Care & Use Manual
30-inch Electric Ranges
© 2003 BSH Home Appliances Corp.

30-Inch Electric Range Care and Use Manual
TABLE OF CONTENTS
Safety Instructions ................2-5
Operating Instructions
Features of Your Range ......................... 6, 7
What You Will Hear & See........................ 8
Cooktop
Cooktop Comparison ................................ 9
Proper Cookware ..................................... 11
Cooktop Operation ............................ 11, 12
Heat Setting Chart ................................... 13
Oven
Oven Contro} Features ............................ 14
Setting the Clock/Timer ......................... 15
Child Lockout........................................... 16
Setting the Oven - Bake/Convection .... 17
Setting the Oven - Broiling ..................... 17
Setting the Oven - Auto Cook ................ 18
Setting the Oven - Delay Auto ............... 19
Setting the Oven - To Change Auto Cook .... 20
Using the Oven
Oven Racks ............................................... 21
Slow Cooking/Holding Foods .............. 21
General Oven Tips ................................... 22
Bake Techniques....................................... 23
Convection Techniques ........................... 24
Broil Techniques ....................................... 25
Baking / Roasting / Broiling Charts.. 26 - 33
Food Safety Guidelines ........................... 30
Care and Cleaning
Self-Cleaning the Oven ..................... 34, 35
Range Cleaning ........................................ 36
Range Finishes/Cleaning Method ........ 37
Cleaning the Glass Ceramic Cooktop ... 38
Cook’nVent®Care and Cleaning...... 40, 41
Cook’n’Vent®
Cook’n’Vent®Operation ......................... 39
Cook’nVent®Care and Cleaning...... 40, 41
Problem Solver
Do-It-Yourself Maintenance ............. 42, 43
Solving Baking Problems........................ 44
Solving Operational Problems ............... 45
How To Obtain Selvice............................ 45
Consumer Services
Warranty.................................................... 46

30-Inch Electric Range Care and Use Manual
A Special Message to Our Customers
Thank you for buying a Thermador®Range. We recommend that you take
the time to read this entire booklet before using your new appliance.
Before you use the cooktop, the glass ceramic surface must be thoroughly
cleaned with the Cooktop Cleaning Cream®. The cleaning cream helps to
protect the smooth-top surface and guarantees a clean cooking surface. To
maintain the cooktop’s appearance, read page 40 for “Daily 3 step care” of
the glass ceramic cooktop.
We hope that the information in this manual helps you easily operate and
care for your range for years of satisfaction.
Please contact us if you have any questions or comments. Thermador’s ad-
dress and phone number are listed on Page 45 and on the back cover of this
manual.
Sincerely,
Thermador Test Kitchen Consumer Scientists
