Thermador KBUIT4255E User manual

INSTALLATION
INSTRUCTIONS
For Built-in Refrigerators
INSTRUCCIONES DE
INSTALACIÓN
Para los refrigeradores
empotrados
INSTRUCTIONS
D’INSTALLATION
Pour réfrigérateurs encastrés
Side by Side Models/
Modelos con dos puertas/
Modèles côte à côte
KBUIT4255E, KBUDT4255E
KBUIT4265E, KBUDT4265E
KBUIT4275E, KBUDT4275E
KBUIT4855E, KBUDT4855E
KBUIT4865E, KBUDT4865E
KBUIT4875E, KBUDT4875E
W10291427A

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY........................................................................... 3
DESIGN SPECIFICATIONS......................................................................... 4
Models - Side by Side Non-Dispensing Refrigerators ............................. 4
Models - Side by Side Dispensing Refrigerators ..................................... 5
Product Dimensions ................................................................................. 6
Tipping Radius.......................................................................................... 7
Door Swing Dimensions ........................................................................... 7
Handle and Door Clearances for Custom Panel Series...........................8
Custom Panels........................................................................................10
Full-Overlay Custom Panels ...................................................................12
Stainless Steel Series Side Panels .........................................................13
Custom Panel Series Side Panels .......................................................... 14
INSTALLATION REQUIREMENTS ...........................................................14
Tools and Parts.......................................................................................14
Location Requirements........................................................................... 15
Electrical Requirements..........................................................................16
Water Supply Requirements...................................................................16
INSTALLATION INSTRUCTIONS............................................................. 17
Unpack the Refrigerator ......................................................................... 17
Reduce Tipping Radius .......................................................................... 17
Move the Refrigerator into House .......................................................... 17
Install Anti-Tip Boards ............................................................................ 18
Connect the Water Supply ..................................................................... 18
Plug in Refrigerator................................................................................. 20
Move Refrigerator to Final Location....................................................... 20
Lower Leveling Legs............................................................................... 20
Install Custom Panels............................................................................. 20
Level Refrigerator.................................................................................... 21
Adjust Doors ........................................................................................... 22
Install Side Panel .................................................................................... 22
Install Base Grille .................................................................................... 22
Complete Installation.............................................................................. 23
Water System Preparation ..................................................................... 23
ÍNDICE
SEGURIDAD DEL REFRIGERADOR........................................................24
ESPECIFICACIONES DE DISEÑO ........................................................... 25
Modelos - Refrigeradores de dos puertas sin despachador................. 25
Modelos - Refrigeradores de dos puertas con despachador................26
Medidas del producto.............................................................................27
Arco de vuelco ........................................................................................28
Medidas de oscilación de las puertas....................................................28
Espacios para la agarradera y la puerta para
la serie de paneles a la medida ..............................................................29
Paneles a la medida................................................................................31
Paneles a la medida totalmente recubiertos.......................................... 33
Paneles laterales de la serie de acero inoxidable ..................................34
Paneles laterales para la serie de paneles a la medida .........................35
REQUISITOS DE INSTALACIÓN..............................................................35
Piezas y herramientas.............................................................................35
Requisitos de ubicación .........................................................................36
Requisitos eléctricos............................................................................... 37
Requisitos del suministro de agua ......................................................... 37
INSTRUCCIONES DE INSTALACIÓN...................................................... 38
Cómo desempacar su refrigerador ........................................................ 38
Cómo reducir el arco de vuelco ............................................................. 38
Cómo hacer entrar el refrigerador en la casa ........................................ 39
Cómo instalar los tableros antivuelco .................................................... 39
Conexión del suministro de agua........................................................... 40
Cómo enchufar el refrigerador ............................................................... 41
Cómo mover el refrigerador a su ubicación final................................... 42
Baje las patas niveladoras...................................................................... 42
Cómo instalar los paneles a la medida .................................................. 42
Cómo nivelar el refrigerador................................................................... 43
Cómo ajustar las puertas ....................................................................... 43
Cómo instalar el panel lateral ................................................................. 44
Cómo instalar la rejilla de la base........................................................... 44
Cómo terminar la instalación.................................................................. 45
Preparación del sistema de agua........................................................... 45
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ...........................................................46
SPÉCIFICATIONS DE DESIGN.................................................................47
Modèles - Réfrigérateurs côte à côte sans distributeur.........................47
Modèles - Réfrigérateurs côte à côte avec distributeur.........................48
Dimensions du produit............................................................................49
Rayon de basculement...........................................................................50
Dimensions pour l'ouverture des portes ................................................50
Dégagements pour les poignées et portes pour
la série de panneaux personnalisés .......................................................51
Panneaux personnalisés......................................................................... 53
Panneaux de revêtement personnalisés ................................................55
Panneaux latéraux de la série de panneaux en acier inoxydable..........56
Panneaux latéraux de la série de panneaux personnalisés...................57
EXIGENCES D’INSTALLATION................................................................57
Outillage et pièces .................................................................................. 57
Exigences d’emplacement .....................................................................58
Spécifications électriques ......................................................................59
Spécifications de l’alimentation en eau..................................................59
INSTRUCTIONS D’INSTALLATION ......................................................... 60
Déballage du réfrigérateur...................................................................... 60
Réduction du rayon de basculement..................................................... 60
Faire entrer le réfrigérateur dans le domicile.......................................... 61
Installation de planches antibasculement.............................................. 61
Raccordement à l'alimentation en eau................................................... 62
Brancher le réfrigérateur......................................................................... 63
Déplacement du réfrigérateur à l'emplacement final............................. 64
Déploiement des pieds de nivellement .................................................. 64
Installation des panneaux personnalisés ............................................... 64
Nivellement du réfrigérateur ................................................................... 65
Ajustement des portes............................................................................ 66
Installation du panneau latéral................................................................ 66
Installation de la grille de la base ........................................................... 67
Achever l’installation............................................................................... 67
Préparation du système d’eau ............................................................... 67

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

4
DESIGN SPECIFICATIONS
Models - Side by Side Non-Dispensing Refrigerators
Stainless Steel Series
Features stainless steel exterior styling.
KBUIT4255E KBUIT4265E
KBUIT4855E KBUIT4865E
Custom Panel Series
Features factory-installed, traditional style trim to provide a
“framed” look. This series requires the installation of custom
panels that are not included.
KBUIT4275E KBUIT4875E
TRIMKITSXS - Trimless Trim Kit
On the Custom Panel Series, you can create a “frameless” look
using full-overlay custom panels. You will need to order a
Trimless Trim Kit for Side by Sides TRIMKITSXS. This accessory
kit contains parts to replace the factory trim.
Full-overlay custom panels and handles are required but not
included in the accessory kit. Create the panels according to the
specifications in the “Full-Overlay Custom Panels” section. You
can order a set of Thermador’s Handles or select handles from
another source. For door clearances, see “Handle and Door
Clearances for Custom Panel Series.”
Handle Kits
For use with Stainless Steel models. You can purchase a handle
type other than that provided with your model. See your dealer for
Details.
CURVHNDL10 - Curved Handle Kit
PROHNDL160 - Pro Handle Kit
PROHNDL165 - Designer Pro Handle Kit
MASTHNDL55 - Masterpiece Handle Kit
EXTHANDSXS - Extended Handle Kit for Side by Sides
This kit may be required if you install a custom raised panel. See
“Handle and Door Clearances for Custom Panel Series.”

5
Models - Side by Side Dispensing Refrigerators
Stainless Steel Series
Features stainless steel exterior styling.
KBUDT4255E KBUDT4265E
KBUDT4855E KBUDT4865E
Custom Panel Series
Features factory-installed, traditional style trim to provide a
“framed” look. This series requires the installation of custom
panels that are not included.
KBUDT4275E KBUDT4875E
TRIMKITSXS - Trimless Trim Kit
On the Custom Panel Series, you can create a “frameless” look
using full-overlay custom panels. You will need to order a
Trimless Trim Kit for Side by Sides TRIMKITSXS. This accessory
kit contains parts to replace the factory trim.
Full-overlay custom panels and handles are required but not
included in the accessory kit. Create the panels according to the
specifications in the “Full-Overlay Custom Panels” section. You
can order a set of Thermador’s Handles or select handles from
another source. For door clearances, see “Handle and Door
Clearances for Custom Panel Series.”
Handle Kits
For use with Stainless Steel models. You can purchase a handle
type other than that provided with your model. See your dealer for
Details.
CURVHNDL10 - Curved Handle Kit
PROHNDL160 - Pro Handle Kit
PROHNDL165 - Designer Pro Handle Kit
MASTHNDL55 - Masterpiece Handle Kit
EXTHANDSXS - Extended Handle Kit for Side by Sides
This kit may be required if you install a custom raised panel. See
“Handle and Door Clearances for Custom Panel Series.”

6
Product Dimensions
Side View
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 25¹⁄₈" (64 cm).
■The power cord is 84" (61 cm) long.
■The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (32 mm) below
rollers, add 1¹⁄₈" (29 mm) to the height dimensions.
Top View
Front View
■Width dimensions were measured from trim edge to trim
edge.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (32 mm) below
rollers, add 1¹⁄₈" (29 mm) to the height dimensions.
Model Width A
42" (106 cm)
48" (122 cm) 41" (104 cm) 47" (119 cm)
A
23¹⁄₂"
(59.7 cm)
84" (213.4 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (8.9 cm)
25¹⁄₈"
(64 cm)
A
Model Width A (Trim edge to trim edge)
42" (106 cm)
48" (122 cm) 42¹⁄₄" (107 cm) 48¹⁄₄" (123 cm)
*83³⁄₈"
(211.8 cm)
A
(see chart following)

7
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
■If needed, the tipping radius can be reduced. See “Reduce
Tipping Radius.”
Side Tipping Radius
The side tipping radius varies depending upon the width of the
model. Use the chart provided to determine the side tipping
radius.
NOTE: Tip on side only.
Door Swing Dimensions
The location must permit both doors to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels or custom handles.
To adjust the door swing, see “Adjust Doors.”
42" (106 cm) Models
48" (122 cm) Models
Model Tipping Radius A
42" (106 cm)
48" (122 cm) 93" (236.2 cm) 96" (243.8 cm)
A
130˚
130˚
90˚
90˚
110˚
110˚
47⁷⁄₈"
(121.6 cm)
41¹⁄₂"
(105.4 cm)
16⁷⁄₈"
(42.9 cm)
12⁵⁄₈"
(32.1 cm)
37¹⁄₄"
(94.6 cm)
41³⁄₈"
(105.1 cm)
130˚
130˚
90˚
90˚
110˚
110˚
51 ³⁄₈ "
(130.5 cm)
44"
(111.8 cm)
19
¹⁄₄ "
(48.9 cm)
14
³⁄₈ "
(36.5 cm)
39"
(99.1 cm)
43
⁷⁄₈ "
(111.4 cm)

8
Handle and Door Clearances for Custom Panel Series
If you are installing custom panels, the panels must allow certain clearances for the handles and for the doors to swing open. An
Extended Handle Kit may be required if you install a custom raised panel. See the “Models” section under “Design Specifications.”
1/4" (6.35 mm)
1/2" (1.3 cm)
3/4" (1.9 cm)
1" (2.5 cm)
11/4" (3.2 cm)
11/2" (3.8 cm)
13/4" (4.4 cm)
2" (5.1 cm)
21/4" (5.7 cm)
21/2" (6.4 cm)
23/4" (7 cm)
3" (7.6 cm)
1"
(2.5 cm)
2"
(5.1 cm)
3"
(7.6 cm)
Door
Custom Panel
Handle Dimensions
Actual Size
Custom
Panel
Series
Handle
Optional
Extended
Handle

9
Door Swing 110˚
Actual Size
Custom Panel Series
Clearances for
Full-Overlay Custom Panels
NOTE: To use full-overlay custom panels, you
must order the Trimless Trim Kit. Additionally,
you will need to order either a set of
Thermador's Handles or select handles from
another source. See the “Models” section of
“Design Specifications” for more information
and specific kit.
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
11/4" (3.2 cm)
11/2" (3.8 cm)
1/2" (1.3 cm)
1/4"
1/2"
3/4"
1"
11/4"
11/2"
13/4"
2"
3/4"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Spacer Panel
Custom Panel
(6.35 mm)
(1.3 cm)
(1.9 cm)
(2.5 cm)
(3.2 cm)
(3.8 cm)
(4.4 cm)
(5.1 cm)
(1.9 cm)
(1.3 cm)

10
Custom Panels
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT: Panels weighing more than recommended may
cause damage to your refrigerator.
NOTE: Dimensions shown have a (±)¹⁄₁₆" (1.5 mm) tolerance.
Panels that are more than ¹⁄₄" (6 mm) thick must be routed. If
panels are less than ¹⁄₄" (6 mm) thick, install a filler panel between
the doors and decorative panels.
Top Grille Panel
The top panel should not weigh more than 10 lbs (4.5 kg) total
weight.
Door Panels for Non-dispenser Models
The freezer panel should not weigh more than 30 lbs (13.5 kg)
total weight. The refrigerator panel should not weigh more than
50 lbs (23 kg) total weight.
Door Panels for Dispenser Models
The two freezer panels combined should not weigh more than
30 lbs (13.5 kg) total weight. The refrigerator panel should not
weigh more than 50 lbs (23 kg) total weight.
Model A
42" (106.6 cm)
48" (122 cm) 40¹⁄₂" (105 cm) 46¹⁄₂" (120 cm)
Model A B
42" (106.7 cm)
48" (122 cm) 16³⁄₄" (42.5 cm) 19¹⁄₄" (48.9 cm) 22³⁄₄" (57.8 cm) 26¹⁄₄" (66.8 cm)
A
7"
(17.8 cm)
70¹⁄₂"
(179.1 cm)
A B
Model A B
42" (106.6 cm)
48" (122 cm) 16³⁄₄" (42.5 cm) 19¹⁄₄" (48.9 cm) 22³⁄₄" (57.8 cm) 26¹⁄₄" (66.8 cm)
70⁷⁄₁₆"
(179 cm)
23⁷⁄₁₆"
(59.5 cm)
34⁷⁄₁₆"
(87.4 cm)
A B

11
Top Grille Panel – Routing Requirements
Top and bottom edges of the top panel should be edge routed
¹⁄₂" (1.3 cm) and ³⁄₈" (9.5 mm), respectively. Both ends should be
edge routed ⁷⁄₈" (2.2 cm) as shown.
NOTE: When creating a panel with face detail, the offsets will be
hidden and must be accounted for in order to center the detail in
the top grille.
Door Panels – Routing Requirements
If an extended handle kit is used, then routing the handle side of
the panels is not required. See “Handle and Door Clearances” for
more information on ordering extended handles.
If the standard handle is used, rout the entire handle side of both
panels 3¹⁄₄" (8.25 cm) to allow for finger clearance. Then rout the
other sides 1" (2.54 cm).
Standard Handle – Top View
Door Panel - Side View
¹⁄₄"
(6.35 mm)
max.
⁷⁄₈"
(2.2 cm)
Top
Grille
¹⁄₄"
(6.35 mm)
max.
⁷⁄₈"
(2.2 cm)
Top
Grille
¹⁄₂"
(1.3 cm)
min.
¹⁄₄"
(6.35 mm) max.
Top
Bottom
³⁄₈"
(9.5 mm)
min.
¹⁄₄"
(6.35 mm) max.
Center face
detail between
offsets
2" (5 cm)
min.
¹⁄₄" (6.35 mm) max.
3¹⁄₄"
(8.25 cm)
min.
Door
Panel
Handle
1"
(2.54 cm)
Door
Panel
Hinge Side
¹⁄₂" (1.3 cm)
min.
¹⁄₄"
(6.35 mm)
max.
Panel

12
Full-Overlay Custom Panels
Custom overlay panels allow you to blend the exterior of your
refrigerator into the overall kitchen décor, and to use custom
handles for additional design flexibility.
NOTE: To use full-overlay custom panels, a Trimless Trim Kit for
Side by Sides is required (TRIMKITSXS). Full-overlay custom
panels and handles are required but not included. Create the
panels according to these specifications. You may order
Thermador’s Handle Kit (HANDKIT) or select handles from another
source. See the “Models” section under “Design Specifications”
for additional information.
The custom panels must have backer panels attached in order to
mount them to the refrigerator. It is most common to work with
three panels, as shown in the following graphic: a decorative
overlay panel, a ¹/₈" (3.18 mm) spacer panel or spacer strips and a
¹/₄" (6.35 mm) backer panel.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom overlay panels will fit properly.
IMPORTANT:
■The total weight of the refrigerator door overlay panel cannot
exceed 50 lbs (23 kg).
■The total weight of the freezer door overlay panel cannot
exceed 30 lbs (13.5 kg).
■The total weight of the top grille overlay panel cannot exceed
10 lbs (4.5 kg).
To minimize panel weight, you may use 2" (5.08 cm) spacer strips
around the perimeter in place of full-sheet solid spacer panels.
The spacer strips must be set in at least 1" (2.54 cm) from the top,
bottom and sides edges of the backer panel. If you use spacer
strips, it is also recommended that you use two 2" (5.08 cm) strips
horizontally centered for added support.
Overlay Panel Spacer Panel
Backer Panel
5/8" to 3/4"
(15.88 to
19.05 mm) 1/8"
(3.18 mm)
1/4"
(6.35 mm)
1" minimum
(2.54 cm)
Door/Grille Trim
Spacer Panel
Offset Dimension
1/8"
(3.18 mm)
Overlay Panel
Backer Panel
Top Grille
C
7
3
/ 8 "
(18.73 cm)
8
1
/ 2 "
(21.59 cm)
Bottom Offset
1" (2.54 cm)
F
Decorative Overlay Panels Backer Panels
Model A B C Model D E F
42" (106 cm) 17 ¹⁄₈"
(43.50 cm) 23 ¹⁄₈" (58.74 cm) 41 ³⁄₈" (105.09 cm) 42" (106 cm) 16 ¹⁵⁄₁₆" (43.50 cm) 22 ¹⁵⁄₁₆" (58.26 cm) 40 ¹⁄₂" (102.87 cm)
48" (122 cm) 19 ⁵⁄₈"
(49.85 cm) 26 ⁵⁄₈" (67.63 cm) 47 ³⁄₈" (120.33 cm) 48" (122 cm) 19 ⁷⁄₁₆" (49.37 cm) 26 ⁷⁄₁₆" (67.15 cm) 46 ¹⁄₂" (118.11 cm)
70 ¹⁄₂ "
(179.07 cm)
70 ¹⁄₂ "
(179.07 cm)
71 ¹⁄₁₆ "
(180.50 cm)
24"
(60.96 cm)
34 ³⁄₄ "
(88.27 cm)
E
D
Bottom Offset
¹⁄₈ " (3.2 mm)
Bottom Offset
¹⁄₈ " (3.2 mm)
B
Refrigerator
Freezer
Non-Dispenser
Freezer Frameless
Dispenser
Handle-Side
Offset
¹⁄₈ " (3.2 mm)
34 ³⁄₈ "
(87.3 cm)
34 ³⁄₈ "
(87.3 cm)
23 ⁷⁄₁₆ "
(59.53 cm)
23 ⁷⁄₁₆ "
(59.53 cm)
D
DD
Bottom Offset
¹⁄₈ " (3.2 mm)
AA
71 ¹⁄₁₆ "
(180.50 cm)
47 ³⁄₁₆ "
(119.86 cm)
D
Bottom Offset
¹⁄₈ " (3.2 mm)
Freezer
Framed Dispenser
Handle-Side
Offset
¹⁄₈ " (3.2 mm)
A
A
Handle-Side
Offset
¹⁄₈ " (3.2 mm)
Handle-Side
Offset
¹⁄₈ " (3.2 mm)
Bottom Offset
¹⁄₈ " (3.2 mm)
12 ⁵⁄₁₆ "
(31.27 cm)

13
Stainless Steel Series Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset, Flush, or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed panel installation dimensions.
■The side panel should be a minimum of ½" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ⁷⁄₃₂" (5.6 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ¹⁄₄" (6.35 mm) thick, rout the front
edge to allow the side panel to fit into the trim.
Flush Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Attach the support board with a screw or adhesive that is
compatible with aluminum and wood.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Rout the front edge of the support board or attach a ¹⁄₄"
(6.35 mm) board to hold the panel in the cabinet side trim.
24¹⁄₈"
(61.3 cm)
23¹⁄₂"
(59.7 cm)
23¹¹⁄₁₆"
(60.3 cm)
¹¹⁄₆₄"
(4.5 mm)
¹⁄₄"
(6.35 mm)
³⁄₁₆"
(4.7 mm)
⁷⁄₃₂"
(5.5 mm)
¹³⁄₃₂" (10 mm) ⁵⁄₈"
(15.7 mm)
A
A
A

14
Custom Panel Series Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed installation dimensions.
■The side panel should be a minimum of ½" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, rout the front edge
to allow the side panel to fit into the trim.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Rout the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
INSTALLATION
REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
PARTS NEEDED:
■#8 x 3" (7.6 cm) or longer wood screws (6)
■2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board (1 or 2)
■Make custom or overlay panels or consult a qualified
cabinetmaker or carpenter to make the panels. See “Design
Specifications.”
■If you are connecting the water line directly to copper tubing
and not to a shutoff valve, you need a ferrule, a union, and a
¹⁄₄" (6.35 mm) compression fitting.
23³⁄₈"
(59.40 cm)
Overlay
³⁄₁₆"
(4.5 mm)
³⁄₈"
(9.7 mm)
¹⁄₁₆"
(1.5 mm)
¹⁄₈"
(3.2 mm)
■Cordless drill ■T27 Torx®† screwdriver
■Drill bits ■¹¹⁄₃₂" nut driver
■Adjustable wrenches (2) ■³⁄₈" and ¹⁄₂" open-end wrenches
■Phillips screwdriver ■⁵⁄₃₂" Allen wrench
■Small level ■⁵⁄₁₆" socket wrench
■Appliance dolly ■Tape measure
A
A
†®TORX is a registered trademark of Textron Innovations Inc.

15
Location Requirements
The refrigerator can be recessed in an opening between cabinets
or installed at the end of a cabinet run using a side panel to
enclose the refrigerator.
IMPORTANT:
■Observe all governing codes and ordinances.
■It is recommended that you do not install the refrigerator near
an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
■Floor must support the refrigerator weight, more than 600 lbs
(272 kg), door panels and contents of the refrigerator.
■Ceiling height must allow for side tipping radius. See “Tipping
Radius.”
■Location should permit door to open fully. See “Door Swing
Dimensions.”
■Location must permit top grille removal. See “Opening
Dimensions.”
Opening Dimensions
■To avoid tipping during use, the solid soffit must be within 1"
(2.5 cm) maximum above the refrigerator. If the solid soffit is
higher than 1" (2.5 cm) or one is not available, then the
refrigerator must be braced.
If the anti-tip boards are needed, they must be attached to the
rear wall studs 80" to 90" (203 to 229 cm) above the floor. See
“Install Anti-Tip Boards” for more information.
NOTE: A clearance of ¹⁄₂" (1.3 cm) must be maintained above
the top grille in order for the top grille to be removed.
■A grounded 3 prong electrical outlet should be placed within
4" (10.2 cm) of the right side cabinets or end panel. See
“Electrical Requirements” for additional information.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the floor or the
back wall. See “Water Supply Requirements” for more
information.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
¹⁄₂"
(1.3 cm)
Model Width A (as shown above)
42
48 41¹⁄₂" (105.4 cm) to 41³⁄₄" (106.1 cm) 47¹⁄₂" (120.7 cm) to 47³⁄₄" (121.3 cm)
80" - 90"
(203-229 cm) 4"
(10.2 cm)
6"
(15.2 cm)
83¹⁄₂" (212.1 cm) min.
84³⁄₄" (215 cm) max.
to bottom of solid soffit
24"
(60.96 cm) min.
1"
(2.54 cm)
77"
(196 cm)
6"
(15.2 cm)
6"
(15.2 cm)
A
Width
(see chart following)

16
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only, 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground Fault
Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and flavor may be affected. If nuisance tripping has occurred, and
if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, remove the top grille and turn the master
power switch to OFF or disconnect power at the circuit breaker
box.
When you are finished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
Water Supply Requirements
■All installations must meet local plumbing code requirements.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The right-hand side is recommended. The access hole
through the cabinet must be within ¹⁄₂" (12.7 mm) of the rear
wall.
NOTE: If the water shutoff valve is in the back wall behind the
refrigerator, it must be at an angle so that the tube is not
kinked when the refrigerator is pushed into its final location.
■If the water shutoff valve is not in the cabinets, the plumbing
for the water line can come through the floor. A ¹⁄₂" (12.7 mm)
hole for plumbing should be drilled at least 6" (15.2 cm) from
the right or left hand side cabinet or panel. On the floor, the
hole should be no more than 1" (2.54 cm) away from the back
wall. See “Connect the Water Supply.”
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, call a
licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi
(207 and 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter cartridge, it may further
reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter cartridge.
If you have questions about your water pressure, call a licensed,
qualified plumber.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
24"
(60.96 cm) min.
1"
(2.54 cm) 6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)

17
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the protective film until the refrigerator is in its
operating position.
■All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating position.
1. Remove and save the literature package and parts bag taped
to the refrigerator door. Remove the four brackets (two on
each side) that attach the shipping base to the refrigerator
bottom.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final position.
2. If necessary, reduce the tipping radius. See “Tipping Radius”
for ceiling height requirements or “Reduce Tipping Radius” for
step-by-step instructions. If you do not need to reduce the
tipping radius, proceed to “Move the Refrigerator into House.”
Reduce Tipping Radius
(if required)
Before bringing the refrigerator into the home, be sure there is
adequate ceiling height to stand the refrigerator upright. See
“Tipping Radius” in the “Design Specifications” section for more
information.
If you do not have adequate ceiling height to stand the refrigerator
upright, the tipping radius can be reduced by removing the top
grille and side trims (see the following chart).
Custom Panel Series
1. Grasp both ends of the top grille.
2. Push the top grille straight up, then pull straight out. Lay the
grille on a soft surface.
3. Remove the six screws attaching each cabinet side trim to the
refrigerator and remove the side trims.
Stainless Steel Series
1. Grasp both ends of the top grille. Push the top grille straight
up, then pull straight out. Lay the top grille on a soft surface.
2. Remove the six screws attaching each cabinet side trim to the
refrigerator and remove the side trims.
Move the Refrigerator into House
1. Place an appliance dolly under the left side of the refrigerator
as shown. Place the corner posts from the packing materials
over the trims and handles as appropriate. Slowly tighten the
strap.
Model Reduced Tipping Radius
42" (106 cm)
48" (122 cm) 88¹⁄₂" (224.8 cm) 89¹⁄₄" (226.7 cm)
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Top grille
B. Cabinet side trim
A. Top grille
B. Cabinet side trim
B BA
B BA
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

18
NOTE: Pass the dolly strap under the handles for the Curved
and Professional Series.
2. Place pieces of the shipping carton on the floor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the built-in opening.
3. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
4. Do not remove film or cover.
5. If necessary, reassemble the trim and top grille after the dolly
has been removed from the refrigerator.
Install Anti-Tip Boards
IMPORTANT:
■To avoid tipping during use, the solid soffit must be within
1" (2.5 cm) maximum above the refrigerator. If the solid soffit is
higher than 1" (2.5 cm) or one is not available, then the
refrigerator must be braced.
■It is recommended that board(s) be installed before the
refrigerator is installed.
■Board(s) must be long enough to fully cover the width of the
compressor cover.
■Locate the board(s) so the bottom surface(s) of the board(s)
is(are) 84" (213 cm) from the floor.
■During installation, raise the refrigerator up so there is
¹⁄₄" (6.35 mm) maximum between the top of the refrigerator
and the bottom of the anti-tip board(s). Do not crush the
compressor cover when raising the rear leveling legs.
To Install Anti-tip Boards
1. Mark the stud locations on rear wall 80" to 90" (203 cm to
229 cm) above floor.
2. Securely attach one or two 2" x 4" x 32" (5 cm x 10 cm x
81 cm) boards to wall studs behind refrigerator. Use six
#8 x 3" (7.6 cm) (or longer) wood screws. The wood screws
must be screwed into the studs at least 1½" (3.8 cm). The
board(s) must overlap the compressor cover.
Connect the Water Supply
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
Connect to Water Line
Parts Needed:
■Minimum 7 ft (2.13 m) flexible, codes approved water
supply line
Style 1 - Shutoff Valve Connection
NOTE: If your water line connection does not look like Style 1, see
“Style 2 - Copper Line Connection.”
1. Unplug refrigerator or disconnect power supply.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may help avoid filters and/or water valves from
becoming clogged.
2. Connect the flexible, codes approved water supply line to the
water shutoff valve by threading the provided nut onto the
shutoff valve as shown.
NOTE: The shutoff valve shown is in the side cabinet as
recommended.
A. Center board ¹⁄₄ " (6.35 mm) max. above refrigerator
B. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
C. Attach to studs with six #8 x 3" (7.6 cm) screws
D. Compressor cover
A. Bulb
B. Nut
C. Water tubing
BA
C
2" (5 cm)
D
A
B
C

19
3. Place the end of the tubing into a bucket, and turn shutoff
valve ON.
4. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
Style 2 - Copper Line Connection
NOTE: If there is a water supply line that meets the specifications
in “Water Supply Requirements,” proceed to “Connecting to
Refrigerator.” If not, use the following instructions to connect to
the household cold water supply.
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a ½" to 1¹⁄₄" (1.25 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and keep normal sediment from collecting in the
valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
5. Using a cordless drill, drill a ¹⁄₄" (6.35 mm) hole in the cold
water pipe you have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" (6.35 mm)
drilled hole in the water pipe and that the washer is under the
pipe clamp. Tighten the packing nut. Tighten the pipe clamp
screws slowly and evenly so washer makes a watertight seal.
Do not overtighten.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may help avoid filters and/or water valves from
becoming clogged.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten the
clamp or the sleeve. This will crush the copper tubing.
8. Turn off the shutoff valve on the water pipe. Coil the copper
tubing.
9. Connect the flexible, codes approved water supply line to the
water shutoff valve by threading the provided nut onto the
shutoff valve.
10. Place the end of the tubing into a bucket, and turn shutoff
valve ON.
11. Check for leaks around the saddle valve. Tighten any nuts or
connections (including connections at the valve) that leak.
Connect to Refrigerator
Parts Supplied:
■¹⁄₄" to ¹⁄₄" (6.35 mm to 6.35 mm) male-to-male coupling
NOTE: The flexible, codes approved water supply line can
connect to the supply valve through the floor or through the side
cabinets, as indicated by the gray boxes above.
1. Unplug the refrigerator or disconnect power.
2. Connect the 7 ft (2.13 m) flexible codes approved water tube
to the water supply valve.
3. Flush the main water supply line to remove particles and air in
the water line. Allow enough flow so that water becomes clear.
4. Tape the 7 ft (2.13 m) flexible codes approved water supply
line to the floor, 7" (17.78 cm) from the left side of the
refrigerator. Tape along the length of the tubing, which will
allow it to pass beneath the refrigerator without interference.
NOTE: Allow a minimum of 26" (66.04 cm) of flexible codes
approved water supply line to be loose at the front of the
refrigerator for connecting to the refrigerator.
5. Connect the 7 ft (2.13 m) flexible codes approved water
supply line to the refrigerator.
NOTE: If the main water shutoff valve is behind the
refrigerator, a secondary water shutoff valve may be installed
in line with the water supply line at the front of the product.
6. Turn on the water supply valve and check all connections for
leaks.
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
A
B
C
DEF
G
A. Household water line
B. Nut (purchased)
C. Ferrule (purchased)
D. Coupling
E. Bulb
F. Nut
G. Refrigerator water tubing
1"
(2.54 cm)
7"
(17.78 cm)
ABCD
EFG

20
Plug in Refrigerator
1. Set control switch at top of cabinet to the OFF position.
2. Plug into a grounded 3 prong outlet.
Move Refrigerator to Final Location
IMPORTANT: To avoid floor damage, make sure levelers are
raised (not touching floor) and refrigerator is on rollers before
moving.
1. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
2. Do not remove film or cover.
3. Move the refrigerator straight back and evenly into the
opening. Be sure that the refrigerator side trims are not
interfering with the door opening. Also, be sure that the water
tubing is not kinked and the power supply cord is on top of the
refrigerator.
Lower Leveling Legs
NOTE: All four leveling legs must contact the floor to support and
stabilize the full weight of refrigerator. Rollers are for moving
refrigerator and not for permanent support.
Use a ⁵⁄₁₆" socket wrench to turn the leveling bolts clockwise to
lower the 4 leveling legs until refrigerator weight is supported by
leveling legs. The rollers should be off the floor. To avoid cabinet
damage, do not apply more than 50 inch-pounds (58 cm - kg) of
torque to the leveling legs.
Install Custom Panels
IMPORTANT: Thermador is not responsible for the removal or
addition of molding or decorative panels that would not allow
access to the refrigerator for service.
NOTE: To install full-overlay custom panels, refer to the
installation instructions included with the Trimless Trim Kit. See
“Design Specifications.”
Door Panels
1. Remove all tape and door bracing from the refrigerator and
freezer doors.
2. Remove the screws that attach the handles to the door frame.
3. Slide the decorative door panels into the door frames.
4. If needed, route the door panels or install a filler panel
between the doors and the decorative panels. See “Custom
Panels.”
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Rear leveling legs
B. Front leveling legs
A. Panels
A B
A
B
A
A
