6-M95, STANDARD FOR OUTDOOR
COOKING GAS APPLIANCES.
This unit is for outdoor use only in a well-ventilated area.Not to be
used in a building,garage or any other enclosed area.
Check your local building codes for the proper method of installation. In the absence of local codes this
unit should be installed in accordance with the National Fuel Gas Code No. Z223.1 Current Issue and
National Electrical Code ANSI/NFPA No. 70 Current Issue or the CAN/CGA - B149.1 Natural Gas
Installation Code or CAN/CGA - B149.2 Propane Gas Installation Code and C22.1 Canadian Electrical
Code Part 1.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Installer:Please leave these instructions with the unit for the owner.
Owner: Please retain these instructions for future reference.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open Lid.
• Ifodorcontinues,immediatelyphoneyour
gas supplier.
• If you cannot reach your gas supplier, call
the fire department.
AVERTISSEMENT
✓Ne pas entreposer ni utiliser de
l‘essence ni d’autres vapeurs ou
liquides inflammables dans le
voisinage de l’appareil,ni de tout
autre appareil.
FOR YOUR SAFETY
✓Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
S’ILYA UNE ODEUR DE GAZ:
• Coupez l’admission de gaz de l’appariel.
• Ènteindre toute flamme nue.
• Ouvrir le couvercle.
• Si l’odeur peraiste,appeler immediatement
votre compagnie de gaz ou votre
departement des incendies.
▲
!
WARNINGS FOR SAFE GAS INSTALLATIONS

Page 3
IMPORTANT INFORMATION
This outdoor gas cooking appliance is not intended to
beinstalled inoronrecreationalvehicles and/orboats.
Always inspect the natural gas or LP gas hose assembly
beforeeachuseoftheappliance. If thereisevidenceof
excessiveabrasionorwear,orifthehoseiscut,itmust
be replaced prior to the appliance being put into
operation. Replacement hose assemblies can be
purchasedatbarbecuesupplystores,ororderedthrough
Thermador® (see the rear cover for contact
information). If purchased at a retail outlet, the hose
assemblymustbeidenticaltotheonesuppliedwiththe
unit. Toinspectthehoseassemblyinsidetheunit,open
the left door on model CGB30RCULP or slide out the
leftstoragedraweronmodelsCGB36RU,CGB48RSBU
and CGB48RU.
Keeptheareaaroundtheapplianceclearandfreefrom
combustible materials, gasoline and other flammable
vapors and liquids.
Donotplace any itemsin front oftheunit while inuse.
This could obstruct the proper flow of air needed for
proper combustion and ventilation.
Keep the ventilation opening(s) of the LP cylinder
enclosure free and clear of obstructions and debris.
Keepanyelectricalsupplycordandthefuelsupplyhose
away from any heated surfaces.
Do not leave the grill unattended while cooking.
Theburningofgascookingfuelgeneratessomeby-
products that are on the list of substances which
are known by the State of California to cause
cancer or reproductive harm. California law
requiresbusinessestowarncustomersofpotential
WARNING: CALIFORNIA PROPOSITION 65 B
exposuretosuchsubstances.Tominimizeexposure
to these substances, always operate this unit
according to the instructions contained in this
bookletandprovidegoodventilationwhencooking
with gas.
WARNINGS FOR SAFE GAS INSTALLATIONS

Page 4
SECTION 1: SAFETY PRACTICESTOAVOID PERSONAL INJURY
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING YOUR BARBECUE
SAFETY PRECAUTIONS
Whenproperlycaredfor,yournewThermador®Char
Glo® barbecue has been designed to be a safe and
reliable appliance. However, extreme care must be
usedasthegrillproducesintenseheatandcanincrease
the potential for accidents or injury. When using this
appliance, basic safety precautions must be followed,
including the following:
• Read this manual carefully before using the
barbecue to reduce the risk of fire, electric shock, or
injury to persons.
•Insureproperinstallation.Followthe instructions
in Sections 3 through 5 in the Installation Instructions.
Have the installer show you where the gas supply
shutoff valve is located, and how to shut off the gas to
thebarbecue.Alwaysadheretotheminimumclearances
to combustible materials as specified in Section 3.
• Do not repair or replace any part of this
appliance unless specifically recommended in this
manual. All other servicing should be referred to a
qualified service technician.
•If you smellgaswhentheunitisnotinuse,havethe
unit checked for leaks as defined in Section 4. Finding a
gasleakisnotado-it-yourselfprocedureassomeleaks
can only be found with the burner control in the ON
position. This must be done by a qualified technician.
•If yousmell gas whentheunit isinuse, immediately
shut off all controls. Open the lid and let the gas
dissipateforat least fiveminutes. Relight theburner(s)
and verify that they are operating properly. If the
burner(s) fail to relight or are not operating properly,
shutof thegas tothe unitand havethe unitcheckedby
a qualified service technician. See Section 9.
• Children should not be left unattended in the
areawherethebarbecuebeingused.Neverallow
childrentosit,standorplayonoraroundthebarbecue
at any time. When in use, portions of the grill get hot
enough to cause severe burns. Children should never
be allowed to crawl inside the cart or enclosure.
•Toavoidthepotentialforagreasefire,frequently
clean the drip tray. Be sure to let the unit cool
completely before removing the tray for cleaning.
• This appliance is equipped with a three-prong
(grounding) plug for your protection against
shock hazard and should be plugged directly into a
properlygroundedthree-prongreceptacle.Donotcut
or remove the grounding prong from this plug.
• Be aware that spiders and insects can nest in
theburners of thisbarbecue.Thiscanobstructthe
proper flow of gas into the burner and cause improper
operation,firehazardandpotentialdamagetotheunit.
Inspect the burners periodically, or immediately if any
of the symptoms denoted in Section 8 exist.
•Thetopcover (hood) isto beclosed duringthe
outdoor cooking gas appliance preheat period.
• Never move barbecue with hood raised.
• Keep hands and fingers away from all edges of the
hood when it is in raised position.
WARNING: Never block vent opening at rear of
hood. Use with the vent opening
blocked will result in damage to the
unit and may cause a fire or injury.
LP TANK REQUIREMENTS
ModelCGB30RCULPisprovidedwithanLPtankfrom
the factory. All other units can be converted for use
with an LP tank which can be purchased locally at a
barbecue supply store or other retail outlet. The
maximum tank capacity for use with
Thermador® Char Glo® barbecues is twenty
pounds(fivegallons).Thetankmustbeconstructed
and marked in accordance with the specifications for
LP-gastanks oftheU.S.Departmentof Transportation
(DOT) or the National Standard of Canada, CAN/
CSA-B339, tank, Spheres and Tubes for the
Transportation of Dangerous Goods. To minimize the
potential for fire or an explosion, the following
precautions should be observed when using, filling or
storing an LP tank:
• Never use a dented or rusty LP tank. If there is
any question as to the soundness of the tank, have it
checked by your LP supplier.
• Never use a tank with a damaged or defective
shut off valve.
• Always close the tank shut off valve after use.

Page 5
FORYOUR SAFETY
For Outdoor Use Only. If stored indoors,
detach and leave tank outdoors.
AVERTISSEMENT
Pour utlilisation a la l’extérieur seulement.
Si l’appareil est entreposé à l’intérieur,
enlever les bouteilles et les laisser a
l’extérieur.
FORYOUR SAFETY
An LP tank not connected for use shall not
be stored in the vicinity of this or any other
appliance.
AVERTISSEMENT
Une bouteille de propane qui n’est pas
raccordée en vue de son utilisation,ne doit
pas etre entreposée dans le voisinage de cet
appareil ou de tout autre appareil.
•TheLPtankmustbedisconnectedandremoved
from the appliance if the appliance is to be stored
indoors.
•Alwayscheck forleaksaftereverytankchange.
See Section 6 of Installation Instructions.
FOR YOUR SAFETY
•The gas supply must be turned off at the
LP-gas supply tank when this outdoor cook-
ing gas appliance is not in use.
• The LP-gas supply cylinder must be dis-
connected when this outdoor cooking gas
appliance is not in use.
AVERTISSEMENT
• L’alimentation du gaz doit étre fennée a
la bouteille de gaz de pétrole liquéfié,
lorsque cet appareil de cuisson extérieur
n’ est pas utilisé.
• La bouteille d’alimentation en gaz de
pétrole liquéfié doit étre débranchée,
lorsque cet appareil de cuisson extérieur
n’est pas utilisé.
• Do not overfill the LP tank. Neverfillthe LPtank
beyond eighty percent (80%) of its capacity. Overfilling
will cause the pressure relief valve on the tank to vent
excess gas vapor. This vapor is combustible and can
ignite, causing a fire.
• When transporting an LP tank, insure it is in an
upright position and away from any sources of high
heat.
•DonotstoreadditionalLPtanksinsidethecart
of the unit. Tanks must be stored outdoors in a well-
ventilated area out of direct sunlight and/or sources of
high heat, and out of the reach of children.
• LP tank supply system must be arranged for
vapor withdrawal.
•LPtankusedmustincludeacollartoprotectthe
tank valve. CAUTION
Simultaneous operation of rotisserie
burners,smoker burner and grill burners on
the HI setting is not recommended.
Excessive temperatures could result.

Page 6
SECTION 2: MODELAND PARTS IDENTIFICATION MODEL CGB48RSBU
1. Hood / Lid with Handle
2. Thermometer Gauge andThermador Nameplate
3. Infrared Rotisserie Burner (1)
4. Rotisserie Motor
5. Rotisserie Glow Igniter
6. GrillGrates:
6 on Model CGB36RU and
CGB48RSBU
8 on Model CGB48RU
7. Radiants (heating baffles shown Page 7)
8. Burners: 3 on CGB36RU and CGB48RSBU
4 on CGB48RU
9. Drip Pan
10. SmokerTray
11. Control Knobs
12. Ignition Switch
13. Lighting Instructions on control panel
14. LP Container / Storage Cabinet
15. Storage Drawers
16. Side Burners (cover shown in close up)
17. Sure-Lock™ shelves (2) (packaged with panel kit
models C48FP,C48SBFP,C36FP purchased
separately).
18. Toe Kick Panel (not shown)
(packaged with 36 and 48 models)
19. Data Rating Label (left sidewall,inside storage
drawer)
20. Front Caster with Lock.
1
2
317
Front of
hood
20
19 14
15 12
10
11
9
13
8
6
4
16
5

Page 7
MODEL AND PARTS IDENTIFICATION MODEL CGB48RU
Side Panel not
furnished with
built-inmodels.
To install as a
free-standing
model,order
C36FP,C48 FP
or C48SBFP
panel kit.
(Purchase
separately)
Literature Pack Contents:
✓Product Registration Card – Please
complete and return. Thank You.
✓User's Manual:
Care & Use Recommendations
Grill /Rotisserie Cooking Charts
✓Installation Instructions
✓Orifices for LP Conversion
AGA and CGAApproved
20
Infrared
Rotisserie
Burners (2)
Ergo Balanced Hood
7
153
20
Rotisserie Glow
Igniters (2)

Page 8
CAUTION FOR LP HOOK-UPS:
Do not turn off Gas Regulator or Main Tank
Valve while grill is still hot. Wait until it cools.
MODEL CGB30RCULP – Free Standing
1. Hood / Lid with Handle
2. Thermometer Gauge andThermador Nameplate
3. Infrared Rotisserie Burner
4. Rotisserie MotorAssembly
5. Rotisserie Glow Igniter
6. GrillGrates:
5 on Model CGB30RCULP
7. Radiants (heating baffles shown on Page 7)
8. Burners: 2 on CGB30RCULP – Packaged for LP
use only
9. Drip Pan (Behind LP Storage Door)
11. Control Knobs
12. Ignition Switch
13. Lighting Instructions on control panel
14. LP Storage
17. Sure-Lock™ Shelves
19. Data Rating Label (left sidewall,inside storage
compartment)
20. Front Casters with Locks - move barbecue into
place and lock front casters.Push down on the
lever with toe of your shoe to lock wheel.
1
2
3
4
8
7
6
5
9
11
12
13
14
17
Front of
hood
19 20
Literature Pack Contents:
✓ProductRegistrationCard –Pleasecompleteand
return. Thank You.
✓User's Manual:
Care & Use Recommendations
Grill /Rotisserie Cooking Charts
✓Installation Instructions
✓Orifices for converting to natural gas
AGA and CGAApproved

Page 9
INSTALLATION OF LP (Propane) GAS TANK
IN A CGB36/48
LP (Propane) Lighting Instructions
1. Raise hood/lid.
2. Turn on Main Tank Valve to open gas supply.
3. Light one burner at a time.
4. Turncontrolknobtothe"Lite"positionandimmediatelypressandholdtheignitionswitch.
The burner will light within 4 to 10 seconds.
5. Release ignition switch after burner ignites.
6. After cooking, turn off burners and allow to cool.
Tank Gas
Regulator
MainTankValve
Gas Hose – 24"
(Order LP Hose
Accessory)
LP GasTank

Page 10
MODEL AND PARTS IDENTIFICATION MODEL CGB36RU
1
2
3
8
7
6
5
9
10
11
13
14
15
On front
of hood
12
1. Hood / Lid with Handle
2. Thermometer Gauge andThermador Nameplate
3. Infrared Rotisserie Burner (1)
4. Rotisserie Motor
5. Rotisserie IgniterAssembly
6. GrillGrates:
6 on Model CGB36RU
7. Radiants (heating baffles shown Page 7)
8. Burners: 3 on CGB36RU
9. Drip Pan
10. SmokerTray
11. Control Knobs
12. Ignition Switch
13. Lighting Instructions
14. LP Container / Storage Cabinet
15. Storage Drawers
16. Side Burners (cover shown in close up)
17. Sure-Lock Shelves (2) (packaged with panel kit
models C36FP purchased separately).
18. Toe Kick Panel (not shown)
(packaged with 36 and 48 models)
19. Data Rating Label (left sidewall,inside storage
drawer)
20. Front Caster with Lock.
Literature Pack Contents:
✓ProductRegistrationCard –Pleasecomplete and
return. Thank You.
✓User's Manual:
Care & Use Recommendations
Grill /Rotisserie Cooking Charts
✓Installation Instructions
✓Orifices for LP Conversion
AGA and CGAApproved
Side Panel not furnished
with built-in models.
To install as a free-
standing model,order
C36FP,C48 FP or
C48SBFP panel kit.
(Purchase separately)
(inside drawer)
19

Page 11
If you smell gas,do not attempt to
light any burners.
1. Make sure that all control knobs are turned to
the OFF position.
2. Open the hood to allow any accumulated gas to
dissipate and wait five minutes before trying to
light the unit.
3. If the smell of gas is still present, turn off the gas
supply to the unit at the manual shut off valve.
4. Check the unit for leaks by following the
instructions in Section 6 in the Installation
Instructions or call your authorized servicer or
the gas company.
SECTION 3: USINGYOUR CHAR GLO® BARBECUE
Before the First Use
1. Recordmodelandserialnumberofyourbarbecue
for future contacts with Thermador®or an
authorized servicer (Located on left-side LP
storage drawer).
2. Burnoffresidualmanufacturingoils.FollowMain
Burner Lighting Instructions:
✓Turn all burners on HI setting for 15 - 20
minutes with hood/lid down.
✓Cool.
3. Prepare for use.
✓Optional step: Line drip tray with heavy-duty
aluminumfoil and a thin layer ofsand or bird
gravel.
✓Protectthefinishwithastainlesssteelcleaner
or protective polish. See care suggestions
Page 23.
WARNING
Openhood/lidbefore attemptingtolight theappliance. Failureto
openthe hoodcould allowgastoaccumulatewhichcouldcausean
explosion

Page 12
Main and Smoker Burners:
1. Raise hood/ lid.
2. Light only one burner at a time.
3. Alwaysturncontrolknobtothe“Lite”positionand
immediatelypressandholdtheignitionswitch.The
burner will light within 4 -10 seconds.
4. Release ignition switch after burner ignites. Look
for the flame to check that it is lit. For the smoker
burner, pull drawer open to see the flame.
5. Repeatproceduresuntildesirednumberofburners
are lit.
6. Adjust control knobs to the suggested preheat
flame setting. Refer to the Grill Cooking Chart
Pages 16 and 17.
SECTION 3: USINGYOUR CHAR GLO® BARBECUE
Infrared Rotisserie Burner:
1. Raise hood / lid.
2. IMPORTANT NOTE: Make sure the control
knobissettothe“LITE”positionwhenlighting
the infrared burner. Confirm that the burner
haslitwithin30 - 45 seconds. The flame will be
blue initially.
3. Allow the burner to operate on "HI" until it
beginstogloworange/red(typically2-3minutes)
beforeadjustingthecontrolknobtothedesired
flame setting.
3. Adjust control knob to the suggested flame
setting. Refer to the Rotisserie Cooking Chart
Page 20.
Side Burner/s:
1. Remove stainless steel cover; set aside.
2. Turncontrolknobtothe“Lite”andimmediately
press ignition switch. The burner will light
within 4 -10 seconds.
3. Adjustcontrolknobtothedesiredflamesetting.
LIGHTING INSTRUCTIONSWITHAUTOMATIC IGNITION
– Read Before Lighting –

Page 13
Follow these steps to light the Main Burners manually:
1. Turn off all the burners.
2. Wait 5 minutes to allow any accumulated gas to dissipate.
Use a long stem match to light manually:
3. Remove the grill grates.
4. Findtheportsontopoftheburnerbylooking
throughtheopeningatthe end of theradiant.
Keep your hands and face as far away
from the burner as possible.
5. Place the lighted long-stem match through
theholeintheradiant(seeillustrationabove).
This position is near the burner ports.
6. Turn the knob to the LITE position. The
burner will light within 4 to 10 seconds.
SECTION 3: USINGYOUR CHAR GLO® BARBECUE
MANUAL LIGHTING INSTRUCTIONS**
– Read Before Lighting –
Follow these steps to light the Smoker
manually:
1. Turn off all the burners.
2. Wait 5 minutes to allow any accumulated gas
to dissipate.
3. Remove the smoker tray.
4. Find the ports on top of the smoker. Keep
yourhandsandfaceasfarawayfromthe
burner as possible.
5. Place the lighted match through the opening
for the smoker tray and next to the burner
ports.
6. Turn the knob to the LITE position. The
burner will light within 4 to 10 seconds.
**NOTE:Theinfraredrotisserieburnercan-
not be lit manually.
Access Hole for Manual Lighting
Middle section
of radiant

Page 14
GENERAL GRILL INFORMATION
• Thaw food items before grilling.
• Preheating provides the high heat needed to brown and seal in juices.
• After preheating, reduce the flame to setting listed on Grilling Chart.
• The flame setting positions on the knobs are infinite.
• The degree of doneness is influenced by the type of meat, cut of meat (i.e. size, shape and
thickness), heat setting selected, and length of time on the grill.
• Shortenthepreheattimewhengrillinghigh-fatcutsofmeatorpoultry,suchaschickenthighs.
This will help reduce flare-ups.
• Lightly oil grill when cooking low-fat cuts of meat, fish or poultry, such as lean hamburger
patties, shrimp or skinless chicken breasts.
• For best results food should be turned only once.
• Avoid puncturing or cutting the meats to test doneness. This would allow juices to escape.
• Select the “Heating Method”:
USING THE GRILL
1. Refer to the Grilling Chart, Pages 16 and 17, to select the heating method: Direct or Indirect.
2. Follow directions for lighting the burner/s on Page 13.
3. Preheat a minimum of two adjacent burners about 10 minutes with the hood down.
4. After preheating with indirect heat, turn off burner that food is placed over.
4. Estimate the grilling time according to the suggestion on the Grilling Chart.
5. For CGB30 models using a propane gas tank, close the valve on the tank after grill cools.
Note: If all grill burners are in use, a five gallon LP tank can be used for 3-1/2 hours of cooking.
SECTION 4: THE GRILL
◆DirectHeat means thatthefood iscookeddirectly overoneoftheheatedburners.
1. Hood can be up or down. 2. Hood position affects total cooking time.
◆Indirect Heat means the food is placed to either side of the heated area, as on the
CGB30(30"wide)model.On36"or48"widthmodels,thefoodisplacedinthemiddle
and one or both outer grill burners are turned on.
• For best results, turn on at least two burners even when cooking over just one.
Cook with the hood down. This will speed up the cooking time.
• Do not select Indirect Heat when it is windy.
• When using a high flame, add barbecue sauce to food during the last 10 minutes before
removing from grill.
CAUTION: Never attempt to move barbecue with hood raised.
Indirect Heating Method – Model CGB36RU
Place food
over center
burner
Center
burner OFF Right burner ON
Left burner ON

Page 15
USING THE SMOKER
1. Soak wood chips in water as directed on the package. This may take as long as 30 minutes.
2. Prepare the food for cooking on the grill or rotisserie.
3. Once chips are soaked, fill back half of tray.
4. Light smoker burner according to directions on Page 12, then close tray.
5. Set smoker control to the HI setting.
6. Light the grill or rotisserie according to the directions on Page 12.
7. Add a handful of soaked chips every 15-20 minutes.
Do not pull drawer out completely to avoid spilling hot embers. Open about 12 inches
only.
8. Turn smoker to medium if chips burn away too quickly.
9. Aftercookingiscomplete,lettheappliancecoolbeforecleaning.Toremoveashes,simplyremove
the tray by sliding it forward.
Wood Chip
Smoker
Tray
GENERAL SMOKER INFORMATION
• The Smoker is used with the hood down and in combination with the grill or rotisserie.
WARNING: Never block vent opening at rear of hood. Use with the vent
opening blocked will result in damage to the unit and may cause a fire or injury.
• The smoker is used to enhance flavors.
• The smoker tray is designed for small size wood chips.
• The type of wood chips (mesquite, hickory, etc.) will determine the smoke flavor.
• Theamountofchips,flamesettingandlengthofcookingtimedeterminethedegreeofsmoke
flavor.
• Always soak wood chips in water prior to using in the smoker tray.
• Additional chips can be added every 15 minutes to the back of the tray during cooking to
maintain continuous smoke.

Page 16
Grilling Chart
USINGTHE CHART:
• Knobs have HIGH, MEDIUM and LOW setting for flame adjustment.
• Heat settings indicated above are approximate.
* • Grilling time based on heating two adjacent burners with food placed on grate between
burners (Direct).
• Timings are affected by weather conditions.
BEEF:
Ground Beef Patties 3/4" thick Direct Med Hi No pink color 10 - 15 min. total
Roasts:
Rib Eye, Sirloin 4 to 6 lbs Indirect Med/0/Med 140°Med Rare 15 - 20 min.per lb.
150°Med 20 - 25 min.per lb.
TriTip 2" thick Indirect Med/0/Med Medium Rare 25 - 35 min. total
Steaks:
Porterhouse,Rib, 1" thick 135°Rare
T-Bone,Top Loin Direct Med Hi 150°Medium 8 - 12 min. total
Porterhouse,Rib, 1-1/2" thick Direct Med Hi 135°Rare 14 - 18 min. total
T-Bone Top Loin 150°Medium
Top Round or 1-1/2" to 2" Direct Med 135°Rare 14 - 18 min. total
London Broil thick 150°Medium 18 - 22 min. total
Flank 3/4"
to 1" thick Direct Med 140°Med Rare 10 - 15 min. total
150°Medium 15 - 20 min. total
PORK:
Chops 1-1/4" - 1-1/2" Indirect Med/0/Med 160°Well Done 35 - 40 min. total
Ribs 2 1/2 to 4 Ibs. Indirect Med/0/Med Well Done 1to1-1/2 hours total
Roasts,boneless
Top Loin - Single 2 to 4 lbs. Direct Med 160°Well Done 30 min. total
Roasts,boneless
Double Loin (tied) 3 to 5 lbs . Indirect Med/0/Med 160°Well Done 2 – 3 hours total
Ham Steak 1" thick Direct Med 165ºWell Done 16 - 18 min. total
THICKNESS/ GRILL BURNER INTERNAL DONENESS APPROXIMATE
FOOD ITEM WEIGHT METHOD SETTING OR TEMPERATURE (ºF) GRILLING TIME*

Page 17
Grilling Chart
THICKNESS/ GRILL BURNER INTERNAL DONENESS APPROXIMATE
FOOD ITEM WEIGHT METHOD SETTING OR TEMPERATURE (ºF) GRILLING TIME
CHICKEN:
Breasts,boneless pounded to 3/4 Direct Medium Juices run clear 8 - 12 min. total
inch thick
Pieces 2 - 3 lbs. Direct Med Low 170°- breast 25 - 45 min. total
180°- thigh
Halves 1 1/2 - 2 Ibs. Direct Med Low 170°- breast 35 - 60 min. total
each half 180°- thigh
Whole 2 - 3 pounds Indirect Med /0/ Med 170°- breast
50 min. - 1-1/4 hrs. total
3 - 5 pounds 180°- thigh 1 - 1-1/2 hrs. total
CORNISH GAME 170°- breast
HENS: Halved Direct Medium 180°- thigh 35 - 50 min. total
Whole Indirect Med/0/Med Juices run clear 45 - 60 min.Total
TURKEY,whole: 10
- 13 pounds Indirect Med/0/Med 170°- breast 11 - 13 minutes
180°- thigh per lb.
Breast,half 2 - 3 pounds Indirect Med/0/Med 170°- breast 18 - 22 minutes
Breast,whole 5 - 8 pounds Indirect Med/0/Med 170°- breast 16 - 19 minutes
per lb.
LAMB:
Chops
(Loin,Rib,Sirloin) 1" thick Direct Med 145°- Med Rare 10 - 14 min. total
160°- Medium 14 - 16 min. total
Chops
(Loin,Rib,Sirloin) 2"thick Direct Medium 145°- Med Rare 13 - 16 min.Total
160°- Medium 15 - 19 min.Total
FISH:
Fillets,Steaks, 1/2" - 1-1/2" Direct Medium Flakes with a fork. 4 - 6 minutes per
Chunks each 1/2" of fish
Whole Morethan 1 lb. Direct Medium Flakes with a fork. 10 - 15 min. per
inch thick
SHELLFISH:
Scallops Direct Med Hi Opaque 4 - 8 min. with
hood up
Shrimp Direct Med Hi Opaque 4 - 8 min. with
hood up

Page 18
SECTION 5: THE ROTISSERIEANDASSEMBLY
Arrange Food on the
Skewer
1. Slide one fork onto the skewer
as shown above, according to the
model.
2. Insert the skewer through the
center of the food and center it
lengthwise.This willalignit withthe
Infrared burner.
3. Slide the second fork onto the
skewer; push both forks into the
food. Centered lengthwise, tighten
the thumb screws.
4.Check the balance of the food on
the skewer by rolling the skewer in
Rotisserie Assembly for Model CGB48R
Showing Position of Grooves on Skewer
General Rotisserie
Information
• Glow igniter for Infrared burner
remainson entiretime therotisserie
is on.
• Rotisserie cooking rotates food in
front of the Infrared burner.It cre-
ates an intense heat for searing the
outside and sealing in the juices.
•TheInfraredburner reachescook-
ing temperatures in about one
minute and the orange-red glow
evens out in about 5 min.
Do not
preheat when using the rotisserie.
• Select tender meat and poultry
that will allow at least 1" of space
betweentheInfraredburnerand the
grates.
• Can be used in combination with
the Smoker and / or the Grill. For
example, cook a beef roast on the
rotisserieandchickenpieces onthe
grill.
•To make a gravy or clean up easier,
place a pan under the food to catch
the drippings.
• Add a barbecue sauce or glaze
during the last 10 minutes of cook-
ing to prevent it from burning.
WARNING: Never block
vent at the rear of the hood.
Use with the vent opening
blocked will result in damage
to the unbit and may cause a
fire or injury.
the palms of your hands.Food not
evenlybalanced willnot cookevenly.
5.Truss the food with kitchen string
to ensure an even shape and secure
the food in position.Tighten the
thumbscrewswith pliersto flatside
of hexagonal rod. See details on
Page 19
6.Attach handle to skewer.
Assemble Rotisserie
•On modelCGB48RSB,remove the
handle when using the side burner.
Failure to remove it will cause the
handle to melt.
1.Raisehood andplace thesteelleg
of the motor between the left side
trim and the burner box, into the
pocket,as shown above.
2.Keep the power cord away from
the heated sections of the grill.
3.Before plugging the cord into the
receptacle,be surethatthe On/ Off
switch on the motor is turned Off.
4. Place the pointed end of the
skewer into the motor drive shaft.
Make sure it is fully engaged.
5.Rest the handleend oftheskewer
inthesupport bracket notchonthe
right side of the grill.
6. Turn on motor to check for
smoothrotation.Readjusttobalance
rotation, if necessary.Turn off until
Step #7.
7.Turn RotisserieburnertoLitethen
turn on the motor.Do not push ig-
nition.Theinfraredburnerlights au-
tomatically when knob is set at Lite
position. Once lit, adjust knob to
heat setting.
8. Close hood. Refer to Rotisserie
Chart page 20.Use meat thermom-
eter to check for doneness.
Skewer with
center line
indicator Heat edge
indicator
Heat edge
indicator
Rotisserie Assembly for Models CGB30, 36, 48RSB
Motor
Drive Shaft
Fork
Thumb Screw
On/Off Switch
Motor
Cord
Slot to insert
motor support
bracket
Handle
Slot that
rests on
support
arm
Motor Support
Bracket
